Table Of Contents:
Wire Harness Quick View
Installation Of The Major Components
Door Lock / Unlock Harness
Tachometer Programming Information
Transmitter Programming Information
Feature Bank 2 Program Information
Feature Bank 3 Program Information
Data Bus Port Information
Circuit Wiring Diagram
FCC COMPLIANCE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Warning!
Changes or modifications made to this equipment not expressly approved by the part responsible for compliance could void the use's author-
ity to operate the equipment
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
Model APSRS3Z
Installation Manual
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6 & 7
Page 7 - 9
Page 9
Page 10
Page 10
Page 10 & 11
Page 12 & 13
Page 14
Page 14
Page 14
Page 16
128-9482
1 of 16
Advertisement
Related Manuals for Prestige APSRS3Z
Summary of Contents for Prestige APSRS3Z
-
Page 1: Table Of Contents
Model APSRS3Z Installation Manual Table Of Contents: Before You Begin Page 2 Wire Harness Quick View Page 3 Installation Of The Major Components Page 4 6 Pin Power Harness Page 5 Door Lock / Unlock Harness Page 6 & 7... -
Page 2: Before You Begin
Before You Begin PROFESSIONAL INSTALLATION IS STRONGLY RECOMMENDED Roll down window to avoid locking the keys in the vehicle during installation. Avoid mounting components or routing wires near hot surfaces or near moving parts like the steering wheel as it may prevent proper operation of the vehicle. -
Page 3: Pin Power Harness
6 Pin Power Harness: 1124317 1 Blue Ignition 1 (+) 2 Red/White Battery 1 - 12V (+) 3 Green Ignition 2 (+) 4 Purple Accessory (+) 5 Red Battery 2 - 12V (+) 6 Yellow Starter Output 12 Pin Input/Output Harness: 1124321 1 Green/Orange Tachometer Input... - Page 4 This Remote Start System is designed to be used with Automatic Transmission- Fuel Injection Vehicles Only! INSTALLATION OF THE MAJOR COMPONENTS: CONTROL MODULE: (P/N 1365607) Select a mounting location inside the passenger compartment (up behind the dashboard). The mounting location selected must be within 24” of the ignition switch wiring harness to allow connection of the 6 pin main wiring harness.
- Page 5 WIRING THE 6 PIN MAIN POWER HARNESS Connector (P/N 1124317) BLUE Wire: Ignition 1 Output Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the ignition key is turned to the “ON” or “RUN” and the “START” or CRANK” positions, and will have 0 volts when the key is turned to the “OFF”...
- Page 6 output, however always confirm that the factory relays in your particular vehicle do not exceed the the units door unlock/lock circuits. Plug the 2 pin connector of the rated 250mA output of door unlock harness into the mating connector shell of the control module. Determine the door lock and unlock circuit of the vehicle you are working on and wire according to the diagrams shown.
- Page 7 Wiring The 12 Pin Input / Output Harness, Connector (P/N 1124321) The auxiliary 12 pin connector provides low current outputs to control various functions in the vehicle during different stages of the Remote Start unit’s operation. Understand- ing these outputs and the time in which they occur will allow you to determine if they are needed for the particular vehicle you are working on as well as how to use them.
- Page 8 NOTE: Parking Light/Trunk Release Swap. Bank 2 Feature #19 allows the Dark Blue wire to be swapped with the on board parking light relay. In other words, when this feature is selected “ON” the on-board relay will operate when the Trunk button of the transmitter is pressed, and the Dark Blue wire will provide a low current (-) negative output to function as the parking lights would normally do.
- Page 9 start unit shuts down and the G.W.R. O/P turns off. This output will occur regardless of whether the circuit times out or is manually terminated. Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the ignition circuit transitions to off.
- Page 10 5 Wire Antenna Receiver Connector (P/N 1124318) Connect the mating end of the previously mounted receiver harness to the mating connector on the module. This harness will be the supply for the LED, Valet Switch as well as the RX & 5VDC of the receiver. Programming Tach Rate: NOTE: All applications require that tach be programmed.
- Page 11 Page 11 128-9482 11 of 16...
- Page 12 PROGRAMMING BANK 3 (REMOTE START ): You can enter Bank 3 from Bank 2 by turning the ignition key off then on after you've made the changes you wanted in Bank 2, (Siren two Long Chirp). You can also go right to bank 3 by: 1) Turn the ignition key to the On position.
- Page 13 Page 13 128-9482 13 of 16...
-
Page 14: Diagnostics
Diagnostics: Diagnostic mode is automatic and will be displayed by flashing the parking lights a number of times representative of the failed start, or premature shut down based on the chart below. When a failure occurs, or a shut down occurs which in out of the ordinary the parking lights will flash 1 thru 8 times immediately after to advise what the failure could have been. - Page 15 NOTES Page 15 128-9482 15 of 16...
