Edimax EN-9230TX-32 Specifications

Gigabit Ethernet Network Adapter
Gigabit Ethernet Network Adapter
Gigabit Ethernet Network Adapter
Gigabit Ethernet Network Adapter
32 - bit, 66/33MHz PCI 10/100/1000Mbps UTP
32 - bit, 66/33MHz PCI 10/100/1000Mbps UTP
Taiwan / Headquarters
Edimax Technology Co., Ltd.
TEL : 886-2-2299-5648
FAX : 886-2-2299-5647
sales@edimax.com.tw
China
Beijing Edimax Science &
Technology Co., Ltd.
TEL : 8610-6213-9288
FAX : 8610-6213-9231
sales@edimax.com.cn
U.S.A.
Edimax Computer Company
TEL : 1-408-496-1105
FAX : 1-408-980-1530
sales@edimax.com
Latin America
TEL :1-786-845-8099
FAX :1-786-331-8490
sales_latinamerica@edimax.com
Europe
TEL : 31-499-377344
FAX : 31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL: 44-0-1908-255901
FAX: 44-0-1908-255700
info@edimax.co.uk
Features
• Comply with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3x.
• Supports 32-bit, 66/33MHz PCI Local Bus Master for high speed operation of Rev.
2.2/2.1 specification.
• One RJ-45 connector supports 1000Mbps, 100Mbps or 10Mbps network speed and
Auto-MDI/MDI-X.
• Plug-and-Play installation--auto-setup IRQ and I/O address.
• Supports IEEE 802.3x full-duplex flow control.
• Full-duplex design to double the performance to 20/200/2000Mbps.
• Supports PCI 2.2 Wake On LAN function.
• Supports IEEE 802.1Q VLAN tagging.
• Supports Jumbo Frame.
• Supports Web-based Management.
Specifications
Product
Chipset
Standards
Bus Architecture
Network Power
Network Drivers
LED
Dimension
Temperature
Humidity
Certification
EN-9230TX-32
Realtek RTL8169S-32 Single Chip
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
PCI V2.2/2.1, 32-bit, 66/33MHz
UTP x 1 (Auto-MDI/MDI-X)
Windows 98/98SE/Me/NT/2000/XP/Server 2003, Netware
Server 4.x/5.x/6.x, Netware ODI for DOS, Unix and Linux
Link/Activity
120 x 40 mm (4.72 x 1.77 in.)
32~113 ° F (0~45 ° C)
10-95% (NonCondensing)
FCC Class B, CE Mark, C-Tick, VCCI
EN-9230TX-32
