SERVICE MANUAL
2005
2
MA125
KD-G111,KD-G117
Maximum Power Output
Continuous Power Output
FM Band Cover
1
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-26
CD RECEIVER
KD-G111
87.5 MHz to 108.0 MHz

TABLE OF CONTENTS

COPYRIGHT © 2005 Victor Company of Japan, Limited
KD-G111
KD-G117
45 W
17 W
FM1/FM2 : 87.5 MHz to 108.0 MHz
FM3 :
KD-G111
Area suffix
E ------------ Southern Europe
EX ------------ Northern Europe
EY ------------- Eastern Europe
EU ------------------------- Turkey
KD-G117
Area suffix
EE -------- Russian Federation
KD-G117
50 W
19 W
65.00 MHz to 74.00 MHz
No.MA125
2005/2
