IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: __________________________
Serial #: __________________________
Date Purchased: ___________________
OPERATOR'S MANUAL
Gas Fired Steamers
RG24-5
SX-34GC
SX-55GC
!
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
www.southbendnc.com
HEAVY DUTY STEAM
M
1195732 R
0 (11/22/2011)
ANUAL
EV
Advertisement
Related Manuals for Southbend RG24-5
Summary of Contents for Southbend RG24-5
- Page 1 Model #: __________________________ Serial #: __________________________ Date Purchased: ___________________ OPERATOR’S MANUAL Gas Fired Steamers RG24-5 SX-34GC SX-55GC WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
- Page 2 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC IMPORTANT NOTES FOR INSTALLATION AND OPERATION This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
-
Page 3: Table Of Contents
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC TABLE OF CONTENTS DESCRIPTION PAGE 1.0 Service Connections ........... . 4 2.0 Installation... -
Page 4: Service Connections
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 1.0 SERVICE CONNECTIONS RG24-5 MANUAL 1195732 REV0 (11/22/2011) HEAVY DUTY STEAM... - Page 5 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 1.0 SERVICE CONNECTIONS (Continued) MANUAL 1195732 REV0 (11/22/2011) HEAVY DUTY STEAM...
- Page 6 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 2.0 INSTALLATION GENERAL NOTICE: If this equipment is being installed at over 2,000 feet altitude and was not so specified on order, contact service department. Failure to install with proper orifice sizing may void the warranty.
- Page 7 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 2.0 INSTALLATION (Continued) 2.1 EXHAUST FANS AND CANOPIES: Canopies are set over ranges, ovens, kettles, etc., for ventilation purposes. It is recommended that a canopy extend 6" past appliance and be located 6' 6" from the floor. Filters should be installed at an angle of 45 degrees or more with the horizontal.
-
Page 8: Installation
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC INSTALLATION GAS CONNECTION: 1. The Serial and Rating Plate on the unit indicates the type of gas your unit is equipped to burn. DO NOT connect to any other gas type. - Page 9 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC ELECTRICAL CONNECTION WARNING: Do not connect the kettle to the electrical supply until after the gas connection has been made. 120 VAC-60 Hz-Single Phase Units with this electrical rating are factory supplied with a three-wire cord and three-prong plug which fits any standard 120V, three-prong grounded receptacle.
- Page 10 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC (Continued) PLUMBING CONNECTIONS COLD WATER CONDENSER The steamer is equipped with a cold water condenser in the rear of the cooking chamber which helps to condense the steam prior to discharge into drain. The steamer freely vents itself by the negative pressure created by the condensate water drainage.
-
Page 11: Performance Check
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 3.0 PERFORMANCE CHECK Once the steamer is installed and all mechanical connections have been made, thoroughly test the steamer before operation. 1. Check that proper water, drain and electrical and gas connections have been made. - Page 12 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 4.0 OPERATION INSTRUCTIONS WARNING: The steamer and its parts are hot. Use care when operating, cleaning or servicing the steamer. The cooking compartment contains live steam. Stay clear when opening door.
-
Page 13: Operation Instructions
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC OPERATION INSTRUCTIONS Delime (if so equipped) Closes the drain valve while CLR liquid is being poured into the generator during the Delime procedure. Delime Generator Light (if so equipped) Indicates that lime scale deposits have accumulated in the steam generator and that a DELIME procedure should be performed at the next convenient opportunity. - Page 14 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC OPERATION INSTRUCTIONS (Continued) SHUTDOWN NOTE: The cooking compartments are operated independently of each other. Each has its own gas and water supply and generator tank. STAND BY 1. Set timer to “OFF” position and leave door slightly open.
- Page 15 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC OPERATION INSTRUCTIONS STEAM COOKING Your steamer efficiently cooks vegetables or other foods for immediate serving. Steam cooking should be carefully time controlled. Keep hot food holding time to a minimum to produce the most appetizing results.
- Page 16 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS SX-5GR, SX-34GCR, SX-55GCR 5.0 PERIODIC MAINTENANCE NOTICE: As a safety precaution, disconnect the power supply during cleaning or servicing. CLEANING At the end of each day, or between cooking cycles if necessary: 1.
-
Page 17: Periodic Maintenance
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC PERIODIC MAINTENANCE CLEANING Weekly, or more often if necessary: 1. Clean exterior with a damp cloth and polish with a soft dry cloth. 2. Use a non-abrasive cleaner to remove discolorations. - Page 18 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC MAINTENANCE STAINLESS STEEL To remove normal dirt, grease or product residue from stainless steel, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth.
-
Page 19: Deliming Procedure
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 6.0 DELIMING PROCEDURE (For units equipped with this feature) WARNING: Read and follow instructions on the CLR bottle. Use plastic or rubber gloves to avoid skin contact. If CLR comes in contact with skin, rinse with clean water. -
Page 20: Troubleshooting
INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 7.0 TROUBLESHOOTING ADJUSTMENTS WARNING: At least twice a year, have an authorized service person clean and adjust the unit for maximum performance. WARNING: Adjustments and service work may be performed only by a qualified technician who is experienced in, and knowledgeable with, the operation of commercial gas cooking equipment. - Page 21 INSTALLATION AND OPERATION MANUAL, GAS FIRED STEAMER, MODELS RG24-5, SX-34GC, SX-55GC 7.0 TROUBLESHOOTING (Continued) Water flows into cooking compartment: 1. Shortage of circuit at operating probe and body. 2. Scale build-up on operating probe inside generator. 3. Water fill solenoid valve is open, plugged or defective.
