PRODUCT NO.
BASE MODEL NO.
FED300ASA
FED300A
WIRING DIAGRAM - # 318045051
OWNER'S GUIDE - # 318200823
TIMER INSTRUCTION SHEET - # 318200120
INSTALLATION INSTRUCTIONS - # 318201602
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
37854315A1011
white
Publication No.
5995363503
020109
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
RANGE
Model No.
FED300A
©2002 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FED300A
Summary of Contents for Frigidaire FED300A
- Page 1 PRODUCT NO. BASE MODEL NO. FED300ASA FED300A WIRING DIAGRAM - # 318045051 OWNER’S GUIDE - # 318200823 TIMER INSTRUCTION SHEET - # 318200120 INSTALLATION INSTRUCTIONS - # 318201602 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.
- Page 2 Publication No. FED300ASA 5995363503 BACKGUARD 01/02...
- Page 3 POS. NO 12 # 13 # 14 # 14A# 20 # 24 # 54 # # = Functional Parts * = Non-Illustrated Parts FED300ASA BACKGUARD PART NO DESCRIPTION 318059310 Thermostat,oven 318057910 Switch,selector 318076700 Light,indicator ,125v 3200297 Light/Lamp,indicator 5303304668 End Cap,white ,RH 5303304671 End Cap,white ,LH 318182963...
- Page 4 Publication No. FED300ASA 5995363503 BODY 01/02...
- Page 5 POS. NO 14 # 15 # 62 # 66 # 67 # # = Functional Parts * = Non-Illustrated Parts FED300ASA BODY PART NO DESCRIPTION 318066402 Panel,main back 318070910 Panel,main back ,upper 318159800 Panel,body side ,upper 318195100 Bracket,support 318133400 Burner Box 5303310522 Rack,shelf ,30"...
- Page 6 Publication No. FED300ASA 5995363503 01/02...
- Page 7 POS. NO 15 # 15A# 19 # 19A# 27 # # = Functional Parts * = Non-Illustrated Parts FED300ASA PART NO DESCRIPTION 5308011964 Element,surface ,large/8 inch ,(2) ,medallion incl 5303299749 Element,surface ,small/6 inch ,(2) ,medallion incl 5303300166 Main Top,white 3051554 Rod,support ,main top panel 5303305530 Bracket,hinge ,main top ,(2)
- Page 8 Publication No. FED300ASA 5995363503 DOOR 01/02...
- Page 9 POS. NO # = Functional Parts * = Non-Illustrated Parts FED300ASA DOOR PART NO DESCRIPTION 318211601 Glass,oven door ,6.50 x 15.50 ,crosshatch,black 318157017 Liner,door 5303308458 Screw,10-24 x 1/4 5304417411 Screw,handle mtg. ,10-12 x 1 318053301 Seal,oven door 318009076 Panel,oven door ,white 5303311153 Bracket,glass mtg ,RS 5303311154...
-
Page 10: Wiring Diagram
Publication No. FED300ASA 5995363503 WIRING DIAGRAM 01/02...
