CLI configuration

ipsec vip

284
ipsec phase2 command keywords and variables
Keywords and variables
bindtoif
<interface-name_str>
Example
Use the following commands to edit an existing phase 2 configuration named
Tunnel_1. The command binds the tunnel to the interface named internal.
config vpn ipsec phase2
edit Tunnel_1
set bindtoif internal
end
A FortiGate unit can act as a proxy by answering ARP requests locally and forwarding
the associated traffic to the intended destination host over an IPSec VPN tunnel. The
feature is intended to enable IPSec VPN communications between two hosts that
coordinate the same private address space on physically separate networks. The IP
addresses of both the source host and the destination host must be unique. The
ipsec vip command lets you specify the IP addresses that can be accessed at the
remote end of the VPN tunnel. You must configure IPSec virtual IP (VIP) addresses at
both ends of the IPSec VPN tunnel.
Adding an IPSec VIP entry to the VIP table enables a FortiGate unit to respond to
ARP requests destined for remote servers and route traffic to the intended
destinations automatically. Each IPSec VIP entry is identified by an integer. An entry
identifies the name of the FortiGate interface to the destination network, and the IP
address of a destination host on the destination network. Specify an IP address for
every host that needs to be accessed on the other side of the tunnel—you can define
a maximum of 32 IPSec VIP addresses on the same interface.
Note: The interface to the destination network must be associated with a VPN tunnel through a
firewall encryption policy (action must be set to encrypt). The policy determines which VPN
tunnel will be selected to forward traffic to the destination. When you create IPSec VIP entries,
check the encryption policy on the FortiGate interface to the destination network to ensure that
it meets your requirements.
For more information, see
Command syntax pattern
config vpn ipsec vip
edit <vip_integer>
set <keyword> <variable>
end
01-28006-0010-20041105
Description
Bind the tunnel to the specified
network interface. Type the name of
the local FortiGate interface.
"Configuring IPSec virtual IP addresses" on page
VPN
Default Availability
No All models.
default.
296.
