IM2065
10/2020
REV07
ASPECT™ 300
OPERATOR'S MANUAL
ENGLISH
Lincoln Electric Bester Sp. z o.o.
ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland
www.lincolnelectric.eu

Advertisement

Table of Contents
loading

Summary of Contents for Lincoln Electric ASPECT 300

  • Page 1 IM2065 10/2020 REV07 ASPECT™ 300 OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland www.lincolnelectric.eu...
  • Page 2: Table Of Contents

    12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products.  Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer.  For future reference record in the table below your equipment identification information. Model Name, Code &...
  • Page 3: Technical Specifications

    Technical Specifications NAME INDEX ASPECT™ 300 K12058-1 INPUT Input Voltage U EMC Class Frequency 230 - 400Vac ± 15% 50/60 Hz Input Line Mode 100% Input Amperes I PFmax 1max STICK 10.3kW 8.8 kW TIG DC 8.8kW 6.3 kW 4.9 kW 230Vac 27.4 A 0.94...
  • Page 4: Eco Design Information

    ECO design information The equipment has been designed in order to be compliant with the Directive 2009/125/EC and the Regulation 2019/1784/EU. Efficiency and idle power consumption: Efficiency when max power Index Name Equivalent model consumption / Idle power consumption K12058-1 ASPECT™...
  • Page 5 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
  • Page 6: Electromagnetic Compatibility (Emc)

    Electromagnetic Compatibility (EMC) 01/11 This machine has been designed in accordance with all relevant directives and standards. However, it may still generate electromagnetic disturbances that can affect other systems like telecommunications (telephone, radio, and television) or other safety systems. These disturbances can cause safety problems in the affected systems. Read and understand this section to eliminate or reduce the amount of electromagnetic disturbance generated by this machine.
  • Page 7: Safety

    Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation.
  • Page 8 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
  • Page 9: Installation And Operator Instructions

    Installation and Operator Instructions General description 400Vac 3 phases:  Vac peak voltage: below 670V Aspect™ 300 AC/DC machine is designated to performe  Vac frequency: in the range of 50 and 60Hz SMAW and GTAW welding process in DC and AC ...
  • Page 10 TIG Welding (GTAW) WIRELESS This machine does not include a TIG torch necessary for Unit manage TIG welding, but one may be purchased separately. also a remote device Refer to the accessories section for more information. wireless. To accept this part an auxiliary supply connector to supply wireless...
  • Page 11 D. Gas Inlet: Connector for the TIG shielding gas. Use Remote LED: the supplied connector to connect the machine to the gas source line. The gas source must have a pressure regulator and flow gage installed. This indicator will turn on when a Remote command is connected to the machine via the remote control E.
  • Page 12 VRD LED (enabled on Australian Machines only): Output: This machine is provided by VRD (Voltage Reduction Device) function: this reduces the voltage at the output leads. The VRD function is enabled by factory default only on machines that meet the AS 1674.2 Australian This section is designated to allow the operator to set Standards.
  • Page 13 Sequencer Functions: Pulse Sequencer Functions: Percent Peak Current: This functions sets the amount of time the pulse waveform spends at the peak current setting. This function is set as a percentage of the total time for the pulse cycle. The sequencer allows for the customization of the TIG Pulses-Per-Second: Sets the welding operation both in AC &...
  • Page 14 Memory Selection: Menu: The memory function is designed to allow the operator to save up to 9 specific welding procedures. This memory This unit permits an advance setting divided in 3 menu: button will have two functions: 1. Save memory settings 2.
  • Page 15 For default the polarity is DC+. To change in DC- see Operating Instruction menu SMAW operation section. DC Stick (SMAW) Welding See menu SMAW to change value of hot start and arc To start DC Stick welding process: force. 1.) Set polarity AC Stick Welding 2.) To select Stick welding: Process...
  • Page 16 HF TIG TIG Trigger Sequences When the mode pushbutton is in HF TIG position, the TIG welding can be done in either the 2-step or 4-step machine is ready for HF TIG welding. During the HF mode. The specific sequences of operation for the TIG mode, the TIG arc is started by HF without pressing trigger modes are explained below.
  • Page 17 2. Release the TIG torch trigger to stop welding. The 2. Release the TIG torch trigger to start the downslope. machine will now decrease the output current at a During this time press and hold the TIG torch trigger controlled rate, or downslope time, until the Crater to restart welding.
  • Page 18 As shown here, after As shown here, after the the TIG torch trigger is torch trigger quickly pressed quickly pressed released from step 3A, released from step 3A, it it is possible to press is possible to press and and hold the TIG torch hold torch trigger another time to...
  • Page 19 Bi-Level (Set/A2) Trigger sequence Enter Menu GTAW and enable BILV option. When enabled, the bilevel tig function replaces the 4S trigger sequence. To select Bi-Level sequence: Output Visualization Press several times until the LED above lights up When bilevel is selected in left display without any welding operation you can see the text: B-0.0 With this sequence the arc is started as in the 4S...
  • Page 20 List of parameters and Factory stored programs Selectable Value Displayed Displayed value Range parameter name Factory Configuration Function Default Current selected value Preflow 0 - 25s (step 0.1s) Current selected value STRT Starting Current 10 – 200 % (step 1%) Current selected value Initial slope 0 –...
  • Page 21 Note A: When AUTO is selected means 1s/10A; minimun value is 3s. Note B: for frequency value higher than 500Hz, PEAK is locked to 50%. Note C: In AC polarity the pulse frequency is limited to ¼ of the AC-frequency: : if AC frequency is 120Hz that means the max pulse frequency is 30Hz .
  • Page 22 Advanced menu Menu GTAW To enter into Menu GTAW see section Menu, described above Menu GTAW Displayed Selectable Value Displayed value Range parameter name Factory Configuration Function Default SOFT SINE Current selected value WAVE Wave Form SQRE type SQRE AUTO (Note D) 0.5mm (0.02”) 1mm (0.04”) 1.6mm (1/16”)
  • Page 23 Note D. When AUTO is selected, the starting parameters are automatically recalled based on the set current adjustable by main knob in the front panel. Diameter of the electrode is automatically recalled based on the following table User dialed weld I (AMP) Tungsten diameter >...
  • Page 24 Menu SMAW To enter into Menu SMAW see section Menu, descriped above Menu SMAW Selectable Value Displayed Displayed value Range parameter name Factory Configuration Function Default SOFT: 35% 0 – 75% (step 1%) Current selected value FRCE Arc Force CRISP: 75% 75 –...
  • Page 25 Menu SYS To enter into Menu SYS see section Menu, descriped above Menu SYS Selectable Value Displayed Displayed value parameter name Range Factory Configuration Function Default Current selected value UNIT Units mm / INCH ON/OFF Brightness/Intensity HIGH FOOT TIG Remote Current selected value RMTE Options...
  • Page 26 Please contact the nearest the unit is used outside with high sun light luminosity technical service center or Lincoln Electric and report the error code displayed on the meter of the Front Panel. Tig Remote options This remote section in Menu SYS is dedicate to select Error code table the appropriate kind of remote devices connected.
  • Page 27 5s. After that time the based on the best information in our possession at that counter is reset: 0.0 presents in Voltage displays time. Lincoln Electric is not in a position to warrant or  Release SEL Button guarantee such advice, and assumes no liability, with respect to such information or advice.
  • Page 28: Weee

    12/05 Part List reading instructions  Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed.  Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine.
  • Page 29: Suggested Accessories

    Suggested Accessories W000011139 KIT 35C50 W000382715-2 PROTIGIIIS 10RL C5B-S 5M W000382716-2 PROTIGIIIS 10RL C5B-S 8M W000382717-2 PROTIGIIIS 20RL C5B-S 5M W000382718-2 PROTIGIIIS 20RL C5B-S 8M W000382719-2 PROTIGIIIS 30RL C5B-S 5M W000382720-2 PROTIGIIIS 30RL C5B-S 8M W000382721-2 PROTIGIIIS 40RL C5B-S 5M W000382722-2 PROTIGIIIS 40RL C5B-S 8M W000382723-2...

This manual is also suitable for:

K12058-1
