Installation Guide
and Users Manual
VICTORY
Under-Cabinet Range Hood
UC400
Model:
Available sizes: 30"
Available Finishes: Stainless Steel, White
IMPORTANT:
Read and save these instructions.
NOTICE:
For residential use only.
Installer: Leave this guide with the homeowner.
Homeowner: Keep this guide for future reference.
Rev. 1032u.3a
Advertisement
Table of Contents
Related Manuals for Victory UC400
Summary of Contents for Victory UC400
- Page 1 Installation Guide and Users Manual VICTORY Under-Cabinet Range Hood UC400 Model: Available sizes: 30” Available Finishes: Stainless Steel, White IMPORTANT: Read and save these instructions. NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference.
- Page 3 Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction.
- Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........14 Parts supplied...........4 Use and care information.......15 Venting requirements........5 Specifications..........15-16 Mount heights & clearance......5-6 Measurements & Diagrams.......16-17 MAINTENANCE Calculating vent system length.......6 Venting methods ..........7 Cleaning............18 Electrical requirements........8 Replacing the filter & light bulb.......18 WARRANTY Preparation............9 Installation..........10-12... -
Page 6: Parts Supplied
Parts Supplied: UC400 Series Under Cabinet Range Hood (vary with model) Aluminum Filters (Pre-Installed) Stainless Steel Filters (Optional) Qty: 4 PCS Qty: 4 PCS Rectangular Exhaust/Vent Adapter (For sheet rock only) (For vertical or horizontal venting) Round Exhaust Vent Adapter... -
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an at- tic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall caps. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of a 6” round duct (standard for this range hood) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. • Please use Duct Run Calculation below to compute total available duct run when using elbows, transitions and caps. -
Page 9: Venting Methods
Venting Methods IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. • Use metal/aluminum duct work only. • Fasten all connections with sheet metal screws and tape all joints with certified Silver Tape or Duct Tape. •... -
Page 10: Electrical Requirements
Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility: • To contact a qualified electrician • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No. 0-M91 - latest edition** and all local codes and ordinances. -
Page 11: Preparation
Preparation WARNING Advanced Preparations: • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. • Place the range hood on a flat, stable surface. Connect the Excessive Weight range hood to a designated standard outlet (please refer the Require three or more person to move and product label for the suitable voltage of this unit) and turn on install this range hood. -
Page 12: Installation
Installation Installations (refer to Page 4 for parts): Measure the distance between stove top and the bottom of range hood. A distance of 27” to 30” is recommended*. *Due to different ceiling height configurations, recommend- ed height may not be applicable. 1. - Page 13 Installation Figure 3: Cabinet Bottom View (Continued) U400 Wood Filler Strips (Not included) Hood Mounting Screws Electrical Access Wall Centerline Opening U400 Wood Filler Strips (Not included) Electrical Access Opening Hood Mounting Centerline Wall Screws Wood Filler Strips U400 Figure 4: (Not included) Electrical wires through top opening...
- Page 14 Installation (Continued) Figure 5: Cabinet Front View U400 Centerline Hood Electrical Mounting Wire Screws Opening U400 Centerline Electrical Hood Wire Mounting Opening Screws U400 Centerline Figure 6: Electrical wires through rear opening Page 12...
-
Page 15: Range Hood Operations
Range Hood Operations Control Panel Layout and Buttons Configurations: Turning Fan ON: Always turn fans ON a couple of minutes before cooking to establish air flow and allow fans to run for a few minutes after cooking for cleaner air in the kitchen. NOTE: The light setting will not be affected by the Power Control (On/Off) button. -
Page 16: Troubleshooting
Troubleshooting 1. If the range hood or lights do not operate after in- • Check if the range hood has been plugged in, make stallation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected. -
Page 17: Use And Care Information
3-1/4 x 10 inches Rectangular (Top OR Rear) exhaust/ or 6” Round Top 1. In House Test Static Pressure “0”. 2. One sone is roughly equivalent to the sound of a refrigerator (1kHz) at 40 decibels. Page 15 3. Subject to change without notice, please contact Victory Range Hoods for details. -
Page 18: Measurements & Diagrams
Dimensions and Circuit Diagram 23.5” or... - Page 19 U400 Circuit Diagram: NOTE: Wiring Diagram shown above with GU10 light configuration. A transformer is required for MR16/J4 Lights. Page 17...
-
Page 20: Cleaning
Dry the filters and re-install before using the hood. Replacing Filters: • Should filters wear out due to age and prolonged use, please contact Victory Range Hoods for replacement filters. Replacing the light bulb: • This range hood uses LED or Halogen bulbs (please refer to the actual specification of the hood purchased): USA/Canada: Halogen 35W Type GU10 120V (Europe : 220V) USA/Canada: LED 5.5W Type GU10 120V (Europe : 220V) - Page 21 You must also include proof of the date of original purchase as evidence that the product is within the applicable warranty period, and that it is a genuine range hood from Victory Range Hoods.
-
Page 22: Disclaimer & Contact Us
If your range hood is damaged in transit, please contact us within 14 days of receiving your new order to report the damages. Victory Range Hoods will, to the best of its ability, file a damage claim and investigate the matter. - Page 23 VICTORY Range Hoods for Professionals 583 Nicola Ave Port Coquitlam, BC V3B 0M3 Canada www.KitchenHoods.ca...
