MAZDA MIATA 1999-04
SECTION INDEX
A/C /HEATER/VENTILATION............................................................ 235
A/C REFRIGERANT CAPACITIES ................................................... 235
ABS/BRAKES ................................................................................... 237
AIR BAG SYSTEM............................................................................ 237
AIR CLEANER .................................................................................. 241
BACK WINDOW................................................................................ 250
CENTER CONSOLE......................................................................... 245
CLEAR COAT IDENTIFICATION ...................................................... 233
CONVERTIBLE TOP......................................................................... 249
COOLING.......................................................................................... 234
COWL & DASH ................................................................................. 244
CRUISE CONTROL SYSTEM .......................................................... 238
ELECTRICAL.................................................................................... 242
EMISSION SYSTEM......................................................................... 242
ENGINE UNDER COVER................................................................. 241
ENGINE/TRANS ............................................................................... 240
ENGINE/TRANS MOUNTS............................................................... 241
EXHAUST ......................................................................................... 241
FRONT BUMPER ............................................................................. 233
FRONT DOOR.................................................................................. 247
FRONT FENDER .............................................................................. 236
FRONT INNER STRUCTURE........................................................... 236
FRONT LAMPS................................................................................. 234
FRONT STEERING LINKAGE/GEAR............................................... 239
FRONT SUSPENSION ..................................................................... 238
FUEL TANK....................................................................................... 252
HARDTOP......................................................................................... 250
HOOD ............................................................................................... 234
INFORMATION LABELS................................................................... 233
INSTRUMENT PANEL ...................................................................... 244
LUGGAGE LID.................................................................................. 251
PAINT CODE LOCATION.................................................................. 233
QUARTER PANEL ............................................................................ 250
REAR BODY ..................................................................................... 252
REAR BUMPER................................................................................ 254
REAR DRIVE AXLE.......................................................................... 252
REAR LAMPS................................................................................... 253
REAR SUSPENSION........................................................................ 251
ROCKER/PILLARS/FLOOR.............................................................. 246
SEAT ................................................................................................. 246
SEAT BELTS ..................................................................................... 247
SPECIAL CAUTIONS........................................................................ 233
STEERING PUMP ............................................................................ 239
STEERING WHEEL/COLUMN ......................................................... 240
TURBOCHARGER/INTERCOOLER................................................. 241
UNDERHOOD DIMENSIONS........................................................... 236
WHEEL ............................................................................................. 238
WINDSHIELD.................................................................................... 243
SPECIAL CAUTIONS
AIR BAGS
Refer to Procedure Explanation 29 for Supplemental Restraint/Air Bag
Special Cautions.
SUSPENSION
Manufacturer advises that some new fasteners must be used whenever
old fasteners are loosened or removed.
PAINT CODE LOCATION
Paint code located on left lock pillar.
CLEAR COAT IDENTIFICATION
All metallic colors are clear coat.
INFORMATION LABELS
Illustration Located in Next Column
1 Label, Fan Caution
B660-15-031
2 Label, A/C Caution
99-00 NA75-61-439
01-04 NC72-61-439
3 Label, Vacuum Diagram
1999-00
To VIN 138751
NC10-69-044
madpl1_g01_
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax 1-888-256-7969 or 858-549-0629.
Page 233—April 22, 2004—13:34:01—Version
From VIN 138751
2001-04
4 Label, Fuel Economy
1999-02
Man Trans
5 Speed
6 Speed
Auto Trans
2003
Man Trans
Auto Trans
2004
Man Trans
Auto Trans
Label, Emission
5 w/Calif Emission
1999-00
To VIN 138751
From VIN 138751
2001-02
2003
2004
w/Turbo
w/o Turbo
6 w/o Calif Emission
1999-00
To VIN 138751
From VIN 138751
2001-02
2003
2004
w/Turbo
w/o Turbo
7 Label, Air Bag Caution
8 Label, VIN Plate
9 Label, Battery Information
10 Label, Battery Caution
11 Label, Spare Tire
12 Label, Fuel Warning
Label, Gasoline
13 Label, Tire Pressure
1999-00
2001-03
Std Susp
Sport Susp
2004
14 Label, Safety Panel
FRONT BUMPER
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
NC49-69-C31A
NC72-39-044
NC72-69-042
NC76-69-042
NC77-69-042
NC73-69-042
NC81-69-042
NC73-69-042B
NC81-69-042B
NC11-69-036
NC57-69-036
NC57-69-036
NC73-69-036
BP8J-69-036A
NC73-69-036B
NC10-69-036
NC49-69-036
NC72-69-036
NC73-69-036
BP8P-69-036
NC73-69-036B
BG1R-57-K93A
B001-69-D51
FA03-69-C72A
FA01-69-064B
99-03 BF68-69-073B
04 LD47-69-074
BC1M-69-D61
TA16-69-065
NC10-69-014A
NC72-39-014
NC74-69-014
N.A.
FA11-69-C31B
1999-00
MAZDA MIATA 1999-04
1 Cover, Front (P)
NCY1-50-030D-8J
(P) Paint to Match
2 Emblem, Front (Adhesive)
NC10-51-731
3 Nut, Speed (3)
9YB3-20-301
4 Frame, License
NA01-50-180A
5 Protector, Frame
FB01-50-144
6 Cap, Screw (2)
0259-33-693
7 Bracket, Frame (2)
NA01-50-18X
8 Panel, Valance
NC10-51-9K0A
9 Fastener, Upper
R/L 1395-68-676-00
10 Fastener, Outer Lower
R/L BF67-50-033
11 Fastener, Inner Lower
R/L BF82-50-233
12 Guard, Side Bumper
R NC10-50-121B
L NC10-50-131B
13 Clip, Bumper Guard
(4/Side)
R/L GJ21-50-049
14 Slide, Otr Bumper
R/L NC10-50-E11B
15 Slide, Inr Bumper
R/L NC10-50-E13A
16 Seal, Side Bumper
R/L BC1M-50-0Z5
17 Screw, Side
R/L 9CS6-00-520
18 Screw, Center (3)
R/L 9GDB-00-616
19 Grommet
R/L NC10-50-0G8
20 Rivet (2/Side)
R/L 9025-84-809
21 Guide, Air
NC10-50-A21A
22 Cover, Guide (3)
NA01-50-101A
23 Reinf, Bumper
NC10-50-071A
24 Retainer, Bumper
NC10-50-0K0B
2001-04
1 Cover, Front (P)
w/Turbo
04 NE46-50-031A
w/o Turbo
N0Y1-50-030A
(P) Paint to Match
2 Emblem, Front (Adhesive)
N066-51-731
3 Fastener, Upper (2)
BF67-50-033
4 Cover, Grille (3)
NA01-50-101A
5 Rivet (3/Side)
R/L 9025-73-205
6 Seal, Front Cover
R/L N066-50-M25
7 Seal, Rear Cover
R/L N066-50-M15
8 Grommet, Screw
R/L N066-50-0Z5
9 Clip, Side Bumper
R/L N066-50-E13A
10 Nut, Side Bumper (3/Side)
R/L B455-56-135
11 Fastener, Lower
R/L BF82-50-233
Guide, Air
12 w/Turbo
N115-50-A21A
13 w/o Turbo
NC10-50-A21A
14 Reinf, Bumper
N066-50-071
15 Retainer, Bumper Reinf (2)
NA01-50-18X
16 Retainer, Bumper
N066-50-0K0A
17 Fastener, Bumper Retainer
R/L 1395-68-676-00
18 Rivet, Bumper Retainer
(2/Side)
R/L 9025-84-809
19 Guard, Bumper
R N066-50-121
L N066-50-131
20 Cover, Fog Lamp Opng
R N066-50-C11A
L N066-50-C21A
21 Panel, Valance
NC10-51-9K0A
22 Frame, License
NA01-50-180A
23 Protector, Plate
FB01-50-144
24 Cap, Plate Holder
R/L 0259-33-693
25 Spoiler Assy, Front
