Epson LX-1170 Specifications

9-PIN
DOT MATRIX PRINTER
546mm

SPECIFICATIONS

PRINTER TYPE
PRINTING METHOD Impact dot matrix
NUMBER OF PINS IN HEAD 9 pins
PRINT DIRECTION Bi-directional with logic seeking
PRINT SPEED
HIGH SPEED DRAFT 15 CPI
HIGH SPEED DRAFT 12 CPI
HIGH SPEED DRAFT 10 CPI
HIGH SPEED DRAFT 20 CPI CONDENSED
HIGH SPEED DRAFT 17 CPI CONDENSED
DRAFT 15 CPI
DRAFT 12 CPI
DRAFT 10 CPI
DRAFT 20 CPI CONDENSED
DRAFT 17 CPI CONDENSED
NLQ 20 CPI
NLQ 17 CPI
NLQ 15 CPI
NLQ 12 CPI
NLQ 10 CPI
PRINT CHARACTERISTICS
CHARACTER SETS 12 international character sets
13 character code tables ( Standard )
Italic, PC437, PC850, PC860, PC861, PC863, PC865,
Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858,
ISO 8859-15
BITMAP FONTS EPSON Draft:
EPSON Roman:
EPSON Sans Serif:
BAR CODE FONT EAN-13, EAN-8, Interleaved 2 of 5, UPC-A
UPC-E, Code 39, Code 128, PostNet
PRINTABLE COLUMNS
PITCH ( CPI )
CHARACTERS PER LINE
10 CPI
12 CPI
15 CPI
17 CPI CONDENSED
20 CPI CONDENSED
PAPER HANDLING
PAPER PATH Manual Insertion:
Tractor:
Cut Sheet Feeder: (Rear in, Top out)
CUT SHEET SIZE Width:
Length:
ENVELOPES No.6, No.10
CONTINUOUS PAPER SIZE Width:
Length:
PAPER THICKNESS Cut Sheet:
Single sheet
Multi-part forms 0.12~0.39mm ( 0.0047~0.015" )
Envelopes:
Continuous Paper:
Single sheet/ Multi-part forms
Continuous forms with label:
Base Sheet
Total Sheet
PAPER FEEDING
STANDARD Friction:
Push Tractor:
Pull Tractor:
OPTIONAL FEEDER Cut Sheet Feeder: (Rear in, Top out)
Push-Pull Tractor:
COPIES Original + 4 copies
LINE SPACING 1/ 6" inch or programmable by 1/ 432" inch
INPUT DATA BUFFER
8 K Byte
SEIKO EPSON CORPORATION
HEAD OFFICE
3-5, Owa 3-chome, Suwa-shi, Nagano, 392-8502 Japan
Phone: 0266-52-3131 Telex: 3362-435 ( EPSON J )
Fax: 0266-53-4844
163mm
275mm
337 cps
337 cps
300 cps
300 cps
321 cps
225 cps
270 cps
225 cps
225 cps
191 cps
56 cps
47 cps
56 cps
67 cps
56 cps
10, 12, 15 cpi
10, 12, 15 cpi, Proportional
10, 12, 15 cpi, Proportional
CHARACTER
136 10
163 12
204 15
233 17.1
272 20
(Rear in, Top out)
(Rear in, Top out)
(Bottom in, Top out)
148~420mm ( 5.8~16.5" )
100~364mm ( 3.9~14.3" )
101.6~406.4mm ( 4.0~16.0" )
Max. 559mm ( 22.0" )
Can also print labels
0.065~0.14mm ( 0.0025~0.0055" )
0.16~0.52mm ( 0.0063~0.0205" )
0.065~0.39mm ( 0.0025~0.015" )
0.07~0.09mm ( 0.0028~0.0035" )
0.16~0.19mm ( 0.0063~0.0075" )
(Rear in, Top out)
(Rear in, Top out)
(Rear in, Top out)
(Bottom in, Top out)
(Rear in, Top out)
INTERFACE
STANDARD Centronics
( IEEE-1284 Nibble mode )
RS-232C Serial Interface
OPTION EpsonNet 10/100 Base TX Ext. Print Server
RIBBON CARTRIDGE
COLOUR Black
TYPE Fabric ribbon cartridge
RIBBON LIFE Black Ribbon: Approx. 3 million characters
( Draft 10cpi, 14 dots/ character )
ACOUSTIC NOISE
Approx. 49dB ( A ) ( ISO 7779 pattern )
RELIABILITY
MVBF ( Mean Print Volume Between Failure )
12 million lines ( Except print head )
MTBF ( Mean Time Between Failure )
6000 POH ( 25% duty cycle )
PRINT HEAD LIFE 400 million strokes/ wire
CONTROL PANEL
4 switches, 4 LEDs
ENVIRONMENTAL CONDITIONS ( OPERATING )
TEMPERATURE 5~35˚C
HUMIDITY 10~80% RH
ELECTRICAL SPECIFICATIONS
RATED VOLTAGE AC 120V or AC 220~240V
RATED FREQUENCY 50~60Hz
Approx. 23W (ISO 10561 Letter pattern)
POWER CONSUMPTION
Energy Star compliant
DIMENSIONS
WIDTH 546mm
DEPTH 275mm
HEIGHT 163mm
WEIGHT Approx. 6.3 kg
PRINTER DRIVER/ UTILITY
OS Microsoft
Windows
EPSON Status Monitor 3 ( Microsoft
UTILITY
95/98/2000/Me and Microsoft
operating system Version 4.0 environment only )
OPTIONS
RIBBON CARTRIDGE
RIBBON PACK
SINGLE BIN CUT SHEET FEEDER
PULL TRACTOR UNIT
ROLL PAPER HOLDER
EpsonNet 10/100 Base TX Ext. Print Server*
* 1 Regional AC Adapter Set (C82525) is required.
E
As an international NERGY
product meets the international
"EPSON ESC/P stands for EPSON standard code for printers. This
system of commands gives you software control of your printer from
your computers. It is standard for all EPSON printers and supported
by most application software for personal computers."
EPSON and EPSON ESC/P are registered trademark of SEIKO EPSON CORPORATION.
Microsoft, Windows and Windows NT are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
All other product names and other company names used herein are for identification purpose
only and maybe the trademarks or registered trademarks of their respective owners.
EPSON disclaims any and all rights in those marks.
Print samples shown herein are simulations.
Specifications are subject to change without notice.
®
