- Page 1 HDHP80A1 HEAT PUMP DRYER USER MANUAL...
- Page 2 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain damaging your health and well-being. When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at least free of charge.
-
Page 3: Table Of Contents
CONTENTS Introduction Safety instruction Installation instructions Getting started quickly Program modes Preparing the dryer Preparing the laundry Loading the dryer Care chart Caring for your dryer Error codes Troubleshooting Customer service... -
Page 4: Introduction
INTRODUCTION DEAR CUSTOMER SCOPE OF DELIVERY INTENDED USE being Warning; Risk of fire/ Flammable materials This marking on product is a safety symbol. Failure to follow the warning outlined in these user instructions can cause a fire hazard. -
Page 5: Safety Instruction
The tumble dryer must not be used in a non-stationary location (e.g. a ship). Do not make any alterations to the tumble dryer, unless authorised to do so by Haier. In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the tumble dryer and its surroundings in a clean condition at all times. - Page 6 SAFETY INSTRUCTIONS Items which contain a large proportion of rubber, foam rubber (latex foam) or rubber like materials such as shower caps, waterproof textiles, rubberised articles and items of clothing and pillows with foam rubber filling should not be dried in the tumble dryer. Items which have been cleaned using industrial chemicals such as professional drycleaning agents, should not be dried in the tumble dryer.
-
Page 7: Installation Instructions
(when viewed from the front). If the dryer has not been transported as described, leave it standing upright for at least one hour before turning on. Accessories Please check you received the following accessories with your Haier dryer. You will find them inside the drum: 1 x Drain hose... - Page 8 The dryer stands on the floor and can easily be moved into position. Stacking Your dryer has been designed to be able to be stacked on top of a Haier front loading washer. A stacking kit MUST BE USED between the products and fitted correctly to the washing machine and dryer, as per the stacking kit instructions.
- Page 9 INSTALLATION INSTRUCTIONS Draining The dryer is equipped with a condenser unit which accumulates water during the drying cycle. This water is collected in the removable water tank located at the top left of the dryer. The accumulated water must be emptied after each drying cycle. However you can also set up your dryer to drain automatically using the drain hose provided.
- Page 10 Do not operate this machine if it has been damaged during transport. Contact your Haier dealer ● or Haier trained and supported service technician.
- Page 11 INSTALLATION INSTRUCTIONS Completing the installation Installation test cycle IMPORTANT! Ensure the installation test cycle is completed before you dry any items in your dryer. This is to check that your dryer is installed correctly and that it is functioning properly prior to use.
- Page 12 INSTALLATION INSTRUCTIONS Machine specifications HDHP80A1 Capacity (kg)* DIMENSIONS ( mm ) Width Depth Height** Length of drain hose 1300 ELECTRICAL Volts 220 – 240 Amps (maximum) Heating Power (W) * Capacity refers to the maximum dry weight of items the machine can dry at any one time.
-
Page 13: Getting Started Quickly
GETTING STARTED QUICKLY The display shows the remaining time, the delay time and other Display related information. Note: The remaining time is a default value, this time will be re-calculated depending on additional program settings and the moisture content of the laundry. Program knob Select one of the 16 programs using the knob. - Page 14 GETTING STARTED QUICKLY Anti-Crease If you wish to minimise wrinking, touch the Anti-Crease. At the end of the cycle, the drum will rotate periodically and cool air will be circulated through the load to minimise wrinkling and creaseing. This is particularly useful if you cannot remove the items immediately after the cycle ends.
-
Page 15: Program Modes
PROGRAM MODES DEFAULT RECOMMENDED MAX . PROGRAM DRYNESS LAUNDRY LOAD LEVEL* Duvet Duvet/Doona Products Drying items for a specific Air Dry** time period, without heat Heavy fabrics, need Time Dry Time further drying Warm 30 Suitable for all clothing Warm 60 Suitable for all clothing Cotton*** Cotton... -
Page 16: Preparing The Dryer
PREPARING THE DRYER 1 Connect the tumble dryer to a power socket. 2 Make sure the water tank is empty and properly installed. Make sure that the lint filter is clean and properly installed. Make sure that the condenser filter is clean and properly installed. -
Page 17: Care Chart
CARE CHART Do not dry clean Resistant material Bleachable in cold water Do not bleach Delicate fabric Hang to dry Iron at 200 °C Washable at 95 °C Dry on clothes Washable Iron at 150 °C hanger at 60 °C Tumble dry Washable Iron at 100 °C... -
Page 18: Caring For Your Dryer
IMPORTANT! If the lint filter becomes damaged, contact your Haier trained and supported service technician to arrange getting a new filter. Do not operate your dryer with a damaged lint filter or without the filter in place, as this will cause damage... - Page 19 CARING FOR YOUR DRYER Emptying the water collection tank During the drying cycle steam condenses into water and is collected in the water tank, located at the top left of the dryer. It is important to empty the water tank after every load. A user warning will also be displayed on the screen If the water tank becomes full during operation, the dryer will pause and beep to alert you.
- Page 20 CARING FOR YOUR DRYER Cleaning the condenser filter To clean the condenser filter: Switch off the power supply and remove the power plug before cleaning the condenser. Open the condenser filter cover. Turn the four condenser lock levers 90° then pull out the condenser filter. Remove rear filter and wipe the surface clean with your hand.
-
Page 21: Error Codes
ERROR CODES CODE CAUSE SOLUTION Contact the customer service. Drain pump error. Contact the customer service. F32, The condenser thermal sensor is open-circuited or short-circuited. Contact the customer service. 1,Temperature of the laundry in the drum does not change. 2,Refrigerant leaks. Communication failure between Contact the customer service. -
Page 22: Troubleshooting
TROUBLESHOOTING Before contacting the customer service, please check the following circumstances: PROBLEM CAUSES SOLUTION Check connection to the power – Poor connection to the Tumble dryer supply. power supply. fails to operate. Check the power supply. – Power failure. Set a drying program. –... -
Page 23: Customer Service
CUSTOMER SERVICE If you have a problem with your appliance first see the Troubleshooting section of the manual. If you cannot find a solution, please contact your local dealer or try one of the following numbers. Free Toll Australia: 1300 729 948 Free Toll New Zealand: 0800 242 437 Before contacting the customer service, emsure that you have the following data avaliable.
