Alpine iLX-F903D Installation Manual

Alpine iLX-F903D Installation Manual

9-inch digital media station
Hide thumbs Also See for iLX-F903D:

Advertisement

Quick Links

FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/PARA USO
EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE
AUTO/ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067, JAPAN
Phone: 03-5499-4531
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
JEIL Moon Hwa Co.
18-6, 3Ga, Pil_dong, Jung_gu, Seoul, Korea
9-inch Digital Media Station
iLX-F903D
• INSTALLATION MANUAL
• INSTALLATIONSANLEITUNG
• GUIDE D'INSTALLATION
• MANUAL DE INSTALACIÓN
• MANUALE DI INSTALLAZIONE
• INSTALLATIONSHANDBOK
• INSTALLATIEHANDLEIDING
• РУКОВОДСТВО ПО УСТАНОВКЕ
• INSTRUKCJA MONTAŻU
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
www.alpine.co.uk
ALPINE ELECTRONICS France S.A.R.L.
184 allée des Erables
CS 52016 – Villepinte
95 945 Roissy CDG cedex
Phone : + 33(0)1 48 63 89 89
FRANCE
ALPINE ITALIA S.p.A.
Viale Cristoforo Colombo 8,
20090 Trezzano sul Naviglio MI, Italy
Phone +39 02 484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in Korea
PART NO. 68-34732Z92-A
M3514663010
EN
DE
FR
ES
IT
SE
NL
RU
PL

Advertisement

Table of Contents
loading

Summary of Contents for Alpine iLX-F903D

  • Page 1 01013 Vitoria (Alava)-APDO 133, Spain Phone 1-800-ALPINE-1 (1-800-257-4631) Phone 945-283588 ALPINE ELECTRONICS France S.A.R.L. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 184 allée des Erables 161-165 Princes Highway, Hallam CS 52016 – Villepinte Victoria 3803, Australia 95 945 Roissy CDG cedex...
  • Page 3: Table Of Contents

    ENGLISH Contents WARNING ............2 CAUTION ............2 Precautions ........... 3 Accessory List ............3 Installation .............. 3 Caution concerning the installation location ............3 Adjust the front-back position of the Display unit (Optional) ..........4 Attach the Sheet cap (Only necessary when the front-back position of the Display unit is in the forward position) ......
  • Page 4: Warning

    DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO WARNING MAKE GROUND CONNECTIONS. Bolts or nuts used for the brake or steering systems (or any other This symbol means important instructions. Failure safety-related system), or tanks should NEVER be used for to heed them can result in serious injury or death.
  • Page 5: Precautions

    If blocked, heat will accumulate inside amperage. When in doubt, consult your Alpine dealer. the unit and may cause a fire. • The unit uses female RCA-type jacks for connection to other <example>...
  • Page 6: Adjust The Front-Back Position Of The Display Unit (Optional)

    Tightly fix the slider using the 4 screws that were Adjust the front-back position of the Display removed in Step 1. unit (Optional) Flush head screw Depending on the vehicle, it may be necessary to adjust the front- back position of the Display unit when mounting it. If front-back position adjustment is necessary, set the slider to the back position before mounting the display unit to the vehicle.
  • Page 7: Mounting The Microphone

    • If the GPS Antenna is mounted near the unit, the reception becomes Note on using HDMI Connection Cables (HDMI Cable not poor, and the location of your vehicle may not be displayed correctly. included) - Mount the GPS Antenna far away enough from the unit. When using HDMI connection cables, secure the cables to the HDMI - Bundle the GPS Antenna cable away from the rear of the unit.
  • Page 8: Install The Display Unit

    Fix the Display unit to the slider of the main unit using 4 Install the display unit screws (M4×6). Remove the 2 angle adjustment screws (M4×6) fixing the left and right sides of the Display unit and pull the top of the display forward.
  • Page 9 Adjust the mounting position of the display. 2) After adjustment, tightly fix the display with the 4 Flush head screws (M4×13) for up-down adjustment. • The available adjustment positions of the Display differ depending on the front-back/up-down/angle positions. Consult “Position Adjustment and Mounting Dimensions of the Display”...
  • Page 10 Refer to the illustration below to use the screw holes for angle Attach Cover rear-L/R to the left and right sides of the adjustment. display unit. • Example: To install the display at the angle of 20°, use the screw holes 2 and b.
  • Page 11: Connections

    Connections Antenna ISO Antenna Plug GPS Antenna (Included) SPEED SENSOR To the vehicle speed pulse line (Green/White) CAMERA To RCA Rear camera CONNECT2 I/F To CAN Interface box AUX INPUT To AUX output device CAN I/F cable REMO To amplifier or equalizer (Blue/White) REVERSE To plus side of the back lamp signal...
  • Page 12 ISO/JASO Antenna Adapter may be required, depending on the To steering remote control interface. vehicle. For details about connections, consult your nearest Alpine dealer. Speed Sensor Lead (Green/White) MIC Input Connector Improper connection of the speed pulse line may cause...
  • Page 13: If An Acc Power Supply Is Not Available

    • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
  • Page 14: System Example

    System Example Connection of an iPod/iPhone When connecting to an iPod/iPhone with a Lightning connector iPod/iPhone with a Lightning USB connector connector (sold separately) USB extension cable (Included) Lightning to USB Cable KCU-471i (sold separately) When connecting to iPhone 4S iPhone 4S USB connector (sold separately)
  • Page 15 Connection of a Flash Drive USB connector USB extension cable (Included) USB Flash Drive (sold separately) • Do not leave a flash drive in a vehicle for a long time. Heat and humidity may damage the flash drive. Connection of an HDMI Device (iPhone with a Lightning connector) iPhone with a Lightning USB connector HDMI input connector*...
  • Page 16 Connection of an HDMI Device (Android device) Android device with HDMI connector USB connector HDMI input connector* (sold separately) HDMI connection kit KCU-610HD (sold separately) USB extension cable (Included) HDMI Type-D HDMI connection cable conversion adapter Micro USB conversion cable Android device with MHL connector (sold separately)
  • Page 17 Connection of an External Device CAN I/F connector CAN I/F cable To Video Output terminal (Yellow) (Red) External Device (sold separately) AUX INPUT (White) To Audio Output terminal AUX Input Connector AV/RCA Interface Cable (4-pole mini AV plug to 3-RCA) (sold separately) RCA Extension Cable (sold separately) •...
  • Page 18 Connection of an External Amplifier REMOTE ON Power Supply connector PRE OUT connector (Blue/White) REMO REMOTE ON (Blue/White) (Blue/White) Power cable (Red) SUBW PRE OUT cable Amplifier for subwoofer Subwoofer (sold separately) (White) To subwoofer input terminal To front input terminal (Red) FRONT OUT Front speaker...
  • Page 19 Connection of a Rearview camera CAN I/F connector Power Supply connector Power cable Reverse Connect to the plus side of the car’s reverse lamp. (Orange/White) CAN I/F cable To Video Output terminal Camera with RCA video output (sold separately) CAMERA CAMERA Input RCA Connector RCA Extension Cable (sold separately) Reverse Lead (Orange/White)
  • Page 20: Position Adjustment And Mounting Dimensions Of The Display

    Position Adjustment and Mounting Dimensions of the Display The mounting position of this unit’s Display can be adjusted (front-back/up-down/angle). When mounting the Display, confirm the mounting position and mounting dimensions so that it does not obstruct your field of vision or impair driving. WARNING •...
  • Page 21 Mounting Dimensions for Angle Adjustment of the Display <Front-back position: forward> Angle: 45° Angle: 20° Angle: -20° A’ A’ A’ B’ B’ B’ A’ B’ A’ B’ A’ B’ 100.8 142.4 -5.3 36.2 134.2 106.7 -5.3 53.4 100.2 -15 mm 120.1 101.6 -19.4...
