Sony PCG-FXA59 VAIO User Guide (primary manual) Specifications

MOVIES AND PHOTOS
Capture, edit, and share your digital
movies or photos, using Sony's
exclusive multimedia software!
FEATURES
• Powerful mobile AMD Athlon
• Bright and clear super high-resolution 15" SXGA+ screen!
• Spacious 30 GB 2 hard drive!
• All-in-one convenience with CD-RW/DVD combo drive, hard drive, and floppy drive
• Dual battery capability - so you can work or play longer!
®
• i.LINK (IEEE 1394) S400 digital interface

SPECIFICATIONS

Mobile AMD Athlon™ XP Processor
Mobile AMD Athlon™ XP processor 1500+ at 1.3 GHz
QuantiSpeed™ architecture for improved performance
AMD PowerNow!™ technology for improved battery life
2
Cache Memory
256 KB integrated on-die level 2
Bus Speed
2 0 0 M H z
LCD
15" SXGA+ (1400x1050) TFT display
Graphics
ATI RAGE™ MOBILITY graphics chip with 8 MB SDRAM
SDRAM
256 MB SDRAM, expandable to 512MB
Hard Drive
30 GB 3 hard drive
CD-RW/DVD-ROM Combo Drive
Internal CD-RW/DVD combo drive
(R-write 8x; RW-write 8x; DVD-read 8x; CD-read 24x)
Floppy Drive
Internal removable 1.44 MB, 3.5" USB floppy drive
When floppy is removed, supports dual battery operation
Modem
Integrated V.90 modem
Ethernet
10BASE-T/100BASE-TX Ethernet with RJ-45 interface
Pointing Device/Keyboard
Electro-Static touch pad
86 key QWERTY layout, with 3mm stroke and 19mm pitch
Estimated Battery Life 5
Lithium-ion battery, supports dual battery operation
5
2.0-2.5 hours with one battery
4.0-5.0 hours with optional second battery
PC Card Slots
Two type I or II, or one type III card slot; CardBus support
Audio
Windows sound system compatible with 3D surround
®
Built-in stereo speakers; monoral mini-jack microphone
Other Interfaces
i.LINK (IEEE 1394) interface , NTSC video out, 2 USB ports,
® 4
RJ-11 modem jack, RJ-45 Ethernet, VGA output, parallel,
serial, headphone (stereo), mic-in, port replicator interface
Optional Port Replicator (PCGA-PRFX1)
DC in, PS/2 ® keyboard or mouse, 3 USB ports, serial, parallel,
VGA output monitor, RJ-45, docking CN
Power Requirements
58.5 watts maximum (19.5V / AC100-240V)
Energy Star ® compliant
Advanced power management - APM-ACPI compatible
Size (H x W x D)
1.5" - 2.1" X 12.8" X 10.5"
Sony VAIO ® FXA-Series Notebook
Powerful performance on a big screen.
MUSIC AND ENTERTAINMENT
Download. Play. Make custom CDs
that you can enjoy on the go!
™
XP processor
4
Weight
1
with 7.1 lbs.with one battery
7.5 lbs. with battery and floppy drive
Supplied Accessories
Lithium-ion battery, power cord, floppy drive, AC adapter,
and weight saver
Optional Accessories
Port replicator (PCGA-PRFX1)
Second battery (PCGA-BP71A)
USB mouse (PCGA-UMS1/A)
Carrying case (PCGA-CCF)
Notebook backpack (PCGA-CCP1)
Neoprene notebook & AC adapter cases (PCGA-CCN1)
External speakers (PCGA-SP1)
Additional AC adapter (PCGA-AC19V1)
2.4GHz Wireless LAN Pro access point (PCWA-A200)
2.4GHz Wireless LAN PC card (PCWA-C100)
5GHz wireless LAN access point (PCWA-A500)
5GHz wireless LAN PC card (PCWA-C500)
Service and Warranty Information
One year limited Express Service
One year limited parts and labor
Telephone Support: One year hardware from purchase date
Sony and Microsoft software: 90 days from purchase date
Included Operating System
Microsoft ® Windows
Home and Business Software
Quicken ® 2002 New User Edition
Corel Word Perfect Office 2002
Movie and TV Software
Sony DVgate™
Sony MovieShaker™
5 Sony Pico Player™
InterVideo WinDVD™ 2000
Music Software
Sony SonicStage™
Screenblast™ ACID™
Screenblast™ Sound Forge
Photo Software
Adobe Photoshop Elements
Arcsoft PhotoPrinter
Sony Digital Print
Sony PictureGear™
Sony Smart Capture
Online Center
America Online
Earthlink Total Access
Real Networks
Games
Sony EverQuest
FXA59
GOT WIRELESS?
High-speed wireless access for
mobile network connection
6,9
9
® XP Home Edition 9
12
®
® 2 0 0 0 P r o
® 11
11
® Real Entertainment ® Suite
® 11
Sony PCs use genuine Microsoft
STYLISH AND PROFESSIONAL
Serious power and ultimate style with
. magnesium alloy casing. Who says
8
you can't have it all?
Virus, Tools, and Support Software
11
Skydesk SmartClone™
Trend Micro PC-Cillin ®11
VAIO Support Agent
