Do not push the eject button when the LED indicator is turned on. Otherwise, data
may be lost.
To remove the floppy disk drive
1 Turn off the notebook.
2 There is a RELEASE lever on the bottom of the computer. Slide this lever in
the direction of the arrow.
Multipurpose bay release lever
3 Slide the drive out of the multipurpose bay.
4 Insert the weight saver. See "Using the Weight Saver" for details.
To reinsert the floppy disk drive
1 Turn off the notebook.
2 If another device is in the multipurpose bay, remove the device. See "To
remove the second battery pack" for details.
3 Insert the floppy disk drive, with the VAIO label facing up, into the
multipurpose bay until the RELEASE lever locks into place.
Using the Floppy Disk Drive
