PRODUCT NO.
BASE MODEL NO.
FAC055K7A3
FAC055K7A
MARKET
USA
WIRING DIAGRAM - # 309341601
OWNER'S GUIDE - # 309000825
ENERGY GUIDE - # 309367414
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
115
5450 BTU
Publication No.
5995367744
020307
-EN/SERVICE /KSC
345
ROOM AIR CONDITIONER
Model No.
FAC055K7A3
©2002 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Table of Contents
Related Manuals for Frigidaire FAC055K7A3
Summary of Contents for Frigidaire FAC055K7A3
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAC055K7A3 FAC055K7A MARKET WIRING DIAGRAM - # 309341601 OWNER’S GUIDE - # 309000825 ENERGY GUIDE - # 309367414 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS BTU-COOLING... -
Page 2: Cabinet Front And Wrapper
Publication No. FAC055K7A3 5995367744 CABINET FRONT AND WRAPPER 03/02... - Page 3 Front-cabinet,4 way ,complete assy 3015312 Screw,8-18AB x 0.500 309340802 Overlay,control 309328603 Door,fresh air vent 309330201 Detent-vent 309638201 Handle,vent door 309646301 Panel,cabinet front 309646401 Frame,cabinet front 309342201 Enclosure,elec control mt 309350502 Remote Control,transmitter ,with batteries 309367414 Energy Guide,FAC055K7A3 Publication No. 5995367744 03/02...
- Page 4 Publication No. FAC055K7A3 5995367744 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # 71 # 72 # 72*# # = Fast-moving Parts * = Non-Illustrated Parts FAC055K7A3 CONTROLS PART NO DESCRIPTION 309643801 Control Box 309643702 Bulkhead 309111201 Grommet,wire protector 5304413782 Holder,thermistor ,w/seal 5304426655 Capacitor,250 V ,35+4 mfd 3015312 Screw,8-18AB x 0.500...
-
Page 6: Air Handling Parts
Publication No. FAC055K7A3 5995367744 AIR HANDLING PARTS 03/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC055K7A3 AIR HANDLING PARTS PART NO DESCRIPTION 309646202 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309643901 Housing,fan shroud 5303303759 Seal,bottom 5304421913 Seal,top 08007481 Nut,Keps ,motor mtg ,(4)
-
Page 8: Compressor Parts
Publication No. FAC055K7A3 5995367744 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 10 # 11 # 12 # 13 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 5304426656 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover,elec terminal ,compressor 5304417320 Overload Protector 5303294292 Nut,terminal cover 5303317601...
- Page 10 Publication No. FAC055K7A3 5995367744 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC055K7A3 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 309644901 Frame Extension Kit,accordian ,LH & RH ,includes 4 & 14 5304414120 Frame,cab extension ,LH 08016226 Seal,top rail/cab...
-
Page 12: Wiring Diagram
Publication No. FAC055K7A3 5995367744 WIRING DIAGRAM 03/02...
