Page 1 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove compartment as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 2: How To Use This Manual
Illustrations complement the words of caution is ignored. the manual to best explain how to enjoy your Mazda. By reading your manual, you can nd out about the features, important safety information, and driving under NOTE various road conditions.
Page 3: Table Of Contents
Table of Contents Pictorial Index Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 5: Pictorial Index
Pictorial Index Interior, exterior views and part identi cation of your Mazda. Interior Overview (Left-Hand Drive Model)........1-2 Interior Equipment (View A) ............1-2 Interior Equipment (View B) ............1-4 Interior Equipment (View C) ............1-5 Interior Overview (Right-Hand Drive Model) ........ 1-6 Interior Equipment (View A) ............
Page 6 Blind Spot Monitoring (BSM) switch ..............page 4-127 Headlight levelling switch ..................page 4-70 Outside mirror switch.................... page 3-35 Door-lock switch ....................page 3-17 Power window lock switch ................... page 3-45 Power window switches ..................page 3-40 1–2 The equipment and installation position varies by vehicle...
Page 7 Push button start ...................... page 4-4 Steering shift switches ..................page 4-58 Lock release lever ....................page 3-33 Bonnet release handle ................... page 6-18 Remote fuel- ller ap release ................page 3-31 1–3 The equipment and installation position varies by vehicle...
Page 8 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View B) SRS air bags ......................page 2-38 Active driving display ................... page 4-38 Air-conditioning system ..................page 5-2 Rear window defogger switch................page 4-80 Audio system......................page 5-18 Glove compartment ..................... page 5-158 Shift lever/Selector lever ................page 4-50 , 4-52 Commander switch ....................
Page 9 Seat belts ....................... page 2-13 SRS air bag......................page 2-38 Bottle holder ......................page 5-157 Overhead lights ....................page 5-151 Sunroof switch ...................... page 3-46 Sunvisor ......................page 5-151 Vanity mirror ....................... page 5-151 Rearview mirror ....................page 3-38 Cup holders ......................page 5-156 Front seat .........................
Page 10 Lighting control..................... page 4-65 Door-lock knob ..................... page 3-19 Power window switches ..................page 3-40 Power window lock switch ................... page 3-45 Power folding mirror switch ................. page 3-35 Outside mirror switch.................... page 3-35 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF switch ..page 4-163 i-stop OFF switch ....................
Page 11 Instrument cluster ....................page 4-23 Instrument panel illumination knob ..............page 4-27 Cruise control switches ................page 4-150 , 4-211 Remote fuel- ller ap release ................page 3-31 Bonnet release handle ................... page 6-18 Lock release lever ....................page 3-33 Steering shift switches ..................page 4-58 Push button start ......................
Page 12 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View B) SRS air bags ......................page 2-38 Audio system......................page 5-18 Air-conditioning system ..................page 5-2 Rear window defogger switch................page 4-80 Active driving display ................... page 4-38 Drive selection switch ..................page 4-105 Parking Brake ....................page 4-85 , 4-86 Commander switch ....................
Page 13 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View C) Rearview mirror ....................page 3-38 Sunvisor ......................page 5-151 Vanity mirror ....................... page 5-151 Overhead lights ....................page 5-151 Sunroof switch ...................... page 3-46 Bottle holder ......................page 5-157 SRS air bag......................
Page 14: Exterior Overview
(Saloon) Bonnet ........................page 6-18 Windscreen wiper blades ..................page 6-36 Sunroof ........................page 3-46 Doors and keys ...................... page 3-12 Fuel- ller ap ......................page 3-31 Wheels and Tyres ....................page 6-46 Exterior lights ......................page 6-52 Boot lid ........................page 3-22 Child safety locks ....................
Page 15 (Hatchback) Bonnet ........................page 6-18 Windscreen wiper blades ..................page 6-36 Sunroof ........................page 3-46 Doors and keys ...................... page 3-12 Fuel- ller ap ......................page 3-31 Wheels and Tyres ....................page 6-46 Exterior lights ......................page 6-52 Rear window wiper blade ..................page 6-38 Liftgate ........................
Page 16 MEMO 1–12...
Page 17: Essential Safety Equipment
Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ..................... 2-2 Seat Precautions ................2-2 Front Seat ..................2-5 Rear Seat ..................2-8 Head Restraints ................2-11 Seat Belt Systems ................2-13 Seat Belt Precautions ..............
Page 18: Seats
The front seats contain air bag components essential to the supplementary restraint system. Such modi cations could damage the supplementary restraint system and result in serious injury. Consult an Authorised Mazda Repairer if there is any need to remove or reinstall the front seats.
Page 19: Before Driving
Playing with the folding rear seats is dangerous. Once the seatbacks are back up, a child in the boot would not be able to get out the way they had entered. If you have small children, keep the seatbacks locked. 2–3...
Page 20 Essential Safety Equipment Seats WARNING Always leave your car locked and keep the car keys safely away from children (Saloon): Leaving your car unlocked or the keys in reach of children is dangerous. Children who nd their way into the boot through an unlocked rear seatback or an open boot can become accidentally locked in the boot.
Page 21: Front Seat
Essential Safety Equipment Seats Front Seat Seat Operation Power operation Seat Slide (Manual Seat) To move a seat forward or backward, raise the lever and slide the seat to the desired position and release the lever. Make sure the lever returns to its original position and the seat is locked in place by attempting to push it forward and backward.
Page 22 Essential Safety Equipment Seats Seat Recline (Manual Seat) To change the seatback angle, lean forward slightly while raising the lever. Then lean back to the desired position and release the lever. Make sure the lever returns to its original position and the seatback is locked in place by attempting to push it forward and backward.
Page 23 Essential Safety Equipment Seats Seat Warmer WARNING The front seats are electrically heated. The ignition must be switched ON. Be careful when using the seat Press the seat warmer switch while the warmer: ignition is switched ON to operate the seat The heat from the seat warmer may be warmer.
Page 24: Rear Seat
Essential Safety Equipment Seats Rear Seat CAUTION Split/One-piece Folding the Do not use organic solvents to clean the Seatback seat. It may damage the seat surface and the heater. By lowering the rear seatback(s) the luggage compartment space can be expanded.
Page 25 Essential Safety Equipment Seats (Saloon) WARNING 1. (Split-folding type seat) Open the boot lid and pull the lever of When transporting cargo, do not allow the seatback you want to fold down. the cargo to exceed the height of the (One-piece folding type seat) seatback(s).
Page 26 3-point Seat belt guides seat belt is not caught in the seatback and the 3-point seat belt is not twisted. If the seat belt is used while it is twisted and caught in the seatback, the seat...
Page 27: Head Restraints
Essential Safety Equipment Seats Armrest Head Restraints The rear armrest in the centre of the rear Your vehicle is equipped with head seatback can be used (no occupant in the restraints on all outboard seats and the centre seat) or placed upright. rear centre seat.
Page 28 Essential Safety Equipment Seats Front outboard seat Removal/Installation To remove the head restraint, pull it up while pressing the stop-catch. To install the head restraint, insert the legs into the holes while pressing the stop- catch. WARNING Always drive with the head restraints installed when seats are being used and make sure they are properly installed: Driving with the head restraints not...
Page 29: Seat Belt Systems
Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. All the seats have lap/shoulder belts. These belts also have retractors with inertia locks that keep them out of the way when not in use.
Page 30 Essential Safety Equipment Seat Belt Systems WARNING Positioning the Shoulder Portion of the Seat Belt: Improper positioning of the shoulder portion of the seat belt is dangerous. Always make sure the shoulder portion of the seat belt is positioned across your shoulder and near your neck, but never under your arm, on your neck, or on your upper arm.
Page 31 Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become dif cult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to "Seat Belt Maintenance" (page 6-82 ). Ring Pregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts.
Page 32: Seat Belt
If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an expert repairer, we recommend an Take up slack Authorised Mazda Repairer. Keep low on hip bone Front Shoulder Belt Adjuster Too high...
Page 33: Seat Belt Warning Systems
Essential Safety Equipment Seat Belt Systems Seat Belt Warning Front Seat Belt Systems Pretensioner and Load Limiting Systems If it detects that the occupant seat belt is unfastened, the warning light or beep For optimum protection, the driver and alerts the occupant. front passenger seat belts are equipped Refer to Taking Action on page 7-43 .
Page 34 Have systems cannot provide adequate an expert repairer, we recommend an protection in an accident and this Authorised Mazda Repairer safely could result in serious injury. For more dispose of the pretensioner system or details about wearing seat belts, refer scrap a pretensioner system equipped to "Fastening the seat belts"...
Page 35 Essential Safety Equipment Seat Belt Systems NOTE The pretensioner system may not operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2-52 ). Some smoke (non-toxic gas) will be released when the air bags and pretensioners deploy.
Page 36: Child Restraint
Essential Safety Equipment Child Restraint Child Restraint Precautions Mazda strongly urges the use of child-restraint systems for children small enough to use them. Mazda recommends use of a Mazda genuine child-restraint system or one that complies with the UNECE 44 regulation. If you would like to purchase a Mazda genuine child-restraint system, please contact an Authorised Mazda Dealer.
Page 37 Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident.
Page 38 Essential Safety Equipment Child Restraint WARNING Even in a moderate collision, the child-restraint system can be hit by a deploying air bag and moved violently backward resulting in serious injury or death to the child. If your vehicle is equipped with a front passenger air bag deactivation switch, always set the switch to the OFF position when installing a rear-facing child-restraint system on the front passenger seat.
Page 39 Essential Safety Equipment Child Restraint WARNING Do not allow a child or anyone to lean over or against the side window of a vehicle with side and curtain air bags: It is dangerous to allow anyone to lean over or against the side window, the area of the front passenger seat, the front and rear window pillars and the roof edge along both sides from which the side and curtain air bags deploy, even if a child-restraint system is used.
Page 40 Essential Safety Equipment Child Restraint NOTE Your Mazda is equipped with ISOFIX anchors for attachment of ISOFIX child-restraint systems in the rear. When using these anchors to secure a child-restraint system, refer to “ISOFIX Anchor-Secured Child-Restraint Systems” (page 2-35 ).
Page 41: Child-Restraint System Installation
Less than 13 kg (less than 29 lb) 8 months to 4 years old 9 kg — 18 kg (20 lb — 40 lb) 3 to 7 years old 15 kg — 25 kg (33 lb — 55 lb) 6 to 12 years old 22 kg —...
Page 42 Always read the manufacturer's instructions and this owner's manual Junior seat carefully. Equal to Group 2 and 3 of the UNECE 44 Due to variations in the design of regulation. child-restraint systems, vehicle seats and seat belts, all child-restraint systems may not t all seating positions.
Page 43 Essential Safety Equipment Child Restraint Baby Seat Installation Position WARNING A baby seat is used in the rear-facing position only. Never use a rear-facing child-restraint system on the front passenger seat protected by an air bag: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the...
Page 44 Essential Safety Equipment Child Restraint Rear-facing type Front-facing type WARNING WARNING Always install a rear-facing child seat Never install a front-facing child seat in the correct seat position: in the wrong seat position: Installing a rear-facing child seat Installing a front-facing child seat without rst consulting the table without rst consulting the table “Child-Restraint System Suitability for...
Page 45 Essential Safety Equipment Child Restraint Junior Seat Installation Position WARNING A junior seat is used in the front-facing position only. Always install a junior seat in the correct seat position: Installing a junior seat without rst consulting the table “Child-Restraint System Suitability for Various Seat Positions”...
Page 46: Child-Restraint System Suitability For Various Seat Positions Table
GROUP 2 15 kg — 25 kg (33 lb — 55 GROUP 3 22 kg — 36 kg (48 lb — 79 (1) For the CRS which do not carry the ISO/XX size class identi cation (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle speci c ISOFIX child-restraint system(s) recommended for each position.
Page 47 (Except Europe) Regarding child-restraint systems which can be installed to your Mazda, consult an expert repairer, we recommend an Authorised Mazda Repairer. X = ISOFIX position not suitable for ISOFIX child-restraint systems in this mass group and/or this size class.
Page 48 Essential Safety Equipment Child Restraint (Except Europe) Regarding child-restraint systems which can be installed to your Mazda, consult an expert repairer, we recommend an Authorised Mazda Repairer. X = Seat position not suitable for children in this mass group. *1 When a child-restraint system is installed to the rear centre seat, do not seat occupants in the rear right outboard seat position.
Page 49: Installing Child-Restraint Systems
Essential Safety Equipment Child Restraint Installing Child-Restraint WARNING Systems Always attach the tether strap to the Anchor Bracket correct tether anchor position: Attaching the tether strap to the Anchor brackets for securing child- incorrect tether anchor position is restraint systems are equipped in the dangerous.
Page 50 Essential Safety Equipment Child Restraint WARNING WARNING Always remove the head restraint and (Hatchback) set the tether strap: Tether strap Routing the tether strap on top of the head restraint is dangerous. In a collision the tether strap could slide off the head restraint and loosen the child- restraint system.
Page 51 Essential Safety Equipment Child Restraint Using ISOFIX Anchor WARNING WARNING Make sure there are no seat belts or foreign objects near or around the ISOFIX anchor-secured child-restraint Follow the manufacturer's instructions system: for the use of the child-restraint Not following the child-restraint system system: manufacturer's instructions when An unsecured child-restraint system...
Page 52 Essential Safety Equipment Child Restraint 3. Expand the area between the seat 6. If your child-restraint system came bottom and the seatback slightly to equipped with a tether, that probably verify the locations of the ISOFIX means it is very important to properly anchor.
Page 53 Essential Safety Equipment Child Restraint WARNING WARNING Always remove the head restraint and Always install the head restraint and set the tether strap: adjust it to the appropriate position Routing the tether strap on top of after removing the child-restraint the head restraint is dangerous.
Page 54: Srs Air Bags
Essential Safety Equipment SRS Air Bags Supplementary Restraint System (SRS) Precautions The front and side supplementary restraint systems (SRS) include different types of air bags. Please verify which kinds of air bags are equipped on your vehicle by locating the “SRS AIRBAG”...
Page 55 Essential Safety Equipment SRS Air Bags WARNING Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to in ate only in the rst accident, such as frontal, near frontal or side collisions that are at least moderate.
Page 56 Essential Safety Equipment SRS Air Bags WARNING Sit in the centre of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them, or sleeping up against the door or hanging out the windows is extremely dangerous. The side and curtain air bags in ate with great force and speed directly expanding along the door on the side the car is hit.
Page 57 An expert repairer, we recommend an Authorised Mazda Repairer can provide the special care needed in the removal and installation of front seats. It is important to protect the air bag wiring and connections to assure that the bags do not accidentally deploy and the seats retain an undamaged air bag connection.
Page 58 Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury could result. Have an expert repairer, we recommend an Authorised Mazda Repairer safely dispose of the air bag system or scrap an air bag equipped vehicle.
Page 59 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 60: Front Passenger Air Bag Deactivation Switch
Essential Safety Equipment SRS Air Bags Front Passenger Air Bag Deactivation Switch WARNING Do not deactivate the front passenger air bag unnecessarily: Unnecessary deactivation of the front passenger air bag is dangerous. If turned off unnecessarily, the front passenger will not receive the added protection of the air bag. Serious injuries or even death could occur.
Page 61 NOTE Have the front passenger air bag deactivation switch inspected by an expert repairer, we recommend an Authorised Mazda Repairer if any of these conditions occur: The front passenger air bag deactivation indicator light does not illuminate for a speci ed period of time when the ignition is switched ON.
Page 62 OFF. 2. Remove the key. 3. Make sure the air bag deactivation indicator light remains illuminated when the ignition is switched ON. The front passenger front and side air bags and also the seat belt pretensioner system will remain deactivated until the front passenger air bag deactivation switch is turned to the ON position.
Page 63 ON. 2. Remove the key. 3. Make sure the air bag deactivation indicator light remains illuminated when the ignition is switched ON. The air bag deactivation indicator light turns off after a short period of time.
Page 64: Supplementary Restraint System Components
Essential Safety Equipment SRS Air Bags Supplementary Restraint System Components Driver/Front passenger in ators and air bags Crash sensors, and diagnostic module (SAS unit) Seat belt pretensioners (page 2-17 ) Front air bag sensor Side crash sensors Air bag/seat belt pretensioner system warning light (page 4-42 ) Side and curtain in ators and air bags Front passenger air bag deactivation indicator light (page 2-44 )
Page 65: How The Srs Air Bags Work
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 66 Essential Safety Equipment SRS Air Bags Front Passenger Air Bag The front passenger air bag is mounted in the front passenger instrument panel. The in ation mechanism for the front passenger air bag is the same as the driver's air bag. For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"...
Page 67 Essential Safety Equipment SRS Air Bags Curtain Air Bags The curtain air bags are mounted in the front and rear window pillars, and the roof edge along both sides. When the air bag crash sensors detect a side impact of greater than moderate force, the curtain air bag in ates quickly and helps to reduce injury mainly to the rear outboard passenger's head caused by directly hitting interior parts such as a door or window.
Page 68: Srs Air Bag Deployment Criteria
Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal collision A severe side collision A rear collision equipment...
Page 69: Limitations To Srs Air Bag
Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity. Limitations to front/near front collision detection: The following illustrations are examples of front/near front collisions that may not be detected as severe enough to deploy the SRS air bag equipment.
Page 70 Essential Safety Equipment SRS Air Bags Limitations to side collision detection: The following illustrations are examples of side collisions that may not be detected as severe enough to deploy the SRS air bag equipment. Side impacts with two-wheeled vehicles Side impacts involving trees or poles Roll-over 2–54...
Page 71 Security System ......... 3-48 Keys ..........3-2 Modi cation and Add-On Keyless Entry System ....3-3 Equipment ........3-48 Immobilizer System ..... 3-48 Advanced Keyless Entry System ..3-9 Theft-Deterrent System (With the Advanced Keyless Entry Intrusion Sensor) ......3-50 System ...........
Page 72: Keys
There is equipment which If your key (auxiliary key) is lost, consult discharges radio waves near the your Authorised Mazda Repairer and have vehicle. your code number ready. 3–2...
Page 73: Keyless Entry System
If you have a problem with the key, consult an expert repairer, we recommend an Authorised Mazda Repairer. If your key is lost or stolen, consult an Authorised Mazda Repairer as soon as possible for a replacement and to make the lost or stolen key inoperative. CAUTION...
Page 74 (Without the Intrusion Sensor) on page 3-54 . Additional keys can be obtained at an Authorised Mazda Repairer. Up to 6 keys can be used with the keyless functions per vehicle. Bring all keys to an Authorised Mazda Repairer when additional keys are required.
Page 75 2. Open the driver's door. key. 3. Within 30 seconds of opening the (With the advanced keyless driver's door, press and hold the function (Except European LOCK button on the key for 5 models)) seconds or longer.
Page 76 (With double locking system) lid, press the lock button and the hazard Pressing the lock button twice within warning lights will ash once. 3 seconds will activate the double (With the advanced keyless function locking system. (Except European models)) Refer to Double Locking System on A beep sound will be heard once.
Page 77 30 seconds. Refer to Theft-Deterrent System on page If your vehicle has a theft-deterrent 3-50 . system, the hazard warning lights will ash for con rmation. The time required for the doors to lock automatically can be changed.
Page 78 Operational range NOTE The engine may not start if the key is placed in the following areas: Around the instrument panel In the storage compartments such as the glove compartment or the centre console On the rear parcel shelf (saloon) 3–8...
Page 79: Advanced Keyless Entry System
Before using the key near people who repairer, we recommend an Authorised use medical devices, ask the medical Mazda Repairer for details. If the device manufacturer or your physician advanced keyless entry system has been if radio waves from the key will affect deactivated, you can start the engine by the device.
Page 80: Operational Range
For Operational range determining battery replacement, Refer to Keyless Entry System on page 3-3 . Locking, Unlocking the Doors and the Liftgate/Boot Lid Exterior aerial 80 cm (31in) Locking only...
Page 81: Doors And Locks
3–11...
Page 82 If you have any problems with the double the air bags, all the doors and the locking system, consult an expert repairer, liftgate/boot lid are automatically we recommend an Authorised Mazda unlocked after about 6 seconds have Repairer. elapsed from the time of the accident.
Page 83 1. Close all the windows and the sunroof 2. Switch the ignition off and take the key with you. 3. Close all doors and the liftgate/boot lid. 4. Insert the auxiliary key in the driver's NOTE door, turn the auxiliary key to the lock...
Page 84 Request switch To lock To lock the doors and the liftgate/boot lid, press the request switch and the hazard warning lights will ash once. (Except European models) A beep sound will be heard once. 3–14...
Page 85 The double locking system can 2. Open the driver's door. be activated/deactivated using the 3. Within 30 seconds of opening the request switch. driver's door, press and hold the Refer to Double Locking System on LOCK button on the key for 5 page 3-12 .
Page 86 Always make entry system transmitter, refer to Keyless sure that all doors and the liftgate/ Entry System (page 3-3 ). boot lid are closed and locked before leaving the vehicle. The auto-lock function does not close the power windows.
Page 87 The doors and the liftgate/boot lid can be set to lock or unlock automatically by selecting any one of the functions from the following table and using the driver's door- lock switch on the interior door panel. 3–17 *Some models.
Page 88 1. Safely park the vehicle. All doors must remain closed. 2. Switch the ignition ON. Function 3. Press and hold the lock side of the Function number driver's door-lock switch within 20 The auto door-lock function is seconds of switching the ignition ON, disabled.
Page 89 Press 2 times door-lock switch. Function Number 2 Cancel setting Press 3 times Locking, Unlocking with Door- Wait for 3 second Lock Knob Function Number 3 Function set (The Operation from inside number of beeps Press 4 times...
Page 90 The door can only be opened by pulling lock position and close the door (holding the outside handle. the door handle in the open position is not required). This does not operate the other door locks. Unlock Door-lock knob Lock 3–20...
Page 91: Liftgate/Boot Lid
Otherwise, the luggage may move or collapse, resulting in injury or an accident. In addition, do not load luggage higher than the seatbacks. It may affect the side or rear eld of view. Damper stay 3–21...
Page 92: Boot Lid
(Saloon) CAUTION Do not modify or replace the liftgate damper stay. Consult an expert repairer, we recommend an Authorised Mazda Repairer if a liftgate damper stay is deformed Electric boot lid or damaged for reasons such as a opener collision or if there is some other problem.
Page 93 Boot lid grip recess system and the liftgate/boot lid cannot be unlocked, the liftgate/boot lid can be opened by performing the emergency procedure. Refer to When Liftgate/Boot Lid Cannot be Opened on page 7-57 . 3–23...
Page 94: Luggage Compartment
CAUTION Make sure the luggage compartment 3. Lift the front end of the luggage cover is rmly secured. If it is not compartment cover and remove it. rmly secured, it could unexpectedly disengage resulting in injury.
Page 95 2. Place the second golf bag in the boot with its bottom pointed to the left and t it into the back of the boot. NOTE Some golf bags cannot t depending on their size. 3–25...
Page 96: Fuel And Emission
(LHD), Panama, Peru, B. Virgin, Curacao, Burundi, Gabon, Ghana, Tanzania, Mozambique *1 Europe *2 Republic of Palau & Federated States of Micronesia Fuel with a lower rating will negatively affect the emission control system performance and could also cause engine knocking and serious engine damage. 3–26...
Page 97 Never add fuel system additives, otherwise the emission control system could be damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. Fuel Requirements (SKYACTIV-D 1.5, SKYACTIV-D 2.2) The vehicle will operate ef ciently on diesel fuel with speci cation EN590 or the equivalent.
Page 98 USE ONLY UNLEADED FUEL. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 99 Either condition will damage the converter and cause poor performance. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 100 When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact an expert repairer, we recommend an Authorised Mazda Repairer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 101: Fuel-Filler Flap And Cap
Before Driving Fuel and Emission Fuel-Filler Flap and Cap CAUTION WARNING Always use only a designated Mazda fuel- ller cap or an approved equivalent, available at an expert repairer, we When removing the fuel- ller cap, recommend an Authorised Mazda loosen the cap slightly and wait for any Repairer.
Page 102 Fuel-Filler Cap To remove the fuel- ller cap, turn it anticlockwise. Attach the removed cap to the inner side of the fuel ap. To close the fuel- ller cap, turn it clockwise until a click is heard. Open Close 3–32...
Page 103: Steering Wheel
2. Tilt the steering wheel and/or adjust the steering column length to the desired positions, then push the lever up to lock the column. 3. Attempt to push the steering wheel up and down to make sure it's locked before driving. 3–33...
Page 104 Otherwise, it could cause a low- temperature burn. Infants, small children, elderly people, and physically challenged people People with delicate skin People who are excessively fatigued People who are intoxicated People who have taken sleep- inducing medicine such as sleeping pills or cold medicine 3–34...
Page 105: Mirrors
The perceived distance of objects in the outer and inner regions of the wide angle mirror is different. Objects appearing in the outer region are actually further away than they are in the inner region. 3–35 *Some models.
Page 106 Your rear view will dangerous. Wind blast on the mirror be restricted, and you could have an will cause them to collapse and you will accident. be unable to return it to the on-road position, preventing rearview visibility. 3–36...
Page 107 The outside mirrors can be operated for about 40 seconds after the ignition is switched from ON to off with all doors closed. If any door is opened, the outside Fold out mirrors will stop operating. Fold in 3–37 *Some models.
Page 108: Rearview Mirror
NOTE To reactivate the auto-dimming function, For the manual antidazzle mirror, press the ON/OFF button . The indicator perform the adjustment with the light will illuminate. antidazzle lever in the day position. Indicator light ON/OFF button 3–38...
Page 109 Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor The auto-dimming function is cancelled when the ignition is switched ON and the shift/selector lever is in reverse (R). 3–39...
Page 110: Windows
Power window switches that are not the driver's door is in the unlocked locked with the power window lock position (page 3-45 ). switch would allow children to operate Each passenger window can also be power windows unintentionally, which...
Page 111 5. Repeat Steps 3-4 for the front passenger power window while seated in the front passenger seat. Auto-opening/closing 6. Repeat Steps 3-4 for both the left and right rear power windows while seated To fully open the window automatically, in the rear seat.
Page 112 In the event the jam-safe function activates and the power window cannot be closed automatically, pull and hold the switch fully and the window will close. The jam-safe window function does not operate until the system has been reset. 3–42...
Page 113 3. Press the switch and fully open the In the event the jam-safe function window. activates and the power window 4. Pull up the switch to fully close the...
Page 114 Operating the Passenger Power Windows (Type B) Front passenger's window To open the window to the desired position, hold down the switch. Right rear window To close the window to the desired position, pull up the switch. Close Open 3–44...
Page 115 The light may be dif cult operated. to see depending on the surrounding Unlocked position (button not brightness. depressed): All power windows on each door can be operated. (With door-lock switch) Locked position Unlocked position (Without door-lock switch) Locked position Unlocked position 3–45...
Page 116: Sunroof
ON. water does not get inside the cabin area. After washing your Mazda or after it Tilt/Slide switch rains, wipe the water off the sunroof before operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 117 2. Press the tilt switch, to partially tilt sunroof is opening. Trying to force open the rear of the sunroof. the sunshade closed could damage it. 3. Repeat Step 2. The rear of the sunroof tilts open to the fully open position, then closes a little. NOTE...
Page 118: Security System
Immobilizer System Equipment The immobilizer system allows the engine to start only with a key the system Mazda cannot guarantee the immobilizer recognises. and the theft-deterrent systems' operation if the system has been modi ed or if any If someone attempts to start the engine add-on equipment has been installed.
Page 119 Operation Switch the ignition off, and then restart the engine. If the engine does not start NOTE after 3 or more tries, contact an Authorised Mazda Repairer. The engine may not start and security indicator light may illuminate or NOTE...
Page 120: Theft-Deterrent System (With The Intrusion Sensor)
Do not install seats that are not Intrusion sensor Mazda genuine products. To prevent obstruction of intrusion The intrusion sensor uses ultrasonic waves sensor, do not place objects or cargo to detect movement inside the vehicle and...
Page 121 The intrusion sensor detects a movement in the vehicle. 2. Switch the ignition OFF. The system will be triggered again (up to 3. Make sure the bonnet, the doors, and 10 times) if one of the above conditions the liftgate/boot lid are closed. remains.
Page 122 Leaving the vehicle with a movable closed. object, passengers or pets remaining Refer to Transmitter on page 3-4 . inside. The system will disarm if one of Leaving an object inside the vehicle the following operations takes place...
Page 123 The hazard warning lights will ash twice. NOTE When the doors are unlocked by pressing the unlock button on the transmitter while the theft-deterrent system is turned off, the hazard warning lights will ash twice to indicate that the system is turned off. 3–53...
Page 124: Theft-Deterrent System (Without The Intrusion Sensor)
The system will not function unless it's 2. Switch the ignition OFF. properly armed. So when you leave the 3. Make sure the bonnet, the doors, and vehicle, follow the arming procedure the liftgate/boot lid are closed. correctly. 4. Press the lock button on the transmitter...
Page 125 Refer to Transmitter on page 3-4 . The system will disarm if one of To Stop an Alarm the following operations takes place...
Page 126: Driving Tips
(avoid sudden braking). Avoid unnecessary hard stops. Follow the maintenance schedule (page Avoid full-throttle starts. 6-3 ) and have an expert repairer, Do not tow a trailer. we recommend an Authorised Mazda Repairer perform inspections and servicing. Use the air conditioner only when necessary.
Page 127: Hazardous Driving
Driving Tips Hazardous Driving Floor Mat We recommend the use of Genuine WARNING Mazda oor mats. WARNING Be extremely careful if it is necessary to downshift on slippery surfaces: Downshifting into lower gear while Make sure the oor mats are secured...
Page 128: Rocking The Vehicle
1 (D) to R. When setting a oor mat, position the oor mat so that its grommets or retainers are inserted over the pointed end of the retention posts. 3–58...
Page 129: Winter Driving
If this situation occurs, Ask an expert repairer, we recommend an drive the vehicle slowly, releasing Authorised Mazda Repairer to check the the accelerator pedal and lightly following: applying the brakes several times until the brake performance returns Have the proper ratio of antifreeze in the to normal.
Page 130 Before Driving Driving Tips Tyre Chains Tyre chain selection (Europe) Mazda recommends hexagon type Check local regulations before using tyre steel ring chains. Select the proper type chains. according to your tyre size. CAUTION Chains may affect handling. Do not go faster than 50 km/h (30...
Page 131: Driving In Flooded Area
2. Secure the chains on the front tyres as repairer, we recommend an Authorised tightly as possible. Always follow the Mazda Repairer. chain manufacturer's instructions. 3. Retighten the chains after driving 1/2—1 km (1/4—1/2 mile). 3–61...
Page 132: Turbocharger Information (Skyactiv-D 1.5, Skyactiv-D 2.2)
To get the most from it, observe the following. 1. Change engine oil and lter according to Scheduled Maintenance (page 6-3 ). 2. Use only recommended engine oil (page 6-22 ). Extra additives are NOT recommended.
Page 133: Towing
Never overload vehicle or trailer. Consult an Authorised Mazda Dealer if you need further details. CAUTION Do not tow a trailer during the rst 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components.
Page 134 1,000 meter (3,280 ft 10 in), always reduce the towing load by 10% for every 1,000 meter (3,280 ft 10 in) increase in altitude from the load indicated under the gross combination weight heading in the maximum trailer towing-load table. If the determined maximum total towing load weight is exceeded, the engine and other power train parts may be damaged.
Page 135 3,430 kg Hatchback EURO6 × — transaxle (1,432.9 lb) (3,306.9 lb) (7,561.7 lb) ×: Available —: Not available TRAILER NOSE WEIGHT: 75 kg (165.3 lb) Germany and Austria/Gradient up to 8% GROSS TOTAL TRAILER MODEL COMBINATION WEIGHT WEIGHT Trailer Emission i-stop...
Page 136 3,430 kg Hatchback EURO6 × — transaxle (1,432.9 lb) (3,306.9 lb) (7,561.7 lb) ×: Available —: Not available TRAILER NOSE WEIGHT: 75 kg (165.3 lb) Russia/Gradient up to 12% GROSS TOTAL TRAILER MODEL COMBINATION WEIGHT WEIGHT Trailer Emission i-stop i-ELOOP...
Page 137 3,135 kg Hatchback EURO5 — — transaxle (1,322.7 lb) (2,865.9 lb) (6,911.4 lb) ×: Available —: Not available TRAILER NOSE WEIGHT: 75 kg (165.3 lb) Israel/Gradient up to 12% GROSS TOTAL TRAILER MODEL COMBINATION WEIGHT WEIGHT Trailer Emission i-stop i-ELOOP...
Page 138 (2,645.5 lb) (6,746.0 lb) ×: Available —: Not available TRAILER NOSE WEIGHT: 75 kg (165.3 lb) WARNING Always keep tow loads within speci ed limits as indicated in the Trailer Towing-Load Table: Attempting to tow loads greater than those speci ed is dangerous as it may cause serious handling and performance problems that could result in personal injury or vehicle damage, or both.
Page 139: Trailer Hitch
Trailer Hitch When towing a trailer, use an appropriate trailer hitch. We recommend using a genuine Mazda trailer hitch. Use the original holes drilled by the vehicle manufacture for securing the trailer hitch. Contact your Authorised Mazda Dealer for more information.
Page 140 Before Driving Towing Trailer hitch installation area (Hatchback) Unit:mm (in) A:350—420 (13.8—16.5) B:931.3 (36.67) C:1046.9 (41.217) MAX 75 Kg (165 lb) Hitch coupling point Tyres When towing a trailer, make sure all tyres are in ated to the recommended cold-tyre pressure, as indicated on the tyre pressure chart on the driver's door frame.
Page 141: Trailer Lights
Authorised Mazda Dealer. Trailer Brakes Check the Maximum trailer towing-load table in Weight Limits (page 3-63 ), and if your trailer weight exceeds the value in the TOTAL TRAILER WEIGHT (Trailer without brake), trailer brakes are required.
Page 142 Stop and re-inspect all lights and connections after driving a short distance. Driving Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and stopping in a traf c-free area. Take time to get accustomed to the extra weight and length.
Page 143 1. Start the engine (page 4-5 ). 2. Release the parking brake and slowly pull away a short distance from the wheel blocks. 3. Stop on the nearest level ground, set the parking brake, and pick up the wheel blocks. 3–73...
Page 144 MEMO 3–74...
Page 145 When Driving Information concerning safe driving and stopping. Start/Stop Engine ........ 4-4 Brake ..........4-84 Ignition Switch ....... 4-4 Brake System ....... 4-84 Starting the Engine ......4-5 Emergency Stop Signal System ... 4-90 Turning the Engine Off ....4-12 Hill Launch Assist (HLA) ...
Page 146 Rear Cross Traf c Alert Rear View Monitor ......4-221 (RCTA) ........4-141 Rear View Monitor ....4-221 Mazda Radar Cruise Control (MRCC) ........4-146 Parking Sensor System ....4-230 Lane-keep Assist System (LAS) & Parking Sensor System ..... 4-230...
Page 147 MEMO 4–3...
Page 148: Start/Stop Engine
When Driving Start/Stop Engine Ignition Switch The power supply to electrical devices turns off and the push button start indicator Push Button Start Positions light (amber) also turns off. The system operates only when the key is In this position the steering wheel is within operational range.
Page 149: Starting The Engine
ON, the sound of the fuel pump key. Consult an expert repairer, we motor operating near the fuel tank can recommend an Authorised Mazda be heard. This does not indicate an Repairer for details. If the push abnormality.
Page 150 Indicator light 1. Make sure you are carrying the key. 2. Occupants should fasten their seat belts. 3. Make sure the parking brake is on. 4. Continue to press the brake pedal Push button start rmly until the engine has completely started.
Page 151 Refer to Engine Start Function When is dif cult for the system to detect Key Battery is Dead on page 4-10 . the signal (page 3-7 ). A key from another manufacturer similar to the key is in the CAUTION operational range.
Page 152 When Driving Start/Stop Engine NOTE NOTE When the engine is force-started, (SKYACTIV-D 1.5, SKYACTIV-D the KEY warning light (red) remains 2.2) illuminated and the push button When starting the engine, do start indicator light (amber) remains not release the clutch pedal ashing.
Page 153 NOTE If the engine has stopped due to stalling, it can be restarted by (Germany) depressing the clutch pedal within 3 Drive immediately after starting the seconds of the engine stopping. engine. However do not use high The engine cannot be restarted even...
Page 154 3. Verify that the push button start signal from the key will not be received indication light (green) ashes. correctly and the engine may not start.
Page 155 In this case, the engine may at an expert repairer, we recommend an start, however, have the vehicle Authorised Mazda Repairer as soon as checked at an expert repairer, we possible. If this occurs, the engine can recommend an Authorised Mazda be force-started.
Page 156: Turning The Engine Off
(Automatic transaxle) and set the parking brake. If the engine is turned off while the 3. Press the push button start to turn off selector lever is in a position other the engine. The ignition position is off. than P, the ignition switches to ACC.
Page 157: I-Stop
2. While depressing the clutch pedal, shift the shift lever to the neutral position. Engine idling stops after the clutch pedal is released. 3. (SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-G 2.5) The engine restarts automatically when you depress the clutch pedal or start to release it.
Page 158 D or M position (not in second gear xed mode). 3. If the selector lever is in the N or P position, the engine does not restart when the brake pedal is released. The engine restarts when the brake pedal is depressed again or the selector lever is shifted to the D, M (not in second gear xed mode) or the R position.
Page 159 When Driving Start/Stop Engine (Manual transaxle) The vehicle speed is 3 km/h (1.8 mph) or less. The shift lever is in the neutral position. The clutch pedal is not depressed. (Automatic transaxle) The vehicle is stopped. The selector lever is in the D or M position (not in second gear xed mode).
Page 160 When Driving Start/Stop Engine NOTE Under the following conditions, a period of time is required to stop engine idling The battery power is depleted for some reasons such as the vehicle has not been driven for a long period. The ambient temperature is high or low. After the battery terminals are disconnected for some reasons such as for battery replacement.
Page 161 Battery terminals are disconnected Engine idling may not stop right after the battery terminals are disconnected. In addition, if the battery is replaced, the i-stop functions must be veri ed. Consult an expert repairer, we recommend an Authorised Mazda Repairer. 4–17...
Page 162 When Driving Start/Stop Engine i-stop Warning Light (Amber)/i-stop Indicator Light (Green) To ensure safe and comfortable use of the vehicle, the i-stop system constantly monitors the driver's operations, the vehicle's interior and exterior environment, and the operational status of the vehicle, and uses the i-stop warning light (amber) and i-stop indicator light (green) to inform the driver of various cautions and warnings.
Page 163 NOTE A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light does not turn on when the ignition is switched ON. The light continues to remain on even though the i-stop OFF switch has been pressed while the engine is running.
Page 164 When Driving Start/Stop Engine i-stop OFF Switch The i-stop function can be turned off by pressing the switch until the beep sounds and the i-stop warning light (amber) in the instrument cluster illuminates. The i-stop function can be turned back on by pressing the switch again until the beep sounds and the i-stop warning light (amber) turns off.
Page 165 When Driving Start/Stop Engine Vehicle Roll Prevention Function (Automatic transaxle) Vehicles with i-stop are equipped with a vehicle roll prevention function. This function prevents the vehicle from rolling, such as when releasing the brake pedal while on a slope under the following conditions: During idling stop (prevents the vehicle from rolling back) When starting from a stop (prevents the vehicle's sudden movement due to vehicle creep) The braking force is maintained automatically when the brake pedal is released and the...
Page 166 When Driving Start/Stop Engine WARNING The vehicle roll prevention function is a supplementary function which operates for a maximum of four seconds after releasing the brake pedal when starting the vehicle after the vehicle is stopped with the i-stop function operating: Over reliance on the system may result in an unexpected accident if the vehicle were to suddenly accelerate.
Page 167: Instrument Cluster And Display
When Driving Instrument Cluster and Display Meters and Gauges Instrument Cluster Type A (Digital Speed Meter Type) Type B (Analog Speed Meter Type (With Tachometer)) Type C (Analog Speed Meter Type (Without Tachometer)) Steering Switch Some models. Speedometer ......................page 4-24 Odometer, Trip Meter and Trip Meter Selector ............
Page 168 When Driving Instrument Cluster and Display Trip Computer and INFO Switch ................page 4-29 Speed Unit Selector ....................page 4-24 Speedometer Odometer, Trip Meter and Trip Meter Selector The speedometer indicates the speed of the vehicle. The display mode can be changed from odometer to trip meter A to trip meter B Speed Unit Selector (Type A and then back to odometer by pressing the...
Page 169 When Driving Instrument Cluster and Display Type C Trip meter The trip meter can record the total distance of two trips. One is recorded in trip meter Selector A, and the other is recorded in trip meter For instance, trip meter A can record the distance from the point of origin, and trip meter B can record the distance from where the fuel tank is lled.
Page 170 When Driving Instrument Cluster and Display NOTE CAUTION Only the trip meters record tenths of Type B kilometres (miles). The trip record will be erased when: The power supply is interrupted *1 Striped zone (blown fuse or the battery is *1 Red zone disconnected).
Page 171: Instrument Panel Illumination
When Driving Instrument Cluster and Display Type A NOTE After refuelling, it may require some Full time for the indicator to stabilize. In addition, the indicator may deviate while driving on a slope or curve since the fuel moves in the tank. The display indicating a quarter 1/4 Full or less remaining fuel has more...
Page 172 When Driving Instrument Cluster and Display The brightness of the instrument cluster NOTE and instrument panel illuminations can be adjusted by rotating the knob. When the illumination dimmer is cancelled, the instrument cluster The brightness decreases by rotating the cannot be dimmed even if the knob to the left.
Page 173 If you have any problems with your trip ten seconds and a beep sound is heard computer, consult an expert repairer, once. we recommend an Authorised Mazda Repairer. NOTE If the outside temperature is lower than -20 °C (-4 °F), the beep sound does not operate.
Page 174 The display may not change unless you add more than approximately 9 L This mode displays the current fuel (2.3 US gal, 1.9 Imp gal) of fuel. economy by calculating the amount of fuel The distance-to-empty is the consumption and the distance travelled.
Page 175 When Driving Instrument Cluster and Display Average vehicle speed mode NOTE This mode displays the average vehicle Always set the vehicle speed speed by calculating the distance and the according to the laws and regulations time travelled since connecting the battery of the country/city in which the or resetting the data.
Page 176: Multi-Information Display
When Driving Instrument Cluster and Display Multi-information Display Multi-information display INFO switch The multi-information display indicates the following information. Odometer Trip meter Fuel gauge Outside temperature Distance-to-empty Average fuel economy Current fuel economy Lane Departure Warning System (LDWS) Display Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display Cruise Control Display Warning message The screen content changes each time the INFO switch is pressed.
Page 177 When Driving Instrument Cluster and Display Fuel Gauge (SKYACTIV-D 1.5, SKYACTIV-D 2.2) If inconsistency in engine performance The fuel gauge shows approximately or stalling occurs due to low fuel level how much fuel is remaining in the tank conditions, refuel the vehicle as soon as when the ignition is switched ON.
Page 178 ON. The outside temperature display ashes. 2. Press the INFO switch to change the outside temperature unit. 3. Press and hold the INFO switch for 3 seconds or longer while the outside temperature display is ashing. The NOTE outside temperature display illuminates.
Page 179 When you've slowed to about 5 km/h (3 battery leads are disconnected, the mph), - - - L/100 km (- - - mpg) will be actual distance-to empty/range may displayed.
Page 180 When Driving Instrument Cluster and Display Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Display Displays the system status. Refer to Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) on page 4-159 . Cruise Control Set Vehicle Speed Display The vehicle speed preset using the cruise control is displayed.
Page 181 When Driving Instrument Cluster and Display Warning (Display Indication) A message is displayed to notify the user of the system operation status and malfunctions or abnormalities. If the warning light turns on/ ashes simultaneously or a symbol is indicated in the display, check the information regarding the warning light or symbol.
Page 182: Active Driving Display
When Driving Instrument Cluster and Display Active Driving Display Combiner Mirror Optical receiver WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident. CAUTION Do not place beverages near the active driving display.
Page 183 Refer to Traf c Sign Recognition System (TSR) on page 4-128 . Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-146 . Lane Departure Warning System (LDWS) Warnings Refer to Lane Departure Warning System (LDWS) on page 4-114 .
Page 184 1. Select the icon on the home screen and display the Settings screen. 2. Select the AD-Disp tab. 3. Select the desired item and perform the setting/adjustment. Method for adjusting screen brightness (automatically/manually) Screen brightness initial settings (automatic adjustment is selected)
Page 185: Warning/Indicator Lights
When Driving Instrument Cluster and Display Warning/Indicator Lights Instrument Cluster varies depending on model and speci cations. Instrument Cluster Type A (Digital Speed Meter Type) Type B (Analog Speed Meter Type (With Tachometer)) Type C (Analog Speed Meter Type (Without Tachometer)) Centre of Instrument panel Warning/Indicator lights will appear in any of the highlighted areas 4–41...
Page 186: Warning Lights
When Driving Instrument Cluster and Display Warning Lights These lights turn on or ash to notify the user of the system operation status or a system malfunction. Signal Warning Page Brake System Warning Light *1*2 7-34 Electronic Brake Force Distribution ABS Warning Light System Warning 7-34 ,...
Page 187 Except malfunction (Red) 7-43 Adaptive LED Headlights (ALH) Warning Light 7-38 (Amber) Mazda Radar Cruise Control (MRCC) Warning Light 7-38 (Amber) Lane Departure Warning System (LDWS) Warning Light 7-38 Lane-keep Assist System (LAS) & Lane Departure Warning System 7-38 (LDWS) Warning Light...
Page 188 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. *2 The light turns on continuously when the parking brake is applied.
Page 189 When Driving Instrument Cluster and Display Signal Indicator Lights Page i-stop Indicator Light 4-18 (Green) i-ELOOP Indicator Light 4-98 (Green) Shift Position Indication 4-55 Lights-On Indicator Light 4-65 Headlight High- Low Beam 4-69 , Headlight High-Beam Indicator Light Flashing the Headlights 4-69 Turn and Lane-...
Page 190 When Driving Instrument Cluster and Display Signal Indicator Lights Page Mazda Radar Cruise Control (MRCC) Indicator Light 4-150 (Green) Advanced Smart City Brake Support (Advanced SCBS) 4-183 , Smart City Brake Support [Forward] Smart Brake Support/Smart City Brake Support (SBS/SCBS) Indicator...
Page 191 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. *2 The light turns on continuously when the parking brake is applied. (With electric parking brake)
Page 192 If the low engine coolant temperature indicator light remains illuminated after the engine has been suf ciently warmed up, the temperature sensor could have a malfunction. Consult an expert repairer, we recommend an Authorised Mazda Repairer. Glow Indicator Light (SKYACTIV-D 1.5, SKYACTIV-D 2.2) This light may illuminate when the ignition is switched ON.
Page 193: Manual Transaxle Operation
When Driving Manual Transaxle Operation Manual Transaxle Shift WARNING Pattern Do not use sudden engine braking on slippery road surfaces or at high 5-speed transaxle speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine Neutral position braking, which is dangerous.
Page 194 If the engine has stopped due to Indication Condition stalling, it can be restarted by The selected gear position is depressing the clutch pedal within 3 Numeral displayed. seconds of the engine stopping. Shift up or down to the indicated...
Page 195 When Driving Manual Transaxle Operation NOTE The Gear Shift Indicator (GSI) turns off when the following operations are performed. The vehicle is stopped. The vehicle is put in neutral. The vehicle is driven in reverse. The clutch is not fully engaged when accelerating from a stop.
Page 196: Automatic Transaxle
When Driving Automatic Transaxle Automatic Transaxle Controls Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift.
Page 197: Shift-Lock System
1. Depress and hold the brake pedal. screwdriver. 2. Start the engine. 2. Insert a screwdriver and push it down. 3. Press and hold the lock-release button. 4. Move the selector lever. NOTE When the ignition is switched to ACC or the ignition is switched off,...
Page 198: Transaxle Ranges
You must be at a complete stop before shifting to or from R, except Do not shift into N when driving the under rare circumstances as explained in vehicle. Doing so can cause transaxle Rocking the Vehicle (page 3-58 ). damage. 4–54...
Page 199 When Driving Automatic Transaxle Active Adaptive Shift (AAS) NOTE Active Adaptive Shift (AAS) Apply the parking brake or depress the automatically controls the transaxle shift brake pedal before moving the selector points to best suit the road conditions lever from N to prevent the vehicle from and driver input.
Page 200: Manual Shift Mode
When Driving Automatic Transaxle Manual Shift Mode Indicators The manual shift mode gives you the feel Manual shift mode indication of driving a manual transaxle vehicle by In manual shift mode, the “M” of the shift allowing you to operate the selector lever position indication in the instrument panel manually.
Page 201 When Driving Automatic Transaxle Type C Gear Shift Indicator (GSI) The gear shift indicator supports you to obtain optimum fuel economy and smooth driving. It displays the selected gear position in the instrument cluster as well as noti es the driver to change to the most suitable gear position corresponding to the actual driving condition.
Page 202 When Driving Automatic Transaxle Using steering shift switch NOTE To shift up to a higher gear with the The gear shift indicator turns off when steering shift switches, pull the UP switch the following operations are performed. ) toward you once with your ngers.
Page 203 When Driving Automatic Transaxle Manually Shifting Down NOTE You can shift gears down by operating When driving slowly, the gears may the selector lever or the steering shift not shift up. switches Do not drive the vehicle with the 4-speed transaxle model: M4 tachometer needle in the RED ZONE while in manual shift mode.
Page 204 When Driving Automatic Transaxle Second Gear Fixed Mode WARNING When the selector lever is moved back while the vehicle speed is about 10 km/h Do not use engine braking on slippery (6.2 mph) or less, the transaxle is set in the road surfaces or at high speeds: second gear xed mode.
Page 205 When Driving Automatic Transaxle Shift Gear (Shifting) Speed Limit For each gear position while in the manual mode, the speed limit is set as follows: When the selector lever is operated within the range of the speed limit, the gear is shifted. (4-speed transaxle model) (6-speed transaxle model) Shift up...
Page 206 When Driving Automatic Transaxle Auto-shift down The gear shifts down automatically depending on the vehicle speed during deceleration. NOTE If the vehicle comes to a stop while in the second gear xed mode, the gear remains in second. 4–62...
Page 207: Direct Mode
When Driving Automatic Transaxle Direct Mode Type B Direct mode can be used for temporarily switching gears by operating the steering shift switch while the vehicle is being driven with the selector lever in the D range. While in direct mode, the D and M indication illuminate and the gear position in use is illuminated.
Page 208: Driving Tips
1. Depress the brake pedal. speed. 2. Shift to D or M1, depending on the load weight and grade steepness. 3. Release the brake pedal while gradually accelerating. Descending steep grades When descending a steep grade, shift to lower gears, depending on load weight and grade steepness.
Page 209: Switches And Controls
When Driving Switches and Controls Lighting Control Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless safety requires them.
Page 210 When Driving Switches and Controls Without auto-light control Switch Position ACC or ACC or ACC or Ignition Position Headlights Running lights Tail lights Position lights Number plate lights *1 The lights are turned on while the vehicle is driven. *2 The lights are turned on continuously if the ignition is switched from ON to any other position with the lights turned on.
Page 211 *1 The lights are turned on while the vehicle is driven. *2 The lights are turned on by the auto light function. *3 The lights are turned on while the vehicle is driven, and turned off when the headlights are turned on by the auto light function.
Page 212 When Driving Switches and Controls Auto-light control When the headlight switch is in the position and the ignition is switched ON, the light sensor senses the surrounding lightness or darkness and automatically turns the headlights and other exterior lights on or off. CAUTION Do not shade the light sensor by adhering a sticker or a label on the windscreen.
Page 213 Refer to Personalisation Features on page 9-17 . If no operations are done for 3 minutes after the lever is pulled, the headlights turn off. Headlight flashing...
Page 214 When Driving Switches and Controls Leaving Home Light Headlight Levelling The leaving home light turns on the lights The number of passengers and weight of when the transmitter unlock button is cargo in the luggage compartment change pressed while away from the vehicle. the angle of the headlights.
Page 215: Front Fog Lights
When Driving Switches and Controls Select the proper headlight angle from the Front Fog Lights following chart. The front fog lights can be used when the Front seat Rear Switch ignition is switched ON. Load seat Position Driver Passenger Use this switch to turn on the front fog ×...
Page 216: Rear Fog Light
When Driving Switches and Controls Rear Fog Light NOTE The rear fog light can be used when the (With auto-light control) ignition is switched ON. If the fog light switch is in the The rear fog light helps your vehicle to be position or the headlight switch is in seen.
Page 217 When Driving Switches and Controls To turn the rear fog light off, do any of the Without Front Fog Light following: The headlights must be turned on to turn Rotate the fog light switch to the on the rear fog light. position again (the fog light switch returns to the position automatically).
Page 218: Turn And Lane-Change Signals
When Driving Switches and Controls Turn and Lane-Change Lane-Change Signals Signals Move the lever halfway toward the direction of the lane change—until the The ignition must be switched ON to use indicator ashes— and hold it there. It will the turn and lane-change signals. return to the off position when released.
Page 219: Windscreen Wipers And Washer
OFF, consult an expert repairer, we recommend an Authorised Mazda Only use windscreen washer uid Repairer as soon as possible. mixed with anti-freeze protection in...
Page 220 When Driving Switches and Controls Windscreen Wipers With auto-wiper control Turn the wipers on by pressing the lever up or down. With intermittent wiper Switch Position Wiper operation Type Type Operation while pulling up lever Switch Position Wiper operation Stop Type Type Auto control...
Page 221 When Driving Switches and Controls Auto-wiper control CAUTION When the wiper lever is in the position, the rain sensor senses the amount Do not shade the rain sensor by of rainfall on the windscreen and turns the adhering a sticker or a label on the wipers on or off automatically (off—...
Page 222 (page 6-34 ). If the uid level If the auto-wiper lever is left in the is normal, consult an expert repairer, position, the wipers could we recommend an Authorised Mazda operate automatically from the effect Repairer. of strong light sources,...
Page 223: Rear Window Wiper And Washer
To spray washer uid, turn the rear wiper/ 2. Turn on the headlights. washer switch to either of the position. 3. Double ick the wiper lever After the switch is released, the washer several times until the washer will stop.
Page 224: Rear Window Defogger
When Driving Switches and Controls Rear Window Defogger Dual-Zone Automatic Air-Conditioning The rear window defogger clears fog from Indicator light the rear window. The ignition must be switched ON to use the defogger. Press the switch to turn on the rear window defogger.
Page 225 When Driving Switches and Controls Mirror Defogger Dual-Zone Automatic Air-Conditioning The mirror defoggers defrost the outside Indicator light mirrors. The mirror defoggers operate in conjunction with the rear window defogger. To turn on the mirror defoggers, switch the ignition ON and press the rear window defogger switch (page 4-80 ).
Page 226: Horn
When Driving Switches and Controls Horn Hazard Warning Flasher The hazard warning lights should always To sound the horn, press the mark on be used when you stop on or near a the steering wheel. roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traf c hazard and that they must take extreme caution when near it.
Page 227 When Driving Switches and Controls NOTE The direction indicators do not work when the hazard warning lights are Check local regulations about the use of hazard warning lights while the vehicle is being towed to verify that it is not in violation of the law. If the brake pedal is depressed while driving on slippery roads, the emergency stop signal system could...
Page 228: Brake
When Driving Brake Brake System WARNING Foot Brake Do not coast with the engine stalled or turned off, nd a safe place to stop: This vehicle has power-assisted brakes Coasting with the engine stalled or that adjust automatically through normal turned off is dangerous.
Page 229: Parking Brake
NOTE The brakes can overheat For parking in snow, refer to Winter and adversely affect brake Driving (page 3-59 ) regarding parking performance. brake use. Always depress the brake pedal with the right foot. Applying the brakes...
Page 230: Electric Parking Brake
When Driving Brake Releasing the parking brake WARNING Depress the brake pedal and pull the parking brake lever upwards, then press Do not drive the vehicle with the the release button. While holding the electric parking brake applied: button, lower the parking brake lever all If the vehicle is driven with the the way down to the released position.
Page 231 When Driving Brake When applying the electric parking NOTE brake If the electric parking brake switch The electric parking brake can be applied is continually pulled while driving regardless of the ignition switch position. the vehicle, the electric parking Securely depress the brake pedal and pull brake will be applied and the electric up the electric parking brake switch.
Page 232: Warning Light
When Driving Brake Electric parking brake manual release Electric parking brake automatic release Securely depress the brake pedal and press down the electric parking brake switch. If the accelerator pedal is depressed with the electric parking brake applied and all of the following conditions met, the parking brake is released automatically.
Page 233 When you hear this noise, consult an brakes will apply more rmly. This expert repairer, we recommend an is a normal effect of the brake assist Authorised Mazda Repairer as soon as operation and does not indicate a possible. malfunction.
Page 234: Emergency Stop Signal System
System Hill Launch Assist (HLA) is a function which assists the driver in accelerating Your Mazda is equipped with an from a stop while on a slope. When emergency stop signal system that is the driver releases the brake pedal and...
Page 235 When Driving Brake NOTE WARNING Hill Launch Assist (HLA) does not Do not rely completely on Hill Launch operate on a gentle slope. In addition, Assist (HLA): the gradient of the slope on which Hill Launch Assist (HLA) is an the system will operate changes auxiliary device for accelerating from depending on the vehicle's load.
Page 236: Abs/Tcs/Dsc
When Driving ABS/TCS/DSC Antilock Brake System NOTE (ABS) Braking distances may be longer on loose surfaces (snow or gravel, The ABS control unit continuously for example) which usually have a monitors the speed of each wheel. If hard foundation. A vehicle with a one wheel is about to lock up, the ABS normal braking system may require responds by automatically releasing and...
Page 237: Traction Control System (Tcs)
Take your vehicle to an expert Do not rely on the Traction Control repairer, we recommend an Authorised System (TCS) as a substitute for safe Mazda Repairer. driving: The Traction Control System (TCS) NOTE cannot compensate for unsafe and...
Page 238: Dynamic Stability Control (Dsc)
Use tyres of the correct size as ABS and TCS to help control side slip speci ed for your Mazda on all when driving on slippery surfaces, or four wheels. during sudden or evasive manoeuvring, Use tyres of the same enhancing vehicle safety.
Page 239 If the DSC OFF switch is pressed your vehicle to an expert repairer, we and held for 10 seconds or more, recommend an Authorised Mazda the DSC OFF switch malfunction Repairer. The DSC may have a detection function operates and the malfunction.
Page 240: I-Eloop
When Driving i-ELOOP i-ELOOP i-ELOOP is a regenerative braking system. When you depress the brake pedal or use engine braking, the kinetic energy that occurs is converted to electrical energy by the power generator and the converted electrical energy is stored in the rechargeable battery (capacitor and battery).
Page 241 A difference in the fuel economy may occur depending on how the vehicle's electrical devices are used. If the capacitor is to be disposed of, always consult an expert repairer, we recommend an Authorised Mazda Repairer. For details, go to the following URL. http://www.mazda.com/csr/environment/recycling...
Page 242 When Driving i-ELOOP i-ELOOP Indicator Light/Control NOTE Status Display The beep will sound if the vehicle is The driver is noti ed of the i-ELOOP driven while the i-ELOOP indicator power generating status and the vehicle light is ashing. In addition, if you conditions by the i-ELOOP indicator light turn the steering wheel while the and the control status display.
Page 243: Fuel Economy Monitor
2. Select the “Fuel Economy Monitor”. 3. Operate the commander switch or touch the screen and display the menu. NOTE When the menu is displayed by touching the screen, the display is hidden automatically after 6 seconds.
Page 244 When Driving Fuel Economy Monitor Fuel Consumption Display Information regarding the fuel economy is displayed. Indication on display Control status Displays the fuel economy for the past 60 minutes. Displays the fuel economy every minute for the past 1 to 10 minutes. Displays the fuel economy every 10 minutes for the past 10 to 60 minutes.
Page 245 When Driving Fuel Economy Monitor Indication on display Control status With i-ELOOP system Displays the status of the electricity stored in the rechargeable battery and being supplied to the electrical devices (whole vehicle in display is illuminated simultaneously). Displays the accumulated fuel economy. With i-ELOOP system Displays the readiness status as to whether operation of the i-stop function is available.
Page 246 When Driving Fuel Economy Monitor Indication on display Control status With i-ELOOP system Displays the i-stop function status while the vehicle is stopped. Indicates the operations required by the driver to operate the i-stop function while it is not operating. Without i-ELOOP system Displays the current amount of time that the i-stop function has been operating and the accumulated...
Page 247 When Driving Fuel Economy Monitor Effectiveness Display The actual performance of the energy ef ciency is displayed. Indication on display Control status The leaf graphic grows according to the amount of CO 2 emissions reduced by the system effects. The cumulative total amount of leaf growth is indicated in terms of the number of tree graphics.
Page 248: Drive Selection
It may cause tyre slipping. NOTE When the sport mode is selected, driving at higher engine speeds increases and it may increase fuel consumption. Mazda recommends that you cancel the sport mode on normal driving. Drive mode cannot be switched in the following conditions: ABS/TCS/DSC is operating The Mazda Radar Cruise Control (MRCC) system/cruise control is operating.
Page 249 When Driving Drive Selection Drive Selection Switch Select Mode Indicator Light Press the drive selection switch forward When the sport mode is selected, the select mode indicator light turns on in the (“ ”) to select the sport mode. instrument cluster. Pull the drive selection switch back (“...
Page 250: Power Steering
If the steering feels stiffer than usual during normal driving or the steering vibrates, consult an expert repairer, we recommend an Authorised Mazda Repairer. The warning indication/warning light noti es the driver of system abnormalities and operation conditions.
Page 251 Driver Attention Alert (DAA) ................... 4-138 Rear obstruction detection when leaving a parking space Rear Cross Traf c Alert (RCTA) ..................4-141 Driver support systems Inter-vehicle distance Mazda Radar Cruise Control (MRCC) ................4-146 Lane departure Lane-keep Assist System (LAS) ..................4-159 4–107 *Some models.
Page 252: I-Activsense
When Driving i-ACTIVSENSE Speed control Adjustable Speed Limiter ....................4-173 Pre-Crash Safety Technology Pre-crash safety technology is designed to assist the driver in averting collisions or reduce their severity in situations where they cannot be avoided. Collision damage reduction in low vehicle speed range Forward driving Smart City Brake Support [Forward] (SCBS F) ...............
Page 253 The radar sensor (front) functions by detecting the radio waves re ected off a vehicle ahead sent from the radar sensor. The following systems also use the radar sensor (front). Mazda Radar Cruise Control (MRCC) Distance Recognition Support System (DRSS) Smart Brake Support (SBS) The radar sensor (front) is mounted behind the radiator grille.
Page 254: Adaptive Front Lighting System (Afs)
When Driving i-ACTIVSENSE Adaptive Front Lighting System (AFS) The adaptive front lighting system (AFS) automatically adjusts the headlight beams to the left or right in conjunction with the operation of the steering wheel after the headlights have been turned on. NOTE Headlights do not blind drivers approaching in the opposite direction...
Page 255: Adaptive Led Headlights (Alh)
When Driving i-ACTIVSENSE Adaptive LED Headlights (ALH) The Adaptive LED Headlights (ALH) are a system which uses the Forward Sensing Camera (FSC) to determine the situation of a vehicle ahead or a vehicle approaching in the opposite direction while driving at night to automatically switch the illumination range of the headlights, the illuminated area, or the illumination brightness.
Page 256 When Driving i-ACTIVSENSE Wide-Range Low Beam This feature extends the illumination range of the light cast by the low beams while driving at a speed less than about 40 km/h (25 mph). Highway Mode This feature shifts the illumination angle of the light cast by the headlights upward while driving on highways.
Page 257 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Adaptive LED Headlights (ALH) may not operate normally. Manually switch between the high and low beams according to the visibility, and the road and traf c conditions. When there are other sources of light in the area such as street lamps, illuminated signboards, and traf c signals.
Page 258: Lane Departure Warning System (Ldws)
When Driving i-ACTIVSENSE Lane Departure Warning System (LDWS) The LDWS alerts the driver that the vehicle may be deviating from its lane. If the white (yellow) lines on the traf c lane are detected using the Forward Sensing Camera (FSC) and the system determines that the vehicle may be deviating from its lane, it noti es the driver by ashing the LDWS warning light and activating the LDWS warning beep, and by the multi-information display (vehicles with multi-information display) and the active driving...
Page 259 When Driving i-ACTIVSENSE WARNING Do not use the LDWS under the following conditions: The system may not operate adequately according to the actual driving conditions, resulting in an accident. Driving on roads with tight curves. Driving under bad weather conditions (rain, fog, and snow). The functions of the LDWS have limitations: Always stay on course using the steering wheel and drive with care.
Page 260 When Driving i-ACTIVSENSE NOTE Under the following conditions, the LDWS may not be able to detect white or yellow lines correctly and the LDWS may not operate correctly. If an object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 261 When Driving i-ACTIVSENSE When the System Operates The LDWS does not operate in the following cases: If the LDWS OFF indicator light in the The system cannot detect white or instrument cluster turns off when the yellow lines. ignition is switched ON, the system goes The vehicle speed is less than about 65 on standby.
Page 262 The direction indicator lever is operated (after the direction indicator lever is returned, the LDWS may not operate for about 3 seconds which is the period of time required to make a lane correction). Auto cancel NOTE In the following cases, the LDWS cancels...
Page 263 When Driving i-ACTIVSENSE Cancelling the System LDWS Warning Press the LDWS OFF switch to cancel the If the system determines that there is the LDWS. The LDWS OFF indicator light possibility of a lane departure, the LDWS turns on. warning beep activates and the LDWS (Vehicles with multi-information warning light ashes.
Page 264 When Driving i-ACTIVSENSE NOTE If the LDWS warning sound is set to rumble , the sound will be heard from the vehicle speaker on the side which the system determined the vehicle may be deviating from its lane. It may be dif cult to hear the LDWS warning beep depending on the surrounding conditions such as outside noise.
Page 265: Blind Spot Monitoring (Bsm)
When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) The Blind Spot Monitoring (BSM) is designed to assist the driver in checking the area to the rear of the vehicle on both sides during lane changes by notifying the driver of the presence of vehicles approaching from the rear in an adjacent lane.
Page 266 If the Blind Spot Monitoring (BSM) warning indication/warning light remains illuminated, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning indicator lights is detected.
Page 267 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensors (rear) cannot detect target objects or it may be dif cult to detect them. A vehicle is in the detection area at the rear in an adjacent driving lane but it does not approach.
Page 268 When Driving i-ACTIVSENSE NOTE The Blind Spot Monitoring (BSM) warning indicator light may turn on and the vehicle detection screen may be displayed in the display in reaction to stationary objects (guardrails, tunnels, sidewalls, and parked vehicles) on the road or the roadside. Objects such as guardrails and concrete walls Places where the width between guardrails or running alongside the vehicle.
Page 269 When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) Warning Indicator Lights/Blind Spot Monitoring (BSM) Warning Beep The Blind Spot Monitoring (BSM) or Rear Cross Traf c Alert (RCTA) system noti es the driver of the presence of vehicles in adjacent lanes or at the rear of the vehicle using the Blind Spot Monitoring (BSM) warning indicator light, the warning sound and the display indicator (vehicles with active driving display) while the systems are operational.
Page 270 When Driving i-ACTIVSENSE Function for cancelling illumination dimmer If the Blind Spot Monitoring (BSM) warning indicator lights turn on when the position lights are turned on, the brightness of the Blind Spot Monitoring (BSM) warning indicator lights is dimmed. If the Blind Spot Monitoring (BSM) warning indicator lights are dif cult to see due to glare from surrounding brightness when travelling on snow-covered roads or under foggy conditions, press the dimmer cancellation button to cancel the dimmer and increase the brightness of Blind Spot Monitoring (BSM) warning indicator lights when they turn on.
Page 271 When Driving i-ACTIVSENSE Cancelling Operation of Blind Spot NOTE Monitoring (BSM) When the ignition is switched OFF, The Blind Spot Monitoring (BSM) the system status before it was turned and Rear Cross Traf c Alert (RCTA) off is maintained. For example, if the systems are turned off and the Blind Spot ignition is switched OFF while the Monitoring (BSM) OFF indicator light in...
Page 272: Traf C Sign Recognition System (Tsr)
Authorised Mazda Repairer. The Traf c Sign Recognition System (TSR) operates only if the navigation system SD card (Mazda genuine) is inserted in the SD card slot. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details.
Page 273 When Driving i-ACTIVSENSE WARNING Always check the traf c signs visually while driving. The Traf c Sign Recognition System (TSR) helps prevent the driver from overlooking traf c signs and provides support for safe driving. Depending on the weather conditions or problems with traf c signs, a traf c sign may not be recognised or a traf c sign different from the actual traf c sign may be displayed.
Page 274 When Driving i-ACTIVSENSE NOTE The Traf c Sign Recognition System (TSR) does not operate if there is a malfunction in the Forward Sensing Camera (FSC). Under the following conditions, the Traf c Sign Recognition System (TSR) may not operate normally. An object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 275 When Driving i-ACTIVSENSE Traf c Sign Display Indication The following traf c signs are displayed on the active driving display. Speed limit signs (including auxiliary signs) Inclement weather speed limit sign Do not enter signs The above indications are some examples. If the Forward Sensing Camera (FSC) cannot classify an auxiliary sign (such as time restrictions, turning restrictions, end of section) correctly, the following screen is displayed.
Page 276 When Driving i-ACTIVSENSE NOTE Speed limit signs (including auxiliary signs) When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is displayed when any one of the following conditions are met. The Forward Sensing Camera (FSC) recognises a speed limit sign as a sign targeted for your vehicle and the vehicle passes it.
Page 277 3 times in amber, and if the vehicle speed continues to exceed the displayed speed limit sign, the indication stops ashing and remains on. Check the surrounding conditions and adjust the vehicle speed to the legal speed using the appropriate operation such as depressing the brake pedal.
Page 278 Off: The excessive speed warning is not activated. Warning display only: The area around the speed limit sign ashes 3 times in amber, and if the vehicle speed continues to exceed the displayed speed limit sign, the indication stops ashing and remains on.
Page 279: Distance Recognition Support System (Drss)
When Driving i-ACTIVSENSE Distance Recognition Support System (DRSS) The Distance Recognition Support System (DRSS) measures the distance between your vehicle and a vehicle ahead using a radar sensor (front) while the vehicle speed is about 30 km/h (19 mph) or faster, and if your vehicle approaches a vehicle ahead more closely than what is appropriate for maintaining distance between the vehicles according to the vehicle speed, a noti cation in the active driving display is indicated to advise you to keep a safe distance from the vehicle ahead.
Page 280 The Distance Recognition Support System (DRSS) operation status is indicated in the active driving display. Regarding malfunctions, check the vehicle conditions or have it inspected by an expert repairer, we recommend an Authorised Mazda Repairer according to the content of the displayed message.
Page 281 When Driving i-ACTIVSENSE NOTE The distance at which the distance-between-vehicles indication in the display ashes can be changed. Refer to Personalisation Features on page 9-17 . 4–137...
Page 282: Driver Attention Alert (Daa)
When Driving i-ACTIVSENSE Driver Attention Alert (DAA) The Driver Attention Alert (DAA) is a system which detects driver fatigue and decreased attentiveness, and encourages the driver to take a rest. When the vehicle is driven inside traf c lane lines at about 65 to 140 km/h (41 to 86 mph), the Driver Attention Alert (DAA) estimates the amount of accumulated fatigue and decreased attentiveness of the driver based on the information from the Forward Sensing Camera (FSC) and other vehicle information, and encourages the driver to take a rest using...
Page 283 When Driving i-ACTIVSENSE NOTE The Driver Attention Alert (DAA) operates when all of the following conditions are met. The vehicle speed is about 65 to 140 km/h (41 to 86 mph). The system detects white (yellow) lane lines. The system has completed learning of the driver’s driving data. The Driver Attention Alert (DAA) does not operate under the following conditions.
Page 284 When Driving i-ACTIVSENSE Driver Attention Alert (DAA) Display When the system detects driver fatigue or decreased attentiveness, it activates the warning sound and displays an alert in the active driving display. Cancelling Driver Attention Alert (DAA) The Driver Attention Alert (DAA) can be set to not activate.
Page 285: Rear Cross Traf C Alert (Rcta)
When Driving i-ACTIVSENSE Rear Cross Traf c Alert (RCTA) The Rear Cross Traf c Alert (RCTA) system is designed to assist the driver in checking the area to the rear of the vehicle on both sides while the vehicle is reversing by alerting the driver to the presence of vehicles approaching the rear of the vehicle.
Page 286 When Driving i-ACTIVSENSE Rear Cross Traf c Alert (RCTA) operation 1. The Rear Cross Traf c Alert (RCTA) system operates when the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted to the reverse (R) position. 2. If there is the possibility of a collision with an approaching vehicle, the Blind Spot Monitoring (BSM) warning indicator lights ashes and the warning beep is activated simultaneously.
Page 287 If the Blind Spot Monitoring (BSM) warning indication/warning light remains illuminated, have the vehicle inspected at an Authorised Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning indicator lights has occurred.
Page 288 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensors (rear) cannot detect target objects or it may be dif cult to detect them. The vehicle speed when reversing is about 10 km/h (6 mph) or faster. The radar sensor (rear) detection area is obstructed by a nearby wall or parked vehicle.
Page 289 When Driving i-ACTIVSENSE NOTE In the following cases, it may be dif cult to view the illumination/ ashing of the Blind Spot Monitoring (BSM) warning indicator lights equipped on the door mirrors. Snow or ice adheres to the door mirrors. The front door glass is fogged or covered in snow, frost or dirt.
Page 290: Mazda Radar Cruise Control (Mrcc)
WARNING Do not rely completely on the Mazda Radar Cruise Control (MRCC) system and always drive carefully: The Mazda Radar Cruise Control (MRCC) system is designed to reduce load on the...
Page 291 For the purposes of safety, switch the Mazda Radar Cruise Control (MRCC) system off when it is not being used. CAUTION If the vehicle is towed or you are towing something, switch the Mazda Radar Cruise Control (MRCC) system off to prevent an incorrect operation. 4–147...
Page 292 When Driving i-ACTIVSENSE NOTE The Mazda Radar Cruise Control (MRCC) system operates when all of the following conditions are met. The vehicle speed is as follows: (European models) About 30 km/h (19 mph) to 200 km/h (124 mph) (Except European models) About 30 km/h (19 mph) to 145 km/h (90 mph) The Mazda Radar Cruise Control (MRCC) system is turned on.
Page 293 NOTE While the Mazda Radar Cruise Control (MRCC) system is in use, it does not cancel even if the selector lever (automatic transaxle)/shift lever (manual transaxle) is operated and any intended engine braking will not occur. If deceleration is required, lower the vehicle speed setting or depress the brake pedal.
Page 294 NOTE When the ignition is switched to ACC or OFF while the Mazda Radar Cruise Control (MRCC) is ON, the Mazda Radar Cruise Control (MRCC) remains ON automatically. When the MODE switch is pressed while the Mazda Radar Cruise Control (MRCC) system is turned on, the system switches to the cruise control function.
Page 295 When Driving i-ACTIVSENSE NOTE If a vehicle ahead is detected while travelling at a constant speed, the vehicle-ahead indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed.
Page 296 When Driving i-ACTIVSENSE NOTE The distance between vehicles differs depending on the vehicle speed, and the slower the vehicle speed, the shorter the distance. When the ignition is switched to ACC or OFF and then the engine is started again, the system automatically sets the distance between vehicles to the previous setting.
Page 297 When the system is temporarily The driver's seat belt is unfastened. cancelled (Manual transaxle) In the following cases, the Mazda Radar The shift lever is shifted to neutral Cruise Control (MRCC) is temporarily (N) for a certain period of time.
Page 298 RES switch and after all of the operation conditions have been met. If the Mazda Radar Cruise Control (MRCC) system is deactivated, the system does not return to the previously set speed even if the RES switch is pressed.
Page 299 Shift-up/Shift-down Request Display (Manual Transaxle) The shift-up or shift-down request display in the active driving display may be indicated while the Mazda Radar Cruise Control (MRCC) is operating. When this occurs, shift gears because the gear position is not appropriate.
Page 300 Switching to cruise control function When the MODE switch is pressed while While this function is operating, the the Mazda Radar Cruise Control (MRCC) headway control operation is cancelled system is turned on, the system switches to and only the cruise control function the cruise control function.
Page 301 When Driving i-ACTIVSENSE How to Decrease the Set Speed NOTE Press the SET switch continuously and The system may not be able to release the switch at the desired speed. maintain the set speed constantly The set speed can be adjusted depending on driving conditions such incrementally (1 km/h (1 mph) increments) as steep up or down slopes.
Page 302 When Driving i-ACTIVSENSE NOTE If the vehicle speed decreases by about 15 km/h (9.4 mph) or more than the set speed, the cruise control function may be cancelled. When the vehicle speed is less than 21 km/h (13 mph), the cruise control function is cancelled.
Page 303: Lane-Keep Assist System (Las) & Lane Departure Warning System (Ldws)
When Driving i-ACTIVSENSE Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) alerts the driver that the vehicle may be deviating from its lane and it provides steering assistance to help the driver stay within the vehicle lanes.
Page 304 Departure Warning System (LDWS) can operate normally. Do not modify the suspensions. Always use wheels of the speci ed type and size for the front and rear wheels. Consult an expert repairer, we recommend an Authorised Mazda Repairer for tyre replacement. 4–160...
Page 305 When Driving i-ACTIVSENSE NOTE When the direction indicator lever is operated for a lane change, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) is automatically disabled. The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) becomes operational again when the direction indicator lever is returned and the system detects white (yellow) lane lines while the vehicle is being driven normally within its vehicle lane.
Page 306 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) may not be able to detect white (yellow) lane lines correctly and it may not operate normally. If an object placed on the instrument panel is re ected in the windscreen and picked up by the camera.
Page 307 When Driving i-ACTIVSENSE System Operation If the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF indicator light in the instrument cluster turns off when the ignition is switched ON, the system goes on standby. If the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF indicator light in the instrument cluster turns on when the ignition is switched ON, press the Lane-keep Assist System (LAS) &...
Page 308 When Driving i-ACTIVSENSE The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) goes on stand-by status in the following cases: The system cannot detect white (yellow) lane lines. The vehicle speed is less than about 60 km/h (37 mph). The ABS/TCS/DSC is operating.
Page 309 When Driving i-ACTIVSENSE NOTE If you take your hands off the steering wheel (not holding the steering wheel), the warning sound is activated and an alert is indicated in the multi-information display or active driving display. If the steering wheel is held lightly, or depending on the road conditions, the system may detect that you have released the steering wheel (not holding the steering wheel) even if you are holding it, and display a message in the active driving display.
Page 310 When Driving i-ACTIVSENSE Auto cancel In the following cases, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) is automatically cancelled and the vehicle lane lines (stand-by) are indicated in the multi-information display or active driving display. In addition, when the Lane-keep Assist System (LAS) &...
Page 311 When Driving i-ACTIVSENSE Steering operation assist OFF (non-operational) The steering operation assist for the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) can be changed to non-operational (OFF). Refer to Setting Change (Personalisation Features) on page 9-17 . When the steering operation assist has been changed to inoperable (OFF), operate the Lane- keep Assist System (LAS) &...
Page 312 When Driving i-ACTIVSENSE NOTE The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) remains on stand-by until it detects white (yellow) lines on both the left and right sides, or on either side. When the system detects a white (yellow) lane line on one side only, the system will not activate warnings for the lane line on the side that is not being detected.
Page 313 When Driving i-ACTIVSENSE (Auto cancel of warnings) When the following operations are performed, the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) determines that the driver intends to make a lane change and the system operation is cancelled automatically. The Lane-keep Assist System (LAS) &...
Page 314 Have your vehicle inspected at Lane Departure Warning System (LDWS) an expert repairer, we recommend an OFF indicator light turns on. Authorised Mazda Repairer. There is a malfunction in the power steering. There is a malfunction in the DSC.
Page 315: Lane Departure Warning
When Driving i-ACTIVSENSE Lane Departure Warning If the system determines that the vehicle may deviate from its lane, the lane departure warning (beep sound, rumble sound , or steering wheel vibration) is activated and the direction in which the system determines that the vehicle may deviate is indicated in the multi-information display or the active driving display.
Page 316 When Driving i-ACTIVSENSE NOTE The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) can be changed to the following settings regardless of whether the steering operation assist has been set to operational/non-operational. Always check the setting status when driving the vehicle and make setting changes if necessary.
Page 317: Adjustable Speed Limiter
The system consists of the adjustable speed limiter display and the speed limiter switch on the steering wheel. Active Driving Display Display in the instrument cluster With multi- Without multi- information display information display Mazda Radar Cruise Control (MRCC) Cruise control system MODE switch SET+ switch RES/+ switch RES switch SET- switch SET- switch...
Page 318 (Type A instrument cluster ) or the display in the instrument cluster (Type B instrument cluster *1 To determine which instrument cluster is equipped on your Mazda, Refer to Meters and Gauges on page 4-23 . Stand-by display Displays when the speed limiter switch is operated and the system is turned on.
Page 319 When Driving i-ACTIVSENSE Cancel display Displays when any of the following operations is done and the system is temporarily cancelled. OFF/CAN switch is operated Accelerator pedal is strongly depressed Active Driving Display Display in the instrument cluster With multi- Without multi- information display information display Adjustable Speed Limiter Main Indicator Light (Amber)/Adjustable Speed...
Page 320 If the set speed is set lower than the current vehicle speed by pressing the SET or RES / switch, the warning beep is not activated for about 30 seconds even if the vehicle speed is faster than the newly set speed by 3 km/h (2 mph). Be careful not to drive over the set speed.
Page 321 Press the OFF/CAN switch. The adjustable speed limiter screen is no longer displayed and the adjustable speed limiter set indicator light (amber) turns off. NOTE When the MODE switch is pressed while the adjustable speed limiter is operating, the system switches to the cruise control or Mazda Radar Cruise Control (MRCC) system. 4–177...
Page 322 When the current vehicle speed is less than 30 km/h (20 mph), the speed is set to 30 km/h (20 mph). (With Mazda Radar Cruise Control (MRCC)) Press the SET or SET to set the speed. When the current vehicle speed is 30 km/h (20 mph) or more, the speed is set to the current vehicle speed.
Page 323 When the vehicle set speed is displayed in the instrument cluster, press the RES / switch to set the displayed vehicle speed. With Mazda Radar Cruise Control (MRCC) When the vehicle set speed is displayed in the instrument cluster, press the RES switch to set the displayed vehicle speed.
Page 324: Advanced Smart City Brake Support (Advanced Scbs) (Except The Philippines, Taiwan)
When Driving i-ACTIVSENSE Advanced Smart City Brake Support (Advanced SCBS) (Except The Philippines, Taiwan) The Advanced Smart City Brake Support (Advanced SCBS) alerts the driver of a possible collision using the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead or pedestrian and determines that a collision with the object is unavoidable while the vehicle is driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph) if the object is a vehicle ahead and about 10 to 80 km/h (6.2 to 50 mph) if the object is...
Page 325 When Driving i-ACTIVSENSE CAUTION In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off-road. Refer to Stopping the Advanced Smart City Brake Support (Advanced SCBS) System Operation on page 4-184 on how to turn off the Advanced Smart City Brake Support (Advanced SCBS) system.
Page 326 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Advanced Smart City Brake Support (Advanced SCBS) system may not operate normally: The Advanced Smart City Brake Support (Advanced SCBS) system will not operate if the driver is deliberately performing driving operations (accelerator pedal and steering wheel).
Page 327 2 seconds and the Advanced changed. SCBS brake is automatically Refer to Personalisation Features on released. page 9-17 . (With SCBS OFF switch) The operation distance and volume of the collision warning can be changed. Consult an Authorised Mazda Repairer. 4–183...
Page 328 When Driving i-ACTIVSENSE Stopping the Advanced Smart City With SCBS OFF switch Brake Support (Advanced SCBS) Press the SCBS OFF switch to turn System Operation off the system. The Smart City Brake Support (SCBS) OFF indicator light in the The Advanced Smart City Brake Support instrument cluster will illuminate.
Page 329: Smart City Brake Support [Forward] (Scbs F) (The Philippines, Taiwan)
When Driving i-ACTIVSENSE Smart City Brake Support [Forward] (SCBS F) (The Philippines, Taiwan) The Smart City Brake Support [Forward] (SCBS F) system alerts the driver of a possible collision using an indication in the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead and determines that a collision with a vehicle ahead is unavoidable while the vehicle is being driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph).
Page 330 When Driving i-ACTIVSENSE CAUTION When driving off-road in areas where there is dense grass, it is recommended that the Smart City Brake Support [Forward] (SCBS F) system be turned off. In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle.
Page 331 When Driving i-ACTIVSENSE NOTE Under the following conditions, the Smart City Brake Support [Forward] (SCBS F) system may not operate normally: The Smart City Brake Support [Forward] (SCBS F) system will not operate if the driver is deliberately performing driving operations (accelerator pedal and steering wheel).
Page 332 SCBS brake is automatically changed. released. Refer to Personalisation Features on page 9-17 . (With SCBS OFF switch) The operation distance and volume of the collision warning can be changed. Consult an Authorised Mazda Repairer. 4–188...
Page 333 When Driving i-ACTIVSENSE Stopping the Smart City Brake With SCBS OFF switch Support [Forward] (SCBS F) Press the SCBS OFF switch to turn System Operation off the system. The Smart City Brake Support (SCBS) OFF indicator light in the The Smart City Brake Support [Forward] instrument cluster will illuminate.
Page 334: Smart City Brake Support [Reverse] (Scbs R)
(rear), stop using the Smart City Brake Support [Reverse] (SCBS R) system immediately and have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. If the vehicle continues to be driven with cracks or scratch marks left around an ultrasonic sensor, the system may operate unnecessarily and cause an unexpected accident.
Page 335 When Driving i-ACTIVSENSE WARNING Do not modify the suspension: If the vehicle height or inclination is changed, the Smart City Brake Support [Reverse] (SCBS R) system may not operate correctly because it cannot detect obstructions correctly. Do not apply a strong force to an ultrasonic sensor (rear): When washing the vehicle, do not spray highly pressurised water against an ultrasonic sensor (rear), or rub it strongly.
Page 336 When Driving i-ACTIVSENSE NOTE The vehicle posture changes depending on the accelerator pedal, brake pedal and steering wheel operations, which could make it dif cult for the system to recognise an obstruction, or it could facilitate unnecessary detection. In such cases, the Smart City Brake Support [Reverse] (SCBS R) may or may not operate.
Page 337 When Driving i-ACTIVSENSE NOTE In the following cases, the ultrasonic sensors (rear) cannot detect obstructions correctly and the Smart City Brake Support [Reverse] (SCBS R) may not operate. Something is stuck on the bumper near an ultrasonic sensor (rear). The steering wheel is turned sharply, or the brake or accelerator pedal is operated. There is another obstruction near one obstruction.
Page 338 When Driving i-ACTIVSENSE Smart City Brake Support (SCBS) NOTE Indicator Light (Red) The collision warning beep sounds If the Smart City Brake Support (SCBS) is intermittently while the SCBS brake operating, the indicator light (red) ashes. is operating. If the vehicle is stopped by the SCBS operation and the brake pedal is not depressed, the warning beep sounds one time after about 2 seconds and...
Page 339 When Driving i-ACTIVSENSE With SCBS OFF switch Press the SCBS OFF switch to turn off the system. The Smart City Brake Support (SCBS) OFF indicator light in the instrument cluster will illuminate. Press the switch again to turn the system back on.
Page 340: Smart Brake Support (Sbs)
When Driving i-ACTIVSENSE Smart Brake Support (SBS) The Smart Brake Support (SBS) system alerts the driver of a possible collision using a display and warning sound if the radar sensor (front) and the Forward Sensing Camera (FSC) determine that there is the possibility of a collision with a vehicle ahead while the vehicle is being driven at about 15 km/h or faster (10 mph or faster).
Page 341 When Driving i-ACTIVSENSE NOTE The Smart Brake Support (SBS) system operates when all of the following conditions are met: The ignition is switched ON. The Smart Brake Support (SBS) system is on. The vehicle speed is about 15 km/h or faster (10 mph or faster). The relative speed between your vehicle and the vehicle ahead is about 15 km/h or faster (10 mph or faster).
Page 342 When Driving i-ACTIVSENSE Smart Brake Support (SBS) NOTE Indicator Light (Red) If the Smart Brake Support (SBS) If the Smart Brake Support (SBS) is system operation is turned off, the Smart operating, the indicator light (red) ashes. City Brake Support (SCBS) system operation is turned off simultaneously.
Page 343: Forward Sensing Camera
When Driving i-ACTIVSENSE Forward Sensing Camera (FSC) Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing Camera (FSC) is positioned near the rearview mirror and used by the following systems. Adaptive LED Headlights (ALH) Driver Attention Alert (DAA) Lane Departure Warning System (LDWS) Lane-keep Assist System (LAS) &...
Page 344 When Driving i-ACTIVSENSE CAUTION Do not apply accessories, stickers or lm to the windscreen near the Forward Sensing Camera (FSC). If the area in front of the Forward Sensing Camera (FSC) lens is obstructed, it will cause the system to not operate correctly. Consequently, each system may not operate normally which could lead to an unexpected accident.
Page 345: (Fsc)
Always keep the windscreen glass around the camera clean by removing dirt or fogging. Use the windscreen defroster to remove fogging on the windscreen. Consult an expert repairer, we recommend an Authorised Mazda Repairer regarding cleaning the interior side of the windscreen around the Forward Sensing Camera (FSC).
Page 346 When Driving i-ACTIVSENSE CAUTION Always use tyres for all wheels that are of the speci ed size, and the same manufacturer, brand, and tread pattern. In addition, do not use tyres with signi cantly different wear patterns on the same vehicle as the system may not operate normally. The Forward Sensing Camera (FSC) includes a function for detecting a soiled windscreen and informing the driver, however, depending on the conditions, it may not detect plastic shopping bags, ice or snow on the windscreen.
Page 347 When Driving i-ACTIVSENSE NOTE In the following cases, the Forward Sensing Camera (FSC) may not be able to detect target objects correctly. Under bad weather condition, such as rain, fog and snow. The window washer is being used or the windscreen wipers are not used when it's raining.
Page 348 When Driving i-ACTIVSENSE NOTE If the Forward Sensing Camera (FSC) cannot operate normally due to backlight or fog, the system functions related to the Forward Sensing Camera (FSC) are temporarily stopped and the following warning lights turn on. However, this does not indicate a malfunction.
Page 349: Radar Sensor (Front)
If the front part of the vehicle has been damaged in a vehicle accident, the position of the radar sensor (front) may have moved. Stop the system immediately and always have the vehicle inspected at an Authorised Mazda Repairer. 4–205...
Page 350 Do not remove, disassemble, or modify the radar sensor (front). For repairs, replacement or paint work around the radar sensor (front), consult an Authorised Mazda Repairer. Do not modify the suspension. If the suspension are modi ed, the vehicle's posture could change and the radar sensor (front) may not be able to correctly detect a vehicle ahead or an obstruction.
Page 351 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensor (front) may not be able to detect vehicles ahead or obstructions. The beginning and end of a curve. Roads with continuous curves. Narrow lane roads due to road construction or lane closures. The vehicle ahead enters the radar sensor's blind spot.
Page 352: Radar Sensors (Rear)
Refer to Exterior Care on page 6-75 . CAUTION If the rear bumper receives a severe impact, the system may no longer operate normally. Stop the system immediately and have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 4–208 *Some models.
Page 353 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork, and replacement near the radar sensors, consult an expert repairer, we recommend an Authorised Mazda Repairer. Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier is installed to the rear of the vehicle.
Page 354: Ultrasonic Sensor (Rear)
When Driving i-ACTIVSENSE Ultrasonic Sensor (Rear) The ultrasonic sensors (rear) function by emitting ultrasonic waves which are re ected off obstructions at the rear and the returning ultrasonic waves are picked up by the ultrasonic sensors (rear). Saloon Hatchback Ultrasonic sensor (rear) Ultrasonic sensor (rear) The ultrasonic sensors (rear) are mounted in the rear bumper.
Page 355: Cruise Control
When Driving Cruise Control Cruise Control With cruise control, you can set and automatically maintain any speed of more than about 25 km/h (16 mph). WARNING Do not use the cruise control under the following conditions: Using the cruise control under the following conditions is dangerous and could result in loss of vehicle control.
Page 356 The cruise main indicator light must be more than 25 km/h (16 mph). (amber) illuminates. 3. Set the cruise control by pressing the To deactivate the system, press the OFF/ SET switch at the desired speed. The CAN switch.
Page 357 When Driving Cruise Control To Increase Cruising Speed NOTE Follow either of these procedures. The cruise control speed setting To increase speed using cruise control cannot be performed under the switch following conditions: Press the RES / switch and hold it. Your (Automatic transaxle) vehicle will accelerate.
Page 358 When Driving Cruise Control To Decrease Cruising Speed NOTE Press the SET switch and hold it. The If any of the following conditions vehicle will gradually slow. occur, the cruise control system is Release the switch at the desired speed. temporarily cancelled.
Page 359 When Driving Cruise Control To Deactivate When a cruising speed has been set (cruise set indicator light (green) turns Long-press the OFF/CAN switch or press the OFF/CAN switch 2 times. When a cruising speed has not been set (cruise main indicator light (amber) turns on) Press the OFF/CAN switch.
Page 360: Tyre Pressure Monitoring System
When Driving Tyre Pressure Monitoring System Tyre Pressure Monitoring System The Tyre Pressure Monitoring System (TPMS) monitors the air pressure of all four tyres. If the air pressure of one or more tyres is too low, the system warns the driver by indicating the tyre pressure monitoring system warning light in the instrument cluster and operating a beep sound.
Page 361 When Driving Tyre Pressure Monitoring System CAUTION Each tyre, including the spare (if provided), should be checked monthly when cold and in ated to the in ation pressure recommended by the vehicle manufacturer on the vehicle placard or tyre in ation pressure label. (If your vehicle has tyres of a different size than the size indicated on the vehicle placard or tyre in ation pressure label, you should determine the proper tyre in ation pressure for those tyres.) As an added safety feature, your vehicle has been equipped with a tyre pressure...
Page 362 The tyre pressure is excessively higher than the speci ed pressure, or the tyre pressure is suddenly lowered for some reason such as a tyre burst during driving. The vehicle speed is lower than about 15 km/h (9.3 mph) (including when the vehicle is stopped), or the drive period is shorter than 5 minutes.
Page 363 (door open). Refer to Tyres on page 9-14 . 3. Switch the ignition ON. 4. Press and hold the tyre pressure monitoring system set switch and verify that the tyre pressure monitoring...
Page 364: Diesel Particulate Filter (Skyactiv-D 1.5, Skyactiv-D 2.2)
If the vehicle is driven at 15 km/h (9 repairer, we recommend an Authorised mph) or less continuously. Mazda Repairer. If the vehicle is not If the vehicle is repeatedly driven for a inspected and continues to be driven, the short period of time (10 minute or less) engine may malfunction.
Page 365: Rear View Monitor
When Driving Rear View Monitor Rear View Monitor The rear view monitor provides visual images of the rear of the vehicle when reversing. WARNING Always drive carefully con rming the safety of the rear and the surrounding conditions by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an accident or a collision with an object.
Page 366 When replacing the tyres, consult an expert repairer, we recommend an Authorised Mazda Repairer. Replacing the tyres could result in deviation of the guide lines which appear on the display. If the vehicle's front, side, or rear has been involved in a collision, the alignment of the rear view parking camera (location, installation angle) may have deviated.
Page 367 When Driving Rear View Monitor Displayable Range on the Screen The images on the screen may be different from the actual conditions. (Screen display) Boot lid (saloon)/ Obstruction detection garnish (hatchback) indication in parking sensor system. Bumper (Actual view) Object Some models NOTE The displayable range varies depending on the vehicle and road conditions.
Page 368 (from the end of the bumper). The red and yellow lines indicate the points about 50 cm (19 in) for the red line and 100 cm (39.3 in) for the yellow lines from the rear bumper (at the centre point of each of the lines).
Page 369: Rear View Monitor Operation
(Display condition) (Vehicle condition) 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal.
Page 370 When Driving Rear View Monitor 5. Once they are parallel, straighten the wheels and back your vehicle slowly into the parking space. Continue checking the vehicle's surroundings and then stop the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) (Display condition) (Vehicle condition)
Page 371 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and distance guide lines may appear aligned in the monitor, but they may not actually be aligned on the ground.
Page 372 When Driving Rear View Monitor When the vehicle is tilted due to the weight of passengers and load When the vehicle rear is lowered, the object displayed on the screen appears farther than the actual distance. Object Variance When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance.
Page 373 1. Select the icon on the screen to display the tabs. 2. Select the desired tab item. 3. Adjust the brightness, contrast, tint, and colour using the slider. If you need to reset, press the reset button. 4. Select the icon on the screen to close the tab.
Page 374: Parking Sensor System
When Driving Parking Sensor System Parking Sensor System The parking sensors use ultrasonic sensors which detect obstructions around the vehicle when the vehicle is driven at low speeds, such as during garage or parallel parking, and a buzzer sound and detection indicator notify the driver of the approximate distance from the vehicle to the surrounding obstruction.
Page 375 Small, short objects Always have the system inspected at an expert repairer, we recommend an Authorised Mazda Repairer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
Page 376 A: About 50 cm (About 19 in) B: About 50 cm (About 19 in) Rear corner sensor detection range C: About 100 cm (About 39.3 in) Front sensor detection range D: About 150 cm (About 59.0 in) Rear sensor detection range Front corner sensor detection range 4–232...
Page 377 Corner Sensor Sensor Front sensor: Rear sensor: Approx. 100—60 cm Approx. 150—60 cm (39.3—23.6 in) (59.0—23.6 in) Front sensor: Rear sensor: Approx. 60—45 cm Approx. 60—45 cm (23.6—17.7 in) (23.6—17.7 in) Front corner sensor: Rear corner sensor: Approx.
Page 378 When Driving Parking Sensor System Display Distance between vehicle and obstruction Without front sensor With front sensor and Front Sensor /Front Rear Sensor/Rear Corner and front corner sensor front corner sensor Corner Sensor Sensor Front sensor: Rear sensor: Within approx. 35 cm Within approx.
Page 379 When Driving Parking Sensor System Operation conditions The parking sensor system can be used when all of the following conditions are met: The ignition is switched ON. The parking sensor switch is turned on. NOTE (Automatic transaxle vehicle) The detection indicator and buzzer of the front sensors/front corner sensors do not operate when the selector lever is in the P position.
Page 380 When Driving Parking Sensor System Obstruction Detection Indication The position of a sensor which has detected an obstruction is indicated. The gauge illuminates in different areas depending on the distance to an obstruction detected by the sensor. As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the vehicle illuminates.
Page 381 The system may have a malfunction. Have the vehicle inspected at an expert repairer, Disconnection we recommend an Authorised Mazda Repairer as soon as possible. The system may have a malfunction. Have System the vehicle inspected at an expert repairer,...
Page 382 Front Sensor , Rear Sensor Distance between vehicle and obstruction Distance Detection Beeper sound area Front Sensor Rear Sensor Approx. 100—60 cm (39.3— Approx. 150—60 cm (59.0—23.6 23.6 in) Slow intermittent Farthest distance sound Approx. 60—45 cm (23.6—17.7 in) Medium...
Page 383 When Driving Parking Sensor System Distance between vehicle and obstruction Distance Detection Beeper sound area Front Sensor Rear Sensor Within approx. 35 cm (13.7 in) Close distance Continuous sound *1 The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction. Front Corner Sensor , Rear Corner Sensor Distance Detection area...
Page 384: Indicator Light
The system may have a malfunction. Have the vehicle inspected at an expert The beep sound is not heard. repairer, we recommend an Authorised Mazda Repairer as soon as possible. Remove any foreign material from the sensor area. If the system does not...
Page 385: Interior Features
Use of various features for ride comfort, including air-conditioning and audio system. Air-Conditioning System ..............5-2 Operating Tips ................5-2 Vent Operation ................5-3 Manual Air-Conditioning .............. 5-5 Automatic Air-Conditioning ............5-10 Dual-Zone Automatic Air-Conditioning ........5-14 Audio System ..................5-18 Aerial ...................
Page 386: Air-Conditioning System
For details, consult an expert repairer, system ef ciency. we recommend an Authorised Mazda Use the air-conditioning system to defog Repairer. the windows and dehumidify the air.
Page 387: Vent Operation
The air vents can be fully opened and closed by operating the dial. Side Vents Knob Knob Dial Dial Open Close Close Open Centre Vents Knob Open Close Dial Some models. 5–3...
Page 388 Interior Features Air-Conditioning System Selecting the Air ow Mode Instrument panel Vents Defroster and Floor Vents Defroster Vents Instrument panel and Floor Vents Floor Vents 5–4...
Page 389: Manual Air-Conditioning
Interior Features Air-Conditioning System Manual Air-Conditioning Type A Rear window defogger switch Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector Air intake selector (outside air position) (recirculated air position) * Some models Type B Rear window defogger switch Temperature control dial Fan control dial...
Page 390 The indicator light on the 3—Medium high speed switch will illuminate when the fan control 4—High speed dial is set at position 1, 2, 3, or 4. Press the switch once again to turn the air conditioner off. NOTE...
Page 391 2. Set the temperature control dial to the defrost the rear window. cold position. Refer to Rear Window Defogger on page 3. Set the fan control dial to the desired 4-80 . speed. 4. Turn on the air conditioner by pressing the A/C switch.
Page 392 2. Set the temperature control dial to the (Type A) desired position. When maximum cooling is desired, 3. Set the fan control dial to the desired set the temperature control dial to speed. the extreme cold position and set the 4.
Page 393 2. Set the air intake selector to the outside (Type B) air position. For maximum defrosting, turn on the 3. Set the temperature control dial to the air conditioner, set the temperature desired position. control dial to the extreme hot 4.
Page 394: Automatic Air-Conditioning
Interior Features Air-Conditioning System Automatic Air-Conditioning Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch Control Switches Mode selector dial Turn the mode selector dial to select Temperature control dial air ow mode (page 5-4 ).
Page 395 Interior Features Air-Conditioning System Air intake selector NOTE Outside or recirculated air positions can be selected. Press the switch to select outside/ With the air ow mode set to the recirculated air positions. position and the temperature control dial set at a medium temperature, Recirculated air position (indicator light heated air is directed to the feet and illuminated)
Page 396 5-4 ). Air ow amount will be increased. more easily. WARNING 3. Set the fan control dial to the AUTO position. Set the temperature control to the hot 4. Press the A/C switch to operate the air- or warm position when defogging ( conditioning (turn indicator light on).
Page 397 Interior Features Air-Conditioning System Sunlight/Temperature Sensor Sunlight sensor Do not place objects on the sunlight sensor. Otherwise, the interior temperature may not adjust correctly. Sunlight sensor Interior temperature sensor Do not cover the interior temperature sensor. Otherwise, the interior temperature may not adjust correctly.
Page 398: Dual-Zone Automatic Air-Conditioning
Interior Features Air-Conditioning System Dual-Zone Automatic Air-Conditioning Air-conditioning information is displayed on the display. Temperature setting display (driver’s side) Windscreen defroster switch Driver temperature control dial Air intake selector Rear window defogger switch (recirculated air position) Air intake selector A/C mode display Passenger temperature (outside air position) control dial...
Page 399 Interior Features Air-Conditioning System OFF switch NOTE Pressing the OFF switch shuts off the air- conditioning system. With the air ow mode set to the position and the temperature control Temperature control dial dial set at a medium temperature, This dial controls temperature. Turn it heated air is directed to the feet and clockwise for hot and anticlockwise for air at a comparably lower...
Page 400 Interior Features Air-Conditioning System Air intake selector Interconnection mode (indicator light turned off) Outside or recirculated air positions can be selected. Press the switch to select outside/ The set temperature for the driver recirculated air positions. and front passenger is controlled simultaneously.
Page 401 Interior Features Air-Conditioning System Windscreen Defrosting and Sunlight/Temperature Sensor Defogging Sunlight sensor Press the windscreen defroster switch. In this position, the outside air position Do not place objects on the sunlight is automatically selected, and the air sensor. Otherwise, the interior temperature conditioner automatically turns on.
Page 402: Audio System
Interior Features Audio System Aerial CAUTION Aerial (Saloon) To prevent damage to the aerial, remove it before entering a car wash The aerial is embedded into the window facility or passing beneath a low glass. overhead clearance. CAUTION Be careful around the aerial when removing snow from the roof.
Page 403: Operating Tips For Audio System
Interior Features Audio System Type C Operating Tips for Audio The aerial is embedded into the window System glass. WARNING CAUTION Always adjust the audio while the When washing the inside of the window vehicle is stopped: which has an aerial, use a soft cloth Do not adjust the audio control dampened in lukewarm water, gently switches while driving the vehicle.
Page 404 Interior Features Audio System Radio Reception NOTE AM characteristics To prevent the battery from being discharged, do not leave the audio AM signals bend around such things as system on for a long period of time buildings or mountains and bounce off the when the engine is not running.
Page 405 Interior Features Audio System Signals from an FM transmitter are similar Flutter/Skip noise to beams of light because they do not Signals from an FM transmitter move in bend around corners, but they do re ect. straight lines and become weak in valleys Unlike AM signals, FM signals cannot between tall buildings, mountains, and travel beyond the horizon.
Page 406 At this time there will be some malfunction. noise from this disturbance. Station 2 Station 1 88.3 MHz 88.1 MHz Do not use non-conventional discs such as heart-shaped, octagonal discs, etc. The disc may not eject resulting in a malfunction.
Page 407 Interior Features Audio System If the memory portion of the CD is CDs bearing the logo shown in the transparent or translucent, do not use the illustration can be played. No other discs disc. can be played. Transparent A new CD may have rough edges on its inner and outer perimeters.
Page 408 The CD player ejects the CD if the CD Operating Tips for MP3 is inserted upside down. Also dirty and/ MP3 stands for MPEG Audio Layer 3, or defective CDs may be ejected. which is standardised voice compression Do not insert cleaning discs in the CD...
Page 409 Interior Features Audio System This audio system handles MP3 les Operating Tips for AAC that have been recorded on CD-R/CD- AAC stands for Advanced Audio Coding, RW/CD-ROMs. which is standardised voice compression When naming an MP3 le, be sure to established by the ISO working group add an MP3 le extension (.mp3) after...
Page 410 Interior Features Audio System Operating Tips for DVD Player A new DVD may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting Condensation phenomenon will not be possible and the DVD player Immediately after turning on the heater will not play the DVD.
Page 411 Interior Features Audio System Be sure never to touch the signal surface This unit may not be able to play certain when handling the DVDs. Pick up a DVD-R/DVD R/DVD-RW/DVD DVD by grasping the outer edge or the RWs made using a computer or DVD edge of the hole and the outer edge.
Page 412 This unit is compatible for playback of dual-layer DVD/DVD-R. Glossary Regional number for this unit is [2] or [3] (regional number depends on market). DVD-Video DVD-Video/DVD-VR les written DVD-Video is a video image storing under speci cations other than the standard determined by the DVD forum.
Page 413 Interior Features Audio System Multi-language OGG les written under speci cations other than the indicated speci cation As a function of the DVD player, audio may not play normally or les or folder or subtitles for the same video images can names may not display correctly.
Page 414 If data in the iPod is lost while it is playback order. connected to the unit, Mazda cannot To prevent loss or damage of stored guarantee recovery of any lost data. data, we recommend that you always If the iPod battery is deteriorated, the back up your data.
Page 415: Audio Set [Type A/Type B (Non-Touchscreen)]
Interior Features Audio System Audio Set [Type A/Type B (non-touchscreen)] Type A (RDS non-compatible) Type B (RDS compatible) Power/Volume/Sound Controls ................page 5-32 Clock ........................page 5-34 Operating the Radio (Type A) ................page 5-36 Operating the Radio (Type B) ................page 5-38 Operating the Compact Disc (CD) Player.............
Page 416 Interior Features Audio System Power/Volume/Sound Controls Audio display Menu button Power/Volume/Audio control dial The figure is an example showing the type A unit. Power ON/OFF 2. Turn the audio control dial to adjust the selected functions as follows: Switch the ignition to ACC or ON. Press the power/volume dial to turn the audio Setting value system on.
Page 417 Interior Features Audio System ALC (Automatic volume adjustment) Setting value Indication Turn Turn The automatic level control (ALC) Anticlockwise Clockwise changes the audio volume automatically 12Hr 24Hr according to the vehicle speed. The faster 12Hr 24Hr (12 Hr/24 Hr time the vehicle speed, the higher the volume (Flashing) (Flashing)
Page 418 1. Press the clock button ( ) for about 2 seconds until a beep is heard. 2. Press the :00 button ( 1 ). 3. When the button is pressed, the time will be reset as follows: (Example) 12:01—12:29 12:00 12:30—12:59 1:00...
Page 419 MEMO 5–35...
Page 420 Interior Features Audio System Operating the Radio (Type A) Audio display Channel preset buttons Tuning button Scan button Auto memory button Band selector button Radio ON Manual tuning Select the station by pressing the tuning Press a band selector button ( ) to turn the radio on.
Page 421 The preset channel number or station frequency will be displayed. The station is now held in the memory. 3. Repeat this operation for the other stations and bands you want to store. To tune one in the memory, select AM, FM1, or FM2 and then press its channel preset button.
Page 422 Interior Features Audio System Operating the Radio (Type B) Audio display Channel preset buttons Tuning button Scan button Programme-type information button Band selector button Traffic announcement button Radio ON Seek tuning Automatic search for radio stations starts Press a band selector button ( ) to turn the radio on.
Page 423 TA mode and station is now held in the memory. “ TA ” is displayed. 3. Repeat this operation for the other stations and bands you want to store. If a TA broadcast is received while in the...
Page 424 ( , ) when the programme- type code is displayed. 2. Press the Programme-type information button ( , ) and select the programme type. 3. While the programme type is displayed, press a channel preset button for about 2 seconds. 5–40...
Page 425 MEMO 5–41...
Page 426 Interior Features Audio System Operating the Compact Disc (CD) Player Repeat button Text button Play/Pause button Random button Audio display Folder up button Track down/ Reverse button Folder down button Track up/ Media/Scan button Fast-forward button CD eject button CD slot The figure is an example showing the type A unit.
Page 427 ( is displayed next to RPT at the operation (the track number will ash). bottom of the display area). Press and hold the scan button ( 2. To cancel the repeat playback, press the again to cancel scan playback. button again after 3 seconds. 5–43...
Page 428 The information displayed on the audio display changes as follows each time the During music CD playback text button ( 3 ) is pressed during playback. 1. Press the random button ( 2 ) during Music CD playback to play the tracks on the CD randomly.
Page 429 To display the rest of the characters Error Indications of a long title, press and hold the text button ( 3 ). The display scrolls the next 13 If you see an error indication on the characters. Press and hold the text button audio display, nd the cause in the chart.
Page 430: Audio Set [Type C/Type D (Touchscreen)]
Interior Features Audio System Audio Set [Type C/Type D (touchscreen)] NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance. Additionally, depending on future software updates, the content may successively change without notice.
Page 431 Interior Features Audio System Switches around commander knob The following operations can be done by pressing the switches around the commander knob. : Displays the home screen. : Displays the Entertainment screen. : Displays the Navigation screen (Only navigation-equipped vehicles). For operation of the Navigation screen, refer to the navigation system manual.
Page 432 Interior Features Audio System Touch panel operation CAUTION Do not press the screen strongly or press it with a sharp-pointed object. Otherwise, the screen could be damaged. NOTE For safety reasons, operation of the centre display is disabled while the vehicle is being driven.
Page 433 Interior Features Audio System Basic Operation Method TOUCH & TAP 1. Touch or tap on the item indicated on the screen. 2. The operation is launched and the next item is displayed. SLIDE 1. Touch the setting item displaying a slider bar. 2.
Page 434 Interior Features Audio System Return to previous screen 1. Touch the Displaying the home screen 1. Touch the Home screen Icon Function Applications Information such as average fuel economy, maintenance, and warnings can be veri ed. Depending on the grade and speci cation, the screen display may differ. Entertainment Operates audio such as the radio and CDs.
Page 435 MEMO 5–51...
Page 436 Interior Features Audio System Volume/Display/Sound Controls Audio control switch Commander switch Volume dial Volume switch Volume adjustment Daytime/nighttime (Mode) screen setting Turn the commander switch volume dial. The volume switch on the steering switch The daytime or nighttime screen can be can also be pressed.
Page 437 ® Bass enhancement (Low pitch sound) level adjustment) Side: Low pitch reduction Centerpoint lets vehicle owners enjoy ® *3 a Bose surround sound experience from ® Side: Treble Treble their existing CDs and MP3s. enhancement (Treble sound) Speci cally engineered to meet the unique...
Page 438 Interior Features Audio System Operating the Radio (Type C) Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the centre display. AM/FM Radio Icon Function...
Page 439 Favourites list. convenient operation. Up to 50 stations 2. Select can be registered. The Favourites list is 3. Select common to AM and FM radio. 4. Select a radio frequency. The selected Registering to Favourites radio station can be moved.
Page 440 Interior Features Audio System Operating the Radio (Type D) Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the centre display. AM/FM Radio Icon Function...
Page 441 When the icon is selected while Favourites list. FM is selected, each programme is 2. Select selected. 3. Select 4. Select the radio frequency you want to delete. Favourites Radio 5. Select Selected stations can be registered for convenient operation. Up to 50 stations Changing Favourites list order can be registered.
Page 442 Interior Features Audio System Traf c announcement (TA) (Selecting Genre) Select during FM/AM reception to 1. Select the on the station list switch to the TA mode. screen to display the genre list screen. If a TA broadcast is received while in the 2.
Page 443 Interior Features Audio System Operating the Digital Audio Broadcasting (DAB) Radio (Type D) What is DAB radio? DAB radio is a digital broadcasting system for radio. DAB radio provides a high-quality radio sound source using an auto frequency switching function in boundary areas. By displaying the radio text, information such as the song name and artist name can be displayed.
Page 444 Interior Features Audio System Icon Function Goes to the next station. Touch and hold to go to the top station in the next ensemble. Displays the DAB radio setting screen. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-52 . 5–60...
Page 445 2. Select to update the station Link providing the same broadcast is searched list. and switched to. 3. Select to select the On: If the reception ensemble you want to display. condition is bad, a DAB-DAB DAB station which 4. Select a desired station to start radio...
Page 446 Interior Features Audio System Operating the Compact Disc (CD) Player CD eject button CD slot NOTE Type Playable data Music data (CD-DA) Music/MP3/WMA/ There will be a short lapse before play AAC CD player MP3/WMA/AAC le begins while the player reads the digital signals on the CD.
Page 447 Interior Features Audio System Playback Select the icon on the home screen with a CD inserted and display the Entertainment screen. When is selected, the following icons are indicated in the lower part of the centre display. Icon Function Displays the Entertainment menu. Use to switch to a different audio source. (Music CD) Displays the track list of the CD.
Page 448 2. When the folder is selected, folders/ le lists in the folder are displayed. 3. Select the desired song. NOTE Select to move to a folder one level higher.
Page 449 MEMO 5–65...
Page 450 Interior Features Audio System Operating the Digital Versatile Disc (DVD) Player DVD eject button DVD slot NOTE Type Playable data DVD VIDEO/DVD- DVD VIDEO/DVD-VR There will be a short lapse before play VR player begins while the player reads the digital signals on the DVD.
Page 451 Refer to Volume/Display/Sound Controls on page 5-52 . Select to change the aspect ratio (horizontal to vertical ratio of the screen). 16:9 Widescreen, 4:3 Letterbox, and 4:3 Pan-scan are available. Adjusts the screen. Displays the video setting screen at the bottom of the screen.
Page 452 Setting aspect ratio Use a commercially-available, non- impedance (3.5 ) stereo mini plug lead. 1. Select the icon. In addition, audio can be played from the 2. Select vehicle audio device by connecting a USB 3.
Page 453 Interior Features Audio System Settings NOTE Depending on the grade and speci cation, the screen display may differ. Select the icon on the home screen and display the Settings screen. Switch the tab and select the setting item you want to change. You can customize settings in the setup display as follows: Item Function...
Page 454 2. Voice recognition assistance for Play Artist Music Database Update and Play Album System Gracenote can be downloaded from the Mazda Handsfree Website. Refer to Gracenote Database (Type C/Type D) on page 5-90 . Memory and settings are initialized to the factory settings.
Page 455: Audio Control Switch Operation
Interior Features Audio System Applications Audio Control Switch Operation NOTE Without Bluetooth Hands-Free ® Depending on the grade and speci cation, the screen display may differ. Select the icon on the home screen to display the Applications screen. The following information can be veri ed. Top screen Item Function...
Page 456 Interior Features Audio System Adjusting the Volume DAB radio (Type D) To increase the volume, press up the Press the Seek switch ( , ) while volume switch ( ). listening to DAB radio to call up a station To decrease the volume, press down the previously stored to the favourites list.
Page 457: Aux/Usb
NOTE A commercially-available, non-impedance (3.5 ) stereo mini plug lead is required. If the ignition is switched off with the Contact an expert repairer, we recommend audio muted, the mute will be cancelled.
Page 458 Interior Features Audio System Type A/Type B (With CD player) Type C/Type D (With DVD/CD player) With Electric Parking Brake With Electric Parking Brake Auxiliary jac Auxiliary jac /USB port USB port Without Electric Parking Brake Without Electric Parking Brake Auxiliary jac Auxiliary jac /USB port USB port...
Page 459 Use a commercially-available, distract your attention from the vehicle non-impedance (3.5 ) stereo mini operation which could lead to a serious plug for connecting the portable accident. Always adjust the portable audio unit to the auxiliary jack.
Page 460 Interior Features Audio System How to connect USB port/ Type C/Type D (Without DVD/CD Auxiliary jack player) Type A/Type B (Without CD player) USB port Auxiliary jack Auxiliary jack USB port Type C/Type D (With DVD/CD player) Type A/Type B (With CD player) With Electric Parking Brake USB port Auxiliary jac...
Page 461 2. If there is a cover on the AUX jack or Insert or pull out the plug with the USB port, remove the cover. plug perpendicular to the auxiliary 3. Connect the connector on the device to jack/USB port hole. the USB port. Insert or remove the plug by holding its base.
Page 462 USB mode MP3/WMA/AAC le Playback of the USB device is in the order of the folder numbers. Folders This unit does not support a USB 3.0 which have no MP3/WMA/AAC device. In addition, other devices may not les are skipped.
Page 463 ( ), or press the folder playback, and then press the button up button ( ) to advance to the next again within 3 seconds to play the folder. tracks in the current folder repeatedly. Music scan “...
Page 464 3 seconds to play the of a long title, press and hold the text tracks in the USB device randomly. button ( 3 ). The display scrolls the next 13 characters. Press and hold the text button “ ALL RDM ” is displayed (...
Page 465 MEMO 5–81...
Page 466 To stop playback, press the play/pause 2. Press the power/volume dial to turn the button ( 4 ). audio system on. Press the button again to resume playback. 3. Press the media button ( ) to Fast-forward/Reverse switch to the iPod mode and start playback.
Page 467 Audio book, there is no list. randomly. “ SONG RDM ” is displayed is displayed next to RDM at the bottom of the display area). 2. To cancel the random playback, press the button again after 3 seconds. 5–83...
Page 468 To display the rest of the characters shuf e table. of a long title, press and hold the text button ( 3 ). The display scrolls the next 13 characters. Press and hold the text button Switching the display...
Page 469 Error Indications (Type A/Type B) If you see an error indication on the display, nd the cause in the chart. If you cannot clear the error indication, take the vehicle to an expert repairer, we recommend an Authorised Mazda Repairer. Indication Cause Solution...
Page 470 USB mode MP3/WMA/AAC/OGG le This unit does not support a USB 3.0 device. In addition, other devices may not be supported depending on the model or OS version. USB devices formatted to FAT32 are supported (USB devices formatted to other formats such as NTFS are not supported).
Page 471 Interior Features Audio System Playback 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch the USB mode. The following icons are displayed in the lower part of the centre display. Icon Function Displays the Entertainment menu.
Page 472: Category List
Displays the podcast list. Podcast Episode can be selected and played. (Special service for some Apple devices.) Folder Displays the folder/ le list. *1 Playlist folders of Apple devices are not supported. *2 Apple device only *3 USB-Sticks and USB-Android™ device only 5–88...
Page 473 The selected track is played. All the tracks in the USB device can be played by continuing playback. *1 Can be operated using an Android™ device or USB ash memory. NOTE Only the tracks in the desired folder selected in Step 3 are played. 5–89...
Page 474 Gracenote music recognition service. CAUTION For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com Introduction Music recognition technology and related data are provided by Gracenote .
Page 475 Interior Features Audio System You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers for your own personal non-commercial use only. You agree not to assign, copy, transfer or transmit the Gracenote Software or any Gracenote Data to any third party. YOU AGREE NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
Page 476 4. Select . The list of the update package stored in the USB device and the version are displayed. 5. Select the package to use the update. 6. Select NOTE Gracenote can be downloaded from the Mazda Hands-free Website. 5–92...
Page 477: Bluetooth
Interior Features Bluetooth ® Bluetooth ® * Bluetooth Hands-Free outline ® When a Bluetooth device (mobile phone) is connected to the vehicle's Bluetooth unit via ® ® radio wave transmission, a call can be made or received by pressing the talk button, pick- up button, or hang-up button on the audio remote control switch, or by operating the centre display.
Page 478 Bluetooth ® CAUTION Some Bluetooth mobile devices are not compatible with the vehicle. Consult an ® Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding Bluetooth mobile device compatibility: ® Phone: (Germany) 0800 4263 738 (8:00—18:00 Central European Time) (Except Germany) 00800 4263 7383 (8:00—18:00 Central European Time)
Page 479 Conversation volume and the volume of the voice guidance and ringtone can each be set in advance. 1. Select the icon on the home screen to display the Communication screen. 2. Select 3. Adjust the and the using the slider. 5–95...
Page 480 If the vehicle 2. Say: [Beep] “Setup” starts to move, the pairing procedure 3. Prompt: “Select one of the following: will end. Pairing is dangerous while Pairing options, con rmation prompts, driving - pair up your device before language, password, select phone or you start driving.
Page 481 Device registration can also be done by operating the audio unit. 10. Select “Mazda” from the device list Depending on the device, the searched by the device. registration status may be lost after a 11.
Page 482 ® 2. Say: [Beep] “Setup” paired. If you would like to link a different 3. Prompt: “Select one of the following: paired device, it is necessary to change the Pairing options, con rmation prompts, link. The order of device priority after the...
Page 483 2. Say: [Beep] “Setup” NOTE 3. Prompt: “Select one of the following: Pairing options, con rmation prompts, Do this function only when parked. It is language, password, select phone or too distracting to attempt while driving select music player.”...
Page 484 ( ) is pressed. with a short press. Select “ BT SETUP ”. 2. Say: [Beep] “Setup” 3. Prompt: “Select one of the following: Type A Pairing options, con rmation prompts, language, password, select phone or select music player.”...
Page 485 Displaying vehicle's indication changes. DEVICE information Bluetooth unit ® INFO display mode information 3. Press the audio control dial to determine the mode. Bluetooth audio device pairing ® Any Bluetooth ® audio device must be paired to the vehicle's Bluetooth ®...
Page 486 Press channel preset button 1 to input free mobile phone, it does not need the rst digit, 2 for the second, 3 for the to be paired again when using the third, and 4 for the forth. For example, device as a Bluetooth audio device.
Page 487 “ PIN 0000 ” is displayed and the PIN code can be input. 3. Press the audio control dial while “ PIN 0000 ” is displayed. “ PAIRING ” ashes on the audio display. 4. Operate the Bluetooth audio device ®...
Page 488 2. Press the audio control dial to again, together with “ LINK determine the mode. CHANGED ”. “ LINK CHANGED ” is 3. The name of the currently linked displayed for three seconds, then it Bluetooth audio device is displayed.
Page 489 Interior Features Bluetooth ® 3. The name of the rst device among the NOTE paired devices is displayed. 4. Rotate the audio control dial and select Some Bluetooth audio devices need ® the name of the paired device you a certain amount of time before the would like to delete.
Page 490 -Anticlockwise: “ SURE ? NO ” 2. Press the audio control dial to displayed determine the mode. 3. The name of the Bluetooth ® unit device is displayed. 7. Press the audio control dial to delete 4.
Page 491 2. Say: [Beep] “Setup” native pronunciation. 3. Prompt: “Select one of the following: Pairing options, con rmation prompts, language, password, select phone or 3. Prompt: “Would you like to change select music player.”...
Page 492 Speak the 2. Say: [Beep] “Tutorial” voice commands while maintaining a 3. Follow the prompts to receive the safe driving position. appropriate voice guidance instructions. Do not speak too slow or too loud.
Page 493 Refer to Troubleshooting on page is locked. State the password to 5-148 . continue.” 3. Say: [Beep] “XXXX” (Say the set password “PCode”.) 4. If the correct password is input, voice Security Setting (Type A/Type B) guidance “XXXXXX... (Ex. “Mary's If a password is set, the system cannot be device”) (Device tag) is connected”...
Page 494 2. Say: [Beep] “Setup” 2. Say: [Beep] “Voice training” 3. Prompt: “Select one of the following: 3. Prompt: “This operation must be Pairing options, con rmation prompts, performed in a quiet environment while language, password, select phone or the vehicle is stopped.
Page 495 2. Say: [Beep] “Voice training” Do not read out parentheses. “(” and 3. Prompt: “Enrolment is enabled/ hyphens “-” are used for separating disabled. Would you like to disable/ numbers in a phone number.
Page 496 6. Using your device, perform a search for the Bluetooth device (Peripheral ® device). 7. Select “Mazda” from the device list searched by the device. 5–112...
Page 497 (Device with Bluetooth version 2.1 ® mobile phone device, rst clear or higher) “Mazda” displayed on the Bluetooth ® Make sure the displayed 6-digit code setting screen of the mobile device. on the audio is also displayed on the When the OS of the device is updated, device, and touch the the pairing information may be deleted.
Page 498 1. Select the icon on the home screen the Hands-free or audio. to display the Settings screen. Hands-free: Phone calls and E-mail/ 2. Select the tab. 3. Select Audio: Bluetooth audio, Aha™, ® 4. Select Stitcher™ radio 5. Select 6. Input the new PIN code to be set.
Page 499 Interior Features Bluetooth ® Skipping Voice Guidance (for faster Do not speak too slowly or loudly (no operation) loud voice). Speak clearly, without pausing between Press and release the talk button. words or numbers. Troubleshooting for Voice Recognition Dialects or different wording other than hands-free prompts cannot be If you do not understand an operation recognised by voice recognition.
Page 500: Voice Command
Interior Features Bluetooth ® Audio Operation Using Voice Recognition (Type C/Type D) Voice command When the talk button is pressed and the following command is spoken, the audio or navigation can be operated. The commands in the () can be omitted. The speci ed name and number are put into the {}.
Page 501 Interior Features Bluetooth ® Entertainment (audio) related command Corresponding audio Voice command Function source (Go to/Play) AM (Radio) Switches the audio source to AM radio. (Go to/Play) FM (Radio) Switches the audio source to FM radio. (Go to/Play) DAB (Radio) Switches the audio source to DAB radio.
Page 502: Bluetooth
14. Say: [Beep] “XXXXXXXXXXX” Ex. In Step 2, say, “Call John's phone”, (Say the phone number to be then, Steps 3 and 4 can be skipped. registered.) 15. Prompt: “XXXXXXXXXXX (Phone number registration). After the beep, Phonebook registration...
Page 503 Editing phonebook 2. Say: [Beep] “Phonebook” The data registered to the Bluetooth ® 3. Prompt: “Select one of the following: Hands-Free phonebook can be edited. New entry, edit, list names, delete, erase all or import contact.” NOTE 4.
Page 504 Interior Features Bluetooth ® 3. Prompt: “Select one of the following: 14. (Number Change) New entry, edit, list names, delete, Press the pick-up button, then go to erase all or import contact.” Step 15. 4. Say: [Beep] “Edit” (Adding/inputting telephone 5.
Page 505 (Registered voice tag) Home with a short press. (Registered location) deleted.” 2. Say: [Beep] “Phonebook” 3. Prompt: “Select one of the following: New entry, edit, list names, delete, (Complete deletion of the phonebook erase all or import contact.” data) 4.
Page 506 Ex. In Step 2, say, “Dial 123-4567” calls from a safe parking position, and then, Steps 3 and 4 can be skipped. only start driving when you can devote your full attention to driving. Emergency calls 1.
Page 507 1. Press the talk button with a short press. Switching back to the previous call can 2. Say: [Beep] “Transfer call” also be done. 3. Prompt: “Transferred call to phone” Method 1 Transferring a Call from a Device 1. Press the pick-up button.
Page 508 Say, “Go Back”. The prompt replies, 2. Say: [Beep] “XXXX... send” (Say “Go Back. The last entered numbers DTMF code) have been removed.”. Then go back to 3. Prompt: “Sending XXXX... (DTMF Step 3. code)” 7. Prompt: “Dialing” Making calls using the phonebook 1.
Page 509: Bluetooth ® Hands-Free (Type C/Type D)
2. Select to display the contact list. NOTE 3. Select the contact you would like to call to display the details for the If “Import All Contacts” is performed contact. after saving the phonebook to the 4. Select the desired phone number to...
Page 510 2. Select to display the favourites favourites list. 1. Select the icon on the home screen 3. (If only one phone number is to display the Communication screen. registered to contact) 2. Select to display the Select the contact information you favourites list.
Page 511 Communication screen. 2. When is pressed, the dial pad is displayed. 3. Input the telephone number using the dial pad. 4. Select to make the call. Numeral or symbol entry Use the dial pad.
Page 512: Receiving An Incoming Call
Mute The microphone can be muted during a call. When selected again, the mute is cancelled. To make a 3-way call, select the contacts from the following: : Call History is displayed. : The phonebook is displayed. : The dial pad is displayed. Input the phone number.
Page 513 (E-mail) or “Auto Download SMS” (SMS) device. setting is off, the message is downloaded using the following procedure. 1. Select the icon on the home screen to display the Communication screen. 2. Select to display the Inbox. 3. Select 5–129...
Page 514 (Method 2) 1. Select the icon on the home screen to display the Communication screen. 2. Select and display the new message list for E-mail and SMS. 3. Select the message you would like to display. 5–130...
Page 515 Interior Features Bluetooth ® The following icons are displayed in the lower part of the details on the message. Icons which can be used differ depending on use conditions. Icon Function Displays the Communication menu. Displays the inbox. Plays back a message. When selected again, playback is temporarily stopped.
Page 516 Select the icon to return to the previous screen without storing the edit. 3. Select the unread message displayed in bold. 4. The details of the message are displayed and replying to the message, making a call, or playback can be performed.
Page 517 Interior Features Bluetooth ® Communication Settings Select the icon on the home screen to display the Communication screen. Select to change the setting. Item Setting Function Go to Bluetooth ® setting menu. Bluetooth — ® Refer to Bluetooth ® Preparation (Type C/Type D) on page 5-112 . Incoming Call On/Off Noti es when an incoming call is received.
Page 518: Bluetooth ® Audio (Type A/Type B)
AVRCP (Audio/Video Remote Control music playback over a Bluetooth ® Pro le) Ver. 1.0/1.3 connection and music playback using a USB connection at the same time. The system may not operate A2DP is a pro le which transmits only...
Page 519 Short-press the track down button ( and start playback. Fast-forward/Reverse (AVRCP Ver. 1.3) If the current device version is lower than AVRCP Ver. 1.3: “ BT Audio ” is Fast-forward displayed. If the current device is AVRCP Ver. 1.3: Press and hold the fast-forward button The playback time is displayed.
Page 520: Bluetooth ® Audio (Type C/Type D)
To display the rest of the characters Applicable Bluetooth speci cation ® of a long title, press and hold the text (Recommended) button (3). The display scrolls the next 13 Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 characters. Press and hold the text button (conformity)
Page 521 Bluetooth ® connection and music playback using AVRCP Function A2DP a USB connection at the same time. Ver. 1.0 Ver. 1.3 Ver. 1.4 The system may not operate Playback normally depending on the Pause Bluetooth ®...
Page 522 1. Turn on the Bluetooth audio device's power. ® 2. Switch the ignition to ACC or ON. 3. Select the icon on the home screen to display the Entertainment screen. 4. When is selected, switches to the Bluetooth audio mode to begin playback.
Page 523 Select the folder which you want to select. The les in the selected folder are displayed. Select the le you want to play. (AVRCP Ver. 1.3 or higher) Replays the song currently being played repeatedly. When selected again, the songs in the folder are played repeatedly.
Page 524 If a Bluetooth audio device is connected, ® the following information is displayed in the centre display. AVRCP AVRCP AVRCP Ver. lower Ver. 1.4 or Ver. 1.3 than 1.3 higher Device name Remaining battery charge of device Song name —...
Page 525 Interior Features Bluetooth ® How to Use Aha™ What is Aha™? is an application which can be used to enjoy various Internet content such as Internet radio and podcasts. Stay connected to your friends activities by getting updates from Facebook and Twitter. Using the location-based service, nearby services and destinations can be searched or real- time local information can be obtained.
Page 526 Interior Features Bluetooth ® Icon Function Like Evaluates the current content as “Like”. Dislike Evaluates the current content as “Dislike”. Reverses for 15 seconds. Map (vehicles with navigation system) Displays the destination searched by the location based services on the navigation system. Call A call can be made to the telephone number of a shop searched using the Location Based Services.
Page 527: Main Menu
Interior Features Bluetooth ® Main menu Select the icon. Switch the tab and select the station category. Function Displays the preset station list set on the device. Presets Select the preset station name to play the station content. Select the desired station. Guidance is provided to the searched destination near the vehicle's position.
Page 528 The destination name or address function. playback starts in the order of the 1. Select the icon and start the destination name list. countdown (3, 2, 1, 0). Recording starts when the countdown reaches zero. 2. Records voice. 3. Select and store/post the recording.
Page 529 Interior Features Bluetooth ® How to Use Stitcher™ Radio What is Stitcher™ Radio? Stitcher™ radio is an application which can be used to listen to Internet radio or stream podcasts. Recommended content is automatically selected by registering content which you put into your favourites, or by pressing the Like or Dislike button.
Page 530 Interior Features Bluetooth ® Icon Function Reverses for 30 seconds. Plays the station. Select it again to pause playback. Goes to the next station. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-52 . Station list 1.
Page 531 2. Select the station name which you want to register. 3. Select to add the programme to the selected favourites station. NOTE Multiple favourites stations can be selected and registered.
Page 532: Troubleshooting
The pairing information paired to Pairing cannot be performed again the Bluetooth unit or device is not ® Clear “Mazda” stored in the device. recognised correctly. Perform pairing again. Unable to perform pairing The Bluetooth ® function and the Check whether the Bluetooth ®...
Page 533 ® If you pair your phone which has already been paired to your vehicle more than once in the past, you need to delete “Mazda” on your mobile device. Then, execute the Bluetooth search on your mobile device once again, and pair to a newly detected ®...
Page 534 Interior Features Bluetooth ® Symptom Cause Solution method If there is any malfunction after There is a problem with the Phone-related voice recognition is checking the pairing situation, check connection between the Bluetooth ® disabled for device pairing or connection unit and the device.
Page 535: Interior Equipment
Interior Features Interior Equipment Sunvisors Interior Lights When you need a sunvisor, lower it for use NOTE in front or swing it to the side. Sunvisor Do not leave the lights on for long periods while the engine is turned off. Otherwise the battery power could be depleted.
Page 536 Interior Features Interior Equipment Without Map Lights NOTE The map lights will not turn off even if the lens is pressed in the following cases: The overhead light switch is in the ON position. The overhead light switch is in the door position with the door open.
Page 537: Illuminated Entry System
Interior Features Interior Equipment Boot Light (Saloon) Illuminated Entry System The boot light is on when the lid is open When the illuminated entry system and off when it's closed. operates, the overhead lights turn on in the following conditions: After the driver's door is unlocked and the ignition is switched off.
Page 538: Accessory Sockets
Interior Features Interior Equipment Accessory Sockets Type A/Type B (With CD player) Only use genuine Mazda accessories or With Electric Parking Brake the equivalent requiring no greater than 120 W (DC 12 V, 10 A). The ignition must be switched to ACC or...
Page 539 Do not use accessories that require more than 120 W (DC 12 V, 10 A). Do not use accessories that are not genuine Mazda accessories or the equivalent. Close the cover when the Without Electric Parking Brake accessory socket is not in use to...
Page 540: Cup Holder
Interior Features Interior Equipment Connecting the accessory socket Cup Holder 1. Open the lid. 2. Pass the connection plug cord through WARNING the cutout of the console and insert the plug into the accessory socket. Never use a cup holder to hold hot liquids while the vehicle is moving: With Electric Parking Brake Using a cup holder to hold hot...
Page 541: Bottle Holder
Interior Features Interior Equipment Without electric parking brake Bottle Holder Bottle holders are on the inside of the doors. Front Rear The rear cup holder is on the rear centre Bottle holder armrest. Rear Bottle holder CAUTION Do not use the bottle holders for containers without caps.
Page 542: Storage Compartments
Interior Features Interior Equipment Storage Compartments Overhead Console This console box is designed to store eyeglasses or other accessories. WARNING Push and release to open. Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 543 Interior Features Interior Equipment Centre Console Storage tray The storage tray can be removed. To open, pull the release latch. With Electric Parking Brake With Electric Parking Brake Storage tray Without Electric Parking Brake Without Electric Parking Brake Storage tray Cargo Sub-Compartment Lift the boot mat.
Page 544: Removable Ashtray
Interior Features Interior Equipment (Saloon) Removable Ashtray The removable ashtray can be xed and used in either of the front cup holders. WARNING Only use the removable ashtray in its xed position, and make sure it is completely inserted: Using an ashtray removed from its xed position or not completely inserted is dangerous.
Page 545 Interior Features Interior Equipment To use the ashtray, insert it straight into the cup holder. To remove the ashtray, pull it upward. With Electric Parking Brake Without Electric Parking Brake 5–161...
Page 546 MEMO 5–162...
Page 547: Maintenance And Care
Maintenance and Care How to keep your Mazda in top condition. Essential Information ................ 6-2 Introduction ................... 6-2 Scheduled Maintenance ..............6-3 Scheduled Maintenance ..............6-3 Maintenance Monitor ..............6-14 Owner Maintenance ................. 6-16 Owner Maintenance Precautions ..........6-16 Bonnet ..................6-18 Engine Compartment Overview ..........
Page 548: Essential Information
If you are unsure about any procedure it describes, we strongly urge you to have a reliable and quali ed technician perform the work, we recommend an Authorised Mazda Repairer. Authorised Mazda technicians and genuine Mazda parts are dedicated to your vehicle.
Page 549: Scheduled Maintenance
The ignition and fuel systems are highly important to the emission control system and to ef cient engine operation. Do not tamper with them. All inspections and adjustments must be made by an expert repairer, we recommend an Authorised Mazda Repairer. Europe Number of months or kilometres (miles), whichever comes rst.
Page 550 Maintenance and Care Scheduled Maintenance Number of months or kilometres (miles), whichever comes rst. Months Maintenance Interval ×1000 km ×1000 miles 12.5 37.5 62.5 87.5 112.5 Battery Brake lines, hoses and connections Brake uid Parking brake Disc brakes Steering operation and linkages Manual transaxle oil Replace every 180,000 km (112,500 miles).
Page 551 *5 MZR 1.6, SKYACTIV-G 1.5, SKYACTIV-G 2.0, SKYACTIV-D 1.5, and SKYACTIV-D 2.2 vehicles can select exible setting only some countries in Europe. Consult an Authorised Mazda Repairer for details. Flexible setting can be set if the vehicle is operated mainly where none of the following conditions apply.
Page 552 Maintenance and Care Scheduled Maintenance Except Europe Israel Number of months or kilometres, whichever comes rst. Maintenance Interval Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Spark plugs Replace every 120,000 km or 6 years. Fuel lter Replace every 135,000 km.
Page 553 Driving in extremely hot conditions e) Driving in mountainous conditions continually *3 If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air lter more often than the recommended intervals. *4 Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may cause serious damage to the engine and cooling system.
Page 554 Maintenance and Care Scheduled Maintenance Number of months or kilometres, whichever comes rst. Maintenance Interval Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Cooling system Replace at rst 195,000 km or 10 years; after that, every Engine coolant 90,000 km or 5 years.
Page 555 Driving in extremely hot conditions f) Driving in mountainous conditions continually *3 If the vehicle is operated primarily under any of the following conditions, replace the engine oil at every 2,500 km or 3 months. a) Purpose of vehicle use is police car, taxi or driving school car.
Page 556 Audibly inspect every 120,000 km (75,000 miles), if noisy, adjust. Engine valve countries clearance (Only MZR 1.6) Georgia/ Audibly inspect every 45,000 km (28,125 miles) or 3 years, if noisy, adjust. Armenia Fuel lter Replace every 60,000 km (37,500 miles). SKYACTIV-G 1.5, SKYACTIV-G Replace every 120,000 km (75,000 miles).
Page 557 Replace every 10,000 km (6,250 miles) or 1 year. Cambodia Engine oil lter Gabon/ Ghana/ Cameroon/ Replace every 5,000 km (3,125 miles) or 6 months. Burundi/ Mozambique Tanzania Replace every 3,000 km (1,875 miles) or 3 months. Cooling system Replace at rst 200,000 km (125,000 miles) or 10 years; after that, every Engine coolant 100,000 km (62,500 miles) or 5 years.
Page 558 Maintenance and Care Scheduled Maintenance Number of months or kilometres (miles), whichever comes rst. Months 18 24 30 36 42 48 54 60 66 72 78 84 90 96 Maintenance Interval ×1000 km 30 40 50 60 70 80 90 100 110 120 130 140 150 160 ×1000 miles 6.25 12.5 18.75 25 31.25 37.5 43.75 50 56.25 62.5 68.75 75 81.25 87.5 93.75 100 Cabin air lter (if installed) Tyres (including spare tyre)
Page 559 Tanzania, United Arab Emirates, Vietnam, Zaire, Zimbabwe *2 Implement the fuel injection amount correction. *3 Also inspect the air conditioner drive belts, if installed. If the vehicle is operated primarily under any of the following conditions, inspect the drive belts more often than the recommended intervals.
Page 560: Maintenance Monitor
Maintenance Monitor (Type C/Type D audio) 1. Select the icon on the home screen to display the “Applications” screen. 2. Select “Maintenance” to display the maintenance list screen. 3. Switch the tab and select the setting item you want to change. 6–14...
Page 561 *1 The engine oil exible maintenance setting is available (only some countries in Europe). Consult an Authorised Mazda Repairer for details. Once the engine oil exible maintenance setting is selected, you will see the following items in the display. The vehicle calculates the remaining oil life based on the engine operating conditions and lets you know when an oil change is due by illuminating the wrench indicator light in the instrument cluster.
Page 562: Owner Maintenance
Improper do-it yourself maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you are unsure about any servicing or maintenance procedure, have it done by an expert repairer, we recommend an Authorised Mazda Repairer.
Page 563 Maintenance and Care Owner Maintenance WARNING Do not perform maintenance work if you lack suf cient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a quali ed technician: Performing maintenance work on a vehicle is dangerous if not done properly. You can be seriously injured while performing some maintenance procedures.
Page 564: Bonnet
NOTE The lever is located a little to the left of centre when facing the vehicle. 3. Grasp the support rod in the padded area and secure it in the support rod hole indicated by the arrow to hold the Release handle bonnet open.
Page 565 Verify that the support rod is secured in the clip before closing the bonnet. Clip Clip Clip 3. Lower the bonnet slowly to a height of about 20 cm (7.9 in) above its closed position and then let it drop. 6–19...
Page 566: Engine Compartment Overview
Maintenance and Care Owner Maintenance Engine Compartment Overview SKYACTIV-G 1.5, SKYACTIV-G 2.0, and SKYACTIV-G 2.5 Windscreen washer fluid reservoir Brake/Clutch fluid reservoir Battery Fuse block Engine oil dipstick Cooling system cap Engine coolant reservoir Engine oil-filler cap MZR 1.6 Windscreen washer fluid reservoir Brake/Clutch fluid reservoir Battery Fuse block...
Page 567 Maintenance and Care Owner Maintenance SKYACTIV-D 1.5 Windshield washer fluid reservoir Brake/Clutch fluid reservoir Battery Fuse block Engine oil dipstick Engine oil-filler cap Cooling system cap Engine coolant reservoir SKYACTIV-D 2.2 Windscreen washer fluid reservoir Brake/Clutch fluid reservoir Battery Fuse block Engine oil dipstick Cooling system cap Engine coolant reservoir...
Page 568: Engine Oil
Authorised Mazda Repairer. Recommended Oil In order to keep the maintenance interval (page 6-3 ) and to protect the engine from damage caused by poor lubrication, it is vitally important to make use of engine oil with the correct speci cation. Do not use oils which do not meet the following speci cations or requirements.
Page 569 *1 Use API SM/SN in Kazakhstan. (SKYACTIV-D 1.5 and SKYACTIV-D 2.2) Temperature Range SAE Viscosity Numbers –30 –20 –10 –40 Grade –40 –20 Recommended oils Mazda Original Oil Supra DPF 0W-30 Mazda Original Oil Ultra DPF 5W-30 Alternative Oil Quality 0W-30 ACEA C3 5W-30 6–23...
Page 570 Maintenance and Care Owner Maintenance Except Europe (MZR 1.6) Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –20 –40 API SG/SH/SJ/SL/SM/SN or ILSAC GF-II/GF-III/GF-IV/GF-V (SKYACTIV-G 1.5, SKYACTIV-G 2.0, and SKYACTIV-G 2.5) Temperature Range SAE Viscosity Numbers –30 –20 –10 –40 Grade –40...
Page 571 Maintenance and Care Owner Maintenance Engine oil viscosity, or thickness, has an effect on fuel economy and cold-weather operation (starting and oil ow). Low-viscosity engine oils can provide improved fuel economy and cold-weather performance. When choosing an oil, consider the temperature range your vehicle will operate in before the next oil change.
Page 572 Otherwise the wrench indicator light or engine oil warning light may turn on. To reset the engine control unit, consult an expert repairer, we recommend an Authorised Mazda Repairer or refer to the vehicle engine control unit reset procedure on page 6-27 .
Page 573 SKYACTIV-G 1.5 or SKYACTIV-G 2.0 which have the engine oil exible maintenance setting selected. After replacing the engine oil, have a repair shop such as an Authorised Mazda Repairer perform the initialization (engine oil data resetting) of the recorded value. If the value recorded by the computer is not initialized, the wrench indicator light may not turn off or it may turn on earlier than normal.
Page 574 2. Warm up the engine to normal operating temperature. 3. Turn it off and wait at least 5 minutes for the oil to return to the sump. 4. Pull out the dipstick, wipe it clean, and reinsert it fully.
Page 575: Engine Coolant
Maintenance and Care Owner Maintenance 5. Pull it out again and examine the level. Engine Coolant The level is normal if it is between the MIN and MAX marks. Inspecting Coolant Level If it is near or below MIN, add enough oil to bring the level to MAX.
Page 576 SKYACTIV-D 1.5 NOTE Changing the coolant should be done by an expert repairer, we recommend an Authorised Mazda Repairer. Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year—at the beginning of the winter season—and before travelling where temperatures may drop below freezing.
Page 577 If the coolant reservoir is empty or new CAUTION coolant is required frequently, consult an expert repairer, we recommend an Authorised Mazda Repairer. Radiator coolant will damage paint. Rinse it off quickly if spilled. Use only soft (demineralised) water in the coolant mixture. Water that contains minerals will cut down on the coolant's effectiveness.
Page 578: Brake/Clutch Fluid
The level normally drops with accumulated distance, a condition associated with wear of brake and clutch linings. If it is excessively low, have the brake/clutch system inspected by an expert Right-hand drive model repairer, we recommend an Authorised Mazda Repairer. 6–32...
Page 579: Automatic Transaxle Fluid (4-Speed Transaxle)
2. Start the engine and depress the brake When the vehicle has been driven and the pedal. uid is at normal operating temperature, 3. Move the shift lever through all ranges about 65°C (150°F), the level must be and set it at P. between Full and Low.
Page 580: Window And Headlight Washer Fluid
Inspect uid level in the washer uid appropriate level, consult an expert reservoir; add uid if necessary. repairer, we recommend an Authorised Mazda Repairer to have the vehicle Type A inspected. NOTE Inspect the uid on both sides of the dipstick in a well lit area for an accurate reading.
Page 581: Body Lubrication
Maintenance and Care Owner Maintenance Type B Body Lubrication All moving points of the body, such as door and bonnet hinges and locks, should be lubricated each time the engine oil is changed. Use a nonfreezing lubricant on locks during cold weather. Make sure the bonnet's secondary latch keeps the bonnet from opening when the primary latch is released.
Page 582: Wiper Blades
Maintenance and Care Owner Maintenance Wiper Blades Replacing Windscreen Wiper Blades When the wipers no longer clean well, the CAUTION blades are probably worn or cracked. Replace them. Hot waxes applied by automatic car washers have been known to affect CAUTION the wiper's ability to clean windows.
Page 583 Maintenance and Care Owner Maintenance 3. Tilt the blade assembly and remove it CAUTION from the arm. Do not bend or discard the stiffeners. You need to use them again. If the metal stiffeners are switched, the blade's wiping ef ciency could be reduced.
Page 584 1. Raise the wiper arm and rotate the 3. Remove the metal stiffeners from the wiper blade to the right until it unlocks, blade rubber and install them in the then remove the blade.
Page 585 Maintenance and Care Owner Maintenance 4. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal. 6–39...
Page 586: Battery
Maintenance and Care Owner Maintenance Battery WARNING Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery: Working without eye protection is dangerous. Battery uid contains SULPHURIC ACID which could cause blindness if splashed into your eyes.
Page 587 Maintenance and Care Owner Maintenance WARNING Keep all ames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 588: Battery Maintenance
Maintenance and Care Owner Maintenance Battery Maintenance Inspecting Electrolyte Level A low level of electrolyte uid will cause the battery to discharge quickly. Upper level To get the best service from a battery: Keep it securely mounted. Lower level Keep the top clean and dry. Inspect the electrolyte level at least once Keep terminals and connections clean, a week.
Page 589: Battery Recharging
Insulate the plus and minus Battery Replacement terminals of the battery using cellophane or equivalent tape. Contact an Authorised Mazda Repairer for Never disassemble. a battery replacement purchase. Never throw the battery into re or water. Never deform or crush.
Page 590 Replacing the battery at an Authorised Mazda Repairer is recommended to prevent damage to the key. If replacing the 3. Insert the tape-wrapped athead battery by yourself, follow the instruction. screwdriver into the gap and slide it in Replacing the key battery the direction of the arrow.
Page 591 Maintenance and Care Owner Maintenance 5. Remove the battery cap, then remove CAUTION the battery. Be careful not to allow the rubber ring shown in the gure to be scratched or damaged. If the rubber ring detaches, reattach it before inserting a new battery. Rubber ring 6.
Page 592: Tyres
Using Different Tyre Types: Refer to Tyres on page 9-14 . Driving your vehicle with different types of tyres is dangerous. It could Use only a Mazda-genuine tyre valve cause poor handling and poor braking; cap: leading to loss of control.
Page 593: Tyre Rotation
Have an expert repairer, we recommend an Authorised Mazda Repairer perform tyre rotation. Forward Do not include (TEMPORARY USE ONLY) spare tyre in rotation.
Page 594 It could cause poor handling and poor initialization of the tyre pressure braking resulting in loss of vehicle monitoring system is necessary to make control. Mazda strongly recommends the system operate normally. that you replace all four tyres at the Refer to Tyre Pressure Monitoring System same time.
Page 595 When replacing a wheel, make The temporary spare tyre has a tread sure the new one is the same as the life of less than 5,000 km (3,000 original factory wheel in diameter, miles). The tread life may be shorter rim width, and offset (inset/outset).
Page 596 Maintenance and Care Owner Maintenance Proper tyre balancing provides the best riding comfort and helps reduce tread wear. Out-of-balance tyres can cause vibration and uneven wear, such as cupping and at spots. 6–50...
Page 597 MEMO 6–51...
Page 598: Light Bulbs
Maintenance and Care Owner Maintenance Light Bulbs With LED Headlights With Halogen Headlights Saloon Hatchback 6–52...
Page 599 Maintenance and Care Owner Maintenance Headlights (Low/High beam) Running lights Headlights (Low beam) Headlights (High beam)/Running lights Front fog lights Front direction indicator lights Position lights Front side-marker lights Side direction indicator lights Brake lights (With LED headlights) Tail lights (With LED headlights) Brake lights/Tail lights (With halogen headlights) Rear side-marker lights (Bulb type) Rear direction indicator lights...
Page 600 The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is CAUTION necessary. Headlights (With halogen headlights) When removing the lens or lamp unit...
Page 601 Maintenance and Care Owner Maintenance 3. Pull the centre of each plastic retainer 5. Disconnect the connector from the unit and remove the retainers. by pressing the tab on the connector with your nger and pulling the connector downward. Removal Installation 4.
Page 602 3. Turn the cover anticlockwise and 2. Lift the bonnet. remove it. 3. Disconnect the connector from the unit by pressing the tab on the connector with your nger and pulling the connector downward.
Page 603 If you are changing the left bulb, turn the steering wheel to the right, and turn off engine. 2. Make sure the headlight switch is off. 3. Pull the centre of each plastic retainer and remove the retainers. Removal 6. Turn the socket and bulb assembly anticlockwise and remove it.
Page 604 1. Make sure the ignition is switched off, and the headlight switch is off. 2. Pull the centre of each plastic retainer and remove the retainers. 3. Remove boot end trim. Position lights/Front side-marker lights (With halogen headlights), Front side-marker lights (With LED...
Page 605 Maintenance and Care Owner Maintenance 6. Turn the socket and bulb assembly 7. Disconnect the connector from the unit anticlockwise and remove it. by pressing the tab on the connector Rear direction indicator lights with your nger and pulling the connector.
Page 606 Maintenance and Care Owner Maintenance 8. Disconnect the bulb by pulling it out. 3. Turn the socket and bulb assembly Rear direction indicator lights, Brake anticlockwise and remove it. lights/Tail lights/Rear side-marker Rear direction indicator lights lights (Bulb type) Brake lights/Tail lights (Bulb type) 9.
Page 607 Maintenance and Care Owner Maintenance 4. Disconnect the connector from the unit 5. Disconnect the bulb by pulling it out. by pressing the tab on the connector Rear direction indicator lights, Brake with your nger and pulling the lights/Tail lights (Bulb type) connector.
Page 608 Rear direction indicator lights 2. Turn the knob and remove the cover. Brake lights/Tail lights/Rear side- marker lights (Bulb type) 3. Turn the wing bolt and jack screw anticlockwise. 6–62...
Page 609 Maintenance and Care Owner Maintenance 6. Disconnect the connector from the unit 7. Disconnect the bulb by pulling it out. by pressing the tab on the connector Rear direction indicator lights, Brake with your nger and pulling the lights/Tail lights/Rear side-marker connector.
Page 610 Maintenance and Care Owner Maintenance 12. Install the cover in the reverse order of 3. Peel back the boot lid trim. the removal procedure. 13. Insert the cover tabs and install the cover. Removal Installation Tabs 4. Disconnect the electrical connector...
Page 611 Maintenance and Care Owner Maintenance 6. Disconnect the bulb from the socket. 3. Disconnect the electrical connector from the bulb by pressing the tab on the connector with your nger and pulling the connector. 7. Install the new bulb in the reverse order of the removal procedure.
Page 612 2. Turn the socket and bulb assembly anticlockwise and remove it. 3. Disconnect the bulb from the socket. 5. Turn the socket and bulb assembly anticlockwise and remove it. 6. Disconnect the bulb from the socket.
Page 613 3. Disconnect the bulb by pulling it out. carefully prying on the edge of the lens with the athead screwdriver. 2. Disconnect the bulb by pulling it out.
Page 614 1. Press both sides of the lens cap to remove it. 2. Disconnect the bulb by pulling it out. Edge Overhead lights (Rear) 3. Install the new bulb in the reverse order of the removal procedure. Luggage compartment light (Hatchback) 1. Wrap a small athead screwdriver with...
Page 615: Fuses
Authorised Mazda Repairer as soon as possible. Fuse Replacement 3. Disconnect the bulb by pulling it out. Replacing the fuses on the vehicle's left side If the electrical system does not work, rst inspect the fuses on the vehicle's left side.
Page 616 Maintenance and Care Owner Maintenance 3. Pull the fuse straight out with the CAUTION fuse puller provided on the fuse block located in the engine compartment. Always replace a fuse with a genuine Mazda fuse or equivalent of the same rating.
Page 617 Maintenance and Care Owner Maintenance 3. If any fuse but the MAIN fuse is blown, replace it with a new one of the same amperage rating . Normal Blown WARNING Do not replace the main fuse and multiplex slow blow fuse by yourself.
Page 618: Fuse Panel Description
Maintenance and Care Owner Maintenance Fuse Panel Description Fuse block (Engine compartment) Multiplex slow blow fuse FUSE DESCRIPTION PROTECTED COMPONENT RATING 15 A Front fog lights H/L HI 20 A Headlight high beam H/CLEAN 20 A Headlight washer STOP 10 A Brake lights, Rear fog light ROOM 15 A...
Page 619 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING 15 A Transaxle control system R.WIPER 15 A Rear window wiper 7.5 A Air conditioner ENGINE3 15 A Engine control system ENGINE2 15 A Engine control system ENGINE1 15 A Engine control system GLOW SIG Engine control system...
Page 620 Maintenance and Care Owner Maintenance Fuse block (Left side) FUSE DESCRIPTION PROTECTED COMPONENT RATING P.WINDOW3 30 A Power seat P.SEAT D D.LOCK 25 A Power door locks P.WINDOW2 25 A Power windows SEAT WARM 20 A Seat warmer R.OUTLET3 15 A —...
Page 621: Appearance Care
These acids can settle on a vehicle's nish. As the water evaporates, Prevention the acid becomes concentrated and can It is necessary to have your Mazda washed damage the nish. and waxed to preserve its nish according And the longer the acid remains on the to the instructions in this section.
Page 622 The rings can damage paint chipping. your vehicle's nish. Chipped paint can lead to rust forming on your Mazda. Before this Prevention happens, repair the damage by using It is necessary to wash and wax your Mazda touch-up paint according vehicle to preserve its nish according to to the instructions in this section.
Page 623 Maintenance and Care Appearance Care Maintaining the Finish To help protect the nish from rust and deterioration, wash your Mazda thoroughly and frequently, at least once a Washing month, with lukewarm or cold water. CAUTION If the vehicle is washed improperly, the paint surface could be scratched.
Page 624 Maintenance and Care Appearance Care CAUTION WARNING Do not use steel wool, abrasive Dry off brakes that have become cleaners, or strong detergents wet by driving slowly, releasing the containing highly alkaline or caustic accelerator pedal and lightly applying agents on chrome-plated or anodised the brakes several times until the brake aluminium parts.
Page 625 2. Use a good grade of natural wax for 2. Wipe with a clean soft cloth. metallic, mica, and solid colours. 3. Apply rust preventive primer to the 3. When waxing, coat evenly with the area. sponge supplied or a soft cloth.
Page 626 Check this coating periodically. An expert repairer, we recommend an Authorised Mazda Repairer are well informed on how repairs should be made. Consult an expert repairer, we recommend an Authorised Mazda Repairer.
Page 627: Interior Care
Maintenance and Care Appearance Care Plastic Part Maintenance Interior Care When cleaning the plastic lenses of the lights, do not use petrol, paraf n, WARNING recti ed spirit, paint, thinner, highly acidic detergents, or strongly alkaline Do not spray water into the vehicle detergents.
Page 628 Upholstery Maintenance wrung out well. 3. Before retracting seat belts which have 1. Clean the soiled area by lightly dabbing been pulled out for cleaning, dry them it with a soft cloth soaked in a mild off thoroughly and make sure there is detergent (approx.
Page 629 Maintenance and Care Appearance Care Plastic Part Maintenance NOTE Because genuine leather is a natural CAUTION material, its surface is not uniform and it may have natural scars, Do not use polishing agents. scratches, and wrinkles. Depending on the product ingredients, To maintain the quality for as long they could cause discolouration, stains, as possible, periodical maintenance,...
Page 630 Maintenance and Care Appearance Care Panel Maintenance If a panel becomes soiled, wipe it off with a soft cloth soaked in clean water and thoroughly wrung out. If some areas require further cleaning, use the following procedure: 1. Wipe the soiled area with a soft cloth soaked in a mild detergent (approx.
Page 631: If Trouble Arises
......7-2 Flashes .......... 7-34 Message Indicated in Multi- Flat Tyre ..........7-3 information Display ..... 7-47 Spare Tyre and Tool Storage ..7-3 Message Indicated on Display ..7-49 Warning Sound is Activated ..7-51 Emergency Flat Tyre Repair ..........
Page 632: Parking In An Emergency
If Trouble Arises Parking in an Emergency Parking in an Emergency Roadside Emergency Triangle Retaining Strap The hazard warning lights should always be used when you stop on or near a Keep the roadside emergency triangle in roadway in an emergency. the right side trim and secure it with the strap.
Page 633: Flat Tyre
If Trouble Arises Flat Tyre Spare Tyre and Tool Storage NOTE Your vehicle may or may not be equipped with a spare tyre, jack, wheel brace, and tool bag. For details, consult an Authorised Mazda Repairer. 7–3...
Page 634 If Trouble Arises Flat Tyre Spare tyre and tools are stored in the locations illustrated in the diagram. Saloon (With spare tyre (Except Saudi Arabia)) Spare tyre hold-down bolt Towing eyelet Screwdriver Jack lever Jack Wheel brace Wrench Spare Tool bag tyre (With spare tyre (Saudi Arabia)) Spare tyre hold-down bolt...
Page 635 If Trouble Arises Flat Tyre Hatchback (With spare tyre) Spare tyre hold-down bolt Towing eyelet Wheel brace Screwdriver Jack Jack lever Wrench Tool bag Spare tyre (Without spare tyre) Emergency flat tyre repair kit Towing eyelet Wheel brace Jack lever Some models.
Page 636 Turn the knob and remove the cover. temporarily tighten it. 2. Turn the jack screw in the direction shown in the gure. 3. Turn the wing bolt completely to secure the jack. NOTE If the jack is not completely secured, it could rattle while driving.
Page 637 Flat Tyre 4. Insert the cover tabs and install the Spare Tyre cover. Your Mazda has a temporary spare tyre. The temporary spare tyre is lighter and (Saloon) smaller than a conventional tyre, and is designed only for emergency use and should be used only for VERY short periods.
Page 638 Spare tyre hold-down bolt Do not use your temporary spare tyre on any other vehicle, it has been designed only for your Mazda. Use only one temporary spare tyre on your vehicle at the same time. To secure the spare tyre Store the spare tyre in the reverse order of removal.
Page 639: Emergency Flat Tyre Repair
The emergency at tyre repair kit includes the following items. The emergency at tyre repair kit included with your Mazda is for a temporary repair of a slightly damaged at tyre resulting from running over nails or similar sharp objects on the road surface.
Page 640: Kit
P position recommend an Authorised Mazda for an automatic transaxle. Repairer. 3. Apply the parking brake with the brake pedal depressed and turn off the engine. The period of effective use for 4. If necessary, ash the hazard warning the tyre sealant has expired.
Page 641 If Trouble Arises Flat Tyre 6. Shake the sealant bottle to mix the 7. Pull out the compressor hose and contents. Then extend the injection the compressor plug from the air hose. compressor. Compressor hose 8. Install the compressor hose which was Injection hose pulled out of the air compressor to the injection valve of the bottle.
Page 642 NOTE The in ation pressure may increase to about 300 kPa (3.1 kgf/cm , 3 bar, 43.5 psi) temporarily to inject the sealant through the valve. Normally, the in ation pressure decreases gradually and it reaches the actual in ation pressure after about 30 seconds.
Page 643 Never use the air compressor above 300 kPa (3.1 kgf/cm , 3 bar, 43.5 psi): Using the air compressor at an in ation pressure above 300 kPa (3.1 kgf/cm , 3 bar, 43.5 psi) continuously is dangerous. If the air compressor overheats, hot air will be exhausted and you could get burned.
Page 644 (page 4-41 ). 19. After driving the vehicle for about 10 minutes or 5 km (3 miles), connect the air compressor to the tyre using Step 9 of the procedure, and check the tyre in ation pressure using the tyre pressure gauge on the air compressor.
Page 645: Tyre Repair Kit
Replacement with a new tyre use it if it has expired. Have the tyre is recommended. If the tyre is to be sealant replaced at an Authorised Mazda repaired or reused, consult an expert Repairer before the period of effective repairer, we recommend an Authorised use has expired.
Page 646: Changing A Flat Tyre (With Spare Tyre)
Reverse (R) or 1, and turn The vehicle pulls in one direction. off the engine. 3. Turn on the hazard warning asher. 4. Have everyone get out of the vehicle If you have a at tyre, drive slowly to a and away from the vehicle and traf c.
Page 647 3. Place the jack on the ground. 4. Turn the jack screw in the direction NOTE shown in the gure and adjust the jack...
Page 648 Use only the jack provided with your Mazda: Using a jack that is not designed for your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Jacking position Never place objects under the jack: Jacking the vehicle with an object under the jack is dangerous.
Page 649 Before removing the wheel nuts, make sure Never go under the vehicle while it is your Mazda is rmly in position and jacked up: that it cannot slip or move. Going under the vehicle while it is...
Page 650 If Trouble Arises Flat Tyre Mounting the Spare Tyre 3. Install the wheel nuts with the bevelled edge inward; tighten them by hand. 1. Remove dirt and grime from the mounting surfaces of the wheel and hub, including the hub bolts, with a cloth.
Page 651 Because the wheel studs and wheel nuts on your Mazda have metric If you are unsure of how tight the nuts threads, using a non-metric nut is should be, have them inspected at an dangerous.
Page 652 If Trouble Arises Flat Tyre WARNING Do not drive with any tyres that have incorrect air pressure: Driving on tyres with incorrect air pressure is dangerous. Tyres with incorrect pressure could affect handling and result in an accident. When you check the regular tyres' air pressure, check the spare tyre, too.
Page 653: Battery Runs Out
If Trouble Arises Battery Runs Out Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 654 If Trouble Arises Battery Runs Out CAUTION Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V motor generator set).
Page 655 V and that its negative terminal is If the vehicle is driven with the grounded. i-ELOOP indicator light ashing, a 3. If the booster battery is in another beep sound is heard. vehicle, do not allow both vehicles If the steering wheel is operated with to touch.
Page 656: Emergency Starting
2. Make sure the parking brake is on. CAUTION 3. Depress the accelerator all the way and hold it there. 4. Depress the clutch pedal (Manual Do not push-start a vehicle that has a transaxle) or the brake pedal manual transaxle.
Page 657: Running Out Of Fuel (Skyactiv-D 1.5 And Skyactiv-D 2.2)
If the engine does not start the rst time, try starting it several more times. If it still does not start, contact an expert repairer, we recommend an Authorised Mazda Repairer. 7–27...
Page 658: Overheating
(P), a manual transaxle in neutral. WARNING 3. Apply the parking brake. 4. Turn off the air conditioner. 5. Check whether coolant or steam is escaping from the engine compartment. Pull over to a safe location, then...
Page 659 If you nd a leak or other damage, or if SKYACTIV-D 2.2 coolant is still leaking: Cooling system cap Stop the engine and call an expert repairer, Coolant reservoir we recommend an Authorised Mazda Repairer. MZR 1.6, SKYACTIV-G 1.5, SKYACTIV-G 2.0, and SKYACTIV-G Cooling system cap Cooling fan...
Page 660: Emergency Towing
CAUTION We recommend that towing be done only by an expert repairer, we recommend Do not tow the vehicle pointed an Authorised Mazda Repairer or a backward with driving wheels on commercial tow-truck service. the ground. This may cause internal damage to the transaxle.
Page 661: Towing Hooks
If Trouble Arises Emergency Towing Towing Hooks CAUTION CAUTION Follow these instructions when towing the vehicle with all wheels on the ground. The towing eyelet should be used in an emergency (to get the vehicle Shift to neutral (Manual transaxle), out of a ditch or a snow bank, for or the N position (Automatic example).
Page 662 (Hatchback) 1. Remove the towing eyelet and the wheel brace from the luggage compartment (page 7-3 ). 2. Wrap a athead screwdriver or similar tool with a soft cloth to prevent damage to a painted bumper, and open the cap located on the front or rear bumper.
Page 663 If Trouble Arises Emergency Towing 3. Securely install the towing eyelet using CAUTION the wheel brace or equivalent. Consult an Authorised Mazda Repairer. Front If the towing eyelet is not securely tightened, it may loosen or disengage from the bumper when towing the Wheel brace vehicle.
Page 664: Warning/Indicator Lights And Warning Sounds
4. Select the applicable warning to view the warning details. Stop Vehicle in Safe Place Immediately If any of the following warning lights turns on, the system may have a malfunction. Stop the vehicle in a safe place immediately and contact an Authorised Mazda Repairer. 7–34...
Page 665 Do not drive with the brake system warning light illuminated. Contact an expert repairer, we recommend an Authorised Mazda Repairer to have the brakes inspected as soon as possible: Driving with the brake system warning light illuminated is dangerous. It indicates that your brakes may not work at all or that they could completely fail at any time.
Page 666 Have the vehicle towed to an expert repairer, we recommend an Warning Authorised Mazda Repairer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 667 1. Drive to the side of the road and park off the right-of-way on level ground. 2. Turn off the engine and wait 5 minutes for the oil to drain back into the sump. 3. Inspect the engine oil level 6-28 . If it's low, add the appropriate amount of engine Engine Oil Warning oil while being careful not to over ll.
Page 668 Contact Authorised Mazda Repairer and Have Vehicle Inspected If any of the following warning lights or the indicator light turns on/ ashes, the system may have a malfunction. Contact an expert repairer, we recommend an Authorised Mazda Repairer to have your vehicle inspected.
Page 669 The emission control system has a problem. If the check engine light remains on, or it ashes continuously, do not drive at high speeds and consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. When illuminated...
Page 670 ON. If any of these occur, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. The system may not operate in an accident.
Page 671 Make sure the key is within the operational range for signal transmission. Switch the ignition off, and then restart the engine. If the engine does not start after 3 or more tries, Security Indicator contact an expert repairer, we recommend an Authorised Mazda Repairer.
Page 672 The LDWS does not operate when the warning light ashes. NOTE If any of the following cases occurs, the system may have a malfunction. Have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. Lane Departure The light ashes while the vehicle is being driven.
Page 673 Inspect the tyres and adjust to the speci ed When the warning light illuminates, and in ation pressure (page 6-46 ). the warning beep sound is heard (about 3 seconds), tyre pressure is too low in one or NOTE more tyres.
Page 674 Warning Light recommend an Authorised Mazda Repairer. The light turns on when the remaining fuel is about 9.0 L (2.3 US gal, 1.9 Imp gal). NOTE Add fuel. The light illumination timing may Low Fuel Warning...
Page 675 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Warning Action to be taken With warning light for front passenger's seat The seat belt warning light illuminates if the driver or front passenger's seat is occupied and the seat belt is not fastened with the ignition switched ON.
Page 676 The key is not within the operation range. Bring the key into the operation range The key is placed in areas inside the (page 3-7 ). cabin where it is dif cult for the key to be detected. Take the key from another manufacturer...
Page 677 If Trouble Arises Warning/Indicator Lights and Warning Sounds Message Indicated in Multi-information Display If there is a noti cation from the vehicle, a message is displayed in the multi-information display. Check the information and take the necessary action. (Display example) If the warning light turns on/ ashes simultaneously or a symbol is indicated in the display, check the information regarding the warning light or symbol.
Page 678 If Trouble Arises Warning/Indicator Lights and Warning Sounds Display Content Action to be taken Indicated while the steering wheel is Release the steering lock. locked. 7–48...
Page 679: Message Indicated On Display
Stop Vehicle in Safe Place Immediately If the following messages are displayed in the centre display (Type C/type D audio), a vehicle system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorised Mazda Repairer. Display Indicated Condition Displays if the engine coolant temperature has increased excessively.
Page 680 If Trouble Arises Warning/Indicator Lights and Warning Sounds Make Sure the Message is No Longer Displayed Displays in the following cases: Display Indicated Condition/Action to be taken Displays if i-ELOOP requires charging. Leave the engine idling and wait until the message disappears. NOTE If the vehicle is driven while the message is displayed, the buzzer will sound.
Page 681: Warning Sound Is Activated
Have your vehicle inspected at an expert *1 If the light switch is left on, the auto repairer, we recommend an Authorised headlight off function automatically Mazda Repairer as soon as possible. turns off the lights about 30 seconds after switching the ignition off. The WARNING time setting can be changed.
Page 682 If Trouble Arises Warning/Indicator Lights and Warning Sounds Seat Belt Warning Beep Ignition Not Switched Off (STOP) Warning Beep Front seat If the driver's door is opened with the ignition switched to ACC, a beep will If the vehicle speed exceeds about 20 be heard continuously in the cabin to km/h (12 mph) with the driver or front notify the driver that the ignition has not...
Page 683 Make sure the indicator light is functions have been temporarily stopped. no longer illuminated and the message To restore the key's functions, perform the is no longer displayed before driving the applicable procedure (page 3-8 ). vehicle. 7–53 *Some models.
Page 684 System (LAS) & Lane Departure Warning System (LDWS) warning The warning beep sound will be heard sound can be changed. for about 3 seconds when there is any Refer to Personalisation Features on abnormality in tyre in ation pressures page 9-17 .
Page 685 Speed Limiter Warning Beep Excessive Speed Warning If the vehicle speed exceeds the set speed by about 3 km/h (2 mph) or more, a If the vehicle speed exceeds the speed warning beep operates continuously. The limit sign displayed on the active driving...
Page 686 If Trouble Arises Warning/Indicator Lights and Warning Sounds Collision Warning If there is a possibility of a collision with a vehicle ahead or an obstruction at the rear of the vehicle, the warning light in the instrument cluster ashes at the same time as the warning indication is displayed in the multi-information display or active driving display, and a warning sound is...
Page 687: When Liftgate/Boot Lid Cannot Be Opened
(Hatchback) 1. Remove the cap on the interior surface of the liftgate with a athead screwdriver. 3. (European models) Turn the screw anticlockwise and remove it, and then remove the inner cover. 2. Turn the lever to the right to unlock the liftgate.
Page 688 4. Move the lever to the left to fold the seatback. Cover Lever 5. Move the lever to the left to open the boot lid. After performing this emergency measure, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 7–58...
Page 689: Active Driving Display Does Not Operate
If the active driving display does not operate, switch the ignition off and then restart the engine. If the active driving display does not operate even with the engine restarted, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 7–59...
Page 690 MEMO 7–60...
Page 691: Customer Information
Important consumer information including warranties and add-on equipment. Warranty ..................... 8-2 Registering Your Vehicle in A Foreign Country ......8-2 Add-On Non-Genuine Parts and Accessories ....... 8-3 Cell Phones ..................8-4 Cell Phones Warning ..............8-4 Recording of Vehicle Data ..............8-5 Recording of Vehicle Data ............
Page 692: Warranty
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorised Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 693: Add-On Non-Genuine Parts And Accessories
Other parts and accessories than those mentioned above have not been examined and approved by Mazda unless explicitly stated by Mazda. We cannot certify the suitability of such products. Mazda is not liable for any damage caused by the use of such products. WARNING...
Page 694: Cell Phones
Customer Information Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 695: Recording Of Vehicle Data
Mazda and its subcontracting parties may obtain and use the recorded data for vehicle malfunction diagnosis, research and development, and quality improvement. Mazda will not disclose or provide any of the obtained data to a third party unless: An agreement from the vehicle owner (agreements from lessor and lessee for leased...
Page 696: Declaration Of Conformity
Customer Information Declaration of Conformity Declaration of Conformity Keyless Entry System/Immobilizer System 8–6...
Page 697 Customer Information Declaration of Conformity 8–7...
Page 698 Customer Information Declaration of Conformity 8–8...
Page 699 Customer Information Declaration of Conformity Blind Spot Monitoring (BSM) System 8–9...
Page 700 Customer Information Declaration of Conformity 8–10...
Page 701 Customer Information Declaration of Conformity 8–11...
Page 702 Customer Information Declaration of Conformity Bluetooth® Hands-Free Type A/Type B 8–12...
Page 703 Customer Information Declaration of Conformity 8–13...
Page 704 Customer Information Declaration of Conformity Type C/Type D 8–14...
Page 705 Customer Information Declaration of Conformity 8–15...
Page 706 Customer Information Declaration of Conformity 8–16...
Page 707 Customer Information Declaration of Conformity 8–17...
Page 708 Customer Information Declaration of Conformity Distance Recognition Support System (DRSS)/Mazda Radar Cruise Control (MRCC)/Smart Brake Support (SBS) 8–18...
Page 709 Customer Information Declaration of Conformity 8–19...
Page 710: Electromagnetic Compatibility
Do not fasten aerial lead to original vehicle wiring, fuel pipes or brake pipes. Avoid running the aerial lead parallel with the wire harness to the best extent possible. Keep the aerial and power leads at least 100 mm (3.9 in) from any electronic modules and the air bags.
Page 711 Customer Information Electromagnetic Compatibility Aerial positions: : front right of roof : front left of roof : centre of roof : both sides of liftgate (Hatchback) : both sides of boot lid (Saloon) Frequency Band (MHz) Maximum output power (Wattage) Aerial Positions 50 —...
Page 712: Collection/Disposal Of Old Equipment/Used Battery
Customer Information Collection/Disposal of Old Equipment/Used Battery Information for Users on Collection and Disposal of Old Equipment and Used Batteries When disposing your old battery, please refer to the information as follows. Information on Disposal in the European Union These crossed-out wheeled bin symbols on the products, packaging, and/or accompanying documents mean that used electronic products and batteries should not be mixed with general household waste.
Page 713 Customer Information Collection/Disposal of Old Equipment/Used Battery Information on Disposal in Other Countries Outside the European Union The above symbols are only valid in the European Union. If you wish to discard old products and used batteries, please contact your local authorities, your waste disposal service or the point of sales where you purchased the items, and ask for the correct method of disposal.
Page 714 MEMO 8–24...
Page 715 Speci cations Technical information about your Mazda. Identi cation Numbers ..............9-2 Vehicle Information Labels ............9-2 Speci cations ..................9-5 Speci cations ................9-5 Personalisation Features..............9-17 Personalisation Features .............. 9-17 9–1 9–1...
Page 716 Speci cations Identi cation Numbers Vehicle Information Chassis Number/Vehicle Identi cation Number (Ireland, Labels Kazakhstan, Belarus, Russia, U.K.) Chassis Number Vehicle Identi cation Number Open the cover shown in the gure to (South Africa, Arab Gulf check the chassis number. Cooperation Council) The vehicle identi cation number legally identi es your vehicle.
Page 717 Speci cations Identi cation Numbers Vehicle Emission Control Type B Information Label (The Philippines) Right-hand drive model Tyre Pressure Label Left-hand drive model Type A 9–3...
Page 718 Speci cations Identi cation Numbers Engine Number SKYACTIV-D 2.2 MZR 1.6 Forward Forward Conformity Plate (Arab Gulf SKYACTIV-G 1.5, SKYACTIV-G 2.0, Cooperation Council) SKYACTIV-G 2.5 Production year and month are shown on this plate. Forward SKYACTIV-D 1.5 Forward 9–4...
Page 719: Petrol Engine
Speci cations Engine Petrol engine Speci cation Item MZR 1.6 Type DOHC-16V in-line, 4-cylinder Bore × Stroke 78.0 × 83.6 mm (3.07 × 3.29 in) Displacement 1,598 ml (1,598 cc) Compression ratio 10.0 Speci cation Item SKYACTIV-G 1.5 SKYACTIV-G 2.0 SKYACTIV-G 2.5...
Page 720: Electrical System
*1 Q-85, S-95 or T-110 is designed for i-stop system (FOR STOP & START)/i-ELOOP system. Only Q-85, S-95 or T-110 should be used to ensure correct operation of i-stop system (FOR STOP & START)/i-ELOOP system. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. *2 Not for i-stop system/i-ELOOP system.
Page 721 *2 Mazda Original Oils are specially designed/tested for the respective engine. For optimum performance we recommend to use Mazda Original Oils at all times. *3 If you are unable to nd a Mazda Original Oil, alternative oils meeting the listed speci cation may also be used. *4 Use API SM/SN in Kazakhstan.
Page 722 Capacities (Approximate Quantities) Item Capacity With oil lter replacement 3.9 L (4.1 US qt, 3.4 Imp qt) MZR 1.6 Without oil lter replacement 3.7 L (3.9 US qt, 3.3 Imp qt) With oil lter replacement 4.2 L (4.4 US qt, 3.7 Imp qt) SKYACTIV-G 1.5...
Page 723 5.6 L (5.9 US qt, 4.9 Imp qt) SKYACTIV-G Except Europe 5.8 L (6.1 US qt, 5.1 Imp qt) Left-hand drive model 6.0 L (6.3 US qt, 5.3 Imp qt) Automatic transaxle Right-hand drive model 5.8 L (6.1 US qt, 5.1 Imp qt) Left-hand drive model 6.2 L (6.6 US qt, 5.5 Imp qt)
Page 724 Speci cations Speci cations Item Capacity MZR 1.6 2.91 L (3.07 US qt, 2.56 Imp qt) SKYACTIV-G 1.5 1.59 L (1.68 US qt, 1.40 Imp qt) Manual SKYACTIV-G 2.0 1.70 L (1.80 US qt, 1.50 Imp qt) transaxle oil SKYACTIV-G 2.5, SKYACTIV-D 1.5 1.65 L (1.74 US qt, 1.45 Imp qt)
Page 725 Speci cations Speci cations Dimensions Saloon Item Vehicle speci cation Overall length 4,580 mm (180.3 in) Overall width 1,795 mm (70.7 in) Overall height 1,450 mm (57.1 in) Front tread 1,555 mm (61.2 in) Rear tread 1,560 mm (61.4 in) Wheelbase 2,700 mm (106.3 in)
Page 726: Exterior Light
*2 LED is the abbreviation for Light Emitting Diode. *3 Double- lament light bulb, however, only 55 W lament bulb is used in the headlights (high beam). *4 Double- lament light bulb, however, only 15 W lament bulb is used in the running lights.
Page 727 Speci cations Speci cations Saloon (Arab Gulf Cooperation Council/Iraq) Category Light bulb Wattage UNECE (SAE) With LED High/Low — (—) headlights beam Headlights High beam HB3 (—) With halogen bulb headlights Low beam H11 (H11) Running lights (With LED headlights) —...
Page 728: Index
Speci cations Speci cations Interior light Category Light bulb Wattage UNECE Boot light (Saloon) — Luggage compartment light (Hatchback) — Overhead lights (Front)/Map lights — Overhead light (Front) — Overhead light (Rear) — Vanity mirror lights — *1 UNECE stands for United Nations Economic Commission for Europe. Tyres Sample tyre mark and its meaning Nominal section width...
Page 729 NOTE The tyres have been optimally matched with the chassis of your vehicle. When replacing tyres, Mazda recommends that you replace tyres of the same type originally tted to your vehicle. For details, contact an expert repairer, we recommend an Authorised Mazda Repairer.
Page 730 Refer to Fuses on page 6-69 . Brakes If you require information regarding the wear limit speci cation for the brake disc plates and the measurement method, please contact an expert repairer, we recommend an Authorised Mazda Repairer. The information is made freely available. 9–16...
Page 731 C: Refer to Active Driving Display on page 4-38 . Settings can be changed by operating the vehicle switches. D: Refer to Auto Lock/Unlock Function on page 3-17 . E: Refer to Transmitter on page 3-4 . F: Refer to Locking, Unlocking with Request Switch (With the advanced keyless function) on page 3-14 .
Page 732 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings Safety Advanced The system can be changed so that Smart City Smart City Brake Support (SCBS)/Smart Brake Support On/Off A — Brake Support (SBS) does not operate. (Advanced The distance at which the collision warning Near/Mid/Far...
Page 733 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings The system can be changed so that the On/Off A — steering wheel assist does not operate. The timing at which the steering wheel operation assist of the Lane-keep Assist System (LAS) &...
Page 734 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings The system can be changed so that Blind Spot On/Off A — Blind Spot Monitoring (BSM) does not operate. Monitoring High/ (BSM) (page Warning beep volume High Low/ A —...
Page 735 Driving/ Lock: Driving, Unlock: IGN Off/ Lock: Driving, Door locks Operation condition of auto lock/unlock Lock When Unlock: IGN (page 3-17 ) function Shifting Out Of P/ Lock: Shift From P, Unlock: In P/ Lock: Driving, Unlock: In P Keyless entry...
Page 736 Speci cations Personalisation Features Settings Change Factory Available Item Feature Method Setting Settings Lights-on reminder (page Warning beep volume High High/Low/Off A — 7-51 ) 120 seconds/ Coming home 90 seconds/ light (page Time until headlights turn off 30 seconds 60 seconds/ A —...
Page 737 Street Name & Turn by Turn/ *1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On. *2 For vehicles with an audio system other than the on-screen function type, the warning sound cannot be changed.
Page 738 MEMO 9–24...
Page 739 Index 10–1 10–1...
Page 740 Shift-lock system ......4-53 Temporarily cancelling the Transaxle ranges ......4-54 system .......... 4-179 Advanced Key Advanced keyless entry system ..3-9 Operational range ......3-10 Battery ..........6-40 Advanced Smart City Brake Support Inspecting Electrolyte Level ..6-42 (Advanced SCBS) ......4-180 Maintenance ........
Page 741 Child-restraint system suitability for TCS/DSC Indicator Light ..... 4-94 various seat positions table.... 2-30 Installing child-restraint systems... 2-33 Child Safety Locks for Rear Doors ..3-20 Clock ........... 5-34 Collision warning ........ 7-56 Coming Home Light ......4-69 Control Status Display ...... 4-100...
Page 742 Forward Sensing Camera (FSC) ..4-199 1.5, SKYACTIV-D 2.2) ....... 3-29 Front Seat ..........2-5 Ending Display ........4-103 Fuel Engine Filler ap and cap ......3-31 Bonnet release ....... 6-18 Gauge ..........4-26 Coolant .......... 6-29 Requirements (MZR 1.6, Engine Compartment Overview ..6-20 SKYACTIV-G 1.5, SKYACTIV-G 2.0,...
Page 743 (AFS) ........... 4-110 Adaptive LED Headlights (ALH) ... 4-111 Hazard Warning Flasher ...... 4-82 Adjustable speed limiter ....4-173 Hazardous Driving ......3-57 Advanced Smart City Brake Support Head Restraint ........2-11 (Advanced SCBS) ....... 4-180 Headlight Washer ........ 4-79 Blind Spot Monitoring (BSM) ..
Page 744 Warning light (Amber) ....4-18 i-stop warning beep ......7-53 If a Warning Light Turns On or Flashes..........7-34 Key Suspend Function ......3-8 If the Active Driving Display does not Key left-in-luggage compartment warning operate ..........7-59 beep (With the advanced keyless Ignition function) ..........
Page 745 Rear Coat Hooks ....... 5-160 Average fuel economy ....4-35 Rear Cross Traf c Alert (RCTA) ..4-141 Current fuel economy ....4-35 Rear Door Child Safety Locks .... 3-20 Distance-to-empty ......4-34 Rear Seat ..........2-8 Fuel Gauge ........4-33 Rear View Monitor......
Page 746 ........4-189 Roadside Emergency Triangle Retaining Smart City Brake Support [Reverse] Strap ............7-2 (SCBS R) .......... 4-190 Rocking the Vehicle ......3-58 Stopping the Smart City Brake Running-In .......... 3-56 Support [Reverse] (SCBS R) system operation ........4-194...
Page 747 Tyre in ation pressure warning beep... 7-54 Cargo sub-compartment ....5-159 Tyres ............ 6-46 Centre console ......5-159 Flat Tyre .......... 7-3 Glove compartment ..... 5-158 Replacing a Tyre ......6-48 Overhead console ......5-158 Replacing a Wheel ......6-49 Rear coat hooks ......
Page 748 Index Warning Sound is Activated ....7-51 Windows 120 km/h warning beep ....7-56 Power windows ......3-40 Air Bag/Front Seat Belt Pretensioner Windscreen Washer ......4-78 System Warning Beep ....7-51 Windscreen Wipers ......4-76 Blind Spot Monitoring (BSM) warning Winter Driving ........
