- Page 1 ® Conduit MTCAP-LAP3-915-041 User Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................5 Overview ..................................5 Product Build Options ..............................5 Package Contents................................5 Documentation Overview ............................. 6 Developer Documentation............................6 Chapter 2 – Specifications and Hardware Information ..................... 7 Dimensions..................................7 Specifications ................................8 Connectors and LEDs.............................. - Page 4 CONTENTS Chapter 6 – Getting Started ........................... 18 mPower Models ................................18 mLinux Models................................18 Chapter 7 – Mounting the Device........................... 19 Mounting the Device..............................19 You will need................................19 Determining Location..............................19 Mounting the Device ..............................20 Chapter 8 – Regulatory and Environmental Information ..................22 Regulatory Compliance Mark (RCM) for Australia......................
-
Page 5: Chapter 1 - Product Overview
1 – LoRa antenna 1 – Mounting bracket 1 – Quick Start Important: Contact MultiTech Systems if a replacement power supply is needed. Using a different power supply may damage the device and voids the warranty. ® Conduit AP MTCAP-LAP3-915-041 User Guide... -
Page 6: Documentation Overview
PRODUCT OVERVIEW Documentation Overview The following documents are available at http://www.multitech.com/brands/multiconnect-conduit-ap. Select your model to find the documents specific for that device. Document Description Part Number Conduit AP MTCAP-LAP-915-041 This document. Hardware, regulatory, and S000772 User Guide getting started information. -
Page 7: Chapter 2 - Specifications And Hardware Information
SPECIFICATIONS AND HARDWARE INFORMATION Chapter 2 – Specifications and Hardware Information Dimensions ® Conduit AP MTCAP-LAP3-915-041 User Guide... -
Page 8: Specifications
SPECIFICATIONS AND HARDWARE INFORMATION Specifications Category Description General Standards LoRaWAN 1.0.2 specifications LTE FDD Cat.1, 3GPP release 10 compliant 3G fallback 256MB Flash 256MB Radio Frequency ISM Band 915 MHz ISM band for Australia 4G/LTE 2100 (B1) / 1800 (B3) / 850 (B5) / 800 (B8) / 700 (B28) 2100 (B1) / 850 (B5) / 800 (B8) Physical Description Weight... -
Page 9: Connectors And Leds
SPECIFICATIONS AND HARDWARE INFORMATION Connectors and LEDs LoRa and cellular radio models Item Description Connectors Power 5 Volt power jack. Ethernet RJ45 Ethernet jack. Reset Reset button. Reboots device or restores factory defaults. Refer to Resetting the Device details. (No label) SMA Connector for external LoRa antenna. -
Page 10: Resetting The Device
SPECIFICATIONS AND HARDWARE INFORMATION Resetting the Device You need: A pin, paperclip, or similar thin object that can fit into the reset hole To reset the device: Find the hole labeled RESET. The reset button is recessed into the case. Use the pin to press and release the RESET button as follows: Reset options: To reboot, press RESET for less than 3 seconds. -
Page 11: Antenna
Your device ships with the following antenna. Any replacement antenna should fall with in the same specifications. Pulse Electronics Antenna Manufacturer: Pulse Electronics Description: 868-928 MHz RP-SMA Antenna, 8" Model Number: W1063 MultiTech Part Number: 45009830L MultiTech ordering information: Ordering Part Number Quantity AN868-915A-1HRA AN868-915A-10HRA AN868-915A-50HRA... -
Page 12: Chapter 3 - Safety Information
SAFETY INFORMATION Chapter 3 – Safety Information Power Supply Caution CAUTION: Do not replace the power supply with one designed for another product; doing so can damage the modem and void your warranty. Adapter shall be installed near the equipment and shall be easily accessible. CAUTION: Pour garantir une protection continue contre les risques d'incendie, remplacez les fusibles uniquement par des fusibles du même type et du même calibre. -
Page 13: Sécurité Relative Aux Appareils À Radiofréquence (Rf)
SAFETY INFORMATION Switch OFF your wireless device when in an aircraft. Using portable electronic devices in an aircraft may endanger aircraft operation, disrupt the cellular network, and is illegal. Failing to observe this restriction may lead to suspension or denial of cellular services to the offender, legal action, or both. Switch OFF your wireless device when around gasoline or diesel-fuel pumps and before filling your vehicle with fuel. -
Page 14: Device Maintenance
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 15: User Responsibility
SAFETY INFORMATION User Responsibility Respect all local regulations for operating your wireless device. Use the security features to block unauthorized use and theft. ® Conduit AP MTCAP-LAP3-915-041 User Guide... -
Page 16: Chapter 4 - Labels
Actual labels vary depending on the regulatory approval markings and content. The label shown is not the actual size. 1 - MultiTech Model Identification. 2 - MultiTech Ordering Part Number. 3 - IMEI Number 4 - Device Node Number 5 - UUID... -
Page 17: Chapter 5 - Setting Up Hardware
SETTING UP HARDWARE Chapter 5 – Setting Up Hardware Installing a SIM Card Models with cellular capability have a micro SIM slot, you'll need a micro (3FF) SIM card from your network provider. To install the SIM card: With the contact side facing down, align the notched edge as shown on the following image and slide the SIM card completely into the SIM holder. -
Page 18: Chapter 6 - Getting Started
Models If your device uses the mPower platform, getting started information is in mPower Software Guide (S000727), available through your model's page at https://www.multitech.com/brands/multiconnect-conduit-ap mLinux Models If your device uses the mLinux platform, getting started information is at http://www.multitech.net/developer/software/mlinux/getting-started-with-conduit-mlinux/ ®... -
Page 19: Chapter 7 - Mounting The Device
MOUNTING THE DEVICE Chapter 7 – Mounting the Device Mounting the Device The device ships with a mounting bracket. You will need Device Mounting bracket Four #6 screws, with anchors (not provided) Screwdriver Drill Mounting Bracket Determining Location Follow these guidelines for best performance: For optimal performance, place the device at a level higher than the end devices. -
Page 20: Mounting The Device
MOUNTING THE DEVICE Select a location central to all devices to be connected to this device. Avoid obstructions. Important: Thick walls and reflective surfaces, such as metal, weaken the signal between the device and other devices. We recommend conducting a site survey to test the signal strength in different locations before you mount the device. - Page 21 MOUNTING THE DEVICE ® Conduit AP MTCAP-LAP3-915-041 User Guide...
-
Page 22: Chapter 8 - Regulatory And Environmental Information
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. -
Page 23: Reach Statement
REGULATORY AND ENVIRONMENTAL INFORMATION REACH Statement Registration of Substances Multi-Tech Systems, Inc. confirms that none of its products or packaging contain any of the Substances of Very High Concern (SVHC) on the REACH Candidate List, in a concentration above the 0.1% by weight allowable limit The latest 197 substances restricted per the REACH Regulation were last updated January 2019. -
Page 24: Restriction Of The Use Of Hazardous Substances (Rohs)
2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS 3). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <... -
Page 25: Information On Hs/Ts Substances According To Chinese Standards
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc. -
Page 26: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部... -
Page 27: Index
INDEX Index antenna .................11 maintenance ..............14 attach ...............17 modem safety ...............12 mounting device ............19 build options ..............5 package contents ............5 Ports Ethernet ...............12 power jack...............9 CELL LED ................9 power measurements ...........10 certifications..............8 power supply..............17 Chinese hazardous substances Chinese version............26 English version ............25 connectors...............9 radio frequency interference........12 receive sensitivity............8...
