- Page 1 W950BU / W955BU...
- Page 3 Preface Notebook Computer W950BU / W955BU Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W950BU / W955BU series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
- Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
- Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
- Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
- Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.
-
Page 11: Table Of Contents
Preface Contents Introduction ..........1-1 Part List Illustration Location ............A-2 Top - W950BU ................A-3 Overview ..................1-1 Top - W955BU ................A-4 Specifications ..................1-2 Bottom (W950BU) ................ A-5 External Locator - Top View with LCD Panel Open ......1-4 Bottom (W955BU) ................ A-6 External Locator - Front &... - Page 12 Preface PS8625 ..................B-18 Card Reader & RTL8411B ............B-19 HDMI, RJ45, Fan ................. B-20 M.2 (WLAN, 3G, SSD) ............... B-21 Audio Codec ................. B-22 USB 3.0, G Sensor, TPM ............. B-23 KBC ITE IT8587 ................B-24 CCD, MIC, LID, I/O Connector ..........B-25 HDD, ODD, LED .................
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W950BU / W955BU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. -
Page 14: Specifications
Introduction Specifications Processor Options Audio Intel® Core™ i7 Processor High Definition Audio Compliant Interface i7-7500U (2.70GHz) 2 * Built-In Speakers 4MB Smart Cache, DDR3L-1867MHz, TDP 15W Built-In Microphone Intel® Core™ i5 Processor (Factory Option) Built-In Array Microphone Latest Specification Information i5-7200U (2.50GHz) Security 4MB Smart Cache, DDR3L-1867MHz, TDP 15W... - Page 15 Introduction Card Reader Power Embedded Multi-In-1 Card Reader Full Range AC/DC Adapter MMC (MultiMedia Card) / RS MMC AC Input: 100 - 240V, 50 - 60Hz SD (Secure Digital) / Mini SD / SDHC/ SDXC DC Output: 19V, 2.1A (40W) MS (Memory Stick) / MS Pro / MS Duo Removable 4 Cell Smart Lithium-Ion Battery Pack, 32WH (Factory Option) Removable 4 Cell Smart Lithium-Ion Bat-...
-
Page 16: External Locator - Top View With Lcd Panel Open
*When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone (W950BU only) 4. LCD 5. Power Button 6. Keyboard 7. Touchpad & Buttons 1 - 4 External Locator - Top View with LCD Panel Open... -
Page 17: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator 2. Multi-in-1 Card Reader FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Ports 4. -
Page 18: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor LEFT SIDE VIEW Port 4. Vent 5. HDMI-Out Port 6. USB 3.0 Ports Figure 5 REAR VIEW Rear View 1. -
Page 19: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Speakers Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7... -
Page 20: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts) -
Page 21: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. M.2 Card Connector (3G) 2. CPU 3. Memory Slots DDR3L SO-DIMM 4. CMOS Battery 5. M.2 Card Connector (SSD) 6. M.2 Card Connector (WLAN) Mainboard Overview - Bottom (Key Parts) 1 - 9... -
Page 22: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB Port 3.0 3. Keyboard Cable Connector 4. Audio Board Cable Connector 1 - 10 Mainboard Overview - Top (Connectors) -
Page 23: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. ODD Connector 2. HDD Connector 3. Multi-in-1 Card Reader 4. External Monitor Port 5. RJ-45 LAN Jack 6. DC-In Jack 7. CCD Connector 8. LCD Cable Connector 9. Battery Connector Mainboard Overview - Bottom (Connectors) 1 - 11... - Page 24 Introduction 1 - 12...
-
Page 25: Disassembly
Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W950BU / W955BU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7.0mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 5. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 3d Figure 3 6. Lift the hard disk assembly out of the bay (Figure 3e HDD Assembly 7. Remove the screws and the adhesive cover from the hard disk (Figure 3f Removal (cont’d.)
-
Page 32: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 4 Optical Device 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Removal 2. Carefully pull out the optical device out of the bay at point (Figure 4a). - Page 33 Disassembly 5. Reverse the process to attach the front bezel with the new optical device at point (Figure 5e). Figure 5 6. Insert the new optical device and carefully slide it into the computer (the device only fits one way. DO NOT Optical Device FORCE IT;...
-
Page 34: Removing The Caddy/Second Hard Disk
Disassembly Removing the Caddy/Second Hard disk Figure 6 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Caddy/2nd HDD 2. Carefully pull out the caddy out of the bay at point (Figure 6a). -
Page 35: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 7 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1066/1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR3L Modules. - Page 36 Disassembly 4. Pull the latches to release the second module if necessary. Figure 8 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. RAM Module 6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot Assembly as it will go.
-
Page 37: Removing The M.2 Ssd Module
Disassembly Removing the M.2 SSD Module Figure 9 M.2 SSD Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a). -
Page 38: Removing The Keyboard
Disassembly Removing the Keyboard Figure 10 Keyboard Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Remove screws from the bottom case and press at point to release the keyboard (Figure 10a). a. - Page 39 Disassembly 6. Connect the keyboard ribbon cable to the locking collar socket , and be careful not to bend the keyboard ribbon Figure 11 cable (Figure 11d). Keyboard Assembly 7. Insert the keyboard at point and then slide the keyboard in at point (Figure 11e).
-
Page 40: Removing The 3G Module
Disassembly Removing the 3G Module Figure 12 3G Module Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 2. The 3G module will be visible at point on the mainboard (Figure 12a). -
Page 41: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 13a). -
Page 42: Wireless Lan And Combo Module Cables
Disassembly Wireless LAN and Combo Module Cables Note that the cables for connecting to the antennae on WLAN and WLAN & Bluetooth Combo modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identification as outlined in the table below. -
Page 43: Removing The Ccd
Disassembly Removing the CCD Figure 14 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Run your fingers around the inner frame of the LCD panel at the points as indicated by the arrows (Figure a. - Page 44 Disassembly 5. Disconnect the cable Figure 15 6. Remove the CCD module (Figure 15f). CCD Removal 7. Reverse the process to install a new CCD module. (cont’d) d. Disconnect the cable. e. Remove the CCD mod- ule. 7. CCD Module 2 - 20 Removing the CCD...
-
Page 45: Part Lists
Appendix A:Part Lists This appendix breaks down the W950BU / W955BU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 46: Part List Illustration Location
Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W950BU W955BU Location page A - 3 page A - 4 Bottom page A - 5... -
Page 47: Top - W950Bu
Top - W950BU Figure A - 1 Top - W950BU Top - W950BU A - 3... -
Page 48: Top - W955Bu
Top - W955BU Figure A - 2 Top - W955BU A - 4 Top - W955BU... -
Page 49: Bottom (W950Bu
Bottom (W950BU) Figure A - 3 Bottom (W950BU) Bottom (W950BU) A - 5... -
Page 50: Bottom (W955Bu
Bottom (W955BU) Figure A - 4 Bottom (W955BU) A - 6 Bottom (W955BU) -
Page 51: Lcd (W950Bu
LCD (W950BU) Figure A - 5 LCD (W950BU) LCD (W950BU) A - 7... -
Page 52: Lcd (W955Bu
LCD (W955BU) Figure A - 6 LCD (W955BU) A - 8 LCD (W955BU) -
Page 53: Dvd Dual (W950Bu
DVD DUAL (W950BU) Figure A - 7 DVD DUAL (W950BU) DVD DUAL (W950BU) A - 9... -
Page 54: Dvd Dual (W955Bu
DVD DUAL (W955BU) Figure A - 8 DVD DUAL (W955BU) A - 10... -
Page 55: Dummy Odd (W950Bu
Dummy ODD (W950BU) Figure A - 9 Dummy ODD (W950BU) Dummy ODD (W950BU) A - 11... -
Page 56: Hdd (W950Bu
HDD (W950BU) Figure A - 10 HDD (W950BU) A - 12 HDD (W950BU) -
Page 57: Hdd (W955Bu
HDD (W955BU) Figure A - 11 HDD (W955BU) HDD (W955BU) A - 13... -
Page 58: 2Nd Hdd (W950Bu
2nd HDD (W950BU) Figure A - 12 2nd HDD (W950BU) A - 14 2nd HDD (W950BU) -
Page 59: Schematic Diagrams
Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W950BU / W955BU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1... -
Page 60: System Block Diagram
Schematic Diagrams System Block Diagram VDD3,VDD5 System Block Diagram (Kaby Lake U) SHEET 27 5V,3V,5VS,3VS SHEET 26 HDMI+PS8201A <6.5" (3 VIA) SHEET 19 1.0V SERIES SHEET 29 32.768KHz RTD2136N RTD2168 <10" (4 VIA) EDP TO LVDS DP TO VGA VCORE SHEET 30 SHEET 17 SHEET 16... -
Page 61: Skylake Ult
Schematic Diagrams Skylake ULT Processor Pullups/Pull downs 1.0VS SKL_ULT U55A SINGLE=50ohm, DIFF=85ohm, L <=10" H_PROCHOT# R348 1K_04 VGA_LANE0N EDP_TXN_0 DDI1_TXN[0] EDP_TXN[0] TRACE WIDTH 10MIL, LENGTH <500MILS EDP_TXP_0 VGA_LANE0P DDI1_TXP[0] EDP_TXP[0] EDP_TXN_1 VGA_LANE1N DDI1_TXN[1] EDP_TXN[1] EDP_TXP_1 VGA_LANE1P DDI1_TXP[1] EDP_TXP[1] THRMTRIP_R_N C370 *0.1u_16V_Y5V_04 DDI1_TXN[2] EDP_TXN[2]... -
Page 62: Skylake Ult Ddr
Schematic Diagrams Skylake ULT DDR CHANNEL A CHANNEL B SKL_ULT U55B SKL_ULT U55C AU53 M_A_DQ[63:0] M_A_CLK_DDR#0 DDR0_CKN[0] M_A_DQ0 AL71 AT53 DDR0_DQ[0] DDR0_CKP[0] M_A_CLK_DDR0 M_B_DQ[63:0] M_A_DQ1 AL68 AU55 M_B_DQ0 AF65 AN45 M_B_CLK_DDR#0 DDR0_DQ[1] DDR0_CKN[1] M_A_CLK_DDR#1 DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKN[0] M_A_DQ2 AN68 AT55 M_B_DQ1 AF64 AN46 DDR0_DQ[2]... -
Page 63: Skylake Ult Rtc/Hda/Clk/Sd
Schematic Diagrams Skylake ULT RTC/HDA/CLK/SD 10K_04 PCIECLKRQ0# 3.3VA 3.3VS *0_04 R157 GCLK_32K C336 10K_04 CARD_CLKRQ1# 10p_50V_NPO_04 Zo= 50 ±15% R416 10K_04 W LAN_CLKREQ# RTC_X1 10K_04 PCIECLKRQ4# R383 10K_04 SSD_CLKREQ# SKL_ULT U55J *1K_04 SUS_CK R459 CM200C_32.768KHz CLOCK SIGNALS SUS_CK *10K_04 LAN_CLKREQ# 10M_04 CLKOUT_PCIE_N0 R102... -
Page 64: Skylake Ult Lpc/Spi/Smb
Schematic Diagrams Skylake ULT LPC/SPI/SMB STRAP PIN TLS Confidentiality SKL_ULT U55E LOW = Disable Intel ME SPI - FLASH GPP_C2 Crypto TLS (Default) SMBUS, SMLINK SPI_SCLK_R HIGH =Enable Intel ME SPI0_CLK SMB_CLK Crypto TLS SPI_SO_R GPP_C0/SMBCLK SMB_CLK 22,24 SPI0_MISO SMB_DATA SPI_SI_R GPP_C1/SMBDATA SMB_DATA... -
Page 65: Skylake Ult Power Maint
Schematic Diagrams Skylake ULT Power Maint SKL_ULT U55K SYSTEM POWER MANAGEMENT AT11 SLP_S0# GPP_B12/SLP_S0# AP15 GPD4/SLP_S3# SUSB# 15,22,23,26,29,30 PLT_RST# *10mil_04 PLT_RST_N AN10 BA16 GPP_B13/PLTRST# GPD5/SLP_S4# SUSC# 23,28,29 SYS_RESET# AY16 SLP_S5# SYS_RESET# GPD10/SLP_S5# RSMRST# AY17 RSMRST# RSMRST# RSMRST# PD 10K_04 IN TI8587 SIDE AN15 SLP_SUS# SLP_SUS#... -
Page 66: Skylake Ult Gpios/I2C/Emmc
Schematic Diagrams Skylake ULT GPIOS/I2C/EMMC SKL_ULT U55F LPSS PCH_GPP_B15 PCH_GPP_B15 GPP_B15/GSPI0_CS# T_INT PCH_GPP_B16 GPP_D9 GPP_B16/GSPI0_CLK D-MIC_DET# PCH_GPP_B17 GPP_D10 GPP_B17/GSPI0_MISO PCH_GPP_D11 GSPI0_BBS0 GPP_D11 PCH_GPP_D12 GPP_B18/GSPI0_MOSI GPP_D12 PCH_GPP_B19 GPP_B19/GSPI1_CS# BOARD_ID0 PCH_GPP_B20 GPP_D5/ISH_I2C0_SDA GPP_B20/GSPI1_CLK BOARD_ID1 PCH_GPP_B21 GPP_D6/ISH_I2C0_SCL GPP_B21/GSPI1_MISO PCH_GPP_B22 BOARD_ID2 GPP_B22/GSPI1_MOSI GPP_D7/ISH_I2C1_SDA GPP_D8/ISH_I2C1_SCL SB_BLON GPP_C8/UART0_RXD GPP_C9/UART0_TXD... -
Page 67: Skylake Ult Pcie, Usb, Sata
Schematic Diagrams Skylake ULT PCIE, USB, SATA SKL_ULT U55H PCI-E x1 Usage Lane 1 GLAN / CARD READER SSIC / USB3 PCIE/USB3/SATA Lane 2 WLAN Lane 3 USB3_1_RXN USB3_RX1_N Lane 4 USB3_RX1_P USB3_1_RXP USB 3.0 PORT1 Lane 5 PCIE_RXN1_GLAN PCIE1_RXN/USB3_5_RXN USB3_1_TXN USB3_TX1_N Lane 6... -
Page 68: Skylake Ult Power 1
Schematic Diagrams Skylake ULT Power 1 PROCESSOR CORE POWER VCCIN SVID Signals VCCIO_OUT C1109 C1116 1.0VT C476 C314 C295 C1112 C1113 C1114 R372 56_1%_04 H_CPU_SVIDALRT# 22u_6.3V_X5R_08 22u_6.3V_X5R_08 1u_6.3V_X5R_04 R371 100_1%_04 H_CPU_SVIDDAT_R CAD Note: the PU resistors close to CPU C508 C447 C330 1u_6.3V_X5R_04... - Page 69 Schematic Diagrams Skylake ULT Power 2 C547 22u_6.3V_X5R_08 VCCPRIM_CORE *15mil_short_06 3.3VA C548 22u_6.3V_X5R_08 *15mil_short_06 3.3VA C497 1u_6.3V_X5R_04 *15mil_short_06 *15mil_short_06 1.0VA SKL_ULT 3.3VA 1u_6.3V_X5R_04 U55O C499 1u_6.3V_X5R_04 CPU POWER 4 OF 4 *15mil_short_06 0.696 A 3.3VA *15mil_short_06 VCCPRIM_CORE AB19 1.0VA VCCPRIM_1P0 0.020 A 1u_6.3V_X5R_04 AB20...
-
Page 70: Power-Vss
Schematic Diagrams Power-VSS SKL_ULT U55P SKL_ULT U55Q GND 1 OF 3 GND 2 OF 3 AL65 AL66 AT63 BA49 AM13 AT68 BA53 AM21 AT71 BA57 AM25 AU10 AA65 AM27 AU15 BA62 SKL_ULT U55R AA68 AM43 AU20 BA66 AB15 AM45 AU32 BA71 GND 3 OF 3 AB16... -
Page 71: Cfg, Rsvd, Vccgt
Schematic Diagrams CFG, RSVD, VCCGT SKL_ULT SKL_ULT VCCGT U55M U55S VCCGT VCCGT CPU POWER 2 OF 4 VCCIO_OUT RESERVED SIGNALS-1 VCCGT R369 1K_04 CFG0 BB68 C1104 C1105 C1106 VCCGT VCCGT CFG[0] RSVD_TP_BB68 R386 *10K_04 CFG1 BB69 VCCGT VCCGT CFG[1] RSVD_TP_BB69 R541 *10K_04 CFG2... -
Page 72: Ddr3L So-Dimm_A_0
Schematic Diagrams DDR3L SO-DIMM_A_0 SO-DIMM A_0 V_VCCDDQ 5.2mm 6-86-24204-005 CHANGE TO STANDARD C159 C574 6-86-24204-002 J_DIMM2A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ18 J_DIMM2B M_A_A1 M_A_DQ19 M_A_A2 M_A_DQ23 V_VCCDDQ M_A_A3 M_A_DQ22 M_A_A4 M_A_DQ20 M_A_A5 M_A_DQ16 VDD1 VSS16 M_A_A6 M_A_DQ21 EMI Solution VDD2 VSS17 M_A_A7 M_A_DQ17 VDD3... -
Page 73: Ddr3L So-Dimm_B_0
Schematic Diagrams DDR3L SO-DIMM_B_0 9.2mm SO-DIMM B_0 CHANGE TO STANDARD 6-86-24204-001 6-86-24204-006 J_DIMM1B V_VCCDDQ J_DIMM1A M_B_A[15:0] M_B_DQ[63:0] M_B_A0 M_B_DQ15 M_B_A1 M_B_DQ11 VDD1 VSS16 M_B_A2 M_B_DQ14 VDD2 VSS17 M_B_A3 M_B_DQ10 VDD3 VSS18 M_B_A4 M_B_DQ12 VDD4 VSS19 M_B_A5 M_B_DQ8 3.3VS VDD5 VSS20 M_B_A6 M_B_DQ9 20mils... -
Page 74: Panel, Inverter
Schematic Diagrams Panel, Inverter PANEL CONNECTOR PANEL POWER ^,KZd LED PANEL (LVDS Dual Channel). *OPEN-2mm J_LCD2 VLED LVDS-UCLKN LVDS-UCLKP *MTS3572G6 3.3VS LVDS-U1N LVDS-U2N LVDS-U1P LVDS-U2P LVDS-U0N C248 C234 LVDS-U0P C489 0.1u_16V_Y5V_04 C235 C506 0.1u_16V_Y5V_04 R253 R254 *0.1u_50V_Y5V_06 *0.1u_50V_Y5V_06 *0.22u_50V_Y5V_06 PLVDD 3.3VS PANEL_VCC_EN 2.2K_04... -
Page 75: Crt
Schematic Diagrams J_CRT1 5VS_CRT 95-6047-01 RB751S-40C2 DAC_RED FCM1005MF-600T01 FCM1005MF-600T01 FRED DAC_GREEN FCM1005MF-600T01 FCM1005MF-600T01 FGRN R434 R310 DAC_BLUE FCM1005MF-600T01 FCM1005MF-600T01 FBLUE 2.2K_04 2.2K_04 C523 C524 C521 C525 C437 C293 C324 C420 C533 VGA_SDA R375 R428 R429 VGA_HSYNC R334 36_1%_04 VGA_HS_R VGA_VSYNC VGA_VS_R R324 36_1%_04... -
Page 76: Ps8625
Schematic Diagrams PS8625 3.3VS 3.3VS HCB1005KF-121T20 HCB1005KF-121T20 BCNR3010C-2R2M HCB1005KF-121T20 VDDIO_LVDS VDDIOX_LVDS SW _OUT VDD12 VDDRX_LVDS LVDS_PLVDD_EN LVDS_PLVDD_EN ENBLT ENBLT C457 C456 C1117 C458 C587 C471 C460 C459 BRIGHTNESS_R BRIGHTNESS_R 0.47u_10V_Y5V_04 1u_6.3V_X5R_04 22u_6.3V_X5R_06 0.47u_10V_Y5V_04 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 *4.7u_6.3V_X5R_06 1u_6.3V_X5R_04 GND_LVDS GND_LVDS GND_LVDS GND_LVDS LVDS-L0N LVDS-L0N... -
Page 77: Card Reader & Rtl8411B
Schematic Diagrams Card Reader & RTL8411B Crystal 5032 SIZE Switching Regulator close to PIN48 4 IN 1 SOCKET SD/MMC/MS/MS Pro meet realtek Freq tolerance <50ppm R475 2.49K_1%_04 CO-LAY R566 *0_04 R492 0_06 GCLK_25M R483 *1K_04 (>20mil) J_CARD-REV1 XTAL2 R487 10K_04 REGOUT VDD10 SD_CD#... -
Page 78: [19] Hdmi,Rj45,Fan
Schematic Diagrams HDMI, RJ45, Fan HDMI Repeater 5VS_HDMI LEVEL SHIFT BRANCH POINT BRANCH POINT HDMI2_C0CP TMDS_DATA2-M TMDS_DATA2-RR C226 0.1u_10V_X7R_04 R278 0_04 VOUT HDMI2_C0CN C239 0.1u_10V_X7R_04 TMDS_DATA2#-M R280 0_04 TMDS_DATA2#-RR C161 C164 HDMI2_C1CP C240 0.1u_10V_X7R_04 TMDS_DATA1-M R281 0_04 TMDS_DATA1-RR HDMI2_C1CN C244 0.1u_10V_X7R_04 TMDS_DATA1#-M R283... -
Page 79: Wlan, 3G, Ssd
Schematic Diagrams M.2 (WLAN, 3G, SSD) NGFF_A (M2) WLAN CARD Layout NGFF_B(M2) 3G/LTE CARD 1. SIM (10mil) J_WLAN1 22u_6.3V_X5R_06 3. SIM hold C692 0.1u_16V_Y5V_04 SIM CONNECTOR J_3G1 4. SIM CONN MINI CARD GND10 3.3V3 WLAN_3.3V 80 mil CONN Reserved/REFCLKN1 3.3V2 CONFIG_2 3.3V4 3G_3.3V... -
Page 80: Audio Codec
Schematic Diagrams Audio Codec R602 *0_04 1.5VS EMI Require DVDD_IO 0_04 R522 *20mil_04 3.3VS_AUD PVDD1_2 C432 C431 CLOSE TO PVDD1 CLOSE TO PVDD2 HCB1005KF-121T20 AUDG CLOSE TO CODEC R290 *0_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 R245 *20mil_04 C448 C443 C446 C441 PIN9 PIN9 C409 *0.1u_16V_Y5V_04 10u_6.3V_X5R_06... -
Page 81: Usb 3.0, G Sensor, Tpm
Schematic Diagrams USB 3.0, G Sensor, TPM USB3.0 PORT(PORT3) USB3.0 PORT(PORT1 USB charge) W/ USB CHARGER USBVCC0_2 VDD5 VOUT 100 MIL C191 C213 VDD5 USBVCC0_1 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 R244 24,26 DD_ON# VOUT SY6288D20AAC R239 *0_04 10K_04 C200 C219 Default Low 6,15,23,26,29,30 SUSB# C194 2A/90mohm... -
Page 82: Kbc Ite It8587
Schematic Diagrams KBC ITE IT8587 R177 R176 JOPEN3 HCB1005KF-121T20 10K_04 1K_04 *CV-40mil VDD3 VDD3 C190 C181 C160 C154 KBC_AVDD 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 HCB1005KF-121T20 VDD3 SUS_PW R_ACK GPJ0/TACH2 5VT/SSCE0#/GPG2 GPG2 W LAN_PW R_EN GPJ4/DAC4/DCD0# C168 C178 C179 PCH_DPW ROK_EC GPJ5/DAC5/RIG0# 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04... -
Page 83: Ccd, Mic, Lid, I/O Connector
Schematic Diagrams CCD, MIC, LID, I/O Connector T/P Connect LID SWITCH 3.3VS TP_VCC 3.3VS W94/W95 VDD3 VDD3 C406 C407 VDD3 R503 1u_6.3V_X5R_04 0.1u_16V_Y5V_04 100K_04 LID_SW # J_LID1 LID_SW # 15,23 Q135A 0_06 MTDK5S6R LID_SW # SMB-CLK SMB_CLK 5,22 6-20-94K30-108 Q135B *85204-03001 *BAV99 RECTIFIER MTDK5S6R... -
Page 84: Hdd, Odd, Led
Schematic Diagrams HDD, ODD, LED ODD CONNECT Zero Power ODD J_ODD1 SATATXP1_R C364 0.01u_16V_X7R_04 R469 3.3VS SATATXP1 8 SATATXN1_R C363 0.01u_16V_X7R_04 C360 SATATXN1 8 *100K_04 SATARXN1_R C362 0.01u_16V_X7R_04 ^,KZd *1u_6.3V_X5R_04 SATARXN1 SATARXP1_R C361 0.01u_16V_X7R_04 R470 SATARXP1 PJ12 R468 *20K_04 *OPEN-2mm *10K_04 5VS_ODD *MTP3403N3... -
Page 85: 3V, 5V, 3Vs, 5Vs
Schematic Diagrams 3V, 5V, 3VS, 5VS DD_ON# SUSB 1.0VS_PWRGD VDD3 VDD3 1.0VS VDD3 VDD3 R1590 R1589 100K_04 10K_04 SUSB R1591 R1592 R1593 SUSB 19,28 DD_ON# Q127 DD_ON# 22,24 Q126 MTN7002ZHS3 1K_04 1K_04 100K_04 MTN7002ZHS3 PJ14 C1517 1.0VS_PW RGD# 1.0VS_PW RGD 6,15,22,23,29,30 SUSB# 1.0VS_PW RGD... -
Page 86: Vdd3, Vdd5
Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR278 PR279 *0_04 *20mil_04 PC199 1u_6.3V_X5R_04 PR280 PR281 130K_1%_04 130K_1%_04 EN_3V EN_5V PC200 PC201 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PU11 PC202 PC203 PC204 PC205 PC206 PC207 PC208 1u_6.3V_X5R_04 PR282 *10K_04 0.1u_50V_Y5V_06 4.7u_25V_X5R_08 4.7u_25V_X5R_08 *15u_25V_6.3*4.4 220u_25V_6.3*12 SYS5V LDO3 PC209 0.1u_10V_X5R_04... -
Page 87: Vddq, Vddq_Vtt, 1.5Vs, 1.8Vs
Schematic Diagrams VDDQ, VDDQ_VTT, 1.5VS, 1.8VS VDDQ_VTT PD29 PC221 PC222 PC226 PC223 PQ68A PU12 EMB17A03V VDDQ_VTT RB0540S2 uP6163 Z3709 PC224 VDDQ 10u_6.3V_X5R_06 VDDQ PC227 0.1u_10V_X5R_04 VLDOIN VBST VDDQ_VTT PJ37 *OPEN-2mm Z3701 Z3710 PR297 *20mil_04 Z3718 DRVH PL21 VDDQ PJ38 V_VCCDDQ ^,KZd BCIHP0730-1R0M *OPEN-10mm... -
Page 88: 1.0V Series
Schematic Diagrams 1.0V Series 1.0V PJ42 *CV-40mil R1529 *100K_04 VDD3 For CV test PR319 820K_1%_06 PJ43 *OPEN-1mm 1.0VA_EN PC250 PC251 PC252 22,23,26,27 DD_ON PU16 PJ44 *OPEN-1mm PQ72A VTT_SELECT VTT VR Output Voltages 6,15,22,23,26,30 SUSB# PR320 PC253 EMB17A03V 1.1 V 0_06 0.1u_10V_X7R_04 high (V1.1S_VTT) 1.05 V... -
Page 89: Vcore, Vccgt, Vccsa, Vccio
Schematic Diagrams VCore, VCCGT, VCCSA, VCCIO EMI Solution s'd PC367 PC363 PC364 PC365 PC366 PC327 PC326 PC311 s'd PC325 PC324 PC320 PC104 PC76 PQ88 220u_25V_6.3*12 EEEFZ1E101P MDU1516 PQ86 ULTRASO-8 MDU1516 PR329 2.2_06 ULTRASO-8 HG_GT2 PR328 2.2_06 SW N_GT2 PR371 *20mil_04 PL28 PR373 *20mil_04... -
Page 90: Charger, Dc-In
Schematic Diagrams Charger, DC-In PC165 PR240 0.1u_50V_Y5V_06 *470K_04 SMART CHARGER V_BAT PC167 PC166 PR241 1500p_50V_04 PQ56 0.1u_50V_Y5V_06 EMB20P03V 20K_04 J_DC_JACK1 EML1 VJACK HCB2012KF-800T80 PRS1 PL14 PRS2 PD16 PC170 0.01_1%_32 BCIHP0730-4R7M 0.01_1%_32 Z4104 PC175 PC182 PC183 PC177 GND1 PR242 PC172 GND2 PC168 470K_04 PR244... -
Page 91: Ncp81206 Regulator
Schematic Diagrams NCP81206 Regulator 3.3VS PR37 100K_04 *CV-40mil PJ22 VR_EN 6,15,23 ALL_SYS_PWRGD *OPEN-1mm ^,KZd PR1327 PJ25 CSN_SA DIFFOUT_GT PR1308 100_04 VCCGT TH05-4F104FR VR_ON place PR1320 0_04 VSP_GT VCCGT_SENSE PR1321 *OPEN-1mm 750_1%_04 close PR1324 PC270 49.9_1%_04 to PL8 100K_1%_04 PC280 PC98 PC99 PC101 1000p_50V_X7R_04... -
Page 92: Audio Board
Schematic Diagrams Audio Board USB PORT PCBA CHECK AA_USBVCC1 AA_USBVCC2 1AAR *0_04 4AAR *0_04 60 mil AAC3 AAC2 60 mil AAC15 AAC16 2AAR *0_04 5AAR *0_04 AAC4 AAC17 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 3AAR *0_04 6AAR *0_04 Port3 Port4 AAJ_USB1 AAJ_USB2 AAGND AAGND AAUSB_PN1 AAL6 AAUSB_PN1_R... -
Page 93: Power Sw Board
Schematic Diagrams Power SW Board POWER SW & LED(W94/W95) S_3.3VS POWER SWITCH 330_04 20mil *0.1u_10V_X5R_04 SJ_SW1 AVL18S02015 SMGND SMGND SM_BTN# CLOSE TO SC2 S_3.3VS 20mil SMGND 50578-0040N-001 Sheet 34 of 39 PCB Footprint = 85201-0405L-1 FOR W940TU FOR W950TU Power SW Board SMGND POWER BUTTON SPWR_SW1... -
Page 94: Option Bom List
Schematic Diagrams Option BOM List & > & > R292 C226,C239,C240,C244,C225 U5,C539,C538,C541,C540,C543 U2,R180,R158,C151,C152,C162,C165 C242,C241,C243,R278,R280 C542,C544,C546,R571,R569 R281,R283,R284,R285,R286 C545,C484,C534,C536,C485 R287,D90,D91,D5,D6,D7 C483,C535,C537,R338,R339 Q22,Q42,R288,R488,R518 R358,R570,R572,R573,R574 & > R580,R585,R663,R664,R665 R575 R666,R667,Q24 Šƒ”‰‡” R506,R507,R232,R272 R238,C211,U9,R244,R240,R275 &... - Page 95 Schematic Diagrams ODD to HDD Board ODD TO HDD BOARD W/ RRPEATER Table 1. Tx/Rx EQ and DE Pulse-Duration Settings DE1/DE2 CH1/CH2D e-Emphasis EQ1/EQ2 CH1/CH2E qualization dB (at 6Gbps) dB (at 6Gbps) D_3.3VS NC (default) NC (default) DGND DC14 DC14 DC13 DC13 DC12...
- Page 96 Schematic Diagrams External ODD Board ODD BOARD FROM M/B TO ODD QJ_ODD1 QJ_ODD2 Q_SATA_TXP1 Q_SATA_TXN1 Q_SATA_RXN1 Q_SATA_RXP1 QGND QGND Sheet 37 of 39 Q_ODD_DETECT# Q_5VS Q_5VS External ODD Q_SATA_ODD_DA# GND2 GND1 Board 242003-1 C185J9-11308-L GND1~2=WGND QGND 6-21-14030-013 QGND PIN GND1~4=GND 6-21-13800-013(DIP) Q_5VS H7_0D2_3...
- Page 97 Schematic Diagrams Battery Con. Board 6-7P-W95J4-A01 PCB( 4 IN 1) CHARGER CON. BOARD 6-71-W95K1-D01 HALL SENSOR BOARD 6-71-W95KN-D03 ODD BOARD 6-71-W95KQ-D02 BATTERY BOARD 6-71-W95J9-D01 AUDIO BOARD TO M/B TO Battery Sheet 38 of 39 Battery Con. Board BJBATTA2 BJBATTA1 BV_BAT BV_BAT BBAT_DET *10mil_short_04...
- Page 98 Schematic Diagrams LID Switch Board LID SWITCH BOARD L_3.3V LJ_LID1 L_LID_SW # 85204-03001 L_GND For 15" L_3.3V Sheet 39 of 39 L_U1 L_LID_SW # LID Switch Board L_C1 0.1u_16V_Y5V_04 MH248-ALFA-ESO H2_3B5_0D2_3 C43D43N C43D43N L_GND L_GND 6-02-00248-LC2 6-02-00268-LC1 L_GND DMFWP!DP/!! Title Title Title [02] HALL SENSOR BOAR (W55/W95)
-
Page 99: Updating The Flash Rom Bios
Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files... -
Page 100: Use The Flash Tools To Update The Bios
BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
