SERVICE MANUAL
COMPACT COMPONENT SYSTEM
Contents
Safety precautions ---------------------------- 1- 2
Preventing static electricity ----------------- 1- 3
Important for laser products ---------------- 1- 4
Disassembly method ------------------------ 1- 5
Adjustment method -------------------------- 1- 18
operation until TOC read -------------- 1- 20
MX-KA6
SP-MXKA6
CA-MXKA6
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
SP-MXKA6
Maintenance of laser pickup -------------- 1- 21
Replacement of laser pickup -------------- 1- 21
Description of major ICs ------------------- 1- 22
Wiring connection ---------------------------- 1- 33
MX-KA6
Area Suffix
UW ............. Latin America
No. MB028
Aug. 2003
