Acer TravelMate 3260 Service Manual

Hide thumbs Also See for TravelMate 3260:
Table of Contents

Advertisement

Quick Links

See also: User Manual
TravelMate 2480/3260/3270 Series
Service Guide
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to
http://csd.acer.com.tw
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Acer TravelMate 3260

Summary of Contents for Acer TravelMate 3260

  • Page 1 TravelMate 2480/3260/3270 Series Service Guide Service guide files and updates are available on the ACER/CSD web; for more information, please refer to http://csd.acer.com.tw PRINTED IN TAIWAN...

  • Page 2: Revision History

    Revision History Please refer to the table below for the updates made on TravelMate 2480/3260//3270 service guide. Date Chapter Updates...
  • Page 3 Copyright Copyright © 2006 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 Conventions The following conventions are used in this manual: SCREEN MESSAGES NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 7: Table Of Contents

    Hot Keys 17 Special Key 18 Acer Empowering Technology 20 Empowering Technology password 20 Acer eNet Management (for selected models) 20 Acer ePower Management 22 Acer ePresentation Management 24 Acer eDataSecurity Management (for selected models) 25 Acer eLock Management 27...
  • Page 8 FRU (Field Replaceable Unit) List TravelMate 2480/3260/3270 Exploded Diagram 102 Appendix A Model Definition and Configuration TravelMate 2480 Series 116 TravelMate 3260 Series 126 TravelMate 3270 Series 131 Appendix B Test Compatible Components Microsoft® Windows® XP Pro Environment Test 138 Microsoft®...

  • Page 9: System Specifications

    ® Intel Core 2 Duo processor T5500/T5600 (2MB L2 cache, 1.66/1.83 GHz, 667 MHz FSB) and T7200/ T7400/T7600 (4 MB L2 cache, 2/2.16/2.33 GHz, 667 MHz FSB) (for TravelMate 3260/3270) ® Intel Core Duo processor T2300/T2400/T2500/T2600 (2MB L2 cache, 1.66/1.83/2/2.16 GHz, 667 MHz FSB) (for TravelMate 3260/3270) ®...

  • Page 10: Input Devices

    Sound Blaster Pro S/PDIF (Sony/Philips Digital Interface) support for digital speakers Built-in microphone Communication Acer Video Conference featuring Voice and Video over Internet Protocol (VVoIP) support via Acer OrbiCam and optional Acer Bluetooth VoIP phone Acer OrbiCam 225 degree ergonomic rotation...
  • Page 11 Modem (RJ-11) port DC-in jack for AC adapter Environment Temperature: ° operating: 5 C to 35 C Non-operating: -20 C to 65 C Humidity (non-condensing): operating: 20%~80% Non-operating: 20%~80% Chapter 1 ° ° °...

  • Page 12: System Block Diagram

    System Block Diagram Chapter 1...

  • Page 13: Board Layout

    Board Layout Top View LVDS CONN SW1-4 QUICK KEY SWITCH LCOCK GENERATOR CN5-6 5-IN-1 MMC/SD/MS/MS Pro/xD CARD READER CONN PCI8412/6412 SW5-10 T/P SWITCH Chapter 1 BIOS KB CONTROLLER (87541V) U5-6 G72M-VRAM MEDIA CONN K/B CONN TP/B CONN...

  • Page 14: Bottom View

    Bottom View NOTE: This is engineering sample. The image above may not be exactly the same as the real main board you get. Jumper settings G1: CMOS clear Jumper DOCKING RJ45 CONN CN10 CRT CONN LAN TRANSFORMER SUPER I/O NS87383 CN15 S-VIDEO CONN CN17...
  • Page 15 Jumper Settings/Clear BIOS Password Procedures Please see the bottom side of the main board. Find G1 jumper and short the jumper to clear BIOS password. Chapter 1 G1: CMOS clear Jumper...

  • Page 16: Your Acer Notebook Tour

    4-way scroll button. Arcade/media/volume For use with Acer Arcade and other media buttons playing programs (for selected models, yet TravelMate 2480/3260/3270 do not have Arcade/media/volume buttons).

  • Page 17: Closed Front View

    Closed Front View Item Icon Latch Power indicator Battery indicator Icon Item Speakers Bluetooth communication switch/ indicator Wireless communication button/ indicator Headphones/ Icon Item speakers/line-out jack with S/PDIF support Microphone-in jack Line-in jack Chapter 1 "Easy-launch buttons" on page 18 Description Item Description...

  • Page 18: Left View

    Left View Icon Item Icon Icon Item Icon Description Item External display (VGA) Connects to a display device (e.g., external port monitor, LCD projector). Ventilation slots Enable the computer to stay cool, even after prolonged use. S-Video/TV-out Connects to a television or display device (NTSC/PAL) port with S-video input.

  • Page 19: Right View

    Right View Icon Rear Panel Icon Chapter 1 Item Optical drive Internal optical drive; accepts CDs or DVDs (slot-load or tray-load depending on model). Optical disk access Lights up when the optical drive is active indicator (location depends on model). Optical drive eject Ejects the optical disk from the drive button...

  • Page 20: Bottom Panel

    Icon Bottom Panel Item Memory compartment Cooling fan Battery release latch Battery bay Battery lock Hard disk bay Indicators The computer has four easy-to-read status indicators: Item Ethernet (RJ-45) port Connects to an Ethernet 10/100-based network. Description Houses the computer’s main memory. Helps keep the computer cool.
  • Page 21 The front panel indicators are visible even when the computer cover is closed up. Icon Function Cap lock Icon Function Num lock Bluetooth Wireless LAN Power Battery NOTE: 1. Charging: The light shows amber when the battery is charging. 2. Fully charged: The light shows green when in AC mode.

  • Page 22: Easy-Launch Buttons

    Web browser, Empowering Key “ Press “ “ to run the Acer Empowering Technology. The mail and Web browser buttons are pre-set to email and Internet programs, but can be reset by users. To set the Web browser, mail and programmable buttons, run the Acer Launch Manager.
  • Page 23 Move your finger across the touchpad (2) to move the cursor. Press the left (1) and right (4) buttons located beneath the touchpad to perform selection and execution functions. These two buttons are similar to the left and right buttons on a mouse. Tapping on the touchpad is the same as clicking the left button.

  • Page 24: Using The Keyboard

    Using the Keyboard The keyboard has full-sized keys and an embedded keypad, separate cursor keys, two Windows keys and twelve function keys. Lock Keys and embedded numeric keypad The keyboard has three lock keys which you can toggle on and off. Lock Key Caps Lock When Caps Lock is on, all alphabetic characters typed...

  • Page 25: Hot Keys

    This key has the same effect as clicking the right mouse button; it opens the application’s context menu. Function Hot key help Displays help on hot keys. Acer eSetting Launches the Acer eSettings in Acer eManager. Acer Launches the Acer ePowerManagement in Acer ePowerManagement eManager. Description...

  • Page 26: Special Key

    Hot Key Icon Fn-F4 Fn-F5 Fn-F6 Fn-F7 Fn-F8 Fn-w Fn-y Fn-x Fn-z Special Key You can locate the Euro symbol and US dollar sign at the upper-center and/or bottom-right of your keyboard. To type: Function Sleep Puts the computer in Sleep mode. Display toggle Switches display output between the display screen, external monitor (if connected) and both.
  • Page 27 The Euro symbol Open a text editor or word processor. Either directly press the <Euro> symbol at the bottom-right of the keyboard, or hold <Alt Gr> and then press the<5> symbol at the upper-center of the keyboard. The US dollar sign Open a text editor or word processor.

  • Page 28: Acer Empowering Technology

    To access this utility, either click on the “Acer eNet Management” icon on your netebook, or start the program from the Start menu. You also have the option to set Acer eNet Management to start automatically when you boot up your PC.
  • Page 29 Acer eNet Management can save network settings for a location to a profile, and automatically switch to the appropriate profile when you move from one location to another. Settings stored include network connection settings (IP and DNS settings, wireless AP details, etc.), as well as default printer settings.

  • Page 30: Acer Epower Management

    Acer ePower Management Acer ePower Management features a straightforward user interface. To launch it, select Acer ePower Management from the Empowering Technology interface. AC Mode (Adapter mode) The default setting is “Maximum Performance.” You can adjust CPU speed, LCD brightness and other settings, or click on buttons to turn the following functions on/off: Wireless LAN, Bluetooth, CardBus, FireWire (1394), Wired LAN and Optical Device if supported.

  • Page 31: Battery Status

    For real-time battery life estimates based on current usage, referto the panel on the lower left-hand side of the window. For additional options, click “Settings” to: Set alarms. Re-load factory defaults. Select what actions will be taken when the cover is closed or the power button is pressed. View information about Acer ePower Management. Chapter 1...

  • Page 32: Acer Epresentation Management

    Acer ePresentation Management Acer ePresentation Management lets you project your computer’s display to an external device or project using the hot key: Fn + F5. If auto-detection hardware is implemented in the system, your system display will be automatically switched out when an external display is connected to the system.

  • Page 33: Acer Edatasecurity Management (For Selected Models)

    Acer eDataSecurity Management Acer eDataSecurity Management is handy file encryption utility that protexts your files from being accessed by unauthorized persons. It is conveniently integrated with Windows explorer as a shell extension for quick and easy data encryption/decryption and also supports on-the-fly file encryption for MSN Messager and Microsoft Outlook.
  • Page 34 Chapter 1...

  • Page 35: Acer Elock Management

    Interfaces - includes serial ports, parallel port, infrared (IR), and Bletooth. To activate Acer eLock Management, a password must be set first. Once set, you can apply locks to any of the devices. Lock(s) will immediately be set without any reboot necessary, and will remain locked after rebooting, until unlocked.

  • Page 36: Acer Erecovery Management

    Acer eRecovery Management Acer eRecovery Management is a powerful utility that does away with the need for recovery disks provided by the manufacturer. The Acer eRecovery Management utility occupies space in a hidden partition on your system’s HDD. User-created backups are stored on D:\ drive. Acer eRecovery Management provides you with: Password protection.

  • Page 37: Acer Esettings Management

    Acer eSettings Management Acer eSettings Management allows you to inspect hardware specifications and to monitor the system health status. Furthermore, Acer eSettings Management enables you to optimize your Windows operating system, so your computer runs faster, smoother and better. Acer eSettings Management also: Provides a simple graphical user interface for navigating.

  • Page 38: Acer Orbicam

    Acer OrbiCam The Acer OrbiCam is a 1.3 megapixel CMOS camera appropriately mounted on the top of the LCD panel. The camera’s 225-degree ergonomic rotation allows you to capture high-resolution photos or videos up front or at the back of the LCD panel. The Acer OrbiCam fully supports the Acer Video Conference technology so that you can transmit the best video quality over an instant Messenger service.

  • Page 39: Rotating The Acer Orbicam

    Launching the Acer OrbiCam To launch the Acer OrbiCam, double click on the Acer OrbiCam icon on the screen. Click Start > All programs > Acer > Acer OrbiCam. The Acer OrbiCam capture windows window appears. Changing the Acer OrbiCam settings...
  • Page 40 Click Options to display the Window, Preview, and Folder tabs. Use the options to change the capture window Options size, preview settings, and the folder for captured photos or videos. Camera Settings Basic settings: Click the Camera Settings icon on the bottom right corner of the capture display, then select Camera Settings from the pop-up menu.

  • Page 41: Capturing Photos Or Videos

    Capturing photos or videos To capture a photo or a video clip, rotate the Acer OrbiCam to get the desired angle, then click the Take a Picture or Record a Video button. The Windows Picture and Fax Viewer or the Windows Media Player automatically launches to display or play a preview of the photo/video clip.

  • Page 42: Using The System Utilities

    Settings Apply Acer GridVista is a handy utility that offers four pre-defined display settings so you can view multiple windows on the same screen. To access this function, please go to Start>All Programs and click on Acer GridVista. Start All Programs...

  • Page 43: Launch Manager

    NOTE: Please ensure that the resolution setting of the second monitor is set to the manufacturer's recommended value. Note: Note: Launch Manager Launch Manager allows you to set the four easy-launch buttons located above the keyboard. You can access "Easy-launch buttons" on page 24 the Launch Manager by clicking on Start >...

  • Page 44: Hardware Specifications And Configurations

    667 MHz FSB) (for TravelMate 3260/3270) ® Intel Core Duo processor T2300/T2400/T2500/T2600 (2MB L2 cache, 1.66/1.83/2/2.16 GHz, 667 MHz FSB) (for TravelMate 3260/3270) ® Intel Celeron M processor 410/420/430 (1 MB L2 cache, 1.46/1.60/1.73 GHz, 533 MHz FSB) or higher (for TravelMate 2480) ®...
  • Page 45 Supports DIMM voltage Supports DIMM package Memory module combinations Chapter 1 Specification ® 4MB for Intel Core 2 Duo processor T7200/T7400/T7600 (TravelMate 3260/ 3270) ® 2MB for Intel Core 2 Duo processor T5500/T5600 and Intel processor T2300/T2400/T2500/T2600 (TravelMate 3260/3270) ®...
  • Page 46 Memory Combinations Slot 1 256MB 256MB 256MB 256MB 512MB 512MB 512MB 512MB 1024MB 1024MB 1024MB 1024MB 1024MB 2048MB 2048MB 2048MB 2048MB 2048MB NOTE: Above table lists some system memory configurations. You may combine DIMMs with various capacities to form other combinations. On above table, the configuration of slot 1 and slot 2 could be reversed.
  • Page 47 Bluetooth Interface Item Chipset Data throughput Protocol Interface Connector type Wireless Module 802.11a/b/g (optional device) Item Chipset Data throughput Protocol Interface Hard Disk Drive Interface Item Vendor & HGST Model Name HTS421240H9A Capacity (MB) 40000 Bytes per sector Data heads Drive Format Disks Spindle speed...
  • Page 48 Combo Drive Interface Item Vendor & model name Performance Specification Transfer rate (KB/sec) Buffer Memory Interface Applicable disc format Loading mechanism Power Requirement Input Voltage DVD-Super Multi Interface Item Vendor & model name Performance Specification Transfer rate (KB/sec) Buffer Memory Interface Specification HLDS GCC-4244N...
  • Page 49 HD audio Interface; S/PDIF output for PCM or AC-3 content 1Hz resolution VSR (Variable Sampling Rate) Yes/2 (1.5W speakers) ® Intel 945GM (for TravelMate 3260/3270 UMA models) and Intel 940GML (TravelMate 2480) Nvidia G7300 (G72M-V) (for TravelMate 3260/3270 discrete models) Specification Specification ®...
  • Page 50 FCBGA 1466-pin for Intel 945GM and Intel BGA 533 pin for Nvidia G7300 internal PCIE Specification ® Intel 945GM (for TravelMate 3260/3270 UMA models) and Intel 940GML (TravelMate 2480) Nvidia G7300 (G72M-V) (for TravelMate 3260/3270 discrete models) up to 128MB DDR2 Specification Built-in ICH7M USB 1.1 and USB 2.0 Host controller...
  • Page 51 System Board Major Chips Item Bluetooth Wireless 802.11 b+g/Wireless 802.11 a+b+g PCMCIA/1394/ 5 in 1 Card Reader Audio Codec Keyboard Item Keyboard controller Total number of keypads Windows logo key Internal & external keyboard work simultaneously Battery Item Vendor & model name Battery Type Pack capacity Number of battery cell...
  • Page 52 LCD 14.1” inch Item Response Time (Optical Rise Time/Fall Time)msec Nominal Input Voltage VDD Typical Power Consumption (watt) Weight Physical Size(mm) Electrical Interface Support Color Viewing Angle (degree) Horizontal: Right/Left Vertial: Upper/Lower ° Temperature Range( C) Operating Storage (shipping) LCD Inverter Item Vendor &...
  • Page 53 System Power Management ACPI mode Suspend to RAM (S3) Save to Disk (S4) Chapter 1 Power Management CPU set power down VGA Suspend PCMCIA Suspend Audio Power Down Hard Disk Power Down CD-ROM Power Down Super I/O Low Power mode Also called Hibernation Mode.
  • Page 54 Chapter 1...

  • Page 55: System Utilities

    TSSTcorpCD/DVDW TS-L632D System BIOS Version: V0.310 nVIDIA 5.72.22.46.43 VGA BIOS Version: xxxxxxxxxxxxxxxxxxxxxx Serial Number Asset Tag Number Produce Name Aspire 3680/5570/5580; TravelMate 2480/3260/3270 Manufacturer Name: Acer Inc. xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx UUID: Help Select Item ↑ ↓ ← → Exit Select Menu Chapter 2 during POST (when “Press <F2>...

  • Page 56: Navigating The Bios Utility

    Navigating the BIOS Utility There are six menu options: Info., Main, System Devices, Security, Boot, and Exit. Follow these instructions: To choose a menu, use the cursor left/right keys (zx). To choose a parameter, use the cursor up/down keys ( wy). To change the value of a parameter, press por q.

  • Page 57: Information

    System BIOS Version: V0.310 nVIDIA 5.72.22.46.43 VGA BIOS Version: xxxxxxxxxxxxxxxxxxxxxx Serial Number Asset Tag Number Produce Name Aspire 3680/5570/5580; TravelMate 2480/3260/3270 Manufacturer Name: Acer Inc. xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx UUID: Help ↑ ↓ Select Item ← → Exit Select Menu NOTE: The system information is subject to different models.

  • Page 58: Main

    Main The Main screen displays a summary of your computer hardware information, and also includes basic setup parameters. It allows the user to specify standard IBM PC AT system parameters. Information Main System Time: [15:27:09] System Date: [08/09/2006] System Memory: 634 KB Extended Memory: 1022 MB...
  • Page 59 The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter System Time Sets the system time. The hours are displayed with 24-hour format. System Date Sets the system date. System Memory This field reports the memory size of the system.

  • Page 60: Advanced

    Advanced The Advanced screen displays advanced settings in BIOS. Information Main Serial port : Parallel port : Mode : IrDA Port : Help Select Item ↑ ↓ ← → Exit Select Menu The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings.

  • Page 61: Security

    Security The Security screen contains parameters that help safeguard and protect your computer from unauthorized use. Information Main Supervisor Password Is : User Password Is : HDD 0 Password Set Supervisor Password Set User Password Set HDD 0 Password Password on Boot Help Select Item ↑...

  • Page 62: Setting A Password

    The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter User Password is Supervisor Password is Set User Password Set Supervisor Password Primary HardDisk Security Password on Boot NOTE: When you are prompted to enter a password, you have three tries before the system halts. Don’t forget your password.

  • Page 63: Changing A Password

    Use the w and y keys to highlight the Set Supervisor Password parameter and press the e key. The Set Password box appears: Type the current password in the Enter Current Password field and press e. Press e twice without typing anything in the Enter New Password and Confirm New Password fields. The computer then sets the Supervisor Password parameter to “Clear”.
  • Page 64 If the new password and confirm new password strings do not match, the screen will display the following message. Chapter 2...

  • Page 65: Boot

    Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the distette drive in module bay, the onboard hard disk drive and the CD-ROM in module bay. Information Main Boot priority order: 1: IDE 0: HTS541010G9AT00 - (PM)

  • Page 66: Exit

    Exit The Exit screen contains parameters that help safeguard and protect your computer from unauthorized use. Information Main Exit Saving Changes Exit Disarding Changes Load Setup Defaults Discard Changes Save Changes Help ↑ ↓ Select Item ← → Exit Select Menu The table below describes the parameters in this screen.

  • Page 67: Bios Flash Utility

    BIOS Flash Utility The BIOS flash memory update is required for the following conditions: New versions of system programs New features or options Restore a BIOS when it becomes corrupted. Use the Phlash utility to update the system BIOS flash ROM. NOTE: If you do not have a crisis recovery diskette at hand, then you should create a Crisis Recovery Diskette before you use the Phlash utility.

  • Page 68: Remove Hdd/Bios Utility

    Remove HDD/BIOS Utility This section provide you with removing HDD/BIOS method: Remove HDD Password: If you key in wrong HDD password for three time, “HDD password error code” would display on the screen. See the image below. If you need to solve HDD password locked problem, you can run HDD_PW.EXE Key in “hdd_pw 15494 0”...
  • Page 69 Remove BIOS Password: If you key in wrong Supervisor Password for three time, “System Disabled” would display on the screen. See the image below. Chapter 2...
  • Page 70 If you need to solve BIOS password locked problem, you can run BIOS_PW.EXE Key in “bios_pw 14452 0” Choose one upper-case string Reboot the system and key in “qjjg9vy” or “07yqmjd” to BIOS user password. Chapter 2...
  • Page 71 Chapter 2...
  • Page 72 Chapter 2...

  • Page 73: Machine Disassembly And Replacement

    Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the notebook computer for maintenance and troubleshooting. To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge Small Philips screw driver Philips screwdriver Plastic flat head screw driver Tweezers...

  • Page 74: General Information

    General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system. Remove the battery pack.

  • Page 75: Disassembly Procedure Flowchart

    Disassembly Procedure Flowchart The flowchart on the succeeding page gives you a graphic representation on the entire disassembly sequence and instructs you on the components that need to be removed during servicing. For example, if you want to remove the system board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
  • Page 76 LCD Panel Screw List Item Description SCW HEX NYL I#R-40/O#4-40 L5.5 SCREW MACH WAFER M2*L4 NI CPU SCREW M2.5*4.3L (2.3 KG) CPU SCREW M2.5*4.3L (1.55 KG) SCREW M2.5-6 SCRW M2.5*L8(NON NYLOK) SCREW M2*3 NYLON 1JMCPC-420325 SCREW SCREW M2.5*4L(NYLOCK)BLACK ZN SCREW M2.5X6 SRW M2.5*8L B/ZN NYLOK 700 SCRW M2.5*L3(NON NYLOK) SCREW M3x4(86.9A524.4R0)

  • Page 77: Removing The Battery Pack

    Removing the Battery Pack Unlock the battery lock. Slide the battery latch then remove the battery. Chapter 3...

  • Page 78: Removing The Hdd Module/The Memory/The Wireless Lan Card/The Modem Board/The Odd Module And The Lcd Module

    Removing the HDD Module/the Memory/the Wireless LAN Card/the Modem Board/the ODD Module and the LCD Module Removing the HDD Module Remove the two screws fastening the HDD cover. Detach the HDD cover from the main unit. Remove the screw holding the HDD module as shown. Then disconnect the entire HDD module from the main unit.

  • Page 79: Removing The Odd Module

    Remove the wireless LAN card from the socket. Remove the two screws holidng the modem board to the main board as shown. Detach the modem board from the main board then disconnect the modem board cable. Removing the ODD Module Remove one screw holding the ODD module on the bottom side.
  • Page 80 Remove the two screw fastening the keyboard to the upper case. Disconnect the microphone cable from the launch board. Take out the wireless LAN antenna set from the guide-line as shown. Disconnect the LCD cable from the main board. Disconnect the lid switch cable from the main board. If you laptop has CCD module (web camera module), please disconnect CCD cable as shown.

  • Page 81: Disassembling The Main Uint

    Disassembling the Main Uint Separating the Main Unit into Upper Case and Lower Case Assembly Remove three screws fastening the upper case assembly and the lower case assembly. Remove 18 screws (M2.5L6x17; M2.0L1.7x1) holding the upper assembly and the lower case assembly on the bottom.
  • Page 82 Disconnect the microphone cable from the main board. Remove the two screws fastening the main board to the lower case. Carefully detach the main board from the lower case as shown. Remove the two screws holding the daughter board to the main board. Then detach the daughter board from the main board.

  • Page 83: Disassembling The Lcd Module (With Video Camera)

    Disassembling the LCD Module (with video camera) Remove the six screw caps as shown. Remove the six screws holding the LCD bezel. Then detach the LCD bezel from the LCD module. Take out the inverter from the LCD cover and disconnect the LVDS cable as shwon. Disconnect the inverter cable then take out the inverter.
  • Page 84 13. Then remove the left LCD bracket from the LCD. 14. Tear off the mylar fastening the LCD cable. 15. Disconnect the LCD cable from the LCD. Chapter 3...

  • Page 85: Disassembling The External Modules

    Disassembling the External Modules Disassembling the HDD Module Remove two screws holding the HDD bracket. Then remove two screws fastening the HDD braket on the other side. Remove the HDD bracket. Disassembling the ODD Module Remove the two screws holding the ODD bracket. Then remove the ODD bracket.
  • Page 86 Chapter 3...

  • Page 87: Troubleshooting

    Troubleshooting Use the following procedure as a guide for computer problems. NOTE: The diagnostic tests are intended to test only Acer products. Non-Acer products, prototype cards, or modified options can give false errors and invalid system responses. Obtain the failing symptoms in as much detail as possible.

  • Page 88: System Check Procedures

    System Check Procedures External Diskette Drive Check Do the following to isolate the problem to a controller, driver, or diskette. A write-enabled, diagnostic diskette is required. NOTE: Make sure that the diskette does not have more than one label attached to it. Multiple labels can cause damage to the drive or cause the drive to fail.

  • Page 89: Memory Check

    If any of these devices do not work, reconnect the cable connector and repeat the failing operation. Memory check Memory errors might stop system operations, show error messages on the screen, or hang the system. Boot from the diagnostics diskette and start the doagmpstotics program (please refer to main board. Go to the diagnostic memory in the test items.

  • Page 90: Check The Power Adapter

    Check the Power Adapter Unplug the power adapter cable from the computer and measure the output voltage at the plug of the power adapter cable. See the following figure If the voltage is not correct, replace the power adapter. If the voltage is within the range, do the following: Replace the System board.

  • Page 91: Touchpad Check

    Check the Battery Pack To check the battery pack, do the following: From Software: Check out the Power Management in control Panel In Power Meter, confirm that if the parameters shown in the screen for Current Power Source and Total Battery Power Remaining are correct.

  • Page 92: Power-On Self-Test (Post) Error Message

    Power-On Self-Test (POST) Error Message The POST error message index lists the error message and their possible causes. The most likely cause is listed first. NOTE: Perform the FRU replacement or actions in the sequence shown in FRU/Action column, if the FRU replacement does not solve the problem, put the original part back in the computer.

  • Page 93: Index Of Error Messages

    Index of Error Messages Error Code List Error Codes <No error code> <No error code> Error Message List Error Messages Failure Fixed Disk Stuck Key Keyboard error Keyboard Controller Failed Keyboard locked - Unlock key switch Monitor type does not match CMOS - Run Setup Run “Load Default Settings” in BIOS Setup Utility. Shadow RAM Failed at offset: nnnn System RAM Failed at offset: nnnn Extended RAM Failed at offset: nnnn...
  • Page 94 Error Message List Error Messages Real time clock error Previous boot incomplete - Default configuration used Memory size found by POST differed from CMOS Diskette drive A error Incorrect Drive A type - run SETUP System cache error - Cache disabled CPU ID: DMA Test Failed Software NMI Failed...
  • Page 95 Error Message List No beep Error Messages No beep, power-on indicator turns off and LCD is blank. No beep, power-on indicator turns on and LCD is blank. No beep, power-on indicator turns on and LCD is blank. But you can see POST on an external CRT.

  • Page 96: Phoenix Bios Beep Codes

    Phoenix BIOS Beep Codes Code Beeps Verify Real Mode Disable Non-Maskable Interrupt (NMI) Get CPU type Initialize system hardware Initialize chipset with initial POST values Set IN POST flag Initialize CPU registers Enable CPU cache Initialize caches to initial POST values Initialize I/O component Initialize the local bus IDE Initialize Power Management...
  • Page 97 Code Chapter 4 Beeps 2-1-2-3 Check ROM copyright notice Check video configuration against CMOS Initialize PCI bus and devices Initialize all video adapters in system QuietBoot start (optional) Shadow video BIOS ROM Display BIOS copyright notice Display CPU type and speed Initialize EISA board Test keyboard Set key click if enabled...
  • Page 98 Code Beeps Initialize floppy controller Determine number of ATA drives (optional) Initialize hard-disk controllers Initialize local-bus hard-disk controllers Jump to UserPatch2 Build MPTABLE for multi-processor boards Install CD ROM for boot Clear huge ES segment register Fixup Multi Processor table Search for option ROMs.
  • Page 99 Code Code Chapter 4 Beeps Unknown interrupt Beeps Initialize the chipset Initialize the bridge Initialize the CPU Initialize the system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM Go to BIOS Set Huge Segment Initialize Multi Processor Initialize OEM special code Initialize PIC and DMA Initialize Memory type...

  • Page 100: Index Of Symptom-To-Fru Error Message

    Index of Symptom-to-FRU Error Message LCD-Related Symptoms Symptom / Error LCD backlight doesn't work LCD is too dark LCD brightness cannot be adjusted LCD contrast cannot be adjusted Unreadable LCD screen Missing pels in characters Abnormal screen Wrong color displayed LCD has extra horizontal or vertical lines displayed.
  • Page 101 Power-Related Symptoms Symptom / Error Battery can’t be charged PCMCIA-Related Symptoms Symptom / Error System cannot detect the PC Card (PCMCIA) PCMCIA slot pin is damaged. Memory-Related Symptoms Symptom / Error Memory count (size) appears different from actual size. Speaker-Related Symptoms Symptom / Error In Windows, multimedia programs, no sound comes from the computer.
  • Page 102 Power Management-Related Symptoms Symptom / Error Battery fuel gauge in Windows doesn’t go higher than 90%. System hangs intermittently. Peripheral-Related Symptoms Symptom / Error System configuration does not match the installed devices. External display does not work correctly. USB does not work correctly Print problems.

  • Page 103: Intermittent Problems

    Intermittent Problems Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement should be considered only when a recurring problem exists. When analyzing an intermittent problem, do the following: Run the advanced diagnostic test for the system board in loop mode at least 10 times.

  • Page 104: Undetermined Problems

    System Check” on page 81.): Power-off the computer. Visually check them for damage. If any problems are found, replace the FRU. Remove or disconnect all of the following devices: Non-Acer devices Printer, mouse, and other external devices Battery pack Hard disk drive...

  • Page 105: Jumper And Connector Locations

    Jumper and Connector Locations Top View LVDS CONN SW1-4 QUICK KEY SWITCH LCOCK GENERATOR CN5-6 5-IN-1 MMC/SD/MS/MS Pro/xD CARD READER CONN PCI8412/6412 SW5-10 T/P SWITCH Chapter 5 BIOS KB CONTROLLER (87541V) U5-6 G72M-VRAM MEDIA CONN K/B CONN TP/B CONN Chapter 5...

  • Page 106: Bottom View

    Bottom View NOTE: This is engineering sample. The image above may not be exactly the same as the real main board you get. Jumper settings G1: CMOS clear Jumper DOCKING RJ45 CONN CN10 CRT CONN LAN TRANSFORMER SUPER I/O NS87383 CN15 S-VIDEO CONN CN17...
  • Page 107 Jumper Settings/Clear BIOS Password Procedures Please see the bottom side of the main board. Find G1 jumper and short the jumper to clear BIOS password. Chapter 5 G1: CMOS clear Jumper...
  • Page 108 Chapter 5...

  • Page 109: Fru (Field Replaceable Unit) List

    Guide. For ACER AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code from those given in the FRU list of this printed Service Guide. You MUST use the local FRU list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 110: Travelmate 2480/3260/3270 Exploded Diagram

    TravelMate 2480/3260/3270 Exploded Diagram Chapter 6...
  • Page 111 BATTERY PACK LI+ 9CELL 2.4MAH SANYO WIRELESS LAN BOARD 802.11BG FOXCONN ATHEROS EU WIRELESS LAN BOARD 802.11BG FOXCONN BCM4318 MODEM BOARD FOXCONN T60M845.01 TOUCHPAD BOARD SYNAPTICS TM51-389 LED BOARD Acer Part No. AP.06501.007 AP.06503.011 AP.06506.003 BT.00603.014 BT.00604.006 BT.00605.002 BT.00603.012 BT.00604.005 BT.00605.003 BT.00903.004 54.A74V1.001...
  • Page 112 POWER CORD 10A 250V 3PIN BK SOUTH AFRICA POWER CORD 10A 250V SWISS POWER CORD 2.5A 250V AUSTRALIA POWER CORD 2.5A 250V SOUTH AFRICA BK POWER CODE 7A 125V JAPAN 2PIN Acer Part No. 54.TB2V1.001 54.A74V1.003 50.TCZV1.006 50.TCZV1.001 50.TCZV1.002 50.TCZV1.003 27.01518.781 27.01518.591...
  • Page 113 Part Name and Description LOWERCASE W/SPEAKER SPEAKER MIDDLE COVER W/MICROPHONE (TRAVELMATE) MIDDLE COVER W/MICROPHONE (ASPIRE) FRONT COVER DIMM COVER HDD COVER TOUCHPAD BRACKET UPPER CASE (TRAVELMATE) UPPER CASE (ASPIRE) Acer Part No. 60.TCZV1.001 23.TCZV1.003 60.TCZV1.003 60.ADKV1.003 42.TCZV1.003 42.TCZV1.002 42.TCZV1.001 33.TCZV1.001 60.TCZV1.002 60.ADKV1.002...
  • Page 114 CPU DOTHAN730 1.6GMHZ INTEL CPU DOTHAN740 1.73GMHZ INTEL CPU DOTHAN725A 1.6GMHZ INTEL CPU CEL-M370 1.5G MHZ INTEL CPU CEL-M380 1.6GMHZ INTEL CPU CEL-M390 1.7GMHZ INTEL CPU CEL-M360 1.4GMHZ INTEL DVD-RW MODULE 8X Acer Part No. 6M.TB2V1.001 33.TB2V1.002 33.TB2V1.003 42.TB2V1.003 KO.0240A.005 KO.02409.015 KC.NV001.370 KC.N0001.730...
  • Page 115 ASSY HDD BRACKET AG1 HDD 40GB SEAGATE ST9402112A HDD 40GB TOSHIBA MK4025GAS HDD 40GB HGST HTS421240H9AT00 HDD 40GB WD WD400UE-22HCT0 HDD 40GB SAMSUNG M40MP0402H HDD MODULE 60G ASSY HDD BRACKET AG1 Acer Part No. 33.TB2V1.002 33.TB2V1.003 42.TB2V1.003 42.TB2V1.004 (TM) KU.0080D.017 KU.00804.012 KU.00805.019 KU.00807.022 KU.0080D.019...
  • Page 116 HDD 120G SEAGATE ST9120824A HDD 120G SEAGATE ST9120821A CPU HEATSINK W/SCREW W/O FAN KEYBOARD 89KEY DARFON NSK- H3M00 SWISS KEYBOARD 88KEY DARFON NSK- H30M02 TAIWAN(CHINESE) KEYBOARD 88KEY DARFON NSK- H3M03 THAI Acer Part No. KH.06001.004 KH.06001.003 KH.06004.004 KH.06004.007 KH.06007.010 KH.06008.002 33.TB2V1.004 KH.08004.003 KH.08007.011...
  • Page 117 KEYBOARD 88KEY DARFON NSK- AEK02 TAIWAN(CHINESE) KEYBOARD 88KEY DARFON NSK- AEK03 THAI KEYBOARD 89KEY DARFON NSK- AEK06 PORTUGA KEYBOARD 88KEY DARFON NSK- AEK0A ARABIC KEYBOARD 89KEY DARFON NSK- AEK0C CZECH Acer Part No. KB.A2707.012 KB.A2707.013 KB.A2707.016 KB.A2707.019 KB.A2707.009 KB.A2707.010 KB.A2707.008 KB.A2707.024 KB.A2707.023 KB.A2707.021...
  • Page 118 LCD MODULE CCD 14.1" WXGA GLARE W/ANTENNA LCD MODULE 14.1" WXGA NONE GLARE W/ANTENNA INVERTER BOARD DARFON VK.21189.402 INVERTER BOARD 15.4" FOXCONN T62I240.00 INVERTER BOARD 15.4" YEC YNV- Acer Part No. KB.T5007.019 KB.T5007.009 KB.T5007.010 KB.T5007.008 KB.T5007.024 KB.T5007.023 KB.T5007.021 KB.T5007.018 KB.T5007.017 KB.T5007.025...
  • Page 119 NONE GLARE 420G LCD 14" WXGA CMO N141I1-L02 NONE GLARE LCD MODULE 14.1" WXGA GLARE W/ANTENNA INVERTER BOARD 15.4" FOXCONN T62I240.00 WIRELESS ANTENNA LEFT/RIGHT LCD/INVERTER CABLE 14.1" WXGA Acer Part No. 25.TCZV1.001 50.TCZV1.004 33.TB1V1.003 33.TB1V1.004 60.AA6V1.004(Aspire) 60.TB2V1.004(TravelMate) 60.TCZV1.005(TravelMate) 60.TB2V1.005 6K.TB2V1.001 LK.14105.013...
  • Page 120 M470T3354CZ3-CD5 SDIMM 256M HYNIX HYMP532S64P6-C4 SDIMM 512M INFINEON MHYS64T64020HDL-3.7-A SDIMM 512M NANYA NT512T64UH8A1FN-37B SDIMM 512M MICRON MT8HTF6464HDY-53EB3 SDIMM 512M SAMSUNG M470T6554CZ3-CD5 SDIMM 512M HYNIX HYMP564S64P6-C4 Acer Part No. 33.TB1V1.003 33.TB1V1.004 60.TB2V1.004 60.TB2V1.005 6K.TB2V1.001 LK.1410D.005 LK.14109.005 LK.14105.014 LK.14106.005 LK.14108.003 MB.TCZV1.001 23.TCZV1.004 22.TB2V1.001...
  • Page 121 SCREW M2.5*4L(NYLOCK)BLACK SRW M2.5*8L B/ZN NYLOK 700 SCREW M3x4(86.9A524.4R0) SCREW WAFER NYLOK NI 2ML3 SCRW M2*4 WAFER NI SCRW M2.5*3 WAFER NI SCREW NYLOK M2.5-5 SCREW M2.5*L3 MICROPHONE Acer Part No. 47.A46V1.002 47.TB1V1.001 40.ADKV1.001 40.TCZV1.001 34.00015.081 86.00059.220 86.00C31.220 86.00C34.620 86.5A353.120 86.9A323.6R0...
  • Page 122 Chapter 6...
  • Page 123 Chapter 6...

  • Page 124: Appendix A Model Definition And Configuration

    WXMi Europe TM2482 EMEA Eastern WXMi Europe TM2482 EMEA France WXMi TM2482 EMEA Eastern WXMi Europe Appendix A Acer Part no Description S2.TEC05.001 TM2482WXCi CM420 XPHTC1 UMA 2*512/60/BT/6L/ 5R_bg_AN LX.TEC05.017 TM2482WXMi CM420 XPHSA1 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC05.005 TM2482WXMi CM420 XPHDK1 UMA...
  • Page 125 WXMi TM2482 EMEA WXMi TM2482 EMEA South WXCi Africa TM2482 EMEA Denmark WXCi TM2482 EMEA France WXCi Acer Part no Description LX.TEC05.004 TM2482WXMi CM420 XPHDE7 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC05.018 TM2482WXMi CM420 XPHSLO2 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC05.007 TM2482WXMi CM420 XPHESA UMA...
  • Page 126 TM2482 EMEA Portugal WXCi TM2482 EMEA Israel WXCi TM2482 EMEA Germany WXCi TM2482 EMEA Italy WXCi Appendix A Acer Part no Description LX.TEC06.002 TM2482WXCi CM420 XPPBE1 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC06.012 TM2482WXCi CM420 XPPNL1 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC06.013 TM2482WXCi CM420 XPPNO1 UMA...
  • Page 127 Thailand WXCi TM2482N India WXCi TM2482N Indonesia WXCi TM2482N Philippine WXCi TM2482N Malaysia WXCi TM2482N Thailand WXCi Acer Part no Description LX.TEC06.021 TM2482WXCi CM420 XPPTR1 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC06.006 TM2482WXCi CM420 XPPEL3 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC06.001 TM2482WXCi CM420 XPPAR1 UMA...
  • Page 128 Portugue TM2481N Singapor WXCi TM2481N India WXCi TM2481N Indonesia WXCi TM2481N Philippine WXCi TM2481N Malaysia WXCi Appendix A Acer Part no Description LX.TEC0C.006 TM2482NWXCi CM420 LINPUSVN1 UMA 1*256/40/ 6L/5R_bg_AN LX.TEC05.028 TM2482WXCi CM420 XPHEN1 UMA 1*256/40/6L/ 5R_bg_AN LX.TEC05.030 TM2482WXCi CM420 XPHFR1 UMA...
  • Page 129 Indonesia WXCi TM2481N Philippine WXCi TM2481N Malaysia WXCi TM2481N Thailand WXCi TM2481N Singapor WXCi TM2481N Vietnam WXCi Acer Part no Description LX.TEC0C.012 TM2481NWXCi CM410 LINPUSTH2 UMA 1*256/40/ 6L/5R_bg_AN LX.TEC0C.013 TM2481NWXCi CM410 LINPUSVN1 UMA 1*256/40/ 6L/5R_bg_AN LX.TEC05.036 TM2481WXCi CM410 XPHTC1 UMA...
  • Page 130 WXCi TM2481 Thailand WXCi TM2481 Vietnam WXCi TM2481 Philippine WXCi TM2481 Vietnam WXCi TM2481 Thailand WXCi Appendix A Acer Part no Description LX.TEC05.038 TM2481WXCi CM410 XPHAU1 UMA 1*256/60/6L/ 5R_bg_AN LX.TEC05.039 TM2481WXCi CM410 XPHPH1 UMA 1*256/60/6L/ 5R_bg_AN LX.TEC05.040 TM2481WXCi CM410 XPHMA2 UMA...
  • Page 131 Singapor WXCi TM2482N Singapor WXCi TM2482 EMEA Norway WXMi TM2482 EMEA Norway WXMi TM2482N EMEA Middle WXCi East Acer Part no Description LX.TEC05.042 TM2481WXCi CM410 XPHWSG21W UMA 1*256/60/ 6L/5R_bg_AN LX.TEC06.024 TM2481WXCi CM410 XPPTC2 UMA 1*512/60/6L/ 5R_bg_AN LX.TEC0C.029 TM2482NWXCi CM420 LINPUSPL3...
  • Page 132 Zealand TM2482N Singapor WXCi TM2482 Singapor WXCi TM2482 Philippine WXCi TM2482 Philippine WXCi TM2482N Philippine WXCi Appendix A Acer Part no Description LX.TEC0C.037 TM2482NWXCi CM420 LINPUSAR7 UMA 1*256/40/ 6L/5R_bg_AN LX.TEC0C.038 TM2482NWXCi CM420 LINPUSARC UMA 1*256/40/ 6L/5R_bg_AN LX.TEC05.053 TM2482WXCi CM420 XPHAR2 UMA...
  • Page 133 Model Country TM2482 EMEA Norway WXMi TM2482 EMEA Middle WXMi East Acer Part no Description LX.TEC06.029 TM2482WXMi CM420 XPPNO1 UMA 1*512/80/6L/ 5R_bg_AN LX.TEC06.030 TM2482WXMi CM420 XPPAR2 UMA 1*512/80/6L/ 5R_bg_AN Memory HDD(GB) SO512M N80GB5. NSM8X BII5 SO512M N80GB5. NSM8X BII5 Appendix A...

  • Page 134: Travelmate 3260 Series

    TravelMate 3260 Series For discrete models Model Country TM3261A Singapor NWXMi TM3261A India NWXMi TM3261A Indonesia NWXMi TM3261A Philippine NWXMi TM3261A Malaysia NWXMi TM3261A Thailand NWXMi TM3261A Vietnam NWXMi TM3261A Australia/ WXMi Zealand TM3261A Singapor WXMi TM3261A Malaysia WXMi Appendix A...
  • Page 135 WXMi Canada TM3261A ACLA- WXMi Spanish TM3261A ACLA- WXMi Portugue TM3261A GCTWN WXMi TM3262 GCTWN WXMi TM3262 GCTWN WXMi Acer Part no Description LX.TDY05.003 TM3261AWXMi CDT2050 XPHTH2 G72MV128 1*512/120/BT/ 6L/5R_bg_AN LX.TDY05.004 TM3261AWXMi CDT2050 XPHVN1 G72MV128 1*512/120/BT/ 6L/5R_abg_AN LX.TDY05.007 TM3261AWXC CDT2050...
  • Page 136 WXMi TM3260A China China WXMi For UMA models Model Country TM3261A USA/ WXMi Canada TM3261A USA/ WXMi Canada Appendix A Acer Part no Description LX.TDY05.017 TM3260AWXM CST1350 XPHSC7 G72MV128 1*256/80/6L/ 5R_AN LX.TDY05.018 TM3260AWXM CST1350 XPHSC7 G72MV128 1*256/60/6L/ 5R_AN LX.TDY05.019 TM3260AWXCi...
  • Page 137 India WXMi TM3261A Indonesia WXMi TM3262N Indonesia WXMi TM3262N Malaysia WXMi TM3262N Malaysia WXMi TM3262 Malaysia WXCi Acer Part no Description LX.TEA05.003 TM3261AWXMi CDT2050 XPHES1 UMA 2*512/100/6L/ 5R_abg_AN LX.TEA05.012 TM3261AWXMi CDT2050 XPHXC1 UMA 2*512/100/6L/ 5R_abg_AN LX.TEA05.001 TM3261AWXMi CDT2050 XPHAU1 UMA...
  • Page 138 Model Country TM3262 Malaysia WXCi TM3262 Philippine WXMi Appendix A Acer Part no Description LX.TEA06.002 TM3262WXCi CDT2300 XPPMA2 UMA 1*512/60/BT/6L/ 5R_abg_AN LX.TEA05.014 TM3262WXMi CDT2300 XPHPH1 UMA 1*512/80/6L/ 5R_abg_AN Memory HDD(GB) SO512M N60GB5. NCB24X BII5 SO512M N80GB5. NSM8X BII5...

  • Page 139: Travelmate 3270 Series

    TM3273 China Hong WXMi Kong TM3276 EMEA WXCi TM3274 China China WXMi TM3273 Australia/ WXMi Zealand TM3273 Philippine WXMi Acer Part no Description LX.TF705.004 TM3273WXMi C2DT550 XPHSC7 G72MV128C 1*512/60/BT/6L/ 5R_abg_1.3C_ LX.TF705.002 TM3273WXMi C2DT550 XPHHK9 G72MV128C 1*512/60/BT/6L/ 5R_abg_1.3C_ LX.TF705.003 TM3273WXMi C2DT550...
  • Page 140 TM3273 Singapor WXMi TM3273 India WXMi TM3273 Indonesia WXMi TM3273 USA/ WXMi Canada TM3273 USA/ WXMi Canada Appendix A Acer Part no Description LX.TF705.011 TM3273WXMi C2DT550 XPHMA2 G72MV128C 2*512/120/BT/ 5R_abg_1.3C_ LX.TF705.013 TM3273WXMi C2DT550 XPHTH2 G72MV128C 2*512/120/BT/ 5R_bg_1.3C_A LX.TF705.014 TM3273WXMi C2DT550...
  • Page 141 Country TM3273N India WXMi TM3273N Indonesia WXMi TM3273N Philippine WXMi TM3273N Malaysia WXMi TM3273N Thailand WXMi TM3273N Vietnam WXMi Acer Part no Description LX.TF705.007 TM3273WXMi C2DT550 XPHES1 G72MV128C 2*512/120/BT/ 5R_abg_1.3C_ LX.TF705.016 TM3273WXMi C2DT550 XPHXC1 G72MV128C 2*512/120/BT/ 5R_abg_1.3C_ LX.TF70C.001 TM3273NWXMi C2DT550...
  • Page 142 Eastern WXCi Europe TM3273 EMEA Germany WXCi TM3273 EMEA Greece WXCi TM3273 EMEA Middle WXCi East Appendix A Acer Part no Description LX.TFA05.001 TM3273WXMi C2DT550 XPHAU1 UMA 1*512/100/6L/ 5R_abg_AN LX.TFA05.005 TM3273WXMi C2DT550 XPHPH1 UMA 1*512/100/6L/ 5R_abg_AN LX.TFA05.004 TM3273WXMi C2DT550 XPHMA2 UMA...
  • Page 143 EMEA South WXCi Africa TM3273 EMEA Portugal WXCi TM3273 EMEA Sweden/ WXCi Finland TM3273 EMEA Switzerla WXCi Acer Part no Description LX.TFA06.009 TM3273WXCi C2DT550 XPPESA UMA 1*512/60/6L/ 5R_abg_AN LX.TFA06.005 TM3273WXCi C2DT550 XPPIS1 UMA 1*512/60/6L/ 5R_bg_AN LX.TFA06.006 TM3273WXCi C2DT550 XPPIT1 UMA...
  • Page 144 TM3273 EMEA WXCi TM3273 EMEA Turkey WXCi TM3273 Indonesia WXMi TM3273 Philippine WXMi TM3273 Philippine WXMi Appendix A Acer Part no Description LX.TFA06.001 TM3273WXCi C2DT550 XPPUK1 UMA 1*512/60/6L/ 5R_abg_AN LX.TFA06.007 TM3273WXCi C2DT550 XPPTR1 UMA 1*512/60/6L/ 5R_abg_AN LX.TFA05.010 TM3273WXMi C2DT550 XPHIN1 UMA...

  • Page 145: Appendix B Test Compatible Components

    Appendix B Test Compatible Components This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system ® ® functions are tested under Windows XP Home, Windows XP Pro environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.

  • Page 146: Microsoft® Windows® Xp Pro Environment Test

    ® ® Microsoft Windows Item CRT Port Test CRT Monitor LCD Monitor Projector Audio Jacks Port Test Speaker Head Phone Parallel Port Test Printer USB Port Test USB 1.1-MouseLogitech(Optical) USB 1.1-keyboard USB 1.1-Speaker USB 1.1-FDD USB 1.1-Camera / CCD USB 1.1-HUB USB 1.1-Card Reader USB 2.0-HDD USB 2.0-DVD/CD-RW...
  • Page 147 Sandisk 128MB ATA PCMCIA Flash Card POW four-in-one memory media PCMCIA A4Tech PS/2 mouse - 2 ButtonMicrosoft FCC ID:C3KKZB1 Huaerte Wheel V60 PS/2 wheel mouse ACER PS2 Keyboard Logitech PS2 Keyboard Logitech Serial Three Button Mouse Sandisk 256MB SD Card...

  • Page 148: Microsoft® Windows® Xp Home Environment Test

    ® ® Microsoft Windows Item CRT Port Test CRT Monitor LCD Monitor Projector Audio Jacks Port Test Speaker Head Phone Parallel Port Test Printer USB Port Test USB 1.1-MouseLogitech(Optical) USB 1.1-keyboard USB 1.1-Speaker USB 1.1-FDD USB 1.1-Camera / CCD USB 1.1-HUB USB 1.1-Card Reader USB 2.0-HDD USB 2.0-DVD/CD-RW...
  • Page 149 Sandisk 128MB ATA PCMCIA Flash Card POW four-in-one memory media PCMCIA 雙飛燕 PS/2 mouse - 2 ButtonMicrosoft FCC ID:C3KKZB1 Huaerte Wheel V60 PS/2 wheel mouse ACER PS2 Keyboard Logitech PS2 Keyboard Logitech Serial Three Button Mouse Sandisk 256MB SD Card...
  • Page 150 Appendix B...

  • Page 151: Appendix C Online Support Information

    This section describes online technical support services available to help you repair your Acer Systems. If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch office. Acer Branch Offices and Regional Business Units may access our website. However some information sources will require a user i.d.
  • Page 152 Appendix C...
  • Page 153 AFLASH Utility 59 Audio 41 Battery Pack 69 BIOS 36 package 36 password control 36 ROM size 36 ROM type 36 vendor 36 Version 36 BIOS Supports protocol 36 BIOS Utility 47 Navigating 48 Onboard Device Configuration 54 Security 51, 53 System Security 58 Board Layout Top View 5...
  • Page 154 Second Level Cache 36 System Block Diagram 4 System Check Procedures 80 System Memory 37 System Utilities 47 Test Compatible Components 137 Top 97 Touchpad Check 83 Troubleshooting 79 Undetermined Problems 96 USB 42 utility BIOS 47 Video 41 Windows XP Pro Environment Test 138 Windows XP Home Environment Test 140 Index...
  • Page 155 Index...

This manual is also suitable for:

Travelmate 3270Travelmate 3260 seriesTravelmate 3270 seriesTravelmate 2480 series

Table of Contents
