SERVICE MANUAL
COMPACT COMPONENT SYSTEM
FS-SD770R / FS-SD990R
REMOTE CONTROL
DIMMER
SLEEP
AUTO
DISPLAY
PRESET
FM MODE
PROGRAM
RANDOM
REPEAT
DOOR
CD
AHB PRO
SLIDE
BASS
TREBLE
CANCEL
PTY/EON
DISPLAY MODE
UP
SET
DOWN
FADE MUTING
CD
MD/AUX
FM / AM
VOLUME
REMOTE CONTROL
DIMMER
SLEEP
AUTO
DISPLAY
PRESET
FM MODE
PROGRAM
RANDOM
REPEAT
DOOR
AHB PRO
SLIDE
CD
BASS
TREBLE
CANCEL
PTY/EON
DISPLAY MODE
UP
SET
DOWN
FADE MUTING
CD
MD/AUX
FM / AM
VOLUME
The difference between FS-SD550R and FS-SD770R FS-SD990R is only the speaker systems.
The difference between FS-SD770R and FS-SD990R is cabinets of the speaker.
Contents
These models not have adjustment.
Safety Precautions
Important for laser products
Preventing static electricity
Dismantling and assembling
the traverse unit
Disassembly method
Maintenance of laser pickup
Replacement of laser pickup
FS-SD550R
CD-ROM No.SML200103
FS-SD550R
FS-SD770R, FS-SD990R
2-1
2-2
2-3
2-4
2-5
2-14
2-14
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
FS-SD550R / FS-SD770R / FS-SD990R
Flow of functional operation
unit TOC read
Method of connecting
treatment device wire
Description of major ICs
Area Suffix
U.K
B
Continental Europe
E
Northern Europe
EN
2-15
2-16
2-17
No.20923
Mar. 2001
