PRODUCT NO.
BASE MODEL NO.
GLEQ642CAS2
GLEQ642CA
MARKET
Canada
WIRING DIAGRAM - # 134064800
OWNER'S GUIDE - # 131679000
INSTALLATION INSTRUCTIONS - # 134198100
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
Frig Canada
white
Publication No.
5995381463
021113
-EN/SERVICE /ECL
361
DRYER
VOLTS
240
ELECTRIC
DRYER
Model No.
GLEQ642CA
©2002 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire GLEQ642CA
Summary of Contents for Frigidaire GLEQ642CA
- Page 1 PRODUCT NO. BASE MODEL NO. GLEQ642CAS2 GLEQ642CA MARKET Canada WIRING DIAGRAM - # 134064800 OWNER’S GUIDE - # 131679000 INSTALLATION INSTRUCTIONS - # 134198100 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG SERIES COLOR Frig Canada white Publication No.
- Page 2 Publication No. GLEQ642CAS2 5995381463 CABINET/DRUM 11/02...
- Page 3 Screw,shaft/baffle mt ,10-16AB x 0.375 ,special 131205300 Screw,10-16 x 0.750 131469100 Bracket,hinge ,rear ,top panel mtg. 134122532 Drum,dryer ,galvanized stl. ,service kit 131963900 Glide,drum 5303015671 Screw,hex washer head ,8-18 x 0 .375 ,cup point 131382300 Screw,quadrex head ,10-14 x 1.00 ,vane mtg.,special...
- Page 4 Publication No. GLEQ642CAS2 5995381463 FRONT PANEL/LINT FILTER 11/02...
- Page 5 POS. NO 8* # 26 # 58 # 58*# # = Fast-moving Parts * = Non-Illustrated Parts GLEQ642CAS2 FRONT PANEL/LINT FILTER PART NO DESCRIPTION 134063300 Seal,air duct 131397000 Plug,dome ,white 131621900 Duct,air 131845801 Cover,lint housing ,w/moist sensor 131657500 • Wiring Harness,moisture sensor 131633200 Plug,white 131063700...
- Page 6 Publication No. GLEQ642CAS2 5995381463 CONTROLS/TOP PANEL 11/02...
- Page 7 Screw,pan hd phillips ,8-18B x 0.250 134064501 Bracket,control mtg. 134042600 Knob,timer ,white/gray 134064600 Wiring Harness,controls 134110500 Wiring Harness,main 131666943 Console,frame ,white ,w/trim & tape 134040800 Switch,on/off ,round 131243200 Switch,xrinse/temp/bzr ,2 position ,(2) 131959200 Beeper,continuous ,low tone 134086812 Panel,dryer top ,white ,stackable Publication No. 5995381463 11/02...
- Page 8 Publication No. GLEQ642CAS2 5995381463 MOTOR 11/02...
- Page 9 POS. NO 10 # 15 # 23 # 25 # 28 # # = Fast-moving Parts * = Non-Illustrated Parts GLEQ642CAS2 MOTOR PART NO DESCRIPTION 131435200 Lock,blower housing 131451600 Tube,exhaust ,rear ,w/mtg bracket 131456800 Tube,exhaust ,side/bottom ,Optional Kit 131775600 Housing,blower assy ,cover & wheel 131749800 Spacer,idler 134048800...
-
Page 10: Wiring Diagram
Publication No. GLEQ642CAS2 5995381463 WIRING DIAGRAM 11/02...
