Frigidaire FAC052K7A9 Factory Parts Catalog

Frigidaire fac052k7a9: supplementary guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FAC052K7A9
FAC052K7A
MARKET
North America
WIRING DIAGRAM - # 309107301
OWNER'S GUIDE - # 309000823
ENERGY GUIDE - # 309367412
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG

ROOM AIR CONDITIONER

SERIES
VOLTS
5000 BTU
115
Publication No.
5995369138
020327
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
ROOM AIR CONDITIONER
Model No.
FAC052K7A9

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FAC052K7A9

Summary of Contents for Frigidaire FAC052K7A9

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAC052K7A9 FAC052K7A MARKET North America WIRING DIAGRAM - # 309107301 OWNER’S GUIDE - # 309000823 ENERGY GUIDE - # 309367412 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER...

  • Page 2: Cabinet Front And Wrapper

    Publication No. FAC052K7A9 5995369138 CABINET FRONT AND WRAPPER 03/02...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC052K7A9 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309643602 Cabinet 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs 309639302 Louver,horizontal 309640204 Louver Assy,Includes 8 & 9 309647201 Louver,vertical ,with link 309343501 Filter-air,7.12 x 17.31 ,no frame...
  • Page 4 Publication No. FAC052K7A9 5995369138 CONTROLS 03/02...
  • Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAC052K7A9 CONTROLS PART NO DESCRIPTION 309643802 Control Box 5304410837 Switch,selector ,5 position,2 sp 5304402838 Control,temperature 309643702 Bulkhead 309111201 Grommet,wire protector 309101202 Clip,retainer ,temp sensor ,(2) 5304426655...

  • Page 6: Air Handling Parts

    Publication No. FAC052K7A9 5995369138 AIR HANDLING PARTS 03/02...
  • Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC052K7A9 AIR HANDLING PARTS PART NO DESCRIPTION 309646202 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309643901 Housing,fan shroud 5303303759 Seal,bottom 5304421913 Seal,top 08007481 Nut,Keps ,motor mtg ,(4)

  • Page 8: Compressor Parts

    Publication No. FAC052K7A9 5995369138 COMPRESSOR PARTS 03/02...
  • Page 9 POS. NO 10 # 11 # 12 # 13 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 5304426656 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover,elec terminal ,compressor 5304417320 Overload Protector 5303294292 Nut,terminal cover 5303317601...
  • Page 10 Publication No. FAC052K7A9 5995369138 WINDOW MOUNTING PARTS 03/02...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC052K7A9 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,2indow stuffer 5303211056 Bracket,sash lock 309644901 Frame Extension Kit,accordian ,LH & RH ,includes 4 & 14 5304414120 Frame,cab extension ,LH 08016226 Seal,top rail/cab...

  • Page 12: Wiring Diagram

    Publication No. FAC052K7A9 5995369138 WIRING DIAGRAM 03/02...
