Port Status Indicator LEDs
Display Mode Indicator LEDs
Mode Button
Alarm Indicator LED
Power Module Indicator LEDs
RS-232 Console Port
1.3
Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM
RSG2100PF:
AC power cord (16 AWG)
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #8-32 screws
RUGGEDCOM RSG2100PF
Installation Manual, 07/2021, C79000-G8976-1345-11
Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
Status
Duplex
Speed
The display mode indicator LEDs indicate the current display mode
for the port status indicator LEDs (i.e. Status, Duplex or Speed).
The Mode button sets the display mode for the port status indicator
LEDs (i.e. Status, Duplex or Speed). It can also be used to reset the
device if held for 5 seconds.
The alarm indicator LED illuminates when an alarm condition exists.
The power module indicator LEDs indicate the status of the power
modules.
Green – The power supply is supplying power
•
Red – Power supply failure
•
•
Off – No power supply is installed
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Tools/Materials
1.3 Required Tools and Materials
Mode
Color/State
Green (Solid)
Green (Blinking)
Off
Green
Orange
Off
Green (Solid)
Green (Blinking)
Orange (Solid)
Off
19)".
For connecting power to the device.
For connecting the device to the network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
Introduction
Description
Link detected
Link activity
No link detected
Full duplex mode
Half duplex mode
No link detected
100 Mbps
1000 Mbps
10 Mbps
No link detected
Purpose
3
