Frigidaire GLGR331D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Dryer
  5. GLGR331D
  6. Factory parts catalog
Frigidaire GLGR331D Factory Parts Catalog

Frigidaire GLGR331D Factory Parts Catalog

Frigidaire glgr331d: supplementary guide
Hide thumbs

Advertisement

Quick Links

Download this manual
P16L0032-Z.eps P16V0064.eps P16D0021.eps P16C0204.eps P16M0024.eps
P16b0015.eps
134054800g.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
GLGR331DQ0
Series
Frig Gallery
Market
North America
Color
bisque
Volts
120
Wiring Diagram
134054800
Owner's Guide
131883500
Installation Instructions 134296400
Operating Instructions 134145400
Publication No.
5995416806
04/09/21
(EN/SERVICE/KC)
361
Copyright

GAS DRYER

Model No.
GLGR331D
©
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire GLGR331D

Summary of Contents for Frigidaire GLGR331D

  • Page 1: Gas Dryer

    Frig Gallery Market North America Color bisque Volts Wiring Diagram 134054800 Owner's Guide 131883500 Installation Instructions 134296400 Operating Instructions 134145400 GAS DRYER Model No. GLGR331D Publication No. 5995416806 04/09/21 (EN/SERVICE/KC) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved.
  • Page 2 Publication No: 5995416806 GLGR331DQ0 CABINET/DRUM 09/04...
  • Page 3 Housing, gas heater assy, w/seal Screw, 10-16AB x 0.375 Bracket, hinge, rear, top panel mtg. Drum, dryer, galvanized stl., service kit Glide, drum Screw, hex washer head, 8-18 x 0 .375, cup point Screw, quadrex head, 10-14 x 1.00, vane mtg., special...
  • Page 4 Publication No: 5995416806 GLGR331DQ0 FRONT PANEL/LINT FILTER 09/04...
  • Page 5 Plug, light hole Door Catch Switch, door, w/o drum light Trap, lint blade assy Clip, guide, (3) Hinge, dryer door Screw, flat head, 8-18AB x 0.44, cr/sq drive Gasket, door seal Handle, door, bisque Panel, inner door, white Panel, outer door, bisque Door Strike Screw, pan head, 10-16AB x 0.500, locking...
  • Page 6 Publication No: 5995416806 GLGR331DQ0 CONTROLS/TOP PANEL 09/04...
  • Page 7 Clip, console mtg End Cap, bisque, RH Buzzer Screw, pan head, 8-18B x 0.31 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive Panel, dryer top, bisque, console mtg Screw, pan hd locking, 8-32CA x 0.375, cup point Publication No: 5995416806 09/04...
  • Page 8 Publication No: 5995416806 GLGR331DQ0 MOTOR 09/04...
  • Page 9 Thermostat, temp control Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting Spring, idler arm Idler Arm Assy, w/pulley Belt, dryer Clamp, motor mtg. Motor & Pulley Assy Screw, pan head, 8-18AB x 0.375, cr/sq drive Bracket, motor mtg Seal, exhaust tube Screw, pan head, 8-18B x 0.31...
  • Page 10 Publication No: 5995416806 GLGR331DQ0 BURNER 09/04...
  • Page 11 POS. NO PART NO. 131168200 131243700 55 # 134389600 134122000 134144900 08015112 134128700 134185100 69 # 5308015194 70 # 5303207409 71 # 5303307291 72 # 5303307292 73 # 5303207410 74 # 134192000 77 # 134197700 79 # 5303281135 80 # 134200801 134315100 # Functional Parts...

  • Page 12: Wiring Diagram

    Publication No: 5995416806 GLGR331DQ0 WIRING DIAGRAM 09/04...
