- Page 1 22/08/2016 Version 1.0 RWT2CL...
- Page 2 Important! It is essential that you read the instructions in this manual before operating this machine. SAVE THESE INSTRUCTIONS FOR FUTURE USE...
- Page 3 ■ Do not load with more than 180 kg. Do not leave heavy loads on work surface for extended periods of time. ■ Do not apply an unbalanced load which could cause the workbench to tip over. ■ Do not use the work center as a stepladder or standing platform.
- Page 4 Latches Upper plate Side support Side support Center support Bottom plate Legs Feet Clamps Carry handle...
- Page 5 Operation: Opening The Workbench The Portable Clamping Workstation is packaged completely folded. To open: 1. Place the workbench flat on the floor. 2. Grasp the openings on both sides of the table top and pull out on the release latches as shown in figure A.
- Page 6 Operation: Closing The Workbench 1. Fold the center support section down and push in on the side supports to unlock them (figure F) 2. Reach through the openings in the table top and grasp the lower section of the bench. Pull up on the lower section to begin collapsing the legs.
- Page 7 Adjustable clamps The two adjustable clamps can be used in both a vertical and horizontal mode. The long channels in the table top allow the clamps to be anchored in a stationary horizontal position. The shorter slots in the table top allow for the clamps to be used in a vertical position (figure J). J1 through J6 illustrate how to use the clamps in both horizontal and vertical modes.
- Page 8 Adjustable clamps Transporting & Maintenance Carry the unit by the convenient carrying handle as shown in figure K. Use only mild soap and damp cloth to clean the tool. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid. 12.25 kg 85 x 55 x 75.5 cm 180 kg...
- Page 9 Techtronic Industries (Australia) Pty. Ltd. 31 Gilby Road, Mount Waverley, VIC, Australia 3149 Techtronic Industries New Zealand Ltd. 2 Landing Drive, Auckland Airport, Mangere, New Zealand 2022...
