SELECT vENT-FREE
UNIvERSAL FIREbOxES
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
FIRE OR ExPLOSION hAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WhAT TO DO IF yOU SMELL gAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
GAS-FIRED
ANSI Z21.91
Ventless Fireplace
Enclosures
for Gas Fired
Decorative Type
Unvented Room
Heaters
WARNINg
UNIvERSAL FIREbOx
FOR ALL vENT-FREE
LOg SETS MODELS:
vFS32Fb0F- 6
vFS36Fb0F- 6
vFS36Fb2hF- 6
vFS42Fb0F- 6
vFS42Fb2hF- 6
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information, con-
sult a qualified installer, service agency or
the gas supplier.
IMPORTANT! Read these instructions carefully before in-
stalling or operating this gas appliance. These instructions
should be left with the homeowner for future reference.
FOR USE ONLy WITh A LISTED gAS-FIRED UNvENTED
DECORATIvE ROOM hEATER NOT TO ExCEED 40,000
bTU/h. Do not build a wood fire.
Do not attempt to modify or alter the construction of the
firebox or its components. Any modification or alteration of
construction may void the warranty of this firebox. Children
and adults should be alerted to the hazards of high surface
temperature and should stay away to avoid burns or clothing
ignition. Young children should be carefully supervised when
they are in the same room as the firebox.
Carefully review the instructions supplied with the decorative
type unvented room heater for the minimum fireplace size
requirement. Do not install a vent-free log set in this firebox,
unless this firebox meets the minimum dimensions required
for the installation.
WARNINg
