- Page 1 ® Conduit MTCAP2-L4E1-868-042x-POE and MTCAP2-868- 042x-POE User Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................5 Overview ..................................5 Product Build Options ..............................5 Package Contents................................5 Documentation Overview ............................. 6 Developer Documentation............................6 Power over Ethernet (PoE) ............................6 Chapter 2 – Specifications and Hardware Information ..................... 7 Dimensions.................................. - Page 4 CONTENTS -L4E1-042 Models ..............................18 Chapter 5 – Setting Up Hardware........................... 19 Installing a SIM Card ..............................19 Removing a SIM Card..............................19 Attaching the Antenna ..............................19 Cabling the Device............................... 19 Chapter 6 – Getting Started ........................... 20 mPower Models ................................20 mLinux Models................................
-
Page 5: Chapter 1 - Product Overview
LoRa end points and a centrally located network server on the cloud, in a data center, or a public network. Note: Check for an updated version of this document at https://www.multitech.com/brands/multiconnect- conduit-ap/. Product Build Options Product... -
Page 6: Documentation Overview
PRODUCT OVERVIEW Documentation Overview The following documents are available at http://www.multitech.com/brands/multiconnect-conduit-ap. Select your model to find the documents specific for that device. Document Description Part Number Conduit AP MTCAP2-L4E1-868-042x User This document. Hardware, regulatory, and S000746 Guide getting started information. -
Page 7: Chapter 2 - Specifications And Hardware Information
SPECIFICATIONS AND HARDWARE INFORMATION Chapter 2 – Specifications and Hardware Information Dimensions ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide... -
Page 8: Specifications
SPECIFICATIONS AND HARDWARE INFORMATION Specifications Category Description General Standards LoRaWAN 1.0.2 specifications LTE FDD Cat 4, 3GPP release compliant (-L4E1 models only) HSPA+ with GPRS fallback (-L4E1 models only) 256MB Flash 256MB Radio Frequency ISM Band 868 MHz ISM band for Europe 4G/LTE 4G: B1, B3, B7, B8, B20, B28A (-L4E1 models only) 3G: B1, B3, B8 (-L4E1 models only) -
Page 9: Connectors And Leds
SPECIFICATIONS AND HARDWARE INFORMATION Connectors and LEDs LoRa only models LoRa and cellular radio models Item Description Connectors Power 5 Volt power jack. Ethernet RJ45 Ethernet jack. Reset Reset button. Reboots device or restores factory defaults. Refer to Resetting the Device details. -
Page 10: Resetting The Device
SPECIFICATIONS AND HARDWARE INFORMATION Resetting the Device You need: A pin, paperclip, or similar thin object that can fit into the reset hole To reset the device: Find the hole labeled RESET. The reset button is recessed into the case. Use the pin to press and release the RESET button as follows: Reset options: To reboot, press RESET for less than 3 seconds. -
Page 11: Mtcap2-L4E1-868
SPECIFICATIONS AND HARDWARE INFORMATION MTCAP2-L4E1-868 Note: Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when determining product load. Maximum Power: The continuous current during maximum data rate with the radio transmitter at maximum power. Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE connection. -
Page 12: Pulse Electronics Antenna
SPECIFICATIONS AND HARDWARE INFORMATION Pulse Electronics Antenna Manufacturer: Pulse Electronics Description: 868-928 MHz RP-SMA Antenna, 8" Model Number: W1063 MultiTech Part Number: 45009830L MultiTech ordering information: Ordering Part Number Quantity AN868-915A-1HRA AN868-915A-10HRA AN868-915A-50HRA Antenna Specifications Category Description Frequency Range 868-928 MHz... -
Page 13: Chapter 3 - Safety Information
Power over Ethernet (PoE) Certification does not apply or extend to voltages outside of standard PoE range. Any PoE voltages beyond 0vdc to 60Vdc have not been evaluated by UL or MULTITECH. Nominal PoE voltage is 38 Vdc to 57 VDC. The end user supplies the PoE cable. -
Page 14: General Safety
SAFETY INFORMATION General Safety The device is designed for and intended to be used in fixed and mobile applications. Fixed means the device is physically secured at one location and cannot be easily moved to another location. Mobile means the device is used in other than fixed locations. -
Page 15: Interference With Pacemakers And Other Medical Devices
SAFETY INFORMATION Éteignez votre appareil sans fil à proximité des pompes à essence ou de diesel avant de remplir le réservoir de votre véhicule de carburant. Éteignez votre appareil sans fil dans les hôpitaux ou dans toutes les zones où des appareils médicaux sont susceptibles d'être utilisés. -
Page 16: Ul Notice
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 17: Chapter 4 - Labels
(2) this device must accept any interference received, including interference that may cause undesired operation. The label shown is not the actual size. 1 - MultiTech Model Identification. 2 - MultiTech Ordering Part Number. 3 - IMEI Number 4 - Device Node Number 5 - UUID -868-042 Models ®... -
Page 18: L4E1-042 Models
LABELS -L4E1-042 Models ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide... -
Page 19: Chapter 5 - Setting Up Hardware
SETTING UP HARDWARE Chapter 5 – Setting Up Hardware Installing a SIM Card Models with cellular capability have a micro SIM slot, you'll need a micro (3FF) SIM card from your network provider. To install the SIM card: With the contact side facing down, align the notched edge as shown on the following image and slide the SIM card completely into the SIM holder. -
Page 20: Chapter 6 - Getting Started
Models If your device uses the mPower platform, getting started information is in mPower Software Guide (S000727), available through your model's page at https://www.multitech.com/brands/multiconnect-conduit-ap mLinux Models If your device uses the mLinux platform, getting started information is at http://www.multitech.net/developer/software/mlinux/getting-started-with-conduit-mlinux/ ®... -
Page 21: Chapter 7 - Mounting The Device
MOUNTING THE DEVICE Chapter 7 – Mounting the Device Mounting the Device The device ships with a mounting bracket. You will need Device Mounting bracket Four #6 screws, with anchors (not provided) Screwdriver Drill Mounting Bracket Determining Location Follow these guidelines for best performance: For optimal performance, place the device at a level higher than the end devices. -
Page 22: Mounting The Device
MOUNTING THE DEVICE Select a location central to all devices to be connected to this device. Avoid obstructions. Important: Thick walls and reflective surfaces, such as metal, weaken the signal between the device and other devices. We recommend conducting a site survey to test the signal strength in different locations before you mount the device. - Page 23 MOUNTING THE DEVICE ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide...
- Page 24 MOUNTING THE DEVICE ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide...
-
Page 25: Chapter 8 - Regulatory And Environmental Information
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. - Page 26 REGULATORY AND ENVIRONMENTAL INFORMATION July, 2005 ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide...
-
Page 27: Restriction Of The Use Of Hazardous Substances (Rohs)
2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS 3). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <... -
Page 28: Information On Hs/Ts Substances According To Chinese Standards
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc. -
Page 29: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部... -
Page 30: Index
INDEX Index LEDs.................9 LORA LED.................9 antenna .................12 attach ...............19 maintenance ..............15 mLinux................20 build options ..............5 modem safety ...............14 mounting device ............21 mPower software............20 CELL LED ................9 certifications..............8 Chinese hazardous substances Chinese version............29 package contents ............5 English version ............28 Ports Ethernet ...............13 configuring ..............20 power jack...............9 connectors...............9... - Page 31 INDEX transmission ..............8 user responsibility............16 ® Conduit AP MTCAP2-L4E1-868-042x-POE and MTCAP2-868-042x-POE User Guide...
