MODEL LL2156
21-INCH
SCROLL SAW
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-800-232-1195 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit

Advertisement

Table of Contents
loading

Related Manuals for Wen LL2156

Summary of Contents for Wen LL2156

  • Page 1 1-800-232-1195 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    CONTENTS WELCOME Introduction ..................... 3 Specifications ....................3 SAFETY General Safety Rules ..................4 Scroll Saw Safety Warnings ................6 Electrical Information ..................7 BEFORE OPERATING Unpacking & Packing List .................8 Know Your Scroll Saw..................9 Preparation ...................... 9 Assembly & Adjustments ................10 OPERATION &...

  • Page 3: Welcome

    INTRODUCTION Thanks for purchasing the WEN Scroll Saw. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool.

  • Page 4: Safety

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 6: Scroll Saw Safety Warnings

    SCROLL SAW SAFETY WARNINGS WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. BEFORE OPERATION - Carry the scroll saw by its base. Do not move the scroll saw by pulling on the power cord. Pulling on the power 1.

  • Page 7: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 8: Before Operating

    UNPACKING & PACKING LIST UNPACKING With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the scroll saw from the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard the packaging until everything is removed.

  • Page 9: Know Your Scroll Saw

    TOOL PURPOSE Let the good times scroll! Take on the most intricate and artful cuts with your WEN Scroll Saw. Refer to the following diagrams to become familiarized with all the parts and controls of your scroll saw. The components will be referred to later in the manual for assembly and operation instructions.

  • Page 10: Assembly & Adjustments

    ASSEMBLY & ADJUSTMENTS NOTE: Prior to making adjustments, mount the scroll saw on a Fig. 2 stable surface. See “Bench mounting the saw.” ALIGN THE BEVEL INDICATOR The bevel indicator has been adjusted at the factory, but should be rechecked prior to use for best operation. 1.
  • Page 11 ASSEMBLY & ADJUSTMENTS Fig. 6 WARNING! TO REDUCE RISK OF INJURY: • When carrying the saw, hold it close to your body to avoid injury to your back. Bend your knees when lifting the saw. • Carry the saw by the base, table, housing, or motor. Do not carry the saw by the power cord or upper arm.
  • Page 12 ASSEMBLY & ADJUSTMENTS BLADE SELECTION This scroll saw accepts 5" pinless blades, with a wide variety of blade thicknesses and widths. The type of material and intricacies of cutting operations will determine the number of teeth per inch. Always select the narrowest blades for intricate curve cutting and the widest blades for straight and large curve cutting operations.
  • Page 13 ASSEMBLY & ADJUSTMENTS This saw uses 5” pinless blades. Fig. 10 REMOVING THE BLADE Make sure the saw is turned OFF and unplugged before making any adjustments to the blade. 1. To remove the blade, rotate the tension knob (Fig. 10 - 1) toward you to relieve tension.

  • Page 14: Operation & Maintenance

    OPERATION RECOMMENDATIONS FOR CUTTING A scroll saw is basically a curve-cutting machine. It can also be used for straight cutting and beveling or angle cut- ting operations. Please read and understand the following directions before attempting to use the saw. 1.
  • Page 15 OPERATION POWER SWITCH & SPEED CONTROL KNOB Fig. 12 Always wait for the saw to come to a complete stop before re- starting. 1. To turn the saw on, flip the ON/OFF switch (Fig. 12 - 1) to ON. When first starting the saw, it is best to move the speed control knob (Fig.
  • Page 16 OPERATION ANGLE CUTTING (BEVELING) Fig. 14 1. Layout or secure design to workpiece. 2. Loosen the height adjustment knob (Fig. 14 - 2), move the blade guard foot (FIg. 14 - 1) to the highest position, and re- tighten the knob. 3.
  • Page 17 OPERATION RIP OR STRAIGHT LINE CUTTING You will need a straight edge and a clamp (not included). 1. Raise the blade guard foot (Fig. 16 - 1) by loosening the height adjustment knob (Fig. 16 - 2). 2. Measure from the tip of the blade to the desired distance. Position the straight edge parallel to the blade at that distance.

  • Page 18: Maintenance

    4. Remove fuse. Replace it with an identical 5A, 250V glass fuse, 5mm x 20mm. Fuse designation is F5AL250V, and is available for purchase at wenproducts.com under part no. LL2156-016.1. 5. Replace the fuse. Follow steps 1 – 3 in reverse to re-assemble...
  • Page 19 MAINTENANCE WARNING! Always turn the switch OFF and unplug the power cord from the outlet before maintaining or lubricating the scroll saw. GENERAL MAINTENANCE 1. Clean your saw after each use. Wipe it down with a soft cloth. Clean any accumulated sawdust out of the base. Use low-pressure compressed air (not to exceed 25 PSI) to blow any sawdust out of the blade holders, blade bevel rails, etc.

  • Page 20: Troubleshooting Guide

    1-800-232-1195 for assistance. 5. Defective power switch, PCB, or 5. Contact customer service at 1-800- motor. 232-1195. 1. Defective potentiometer (LL2156- 1. Contact customer service at 1-800- 055). 232-1195 Variable speed does not work. 2. Contact customer service at 1-800- 2.

  • Page 21: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of normal use are not covered under the warranty.
  • Page 22 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. LL2156-001 Power Cord LL2156-031 Bearing, 628-2Z Socket Head Pan Connecting Rod Cover LL2156-002 LL2156-032 Screw, M5x8 Plate LL2156-003 Flat Washer, 5mm LL2156-033 Lock Washer, 8mm LL2156-004 Circuit Board Cover...
  • Page 23 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. LL2156-067 Tension Bushing LL2156-104 Screw, M8x20 LL2156-068 Right Switch Housing Positive Stop Posi- LL2156-105 tioning Plate LL2156-069 Screw M4X20 LL2156-106 Bearing Spacer LL2156-070 Tension Rod Plate LL2156-107...

  • Page 24: Warranty Statement

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship during personal use for a period of two (2) years used for professional or commercial use.
