Page 1 All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Mazda Corporation. Mazda may change the contents without notice and without incurring obligation.
Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3 INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Mazda may change the contents without notice and without incurring obligation. EMISSION WARRANTY The New Vehicle Limited Warranty includes Bumper to Bumper Coverage, Safety Restraint Coverage and Corrosion Coverage.
Page 4 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows...
Page 5 Vehicle Symbol Glossary Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Introduction Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant...
Page 6: Instrumentation
Instrumentation Headlamp and turn signal control (pg. 49) Fog lamp control* (pg. 50) Power mirror control* Speed controls* (pg. 18) (pg. 40) Instrument panel dimmer control (pg. 18) * if equipped Windshield wiper/washer control (pg. 44) Instrument cluster (pg. 8) Manual tilt steering wheel lever (pg.
Page 7 Instrumentation Hazard flasher control (pg. 19) Rear window defroster Audio system control (pg. 23) (pg. 19) 4WD control* (pg. 19) Climate controls (pg. 20) Auxiliary power point (pg. 54)
Page 8 Instrumentation WARNING LIGHTS AND CHIMES CHECK FUEL Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 9 These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the light should turn off.
Page 10 Instrumentation Air bag readiness Momentarily illuminates when the ignition is turned ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts.
Page 11 WARNING: If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.
Page 12 Instrumentation Charging system Illuminates when the ignition is turned to the ON position and the engine is off. The light also illuminates when the battery is not charging properly, requiring electrical system service. Engine oil pressure Momentarily illuminates when the ignition is turned to the ON position.
Page 13 Instrumentation O/D off Illuminates when the Transmission Control Switch (TCS), refer to Overdrive control in the Driving chapter, has been pushed turning the transmission overdrive function OFF. When the light is on, the transmission does not operate in the overdrive mode, refer to the Driving chapter for transmission function and operation.
Page 14 Instrumentation Check fuel cap (if equipped) Momentarily illuminates when the CHECK ignition is turned to the ON position FUEL to ensure your bulb is working. When this light turns on, check the fuel filler cap. Continuing to operate the vehicle with the check fuel cap light on, can activate the warning light.
Page 15 GAUGES CHECK FUEL Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool.
Page 16 Instrumentation Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Speedometer Indicates the current vehicle speed. Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position).
Page 17 Instrumentation Odometer Registers the total kilometers R D 2 1 (miles) of the vehicle. Trip odometer Registers the kilometers (miles) of R D 2 1 individual journeys. Press and hold the button for 1 or more seconds to reset. Press and release the button in less than 1 second to toggle between odometer and trip odometer.
Page 18: Controls And Features
Controls and features INSTRUMENT PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel. Push and hold top of control to brighten. Push and hold bottom of control to dim. POWER MIRROR CONTROL The ignition must be in the ACC or ON position to adjust the power side view mirrors.
Page 19 Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. FOUR WHEEL DRIVE (4X4) CONTROL (IF EQUIPPED) This control operates the four wheel drive (4X4) system. Refer to the Driving chapter for more information.
Page 20 Controls and features CLIMATE CONTROL SYSTEM Manual heating and air conditioning system Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle.
Page 21 NOTE:In snowy or dirty conditions, leave the mode selector in the OFF position. MAX A/C- Uses recirculated air to cool the vehicle. MAX A/C is noisier than A/C but more economical and will cool the inside of the vehicle faster. Airflow will be from the instrument panel registers. This mode can also be used to prevent undesirable odors from entering the vehicle.
Page 22 Controls and features (Defrost)-Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 6°C (43°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging. Operating tips In humid weather, select on your windshield.
Page 23 USING YOUR AUDIO SYSTEM AM/FM Radio with Compact Disc Player CLOCK POWER-VOL PUSH AUDIO DISC Volume/power control Ensure that the ignition switch is in the ACC or ON position. Press the control to turn the audio system on. Turn the control to raise or lower the volume.
Page 24 Controls and features Tune adjust The tune control works in radio mode. Tune adjust in radio mode Press to move up the frequency band in individual increments. Press to move down the frequency band in individual increments. Seek function The seek function control works in radio mode. Seek function in radio mode Press and momentarily hold the SEEK control.
Page 25 Scan function The scan function works in radio mode. Scan function in radio mode Press the SCAN control to hear a sampling of strong stations on the frequency band. Each station will play for approximately 5 seconds. Press the SCAN control again to remain on a station and disable this mode.
Page 26 Controls and features Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the AUDIO control until BASS is illuminated in the display. Turn the volume control to adjust to the desired level of bass. Speaker fade adjust Speaker sound can be adjusted between the front and rear...
Page 27 Radio station memory preset The radio is equipped with five station memory preset controls. These controls can be used to select up to five preset AM stations and ten FM stations (five in FM1 and five in FM2). Setting memory preset stations 1.
Page 28 Controls and features Random play in CD mode Press the RDM control during play. RDM will illuminate in the display. The next selection will be randomly selected. To disengage random play, press the RDM control again. Repeat play The repeat play feature works in CD mode and repeats the current CD selection.
Page 29 3:24, the time will change to 3:00. If the clock’s current time setting is within the latter part of the hour (from 30 to 59 minutes), the hour setting will automatically advance one hour. For example, if the original setting is 3:45, the time will change to 4:00. Changing the display mode Press the CLOCK control to alternate the display between time...
Page 30 Controls and features Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 31 Tune/Seek/Disc function in radio mode Press to find the next available station up the frequency band. Press to find to the next available station down the frequency band. Tune/Seek/Disc function for CD mode Press to select the next disc in the CD changer. Press to select the previous disc in the CD changer.
Page 32 Controls and features Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Press the AUDIO control twice to access the system’s treble adjust mode. Turn the control to increase (right) or decrease (left) the amount of treble output.
Page 33 Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the AUDIO control four times to access the system’s balance adjust mode. Turn the control (right or left) to adjust between the right and left speakers.
Page 34 Controls and features Starting autoset memory preset 1. Select a frequency using the AM/FM select control. 2. Press the control. 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.
Page 35 Fast forward The fast forward control works in tape and CD modes. In the tape mode, tape direction will automatically reverse when the end of the tape is reached. In CD mode, pressing the control for less than three seconds results in slow forward action.
Page 36 Controls and features Press the LOAD control. WAIT will appear in the display as the system prepares to load the IN will appear in the display and the CD door will open when the system is ready to receive a CD. Wait until the CD door opens.
Page 37 Setting the clock Press the CLOCK control. Press the TUNE control. Press to adjust the hours. Press to adjust the minutes. Troubleshooting the CD changer (if equipped) WARNING: The laser beam used in the compact disc player is harmful to the eyes. Do not attempt to disassemble the case. If sound skips: You may be traveling on a rough road, playing badly scratched discs or the disc may be dirty.
Page 38 Controls and features Radio frequency information The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz Not all frequencies are used in a given area.
Page 39 POSITIONS OF THE IGNITION 1. LOCK, locks the gearshift lever and allows key removal. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 3. ON, all electrical circuits operational. Warning lights illuminated.
Page 40 Controls and features SPEED CONTROLS (IF EQUIPPED) To turn speed control on Press ON. NOTE: Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). WARNING: Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Page 41 To set a speed Press SET ACC. NOTE:For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 42 Controls and features To set a higher set speed Press and hold SET ACC. Release the control when the desired vehicle speed is reached or Press and release SET ACC to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or Accelerate with your accelerator pedal.
Page 43 To disengage speed control Depress the brake pedal or Depress the clutch pedal (if equipped). NOTE:Disengaging the speed control will not erase the previously programmed set speed. NOTE:Fully depressing the clutch pedal may cause a flare in engine RPM as the throttle is returned to idle.
Page 44 Controls and features To return to a previously set speed Press RSM. NOTE:For RSM to operate, the vehicle speed must be faster than 48 km/h (30 mph). WINDSHIELD WIPER AND WASHER For intermittent operation, move control down one position. Adjust the rotary control to the desired speed setting.
Page 45 Controls and features For high speed wiper operation, move control down three positions from OFF. To activate the windshield washer, pull control toward you. Release control to stop washer fluid spray. MIST FUNCTION Move control up and release for one wipe.
Page 46 Controls and features For normal speed rear wiper operation, rotate control upward to To activate the rear washer, rotate the control to the position and release. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package.
Page 47 Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: Remove the Velcro pad from the storage compartment door. Place Velcro on aftermarket transmitter opposite of actuator control. Install the transmitter on to storage compartment door aligning the actuator control with...
Page 48 Controls and features WARNING: Do not let children play with the moon roof. They may seriously injure themselves. INTERIOR LAMPS Cargo and dome lamp Rear cargo lamp equipped with an ON/OFF/DOOR control will light when: the doors are closed and the control is in the ON position.
Page 49 The map lamp controls (without moon roof) are located on the dome lamp. Press the controls on either side of each map lamp to activate the lamps. If equipped with a moon roof, the map lamps are located on the moon roof control panel.
Page 50 Controls and features High beams Push forward to activate. Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate. TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal.
Page 51 POWER WINDOWS Press and hold the rocker switches to open and close windows. Press the top portion of the rocker switch to close. Press the bottom portion of the rocker switch to open. One touch down Press AUTO completely down to the second detent.
Page 52 Controls and features NOTE:This feature will only operate the driver’s side window. Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the right side of the control.
Page 53 CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 54 Controls and features AUXILIARY POWER POINT WARNING: Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty.
Page 55 CARGO COVER (IF EQUIPPED) Your vehicle may be equipped with a cargo area shade that covers the luggage compartment of your vehicle. To install the shade: 1. Fasten the cover into the mounting brackets (make sure the cover is right side up). 2.
Page 56 Controls and features LIFTGATE To open the rear window, pull the right side of the liftgate handle. To open the liftgate, pull the left side of the liftgate handle. Do not open the liftgate or liftgate glass in a garage or other enclosed area with a low ceiling.
Page 57 Controls and features If there is any potential remote keyless entry problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to the dealership, to aid in troubleshooting. Unlocking the doors Press this control to unlock the driver’s door.
Page 58 Controls and features Replacing the battery The transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: weather conditions nearby radio towers...
Page 59 Take all your vehicle’s transmitters to your authorized Mazda dealer for programming, or Perform the programming procedure yourself Programming remote transmitters It is necessary to have all (maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure.
Page 60 Controls and features To program the transmitters yourself: Insert a key in the ignition and turn from 1 (LOCK) to 3 (RUN) eight times in rapid succession (within 10 seconds) with the eighth turn ending in the 3 (RUN) position. The doors will lock/unlock to confirm that programming mode has been entered.
Page 61 NOTE: The SecuriLock passive anti-theft system is not compatible with non-Mazda aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Automatic arming NOTE: The vehicle is armed immediately after switching the ignition to the 2 (ACC) position.
Page 62 NOTE: If a problem occurs, turn ignition OFF and restart the engine with all other objects on the key ring held away from the ignition key. Check to make sure the encoded ignition key is an approved Mazda encoded ignition key.
Page 63 If two previously programmed coded keys are not available, you must bring your vehicle to your authorized Mazda dealership to have the spare coded key(s) programmed. NOTE: Please read and understand the entire procedure before you begin.
Page 64 If not successful, the new coded key(s) will not start the vehicle’s engine and the theft indicator will flash on and off and you may repeat steps 1 through 6. If failure repeats, bring your vehicle to your authorized Mazda dealership to have the new spare key(s) programmed.
Page 65 If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to authorized Mazda dealership, to aid in troubleshooting. Arming the system When armed, this system will respond if unauthorized entry is attempted.
Page 66 Controls and features Disarming the system You can disarm the system by any of the following actions: Unlock the doors by using your remote entry transmitter. Unlock the doors with a key. Press the panic control on the remote entry transmitter. This will disarm the system only if the alarm is sounding.
Page 67: Seating And Safety Restraints
Seating and safety restraints SEATING Adjusting the front manual seat WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. Sudden braking or a collision could cause serious injury. Adjust the seat only when the vehicle is stopped. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injuring people in a collision or sudden stop.
Page 68 Seating and safety restraints Pull lever up to adjust seatback. Adjusting the front power seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. This can cause you to lose control of the vehicle and cause an accident. WARNING: Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop.
Page 69 Seating and safety restraints Move the rear of the control up or down to raise or lower the rear portion of the seat cushion. Move the control in the directions shown to move the seat forward, backward, up or down. REAR SEATS Head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are...
Page 70 Seating and safety restraints Push control to lower head restraint. Folding down rear seats 1. Raise the rear seat head restraint and remove. 2. Place the head restraints under the front passenger seat for storage. 3. Pull the seat release control.
Page 71 Seating and safety restraints 4. Flip seat forward. 5. Pull the seatback release strap toward the front seat. Make sure the seat belt buckle heads are fully extended towards the front of the vehicle and are away from the seatback. NOTE:When the seatback release strap is pulled use your other hand to guide the seatback.
Page 72 Seating and safety restraints 6. Rotate seatback down into load floor position. WARNING: Make sure seat belt buckle heads are not trapped underneath the seatback and that the seat belt buckle heads are fully extended towards the front of the vehicle. Seat belt buckle heads may break if they are trapped underneath the seatback as the seatback is...
Page 73 Seating and safety restraints 2. Rotate seat cushion down into the seating position making sure that the seat cushion is locked into place and that the seat belt buckles are exposed. 3. Remove the head restraints stored under the front passenger seat and return them to the original position on the seat backs.
Page 74 Seating and safety restraints To install the rear cushion 1. Push the cushion to the inboard side of the vehicle. 2. Make sure that the hinges are locked into place. SAFETY RESTRAINTS Safety restraints precautions WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 75 Seating and safety restraints WARNING: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 76 Seating and safety restraints WARNING: After any vehicle collision, the safety belt system at all outboard seating positions (except driver, which has no “automatic locking retractor” feature) must be checked by a qualified technician to verify that the “automatic locking retractor”...
Page 77 Seating and safety restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 78 WARNING: After any vehicle collision, the front passenger outboard seat belt system must be checked by an authorized Mazda dealership to verify that the “automatic locking retractor” feature for child seats is still functioning properly. In addition, all seat belts should be checked for proper function.
Page 79 Seating and safety restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 80 20 cm (8 inches) can be added to the safety belt assembly by adding a safety belt extension assembly. Safety belt extension assemblies can be obtained from your authorized Mazda dealership. Use only extensions manufactured by the same supplier as the safety belt.
Page 81 Seating and safety restraints Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding...
Page 82 Mazda recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and an authorized Mazda technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Page 83 Seating and safety restraints WARNING: Failure to inspect and if necessary replace the safety belt assembly under the above conditions could result in severe personal injuries in the event of a collision. Refer to Cleaning and maintaining the safety belts in the Maintenance and care section.
Page 84 WARNING: Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your authorized Mazda dealership.
Page 85 Do not modify the front end of the vehicle. WARNING: Additional equipment may effect the performance of the air bag sensors increasing the risk of injury. Consult your authorized Mazda dealership before installation of additional equipment. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 86 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
Page 87 A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your authorized Mazda dealership immediately.
Page 88 Seating and safety restraints WARNING: Unless serviced, the system may not function properly in the event of a collision. Side air bag system (if equipped) WARNING: Do not place objects or mount equipment on or near the air bag cover on the side of the seatbacks of the front seats or in front seat areas that may come into contact with a deploying air bag.
Page 89 WARNING: Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your authorized Mazda dealer. WARNING: All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 90 Seating and safety restraints How does the side air bag system work? The side air bag system consists of the following: An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 91 If any of these things happen, even intermittently, have the SRS serviced at your authorized Mazda dealership immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 92 Disposal of air bags and air bag equipped vehicles For disposal of air bags or air bag equipped vehicles, see your authorized Mazda dealership. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.
Page 93 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Mazda recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 94 Put the safety belt in the automatic locking mode. Refer to Automatic locking mode (passenger side front seat). Mazda recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
Page 95 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions The rear seat head restraints must be removed when using a child seat. WARNING: Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag.
Page 96 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that...
Page 97 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 98 Seating and safety restraints The tether strap anchors in your vehicle are in the following positions: WARNING: Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 99 Seating and safety restraints 4. Clip the tether strap to the anchor as shown. 5. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat. 6.
Page 100 Seating and safety restraints LATCH anchors for child seat installation have been provided in your vehicle at the following locations: The anchors at the center of the rear seat are much further apart than the sets of lower anchors for child seat installation at other seating positions.
Page 101 Seating and safety restraints WARNING: Always attach the LATCH child restraint to both LATCH lower anchors in any vehicle seat, being sure to confirm that both LATCH attachments are fully engaged by pulling back and forth vigorously. A child seat retained on only one side is creating the risk of throwing the child around the vehicle or even out of the seat and vehicle during an accident, causing serious injury or death.
Page 102 See Guarding against exhaust fumes in this chapter for more instructions. WARNING: If you smell exhaust fumes inside your vehicle, have your authorized Mazda dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute...
Page 103 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: Make sure the parking brake is set.
Page 104 Starting 3. Turn the key to 3 (ON) without turning the key to 4 (START). NOTE: If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: front wheels are turned front wheel is against the curb steering wheel is turned when getting in or out of the vehicle...
Page 105 STARTING THE ENGINE NOTE: Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. 1. Turn the key to 4 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 106 Take precautions to avoid its dangerous effects. WARNING: If you ever smell exhaust fumes of any kind inside your vehicle, have your authorized Mazda dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes. These fumes are harmful and could kill you.
Page 107: Driving
If a “metal-to-metal,” “continuous grinding” or “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by an authorized Mazda dealership. Four-wheel anti-lock brake system (ABS) (if equipped)
Page 108 (If your brake warning lamp illuminates, have your vehicle serviced immediately by an authorized Mazda dealership.) Using four wheel ABS (if equipped) In an emergency or when maximum efficiency from the ABS is required, apply continuous force on the brake.
Page 109 Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, apply the brake pedal and pull the parking brake handle up as far as possible. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 110 Driving STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to help steer the vehicle. To prevent damage to the power steering pump: Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running.
Page 111 WARNING: Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 112 WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized Mazda dealer or a qualified service technician. Driving with an automatic overdrive transaxle Your automatic transaxle electronically controls the shift feel by using an adaptive learning strategy.
Page 113 Understanding gearshift positions Your automatic transaxle electronically controls the shift feel by using an adaptive learning strategy. This feature is designed to optimize shift smoothness. NOTE:It is normal for your transaxle to shift firmly during the first few hundred kilometers (miles) of operation until the adaptive strategy has been learned.
Page 114 O/D OFF control is pressed, there may be a transaxle electronic system malfunction. You should contact your authorized Mazda dealer as soon as possible or damage to the transaxle could occur.
Page 115 O/D OFF control is pressed, there may be a transaxle electronic system malfunction. You should contact your authorized Mazda dealer as soon as possible or damage to the transaxle could occur.
Page 116 Driving 1 (First) Use 1 (First) for when added engine braking is desired when descending steep hills. The automatic transaxle will shift to the proper gear to ascend any grade without any need to shift to 1 (First). To avoid damage to the engine and/or transaxle do not go faster than 56 km/h (35 mph) when in this gear.
Page 117 2. Hold down the brake pedal. 3. Depress the clutch pedal. 4. Without depressing the accelerator pedal, turn the ignition to position 4 (START), release the ignition as soon as the engine starts. 5. Let the engine idle for a few seconds.
Page 118 Driving Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse). Failure to do so may damage the transaxle. Put the gearshift lever into the neutral position and wait at least three seconds before shifting into R (Reverse).
Page 119 2. Set the parking brake. 3. Shift into 1 (First). 4. Turn the ignition to position 1 (LOCK) to shut the engine off and remove the ignition key. WARNING: Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully.
Page 120 Driving FOUR WHEEL DRIVE (4X4) SYSTEM (IF EQUIPPED) 4x4 system general information WARNING: For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. Your vehicle is equipped with a 4x4 system. This 4x4 system can use all four wheels to power the vehicle.
Page 121 The 4x4 mode indicator light illuminates only under the following conditions. If the indicator light illuminates when driving in the 4x4 AUTO mode, contact your Mazda dealer as soon as possible. The indicator light illuminates when the 4x4 ON mode is engaged.
Page 122 Driving Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside. Do not grip the spokes. Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps.
Page 123 Driving After driving through mud, clean off residue stuck to rotating driveshafts, halfshafts and tires. Excess mud stuck on tires and rotating driveshafts causes an imbalance that could damage drive components. NOTE:If the transaxle Power Take Off unit or rear axle are submerged in water, their fluids should be checked and changed, if necessary.
Page 124 Driving Driving on snow and ice NOTE: An 4x4 vehicle has advantages over 2WD vehicles in snow and ice but can skid like any other vehicle. Avoid sudden applications of power and quick changes of direction on snow and ice. Apply the accelerator slowly and steadily when starting from a full stop.
Page 125 Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow. The maximum trailer weight rating is determined by subtracting the vehicle curb weight for each engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle.
Page 126 Driving WARNING: Under no circumstance should these limitations be exceeded. Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Special loading instructions for owners of pickup trucks and utility-type vehicles WARNING: For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section inthe Driving chapter of this owner guide.
Page 127 If driving through deep or standing water is unavoidable, proceed very slowly. Never drive through water that is higher than the bottom of the hubs (for trucks) or the bottom of the wheel rims (for cars). Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 128 Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle. See your authorized Mazda dealer. Hitches Do not use hitches that clamp onto the vehicle bumper. Use a load carrying hitch.
Page 129 Trailer lamps Trailer lamps are required on most towed vehicles. Make sure your trailer lamps conform to local and Federal regulations. See your authorized Mazda dealer for proper instructions and equipment for hooking up trailer lamps. Driving while you tow When towing a trailer: Ensure that you turn off your speed control.
Page 130 Driving Trailer towing tips Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. Allow more distance for stopping with a trailer attached. The trailer tongue weight should be no more than 10–15% of the loaded trailer weight.
Page 131 Recreational towing An example of “recreational towing” is towing your vehicle behind a motorhome. If your vehicle is automatic transmission equipped, with a 4x2 (front-wheel drive only) configured powertrain, “recreational towing” is permitted by trailering the vehicle with its front wheels on a dolly. This protects the transmission’s internal mechanical components from potential lack of lubrication damage.
Page 132 Driving To remove the cross-bar assembly from the roof rack side rails: 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the end of the rail. 3. Use a long, flat object in order to depress the tongue in the endcaps on both sides of the cross-bar.
Page 133 To reinstall the cross-bar assembly to the roof rack side rails: 1. Ensure that both cross-bar assemblies are installed with the F (front) arrow facing towards the front of the vehicle. 2. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar.
Page 134: Roadside Emergencies
Roadside emergencies HAZARD FLASHER CONTROL Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. The hazard lights control is located on the instrument panel by the radio.
Page 135 1. Turn the ignition to the LOCK/OFF position. 2. Check the fuel system for leaks. 3. If no fuel leak is apparent, reset the fuel pump shut-off switch by pushing in on the reset button. 4. Turn the ignition to the ON position. Pause for a few seconds and return the key to the LOCK/OFF position.
Page 136 Roadside emergencies Fuse Mini Standard rating fuses fuses Green Green — — — — — — — — — — Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 137 The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Canister Vent Control Solenoid Blower Relay (coil), Rear Defrost Relay (coil), Pressure Switch to PCM Rear Wiper Motor, Rear Washer Motor, Rear Wiper Relay (coil) Four Wheel Drive Control Module, Cluster (Restraints Control Warning) ABS Unit (EVAC &...
Page 138 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Passive Anti-theft Transceiver (PATS), Restraints Control Module Cluster, Shift Lock Relay (coil), O/D signal to PCM PCM Relay (coil), Fan Relay 1, 2, 3 (coil), A/C Relay (coil) Front Wiper Motor, Front Washer Motor, INT Relay IGN Relay (coil), ACC Relay (coil), Starter Relay (coil), Key Interlock Solenoid, GEM...
Page 139 Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Left/Right Stoplamps, Hight Mounted Stoplamp, Left/Right Trailer Stoplamp, ABS Unit, ASC Unit (Brake Pedal Position Switch), PCM, Shift Solenoid Power Window Motor - Right Front, Left Front, Right Rear, Left Rear Power Door Lock Motor - Right Front, Left Front, Right Rear, Left Rear, GEM (Door Lock Relay Coil), Power Seat...
Page 140 Roadside emergencies MAIN (ABS) 40/50A MAIN 120A BTN 1 BTN 2 MAIN The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating Horn Horn H/L LH 15A* Headlamp (High/Low Left, High Beams) H/L RH 15A* Headlamp (High/Low Right,, High Beams) EEC (KPWR)
Page 141 Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating DIODE — — H/L RELAY — Headlamp (High/Low, Right/Left Relay) MICRO — — — 30A** EEC (VPWR), EVR, MAF, IAC, Bulkhead MAIN 120A Main 15A* Alternator/ Regulator (DRL) 15A* DRL Unit (feed), DRL Relay (DRLZ) 15A*(DRLZ) Daytime Running Lamps (DRL) Module,...
Page 142 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating FUEL — Fuel Pump Relay PUMP ISO MAIN FAN — Low Speed Fan Control Relay (2.0L Engine) High Speed Fan Control Relay 1 (3.0L Engine) ADD FAN — High Speed Fan Control Relay 1 (2.0L Engine) Low Speed Fan Control Relay (3.0L Engine)
Page 143 It is not recommended that the vehicle be operated in 4WD modes with a temporary spare. If 4WD operation is necessary, do not operate above speeds of 16 km/h (10 mph) or for distances above 80 km (50 miles). WARNING: If you use the temporary spare tire continuously or do not follow these precautions, the tire could fail, causing you to lose control of the vehicle, possibly injuring yourself or others.
Page 144 Roadside emergencies 1. Park on a level surface, activate hazard flashers and place gearshift lever in P (Park) (automatic transmission) or R (Reverse) (manual transmission). 2. Set the parking brake and turn engine OFF. 3. Block the diagonally opposite wheel. 4.
Page 145 Before placing the jack under the vehicle, NOTE the jack locations: Front jacking notches are located under the front suspension arm. Rear jacking notches are located under the rear trailing arm. 6. Position the jack according to the following guides and turn the jack handle clockwise until the tire is a maximum of 25 mm (1 inch) off the ground.
Page 146 Roadside emergencies Never use the differentials as a jacking point. It is too easy for the vehicle to tilt or fall and you can be injured. WARNING: To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire.
Page 147 NOTE: To stow the full size flat tire in the cargo floor, the long spare tire rod in the tool bag needs to be installed. 11. Using the lug wrench, remove the spare tire rod from the cargo floor and install the longer spare tire rod.
Page 148 Roadside emergencies Do not attempt to push start your vehicle. Automatic transmissions do not have push-start capability. Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly.
Page 149 Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 150 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the disabled vehicle’s engine, away from the battery and the fuel injection system.
Page 151 Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected.
Page 152 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 153 It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Mazda has not approved a slingbelt towing procedure.
Page 154 Maximum speed is 56 km/h (35 mph). Maximum distance is 80 km (50 miles). Mazda provides a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 155: Maintenance And Care
This could lead to vehicle damage or an accident and injuries. For expert advice and quality service, consult an Authorized Mazda Dealer. The owner should retain evidence that proper maintenance has been performed as prescribed.
Page 156 Maintenance and care SCHEDULE 1 I: Inspect and repair, clean, adjust, or replace if necessary (Oil-permeated air filter cannot be cleaned using the air-blow method) R: Replace L: Lubricate Maintenance Interval (Number of months or km (miles), Months Maintenance Item x 1000 Km (x 1000 Miles) ENGINE...
Page 157 Compressor operation *1 According to state and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage (kilometrage) period to ensure long-term reliability.
Page 158 Maintenance and care SCHEDULE 2 I: Inspect and repair, clean, adjust, or replace if necessary (Oil-permeated air filter cannot be cleaned using the air-blow method) R: Replace L: Lubricate Maintenance Interval (Number of months or km (miles), Months Maintenance Item x 1000 Km (x 1000 Miles) (5) (10) (15) (20) (25) (30) (35) (40) (45) (50) (55) (60) ENGINE...
Page 159 Compressor operation *1 According to state and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage (kilometrage) period to ensure long-term reliability.
Page 160 Check your “Warranty Information” to find out which parts and services are covered. Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. Genuine Mazda parts are designed and built to provide the best performance in your vehicle. PRECAUTIONS WHEN SERVICING YOUR VEHICLE Be especially careful when inspecting or servicing your vehicle.
Page 161 Working with the engine off Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Manual transmission: 1.
Page 162 Maintenance and care OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. At the front of the vehicle, lift up on the auxiliary latch handle located in the center between the hood and the grille. 3.
Page 163 IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.0L DOHC I4 Zetec engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Brake fluid reservoir 4. Air filter assembly 5. Power distribution box 6. Battery 7. Engine oil filler cap 8. Engine oil dipstick 9.
Page 164 Maintenance and care 3.0L DOHC V6 Duratec engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Automatic transmission fluid dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Power distribution box 7. Battery 8. Engine oil dipstick 9.
Page 165 ENGINE OIL Checking the engine oil Refer to the service maintenance section for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 166 Maintenance and care 3.0L DOHC V6 Duratec engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the MIN-MAX or ADD-FULL marks, the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the MIN or ADD mark, add enough oil to raise the level within the MIN–MAX or ADD-FULL range.
Page 167 3.0L DOHC V6 Duratec engine Oil levels above the MAX or FULL mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
Page 168 If a replacement oil filter is used that does not meet Mazda material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Genuine Mazda oil filter (or another brand meeting Mazda specifications) for your engine application.
Page 169 MAX. Do not fill above this line. 4. Use only brake fluids certified to meet Mazda specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used.
Page 170 If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Mazda specifications. Refer to Lubricant specifications in the Capacities and specifications chapter.
Page 171 NOTE:State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive. Washer fluids containing non-methanol antifreeze agents should be used only if they provide cold weather protection without damaging the vehicle’s paint finish, wiper blades or washer system. WARNING: Do not put washer fluid in the engine coolant reservoir.
Page 172 Maintenance and care When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 173 If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. The cooling system in your vehicle is filled with green-colored Mazda Premium Engine Coolant meeting Mazda Specifications. To determine your vehicle’s coolant type (color), check your coolant reservoir.
Page 174 Maintenance and care For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool. Add the proper mixture of coolant and water to the “cold full” level. For all other vehicles, which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant.
Page 175 Not all coolant recycling processes produce coolant which meets Mazda recommend coolants. Use of a recycled engine coolant which does not meet the Mazda recommended coolant, may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner.
Page 176 Maintenance and care decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage. decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage. refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive.
Page 177 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and MAX lines.
Page 178 Maintenance and care 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick. 6. Install the dipstick making sure it is fully seated in the filler tube. 7.
Page 179 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Mazda specifications. Refer to the Capacities and specifications chapter. BATTERY...
Page 180 Maintenance and care However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the service maintenance section for the service interval schedules. Keep the electrolyte level in each cell up to the “level indicator”. Do not overfill the battery cells.
Page 181 WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 182 Refer to the service maintenance section for the appropriate intervals for changing the air filter element. When changing the air filter element, only use a Genuine Mazda air filter element. WARNING: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 183 6. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover. This could cause filter damage and allow unfiltered air to enter the engine if not properly seated. 7.
Page 184 Maintenance and care Changing the wiper blades To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to...
Page 185 Maintenance and care U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Mazda to give you the following information about tire grades exactly as the government has written it. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 186 Maintenance and care WARNING: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge.
Page 187 Maintenance and care Four tire rotation Five tire rotation...
Page 188 WARNING: Make sure that all replacement tires are of the same size, type, load=carrying capacity and tread (e.g., “All Terrain”, etc.), as originally offered by Mazda. Failure to do so can result in tire failure and a serious accident. WARNING: Do not replace your tires with “high performance”...
Page 189 The tires on your vehicle have all-weather treads to provide traction in rain and snow. However, in some climates, using snow tires and traction devices may be necessary. See your authorized Mazda dealer for more information on tire cables and other traction devices for your vehicle.
Page 190 Maintenance and care WARNING: If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury. WARNING: Automotive fuels can cause serious injury or death if misused or mishandled.
Page 191 Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury. Fuels can also be harmful if absorbed through the skin.
Page 192 However, if it knocks heavily under most driving conditions while you are using fuel with the recommended octane rating, see your authorized Mazda dealer to prevent any engine damage. Fuel quality NOTE:If you are experiencing starting, rough idle or hesitation driveability problems during a cold start, try a different brand of “Regular”...
Page 193 World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice Cleaner air Mazda endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 194 Fuel Filter For fuel filter replacement, see your authorized Mazda dealership. Refer to the service maintenance section for the appropriate intervals for changing the fuel filter.
Page 195 Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill capacities section of the Capacities and specifications chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 196 Maintenance and care 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled. Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway).
Page 197 Combine errands and minimize stop-and-go driving. Maintenance Keep tires properly inflated and use only recommended size. Operating a vehicle with the wheels out of alignment will reduce fuel economy. Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle service maintenance section.
Page 198 If other than Mazda authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Mazda parts should be equivalent to genuine Mazda parts in performance and durability. WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 199 Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 200 Maintenance and care BULBS Replacing exterior bulbs Check the operation of the following lamps frequently: Headlamps Fog lamps (if equipped) High-mount brakelamp Brake lamps Turn signals License plate lamp Tail lamps Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones.
Page 201 4. Remove the rubber boot from the lamp assembly by pulling on one of the tabs. 5. Squeeze the retainer spring together releasing it from bulb hooks and rotate it away from the bulb. 6. Without turning, carefully pull bulb out of headlamp assembly. Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 202 Maintenance and care 9. Install rubber boot on the lamp assembly. 10. Connect the electrical connector into the rear of the plastic base until it “snaps.” Replacing brake/tail/turn/backup lamps bulbs The brake/tail/turn/backup lamp bulbs are located in the tail lamp assembly, one just below the other.
Page 203 3. Disconnect the electrical connector from the bulb by pulling rearward. 4. Remove the bulb socket from the lamp assembly by turning counterclockwise. 5. Pull the bulb straight out of the socket and push in the new bulb. 6. To complete installation, follow the removal procedure in reverse order.
Page 204 Maintenance and care Replacing front parking lamp/turn signal bulbs For bulb replacement, see an authorized Mazda dealer. Replacing high-mount brake lamp bulbs For bulb replacement, see an authorized Mazda dealer. Replacing the interior bulbs Check the operation of the following interior bulbs frequently:...
Page 205 The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by your authorized Mazda dealer. VERTICAL AIM ADJUSTMENT 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from a vertical wall or screen directly in front of it.
Page 206 7. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 8. Close the hood and turn off the lamps. CLEANING AND CARING FOR YOUR VEHICLE Contact your local Mazda dealership for a list of Mazda-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water.
Page 207 Repairing paint chips Minor scratches or paint damage from road debris may be repaired with Genuine Mazda Touch-Up Paint. Observe the application instructions on the products. Remove particles such as bird droppings, tree sap, insect remains, tar spots, road salt and industrial fallout immediately.
Page 208 Maintenance and care Cleaning the engine Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: Take care when using a power washer to clean the engine. The high pressure fluid could penetrate the sealed parts and cause damage.
Page 209 Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the wheels Wash with the same detergent as the body of your vehicle. Do not use acid-based or alcohol-based wheel cleaners, steel wool, fuel or strong detergents.
Page 210 Maintenance and care Cleaning seats equipped with side air bags Remove dust and loose dirt with a whisk broom or a vacuum cleaner. Remove fresh spots immediately. Follow the directions that come with the cleaner. Do not saturate the seat cover with upholstery cleaner. WARNING: Do not use chemical solvents or strong detergents when cleaning the seat where the side air bag is mounted.
Page 211 Cleaning and maintaining the safety belts Clean the safety belts with a mild soap solution recommended for cleaning upholstery or carpets. WARNING: Do not bleach or dye the belts, because these actions may weaken the belt webbing. Check the safety belt system periodically to make sure there are no nicks, wear or cuts.
Page 212: Capacities And Specifications
Capacities and specifications REFILL CAPACITIES Fluid Classification Brake fluid High Performance DOT 3 Motor Vehicle Brake Fluid Engine oil API service SJ, (including filter SAE 5W-20, change) 5W-30 Super Premium Motor API service SH or SJ, SAE 5W-20, 5W-30, 10W-30, ACEA A1/B1 Super Premium Motor Fuel tank...
Page 213 Capacities and specifications Fluid Classification Transfer Case SAE 75W-140 Synthetic Lubricant API service GL-5, SAE 80W-90 Engine coolant Use only ethylene-glycol- based coolant Rear axle SAE 80W-90 lubricant Premium Rear Axle Lubricant Windshield washer fluid Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 214 Capacities and specifications For further information on your lubrication specifications, see your authorized Mazda dealer. WHEEL AND TIRE SIZES Vehicle Wheel Tire Grade DX/DX-V6 6.5JJx16 215/70R16 LX-V6/ES-V6 7.0JJx16 235/70R16 ENGINE SPECIFICATIONS Engine 2.0L DOHC I4 Zetec engine Cubic inches Required fuel...
Page 215 Capacities and specifications * Denotes a 4x4 vehicle with optional 16” tires...
Page 216 Capacities and specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification Label be affixed to a vehicle and prescribe where the Certification Label may be located. The Certification Label is located on the front door latch pillar on the driver’s side.
Page 217: Customer Assistance
Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: STEP 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer.
Page 218 Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: STEP 1 Discuss the matter with an Authorized Mazda Dealer.
Page 219 Customer assistance This way, we can be sure to respond to you as efficiently as possible. That is our goal. If you live outside the U.S.A., please contact your nearest Mazda Distributor. Mazda Importers/Distributors U.S.A (Importer/Distributor) Mazda North American Operations 7755 Irvine Center Drive Irvine, CA 92618–2922...
Page 220 The differences may make it difficult or even impossible for your vehicle to receive satisfactory servicing in other countries. We strongly recommend that you NOT take your Mazda outside these areas. You may have these problems if you do: Recommended fuel may be unavailable. Any kind of leaded fuel or low-octane fuel will affect vehicle performance and damage the emission controls and engine.
Page 221 Add-On Non-Genuine Parts and Accessories Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by the manufacturer for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle’s performance or safety system;...
Page 222 NHTSA, U.S. Department of Transportation. Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline. (Note) If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to: Mazda North American Operations 7755, Irvine Center Drive Irvine, California 92618–2922...
Page 223 This booklet contains information regarding the proper care and operation of your vehicle. This is not a technician’s manual. Please note that your Authorized Mazda Dealership has trained personnel and special service tools to correctly and safely maintain Mazda vehicles.
Page 224: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Mazda Corporation. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 225: Index
Air bag supplemental restraint system ...83, 88 and child safety seats ...85 description ...83, 88 disposal ...92 driver air bag ...86, 90 indicator light ...10, 87, 91 operation ...86, 90 passenger air bag ...86, 90 side air bag ...88 Air cleaner filter ...182 Air conditioning ...20 All Wheel Drive (AWD), driving off road ...19, 120...
Page 226 Index interior ...210 mirrors ...211 plastic parts ...209 safety belts ...211 washing ...206 waxing ...207 wheels ...209 windows ...211 wiper blades ...209 woodtone trim ...211 Climate control (see Air conditioning or Heating) ...20 Clock ...28, 37 Clutch fluid ...170 operation while driving ...116 recommended shift speeds ...117 Console ...53 overhead ...46...
Page 227 Four-Wheel Drive vehicles description ...120 driving off road ...121 indicator light ...12, 121 preparing to drive your vehicle ...110 Fuel ...189 calculating fuel economy ...194 cap ...14, 193 capacity ...212 choosing the right fuel ...192 comparisons with EPA fuel economy estimates ...197 detergent in fuel ...193 filling your vehicle with fuel ...189, 193, 195...
Page 228 Index Instrument panel cleaning ...210 cluster ...8 lighting up panel and interior ...18 location of components ...8 Jack ...142 positioning ...142 storage ...142 Jump-starting your vehicle ...147 Keys ...61–63 key in ignition chime ...14 positions of the ignition ...39 Lamps bulb replacement specifications chart ...204 cargo lamps ...18...
Page 229 Octane rating ...192 Odometer ...17 Off-Road Driving ...121 Oil (see Engine oil) ...165 Overdrive ...112 Panic alarm feature, remote entry system ...57 Parking ...118 Parking brake ...109 Power distribution box (see Fuses) ...139 Power door locks ...52 Power steering ...110 fluid, checking and adding ...176 fluid, refill capacity ...212 fluid, specifications ...214...
Page 230 Index Tachometer ...16 Tires ...142, 184–186 changing ...142–143 checking the pressure ...186 replacing ...188 rotating ...186 snow tires and chains ...188 tire grades ...185 treadwear ...185 Towing ...127 recreational towing ...131 trailer towing ...127 wrecker ...153 Transaxle automatic operation ...111 fluid, checking and adding (manual) ...179 manual operation ...116...
Page 231: Filling Station Information
Item Required fuel Fuel tank capacity-2.0L I4 Zetec engine Fuel tank capacity-3.0L V6 Duratec engine Engine oil capacity-2.0L I4 Zetec engine (includes filter change) Engine oil capacity-3.0L V6 Duratec engine (includes filter change) Tire size and pressure Hood release Coolant capacity-2.0L I4 Zetec engine with manual transaxle Coolant capacity-3.0L V6 Duratec engine with automatic transaxle...
Page 232 Filling station information Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle. MERCON and MERCON V are not interchangeable. DO NOT mix MERCON and MERCON V. Refer to your service maintenance section to determine the correct service interval.

Mazda 2001 Tribute Owner's Manual

Quick Links

Related Manuals for Mazda 2001 Tribute

Summary of Contents for Mazda 2001 Tribute

Table of Contents
