Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3 INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. SPECIAL NOTICES...
Page 4 Introduction Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles. Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident.
Page 5 Introduction Notice to owners of the Harley-Davidson F-150 Your vehicle is not designed to be operated off-road. Due to the low-profile tires provided on your vehicle, it is important that correct tire pressure is maintained. Correct tire pressure is important to payload and proper ride and handling attributes.
Page 6 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
Page 7 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature...
Page 8: Instrumentation
Instrumentation Instrument panel dimmer switch (pg. 21) PEDALS Headlamp control (pg. 20) Power rear slider window* (pg. 22) Power adjustable foot pedals* * if equipped Instrument cluster (pg. 10) THEFT FUEL SERVICE ENGINE SOON FUEL DOOR Hood release (pg. 198) Parking brake (pg.
Page 9 Gearshift (includes overdrive button) (pg. 146) VOL - PUSH ON BASS SEEK TUNE Auxiliary power point (pg. 23) Electronic sound system (pg. 24) TREB FADE TAPE SIDE 1 - 2 SCAN PANEL & FLOOR FLOOR PANEL FLR& COOL WARM Climate control systems (pg.
Page 10: Warning Lights And Chimes
Instrumentation WARNING LIGHTS AND CHIMES Standard instrument cluster FUEL SERVICE ENGINE SOON FUEL DOOR Optional instrument cluster FUEL SERVICE ENGINE SOON FUEL DOOR Low fuel Illuminates as an early reminder of a low fuel condition indicated on the fuel gauge (refer to Fuel Gauge in this chapter for more information).
Page 11 Instrumentation Service engine soon Your vehicle is equipped with a SERVICE computer that monitors the engine’s ENGINE emission control system. This SOON system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 12 Instrumentation Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
Page 13 Instrumentation Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position to ensure the circuit is functional. If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.
Page 14 Instrumentation Oil pressure/Engine coolant This light will come on when the key is in the ON position and the: engine coolant temperature is very high engine oil pressure is low The light serves as a notice that a system needs your attention and to check the engine coolant temperature gauge and the engine oil pressure gauge.
Page 15 Instrumentation Door ajar Illuminates when the ignition is in the ON or START position and any DOOR door is open. AJAR Speed control (if equipped) This light comes on when either the CRUISE SET/ACCEL or RESUME controls are pressed. It turns off when the speed control OFF control is pressed, the brake is applied or the ignition is turned to the OFF position.
Page 16: Fuel Gauge
Instrumentation GAUGES Standard instrument cluster gauges FUEL SERVICE ENGINE SOON FUEL DOOR Optional instrument cluster gauges FUEL SERVICE ENGINE SOON FUEL DOOR Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion.
Page 17 Speedometer Indicates the current vehicle speed. Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 18 Instrumentation Trip odometer Registers the kilometers (miles) of individual journeys. Press and release the reset button until a “T” P RN appears in the display (this represents the trip mode). Press and hold the button for three seconds to reset. Tachometer Indicates the engine speed in revolutions per minute.
Page 19 Instrumentation Engine oil pressure gauge This shows the engine oil pressure in the system. Sufficient pressure exists as long as the needle remains in the normal range (the area between the “L” and “H”). If the gauge indicates low pressure, stop the vehicle as soon as safely possible and switch off the engine immediately.
Page 20: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. High beams Push forward to activate. Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate.
Page 21 Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision. Foglamp control (if equipped) The headlamp control also operates the foglamps.
Page 22 Controls and features AUTOLAMP CONTROL (IF EQUIPPED) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for approximately 20 seconds after the ignition switch is turned to OFF.
Page 23 Never adjust the accelerator and brake pedal with feet on pedals or while the vehicle is moving. 4WD CONTROL (IF EQUIPPED) This control operates the 4WD. Refer to the Driving chapter for more information. AUXILIARY POWER POINT Power outlets are designed for accessory plugs only.
Page 24 Controls and features USING YOUR AUDIO SYSTEM AM/FM Stereo (with 2 speakers) PUSH AM/FM Stereo (with 4 speakers and fade capability) PUSH AM / FM STEREO TONE TONE VOL TONE TONE VOL SEEK TUNE AM/FM SEEK TUNE AM/FM...
Page 25 Controls and features Volume/power control Press the control to turn the audio PUSH system on or off. Turn the control to raise or lower volume. PUSH If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 26 Controls and features Tune adjust in radio mode Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly. Press to move to the next frequency up the band (whether or not a listenable station is located there).
Page 27 Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the TONE control once, then use the volume knob to adjust the desired level. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output.
Page 28 Controls and features Setting the clock Press CLK to toggle between listening frequencies and clock mode. To set the hour, press and hold the CLK control until CLOCK SET appears in the display and press the SEEK control: to decrease hours and to increase hours.
Page 29 AM/FM stereo cassette VOL - PUSH ON SEEK TUNE Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 30 Controls and features AM/FM select The AM/FM select control works in radio and tape modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the AM control to select from AM selections, and press the FM control to select from FM1 or FM2 memory preset stations.
Page 31 Controls and features Scan function The scan function works in radio mode. SCAN Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 32 Controls and features Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 33 Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 34 Controls and features Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 35 To set the minute, press and hold the CLK control and press the TUNE control: to decrease minutes and to increase minutes. The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 36 Controls and features Premium AM/FM Stereo/Cassette (CD Changer Compatible) PUSH ON TAPE MUTE Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated. During the operation of any selected mode, lighting for the individual function controls will either illuminate or turn off.
Page 37 Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Speed sensitive volume (if equipped) With this feature, radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise.
Page 38 Controls and features AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play. AM/FM select in CD mode Press this control to stop CD play and begin radio play.
Page 39 Seek function in tape mode Press to listen to the previous selection on the tape or return to the beginning of the current selection. Press to listen to the next selection on the tape. Seek function for CD changer Press to seek to the previous track of the current disc.
Page 40 Controls and features Radio station memory preset The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2). Setting memory preset stations 1.
Page 41 Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the BASS control. Use the SEL control to increase or decrease the amount of bass. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output.
Page 42 Controls and features To begin CD play (if equipped with CD changer), ensure that the CDs are loaded. Press the CD control. The first track of the disc will begin playing. After that, CD play will begin where it stopped last. Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur.
Page 43 Eject function Press the control to stop and eject a tape. Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction.
Page 44 Controls and features The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend FM radio broadcasters to use RDS technology to transmit information. FM radio stations are independently operated and individually elect to use RDS technology to transmit station ID and program type as desired. Press and hold the control for five seconds to turn the feature on or off.
Page 45 Rock Soft Top 40 Show With RDS activated, press the RDS control until SHOW is displayed. Use the SEL control to select TYPE (the display shows the program type), NAME (the display shows the call letters of the station) or NONE. Mute mode Press the control to mute the playing media.
Page 46 Controls and features Premium AM/FM Stereo/Single CD Radio PUSH ON SCAN MUTE Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated. During the operation of any selected mode, lighting for the individual function controls will either illuminate or turn off.
Page 47 If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Speed sensitive volume (if equipped) With this feature, radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise.
Page 48 Controls and features CD select To begin CD play (if CD[s] are loaded), press the CD control. The first track of the disc will begin playing. After that, CD play will begin where it stopped last. Press the CD control again to toggle between CD and CD changer mode (if equipped).
Page 49 Seek function for CD or CD changer (if equipped) Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press that selection from the beginning. Press to seek forward to the next track of the current disc.
Page 50 Controls and features Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 51 Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Rewind The rewind control works in CD mode. In CD mode, pressing the REW control for less than three seconds results in slow rewind.
Page 52 Controls and features Compression feature (if equipped) Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature (if equipped) The shuffle feature operates in CD changer mode and plays all tracks on the current disc in random order.
Page 53 Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data). Program type Press the RDS control until FIND program type is displayed.
Page 54 Controls and features Use the SEL control to select TYPE, NAME or NONE. Mute mode Press the control to mute the playing media. Press the control again to return to the playing media. Setting the clock Press the RDS control until SELECT HOUR or SELECT MINS is displayed.
Page 55 Controls and features 1. Slide the door to access the CD changer magazine. 2. Press to eject the magazine. 3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine.
Page 56 Controls and features If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever (A). 5. Line up the CD with the groove of the disc holder.
Page 57 If your CD changer is located under the rear bench, the following instructions apply for loading discs: 1. The holders DO NOT pull out. Load the discs into the magazine slots (numbered 1 through 6 on the window) one at a time with labeled surfaces upward.
Page 58 Controls and features Troubleshooting the CD changer (if equipped) The laser beam used in the compact disc player is harmful to the eyes. Do not attempt to disassemble the case. If sound skips: You may be traveling on a rough road, playing badly scratched discs or the disc may be dirty.
Page 59 Cassette and cassette player care Use only cassettes that are 90 minutes long or less. Do not expose tapes to direct sunlight, high humidity, extreme heat or extreme cold. Allow tapes that may have been exposed to extreme temperatures to reach a moderate temperature before playing. Tighten very loose tapes by inserting a finger or pencil into the hole and turning the hub.
Page 60 Controls and features The audio system automatically switches to single channel reception if it will improve the reception of a station normally received in stereo. Audio system warranties and service Refer to the “Warranty Guide” for audio system warranty information. If service is necessary, see your dealer or a qualified technician.
Page 61 Controls and features PANEL & FLOOR-Distributes outside air through the instrument panel registers and the floor ducts. FLOOR-Allows for maximum heating. Distributes outside air through the floor ducts. FLOOR & DEF-Distributes outside air through the floor ducts and the windshield defroster ducts. -Distributes outside air through the windshield defroster ducts.
Page 62 Controls and features Do not place objects over the defroster outlets. These objects can block airflow and reduce your ability to see through your windshield. Avoid placing small objects on top of the instrument panel. These objects may fall down into the defroster outlets and block airflow, in addition to damaging the climate control system.
Page 63 Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle. MAX A/C-Uses recirculated air to cool the vehicle.
Page 64 Controls and features Operating tips In humid weather conditions, place the climate control system in DEF before driving. This will reduce fogging on your windshield. Once the windshield has been cleared, operate the climate control system as desired. To reduce humidity buildup inside the vehicle in cold weather conditions, don’t drive with the climate control system in the OFF or MAX A/C position.
Page 65 Avoid placing small objects on top of the instrument panel. These objects may fall down into the defroster outlets and block airflow, in addition to damaging the climate control system. To aid in side window defogging/demisting in cold weather conditions: 1.
Page 66 Controls and features POSITIONS OF THE IGNITION 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 67 SPEED CONTROL (IF EQUIPPED) To turn speed control on Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Page 68 Controls and features To set a speed Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 69 You can accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle to the previously programmed set speed. To set a lower set speed Press and hold CST/COAST. Release the control when the desired speed is reached or Press and release CST/COAST to operate the Tap-Down function.
Page 70 Controls and features To disengage speed control Depress the brake pedal or Depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.
Page 71 To return to a previously set speed Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light This light comes on when either the SET ACCEL or RES controls are pressed. It turns off when the speed control OFF control is pressed, the brake is applied or the ignition is turned to the OFF position.
Page 72 Controls and features Never adjust the steering wheel when the vehicle is moving. HAZARD FLASHER For information on the hazard flasher control, refer to Hazard flasher in the Roadside emergencies chapter. WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position.
Page 73 Controls and features Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of OVERDRIVE the gearshift lever. The Transmission Control Indicator Light (TCIL) (the word OFF) will illuminate on the end of the gearshift lever. The transmission will operate in all gears except overdrive.
Page 74 Controls and features Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: Remove the storage clip from the door. Place Velcro hook onto side of aftermarket transmitter opposite of actuator control.
Page 75 Controls and features Electronic compass/temperature display (if equipped) Outside air temperature The outside temperature display is contained in the overhead console. The temperature display can be turned off and on by pressing the SELECT control on the overhead console. The temperature can be displayed in Centigrade or Fahrenheit by pressing the SELECT control.
Page 76 Controls and features Compass zone adjustment 1. Determine which magnetic zone you are in by referring to the zone map. 2. Turn the ignition to the ON position. 3. Press and hold the SELECT control until VAR appears in the display, then release.
Page 77 Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines: Press and hold the SELECT control until CAL appears in the display (approximately eight seconds) and release. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 78 Controls and features Press the control to turn the mirror OFF or AUTO. The mirror will automatically return to the normal state whenever the vehicle is placed in R (Reverse)(when the mirror is on) to ensure a bright clear view when backing up.
Page 79 One touch down Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. One touch down can be deactivated during operation by pushing down on the top part of the driver power window control.
Page 80 Controls and features POWER SIDE VIEW MIRRORS (IF EQUIPPED) The ignition can be in any position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2.
Page 81 Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in.
Page 82 Controls and features TAILGATE REMOVAL Your tailgate is removable to allow more room for loading. 1. Lower the tailgate. 2. Use a screwdriver to pry the spring clip (on each connector) past the head of the support screw. Disconnect cable. 3.
Page 83 Controls and features 3. Pull one side of the cover outward and upward away from the side rail working from the rear to the front. 4. Starting from the opposite side of the vehicle, pull cover away from the side rail and roll the cover from rear to front.
Page 84 Controls and features 5. Secure the cover behind the cab with two straps. The cover may be removed from the vehicle by sliding it sideways out of the front rail.
Page 85 Flareside only: Remove two cross bars from pickup box by pushing towards either side to release tension. Lower tailgate, depress the levers on each side of the rear rail and remove rear rail from pickup box. Styleside only: Remove three cross bars from pickup box by pushing towards either side to release tension.
Page 86 Controls and features HARD TONNEAU COVER (IF EQUIPPED) The tonneau cover has been designed to maximize fuel economy. To avoid damage to the cover, do not operate the vehicle unless the cover is fully secured. To open the cover: Unlock the cover (with the key) and lift the cover up for access to the pickup box.
Page 87 Keep vehicle doors and tonneau cover locked and keep keys out of a child’s reach. Unsupervised children could lock themselves in an open pickup box and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the pickup box can rise very quickly.
Page 88 Controls and features objects on the key ring held away from the ignition key. Check to make sure the encoded ignition key is an approved Ford encoded ignition key. Spare coded keys can be purchased from your dealership and programmed to your anti-theft system. Refer to Programming spare SecuriLock keys for more information.
Page 89 1. Insert the first previously programmed coded key into the ignition and turn the ignition from OFF to ON (maintain ignition in ON for at least one second). 2. Turn ignition to OFF and remove the first coded key from the ignition. 3.
Page 90 Controls and features The remote entry features only operate with the ignition in the LOCK position. If there is any potential remote keyless entry problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to the dealership, to aid in troubleshooting. Unlocking the doors Press this control to unlock the driver’s door.
Page 91 Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. Autolock (if equipped) This feature automatically locks all vehicle doors when: all doors are closed the engine is running you shift into any gear putting the vehicle in motion.
Page 92 Controls and features 6. Press the unlock control, then press the lock control. The horn will chirp once if autolock was deactivated or twice (one short and one long chirp) if autolock was activated. 7. Turn the ignition to OFF. The horn will chirp once to confirm the procedure is complete.
Page 93 Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: Take all your vehicle’s transmitters to your dealer for programming, or Perform the programming...
Page 94 Controls and features Reprogramming transmitters Your dealer will be able to reprogram remote transmitter(s) to your vehicle. Installation of a new battery to your remote transmitter does not cause the remote transmitter to become deprogrammed. Illuminated entry The illuminated entry system will turn on the interior lights when the remote transmitter unlock control is pressed.
Page 95 Programming your own personal entry code To program your own code: 1. Enter factory set code (keypad will illuminate when pressed). 2. Press 1/2 control within five seconds of step 1. 3. Enter your personal 5 digit code. Enter each digit within five seconds of previous one.
Page 96 Controls and features Locking the doors with the keyless entry system It is not necessary to enter the factory or personal code prior to locking all doors. To lock the doors: Press the 7/8 control and the 9/0 control at the same time. Activating/deactivating autolock with the keyless entry system Before following the activation or deactivation procedures, make sure that the anti-theft system (if equipped) is not armed, ignition is off, and...
Page 97: Seating And Safety Restraints
SEATING Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to reduce the risk of injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 98 Seating and safety restraints Full bench seat (if equipped) Lift the track release bar to move the seat forward or backward. Ensure that the seat is relatched into place. Pull up on the release lever located at the bottom of the seatback to quickly fold the seatback forward.
Page 99 Captain’s chair (if equipped) Lift the track release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. Pull the release lever handle located on the side of the seat up to move the seat back forward or backward.
Page 100 Seating and safety restraints Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Using the manual lumbar support Turn the lumbar support control toward the front of vehicle to move...
Page 101 Folding up the rear seats (if equipped — SuperCab only) The rear seatback has a split 60/40 seat. Each seat cushion can be flipped up into the seatback position. 1. Pull control to release seat cushion. 2. Rotate seat cushion up until it locks into vertical storage position.
Page 102 Seating and safety restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained.
Page 103 It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 104 Seating and safety restraints 2. To unfasten, push the release button and remove the tongue from the buckle. The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free...
Page 105 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 106 Seating and safety restraints Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the front passenger outboard seat belt system must be checked by a qualified technician to verify that the “automatic locking retractor”...
Page 107 Lap belts Adjusting the center lap belt The lap belt does not adjust automatically. The lap belt should fit snugly and as low as possible around the hips, not across the waist. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from).
Page 108 Seating and safety restraints Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended.
Page 109 If... The driver’s safety belt is not buckled approximately 5 seconds after the safety belt warning light has turned off... The driver’s safety belt is buckled while the safety belt indicator light is illuminated and the safety belt warning chime is sounding... The driver’s safety belt is buckled before the ignition switch is turned to the ON...
Page 110 I have an air bag I’d rather be thrown clear Consider... Ford designs its safety belts to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 111 Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below. One time disable Anytime the safety belt is buckled and then unbuckled during an ignition ON cycle, Belt Minder will be disabled for that ignition cycle only.
Page 112 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 113 This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
Page 114 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 115 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
Page 116 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 117 If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision. Disposal of air bags and air bag equipped vehicles (including pretensioners) For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician.
Page 118 If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. In order to avoid inadvertent activation of the switch, always remove the ignition key from the passenger air bag ON/OFF switch.
Page 119 If the light is illuminated when the passenger air bag switch is in the ON position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. The passenger side air bag should always be ON (the air bag OFF light...
Page 120 Seating and safety restraints Always transport children who are 12 and younger in the rear seat. Always use safety belts and child restraints properly. If a child in a rear facing infant seat must be transported in front, the passenger air bag must be turned OFF. This is because the back of the infant seat is too close to the inflating air bag and the risk of a fatal injury to the infant when the air bag inflates is substantial.
Page 121 2. Child age 1 to 12. A child age 1 to 12 must ride in the front seat because: the vehicle has no rear seat; although children ages 1 to 12 ride in the rear seat(s) whenever possible, children ages 1 to 12 sometimes must ride in the front because no space is available in the rear seat(s) of the vehicle;...
Page 122 Seating and safety restraints 3. Medical condition: A passenger has a medical condition that, according to his or her physician: poses a special risk for the passenger if the air bag deploys; and makes the potential harm from the passenger air bag deployment greater than the potential harm from turning OFF the air bag and experiencing a crash without the protection offered by the air bag SAFETY RESTRAINTS FOR CHILDREN...
Page 123 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 124 (passenger side front and outboard rear seating positions) (if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 125 Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 126 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 127 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 128 If you have a SuperCab, attach the bracket to the inside of the back panel of your vehicle. Carefully follow the instructions provided with the kit. If you have a Super Cab, Ford recommends you attach tether safety seats in the rear seating position (if possible) with the tether strap attached to the tether anchorage bracket as shown in the instructions provided with the tether anchor kit.
Page 129 The rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below. The tether anchors in your vehicle may be straps on the seatback or an anchor bracket on the rear edge of the seat cushion. The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as...
Page 130 Seating and safety restraints F150 King Ranch 1. Position the child safety seat on the passenger seat cushion. 2. Route the child safety seat tether strap over the back of the seat. 3. Locate the correct anchor for the selected seating position. You may need to pull the seatback forward to access the tether anchors.
Page 131 Front seat (Regular Cab and SuperCab only) Rear seats (SuperCab only) Rear seats (SuperCrew and King Ranch only) If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. Seating and safety restraints...
Page 132 Seating and safety restraints Front seat Rear seats (if equipped) 5. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat. 6. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
Page 133: Starting
PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 134 Starting 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: Make sure the parking brake is set.
Page 135 3. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: front wheels are turned front wheel is against the curb steering wheel is turned when getting in or out of the vehicle...
Page 136 Starting STARTING THE ENGINE 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 4 (ON). 2. If the temperature is above –12°C (10°F) and the engine does not start within five seconds on the first try, turn the key to OFF, wait 10 seconds and try again.
Page 137 Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes.
Page 138: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 139 With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with parking brake released. (If your brake warning lamp illuminates, have your vehicle serviced immediately.) Using RABS In an emergency, applying full pressure may cause the front wheels to lock.
Page 140 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
Page 141 Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 142 Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface.
Page 143 If the steering wanders or pulls, the condition could be caused by any of the following: underinflated tire(s) on any wheel(s) high crown in center of road high crosswinds wheels out of alignment loose or worn components in steering linkage PREPARING TO DRIVE YOUR VEHICLE Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 144 Driving Use extra caution while becoming familiar with your vehicle. Know the capabilities and limitations of both you as a driver and your vehicle. AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.
Page 145 If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician. Driving with a 4–speed automatic transmission Understanding gearshift positions To put your vehicle in gear, start the engine, depress the brake pedal, then move gearshift lever out of P (Park).
Page 146 Driving (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. (Overdrive) can be deactivated by pressing the transmission control switch (TCS) on the end of the gearshift lever. The transmission control indicator light (TCIL) (the word OFF) on the end of the gearshift lever will illuminate.
Page 147 Driving 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to (Overdrive). Selecting 1 (Low) at higher speeds causes the transmission to shift to a lower gear, and will shift to 1 (Low) after vehicle decelerates to the proper speed.
Page 148 Driving When starting a vehicle with a manual transmission, you must: 1. Make sure the parking brake is fully set. 2. Depress the clutch pedal fully. 3. Put the gearshift lever in Neutral. 4. Turn the ignition to position 5 (START) to start the engine, let the engine idle for a few seconds.
Page 149 Recommended shift speeds Upshift and downshift according to the following charts for your specific engine/drivetrain combination: 4.2L V6 engine (4x2 and 4x4) Upshifts when accelerating (recommended for best fuel economy) Shift from: 1 - 2 2 - 3 3 - 4 (Overdrive) Upshifts when cruising (recommended for best fuel economy) Shift from:...
Page 150 Driving Upshifts when cruising (recommended for best fuel economy) Shift from: 1 - 2 2 - 3 3 - 4 (Overdrive) 4.6L V8 engine (4x2 with optional rear axle ratio) Upshifts when accelerating (recommended for best fuel economy) Shift from: 1 - 2 2 - 3 3 - 4...
Page 151 Parking your vehicle 1. Disengage the clutch, apply brake and shift into Neutral. 2. Set parking brake. 3. Shift into 1 (First). 4. Turn the ignition key to position 3 (OFF). Driving...
Page 152 Driving Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
Page 153 Removing key from ignition Turn the ignition key to position 2. Push the release lever forward and rotate the key towards you and remove. FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. When Four–wheel drive (4WD) is engaged, power is supplied to all four wheels through a transfer case.
Page 154 4WD system indicator lights The 4WD system indicator lights illuminate only under the following conditions. If these lights illuminate when driving in 2WD, contact your Ford dealer as soon as possible. 4X4 —momentarily illuminates after the engine is started. Illuminates when 4H (4WD High) is engaged.
Page 155 Shifting from 4H (4WD high) to 2H (2WD high) Move the transfer case lever to 2H (2WD High) at a stop or any forward speed up to 88 km/h (55 mph). Shifting from 4H (4WD high) to 4L (4WD low) 1.
Page 156 Driving Using the N (Neutral) position The transfer case neutral position overrides the transmission and puts the vehicle in neutral regardless of transmission gearshift lever position. The vehicle can move forward or backwards. This position should only be used when towing the vehicle. Do not leave the vehicle unattended with the transfer case in the N (Neutral) position.
Page 157 Driving Shifting from 4H (4WD high) to 2H (2WD high) Move the 4WD control to 2H at any forward speed. Shifting between 4H (4WD high) and 4L (4WD low) 1. Bring the vehicle to a stop. 2. Depress the brake. 3.
Page 158 Driving You should either know the terrain or examine maps of the area before driving. Map out your route before driving in the area. For more information on driving off-road, read the “Four Wheeling” supplement in your owner’s portfolio. If your vehicle gets stuck If the vehicle is stuck it may be rocked out by shifting from forward and reverse gears, stopping between shifts, in a steady pattern.
Page 159 Driving Water intrusion into the transmission may damage the transmission. Replace rear axle lubricant any time the axle has been submerged in water. The rear axle does not normally require a lubricant change for the life of the vehicle. Rear axle lubricant quantities are not to be checked or changed unless a leak is suspected or repair is required.
Page 160 Driving Allow more stopping distance and drive slower than usual. Consider using one of the lower gears. VEHICLE LOADING Before loading a vehicle, familiarize yourself with the following terms: Base Curb Weight: Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include passengers or aftermarket equipment.
Page 161 Remember to figure in the tongue load of your loaded trailer when figuring the total weight. Do not exceed the GVWR or the GAWR specified on the certification label. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations.
Page 162 Driving Calculating the load your vehicle can carry/tow 1. Use the appropriate maximum gross combined weight rating (GCWR) chart to find the maximum GCWR for your type engine and rear axle ratio. 2. Weigh your vehicle as you customarily operate the vehicle without cargo.
Page 163 Do not exceed the GVWR or the GAWR specified on the certification label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury. Engine Rear axle ratio Regular Cab 4x2 w/automatic transmission 4.2L 4.2L...
Page 164 Driving Engine Rear axle ratio Regular Cab 4x2 w/manual transmission 4.2L 4.2L 4.6L 4.6L 4.6L SuperCab 4x2 w/manual transmission 4.2L 4.2L 4.6L 4.6L 4.6L 4X4 AUTOMATIC TRANSMISSION Engine Rear axle ratio - cm (inches) 4.2L 3.55/40.6 cm (16) 4.6L 3.31/40.6 (40.6) 4.6L 3.55/40.6 (16) 4.6L...
Page 165 Trailer frontal area considerations: Not to exceed towing vehicle front area without Class III trailer towing package Not to exceed 5.52 square meters (60 square feet) with Class III trailer towing package Trailer towing tables 4x2 with automatic transmission Engine Rear axle ratio/Tire size 4.2L...
Page 166 Driving 4x2 manual transmission Engine Rear axle ratio/Tire size 4.2L 3.08/16 in 4.2L 3.55/16 in 4.6L 3.08/16 in 4.6L 3.31/16 in 4.6L 3.55/16 in 4.2L 3.08/16 in 4.2L 3.55/16 in 4.6L 3.08/16 in 4.6L 3.31/16 in 4.6L 3.55/16 in 4x4 automatic transmission Engine Rear axle ratio 4.2L...
Page 167 Engine Rear axle ratio 4.6L 3.31/16 in 4.6L 3.55/16 in 4.6L 3.55/17 in 5.4L 3.31/16 in 5.4L 3.55/16 in 5.4L 3.55/17 in 5.4L 3.73/16 in 4x4 manual transmission Engine Rear axle ratio 4.2L 3.31/16 in 4.2L 3.55/16 in 4.6L 3.31/16 in 4.6L 3.55/16 in 4.6L...
Page 168 Driving Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle. You must distribute the load in your trailer so that 10%–15% of the total weight of the trailer is on the tongue. Load equalizing hitch When hooking up a trailer using a load equalizing hitch, always use the following procedure: 1.
Page 169 Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 170 Driving Trailer towing tips Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. Allow more distance for stopping with a trailer attached. The trailer tongue weight should be no more than 10–15% of the loaded trailer weight.
Page 171 Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation. Improper removal/installation of the driveshaft can cause transmission fluid loss, damage to the driveshaft and internal transmission components.
Page 172 Driving Installing the snowplow Removing the blocker beam without installing snowplow attachment hardware may affect air bag deployment in a crash. Do not operate the truck unless either the blocker beam or snowplow attachment hardware is installed on the vehicle. Read the following instructions before installing a snowplow: Front GAWR must not exceed 63% of the GVW.
Page 173 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Driving...
Page 174 Driving Engine temperature while plowing When driving with a plow, your engine may run at a higher temperature than normal because the attached snowplow blade will restrict airflow to the radiator. If you are driving more than 24 km (15 miles) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator.
Page 175: Roadside Emergencies
GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: 24–hours, seven days a week for the Basic warranty period (Canada) or New Vehicle Limited Warranty period (U.S.) of three years or 60,000 km (36,000 miles),...
Page 176 Roadside coverage beyond basic warranty In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, you may purchase additional coverage beyond the basic coverage period by consulting the Ford Roadside Assistance Club brochure or by calling 1–877–294–CLUB (1–877–294–2582).
Page 177 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 178 Roadside emergencies Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse Mini Rating Fuses Grey...
Page 179 Roadside emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 180 Roadside emergencies The fuses are coded as follows. Fuse/Relay Location Fuse Amp Passenger Compartment Fuse Rating Audio Powertrain Control Module (PCM), Cluster Cigar Lighter, OBD-II Scan Tool Connector Remote Entry Module, Mirrors Speed Control Module, Reverse Lamp, Climate Mode Switch, Daytime Running Lamp Relay Cluster, Brake Shift Interlock Solenoid, GEM Module...
Page 181 Fuse/Relay Fuse Amp Location Rating Relay 1 Relay 2 Relay 3 Relay 4 Relay 5 Roadside emergencies Passenger Compartment Fuse Instrument Illumination (Dimmer Switch Power) — Not Used Audio, GEM (or CTM) Module, Powertrain Control Module (PCM), Starter Relay, Clutch Switch, Fuse 20 Air Bag Module, Passenger Airbag Deactivation Module, Climate Mode Switch (Blower Relay)
Page 182 Roadside emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 183 The high-current fuses are coded as follows. Fuse/Relay Location Roadside emergencies Fuse Amp Rating 20A * Power Point 30A* Powertrain Control Module 30A* Headlamps/Autolamps — Not Used 20A* Trailer Tow Backup/Park Lamps 15A* Parklamps/Autolamps, Passenger Fuse Panel Feed Fuse #18 20A* Horn 15A*...
Page 184 Roadside emergencies Fuse/Relay Location Fuse Amp Rating 30A** Trailer Tow Battery Charge 50/20A** Four Wheel Antilock Brake Module/Rear Wheel Antilock Brake Module 50A** Junction Block Battery Feed 30A** 4x4 Shift Motor & Clutch 40A** Climate Control Front Blower 20A** Inter Cooler Pump (Lightning only) —...
Page 185 Fuse/Relay Location *Mini fuses **Maxi fuses CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Spare tire information Your vehicle is equipped with a spare tire that may be used as a spare or a regular tire.
Page 186 Roadside emergencies Location of the spare tire and tools The spare tire and tools for your vehicle are stowed in the following locations: Tool Spare tire Jack, lug nut wrench Jack handle Removing the spare tire 1. If equipped with a two piece lug wrench, assemble the lug wrench as shown in the illustration.
Page 187 Stowing the spare tire 1. Lay the tire on the ground with the valve stem facing up. 2. Slide the wheel under the vehicle and install the retainer through the wheel center. 3. Turn the jack handle clockwise until the tire is raised to its original position underneath the vehicle.
Page 188 Roadside emergencies 3. Block the diagonally opposite wheel. 4. Obtain the spare tire and jack from their storage locations. 5. Use the tip of the lug wrench to remove any wheel trim. 6. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
Page 189 Roadside emergencies Front (4x2) Front (4x4) Rear...
Page 190 Roadside emergencies To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. Never use the front or rear differential as a jacking point.
Page 191 Roadside emergencies Do not attempt to push start your vehicle. Automatic transmissions do not have push-start capability. Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly.
Page 192 Roadside emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 193 Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts.
Page 194 Roadside emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery.
Page 195 It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 196 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company provides a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 197: Maintenance And Care
SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 198 Maintenance and care 3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 199 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Clutch fluid reservoir (manual transmission) 5. Brake fluid reservoir 6. Power distribution box 7. Engine coolant reservoir 8.
Page 200 Maintenance and care 4.6L V8/5.4L V8 engines 10 11 1. Power steering fluid reservoir 2. Clutch fluid reservoir (manual transmission) 3. Engine oil dipstick 4. Brake fluid reservoir 5. Power distribution box 6. Air filter assembly 7. Engine coolant reservoir 8.
Page 201 3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmission) or 1 (First) (manual transmission). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 6.
Page 202 Maintenance and care If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range. Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7.
Page 203 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 204 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 205 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specifications. Refer to Capacities and specifications. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 206 Checking engine coolant Your engine’s cooling system has been factory-filled with a 50/50 mixture of distilled water and Ford G05 Engine Coolant (yellow in color) per ford specification WSS-M97B51–A1. A 50/50 mixture of distilled water and Ford G05 Engine Coolant provides: maximum cooling system efficiency.
Page 207 an accurate temperature readout from the engine coolant gauge. The engine coolant must be maintained at the correct fluid level and concentration to work properly. If the engine coolant fluid level and concentration is not maintained correctly, damage to the engine and cooling system may result. When the engine is cold, check the level of the engine coolant in the reservoir.
Page 208 Maintenance and care Adding engine coolant Use only Ford G05 Engine Coolant or a premium engine coolant that meets Ford specification WSS-M97B51–A1. DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA (orange in color). DO NOT USE a DEX-COOL engine coolant or an equivalent engine coolant that meets Ford specification WSS-M97B44-D.
Page 209 Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification WSS-M97B51–A1. Use of a recycled engine coolant which does not meet the Ford G05 specification may harm engine and cooling system components. Maintenance and care...
Page 210 Maintenance and care Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter.
Page 211 Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection. What you should know about fail-safe cooling (if equipped) If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred.
Page 212 Maintenance and care When fail-safe mode is activated You have limited engine power when in the fail-safe mode, so drive the vehicle with caution. The vehicle will not be able to maintain high speed operation and the engine will run rough. Remember that the engine is capable of completely shutting down automatically to prevent engine damage, therefore: 1.
Page 213 Maintenance and care 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and MAX lines.
Page 214 Maintenance and care 4. Latch the gearshift lever in P (Park) and leave the engine running. 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick.
Page 215 The transmission fluid should be in this range if at ambient temperature (10°C-35°C [50°F-95°F]). High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
Page 216 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter.
Page 217 2. Remove the filler plug and inspect the fluid level. 3. Add only enough fluid through the filler opening so that the fluid level is at the bottom of the opening. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter.
Page 218 Maintenance and care DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication. Refer to the scheduled maintenance guide for maintenance intervals. If the original universal joints are replaced with universal joints equipped with grease fittings, lubrication will also be necessary. BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery...
Page 219 Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 220 Maintenance and care The vehicle may need to be driven 16 km (10 miles) or more to relearn the idle and fuel trim strategy. If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 221 Maintenance and care Changing the air filter element 1. Loosen the clamp that secures the air filter element in place. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the open end of the air filter housing.
Page 222 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
Page 223 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 224 Maintenance and care SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 225 If you do not follow these precautions, your vehicle may not drive properly and safely. Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Maintenance and care...
Page 226 Maintenance and care Do not replace your tires with “high performance” tires or larger size tires. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over. Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer.
Page 227 WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 228 Maintenance and care Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. Avoid getting fuel liquid in your eyes.
Page 229 Maintenance and care Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle. Do not use fuel containing methanol. It can damage critical fuel system components. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based compounds containing MMT.
Page 230 World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice Cleaner air Ford approves the use of reformulated “cleaner-burning” gasolines to improve air quality. These gasolines may contain oxygenates up to 10% ethanol or 15% MTBE.
Page 231 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 232 Maintenance and care Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill Capacities section of the Capacities and specifications chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 233 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled. Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway).
Page 234 Maintenance and care Maintenance Keep tires properly inflated and use only recommended size. Operating a vehicle with the wheels out of alignment will reduce fuel economy. Use recommended engine oil. Refer to Lubricant Specifications. Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide.
Page 235 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 236 Maintenance and care Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 237 Turn signals License plate lamp Tail lamps Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect lamp performance. Replacing headlamp bulbs 1.
Page 238 Maintenance and care 9. Insert the glass end of the new bulb into the headlamp assembly. When the grooves in the plastic base are aligned, push the bulb into the lamp assembly until the plastic base contacts the rear of the lamp assembly.
Page 239 Maintenance and care 3. Remove bulb socket from the parking lamp assembly by turning it counterclockwise. 4. Pull bulb straight out of socket and press in the new bulb. 5. Install the bulb socket into the lamp assembly by turning clockwise. 6.
Page 240 Maintenance and care 5. Pull bulb straight out of socket and press in the new bulb. 6. Carefully install the tail lamp assembly on tailgate pillar snapping the two snap-in retainers into place. (Flare side tail lamps do not snap into place but have two tabs which fit into slots.) 7.
Page 241 Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper. To change the license plate lamp bulbs: 1. Reach behind the rear bumper to locate the bulb. 2. Twist the bulb socket counterclockwise and carefully pull to remove it from the lamp assembly.
Page 242 If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water.
Page 243 Ultra Touch Prep and Finishing Kit (#F7AZ-19K507–BA), Lacquer Touch-up Paint (#ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (#ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line. Please note that the part numbers (shown as XXXX above) will vary with your vehicle’s specific coloring. Observe the application instructions on the products.
Page 244 Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
Page 245 Ford Ultra-Clear Spray Glass Cleaner, (E4AZ-19C507–AA), available from your Ford Dealer. Do not use abrasive cleansers on glass as they may cause scratches. The windshield or rear window is clean if beads do not form when you rinse it with water.
Page 246 For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
Page 247: Capacities And Specifications
MOTORCRAFT PART NUMBERS Component 4.2L V6 engine Air filter element FA-1634 Fuel filter FG-986B Oil filter FL-400-S PCV valve EV-251 Battery BXT-59 (standard) Battery BXT-65-650 (heavy duty) Spark AGSF-34EE ** plugs-platinum* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information.
Page 248 Capacities and specifications REFILL CAPACITIES Fluid Ford Part Name Brake fluid High and clutch Performance fluid DOT 3 Motor Vehicle Brake Fluid Engine Premium coolant Engine Coolant Engine oil Motorcraft (includes SAE 5W-20 filter Super change) Premium Motor Oil Fuel tank...
Page 249 Ultra-Clear washer fluid Windshield Washer Concentrate Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Capacities and specifications Application...
Page 250 Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A, for complete fill of 8.8 inch and 9.75 inch Traction-Lok axles. Service refill capacity is determined by filling the axle to the bottom of the filler hole with the vehicle on a level surface.
Page 251 Friction Modifier C8AZ-19B546-A or equivalent meeting Ford Specification EST-M2C118-A. LUBRICANT SPECIFICATIONS Ford part name Item or equivalent Motorcraft SAE Front axle 75W-90 Premium (4X4) 4x4 Front Axle Lubricant Motorcraft SAE 75W-140 High Rear axle Performance Synthetic Rear Axle Lube High...
Page 252 Washer Concentrate Add 118 ml (4 oz) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of Traction-Lok axles. Add 236 ml (8 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of 10.25 and 10.5 inch Traction-Lok axles.
Page 253 fluid. However, these dual usage fluids may be used in transmissions that require the MERCON V type fluid. MERCON and MERCON V type fluids are not interchangeable. DO NOT mix MERCON and MERCON V. Use of a transmission fluid that indicates dual usage (MERCON and MERCON V) in an automatic transmission application requiring MERCON may cause transmission damage.
Page 254 Capacities and specifications Dimension Regular Cab 4x2 1 846 mm (72.7 in) (3) Overall (SWB) height 1 838 mm (72.4 in) (LWB) 3 045 mm (119.9 in) (4) Wheel (SWB) base 3 518 mm (138.5 in) (LWB) 1 661 mm (5)Track (65.4 in) front/rear...
Page 255 Flareside Dimension Regular Cab 4x2 (1) Overall 5 212 mm length (205.2 in) (2) Overall 2 014 mm width (79.3 in) (3) Overall 1 846 mm height (72.7 in) (4) Wheel 3 046 mm base (119.9 in) (5) Track 1 661 mm front/rear (65.4 in) Vehicle width, including mirrors: 2 279 mm (89.7 in)
Page 256 Capacities and specifications...
Page 257: Certification Label
The Certification Label is located on the front door latch pillar on the driver’s side. Capacities and specifications MFD. BY FORD MOTOR CO. IN U.S.A. DATE: XXXXX FGAWR: XXXXXX/XXXXXXX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
Page 258 Capacities and specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block and transmission.
Page 259: Customer Assistance
5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 260 Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 261 Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: Your telephone number (home and business)
Page 262 Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
Page 263 DSB’s independent administrator Your dealership and a Ford Motor Company representative will then be asked to submit statements. To properly review your case, the Board needs the following information:...
Page 264 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 265 UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 266 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 267 Customer assistance Ford Deluxe Leather and Vinyl Cleaner (not available in Canada) Motorcraft Vinyl Cleaner (Canada only) Ford Extra Strength Tar and Road Oil Remover* (not available in Canada) Ford Extra Strength Upholstery Cleaner (Canada only) Ford Extra Strength Upholstery Cleaner (not available in Canada)
Page 268 Customer assistance Comfort and convenience Air conditioner Air filtration systems Automatic Headlamp System with Daytime Running Lights (DRL) Cargo nets Cargo organizers (interior) Cargo storage bin (regular cab) Cargo trays (interior) Celluar phone holder Dash trim (wood grain) Engine block heaters Manual sliding rear window Moon roof deflector Power sliding rear window...
Page 269 Customer assistance Speed control Towing mirrors Trailer hitch (Class III) Trailer hitch bars and balls Trailer hitch wiring adaptor Protection and appearance equipment Air bag anti-theft locks Battery warmer/blanket Bed mat/bedliner tailgate covers Bed mats Bedliners Cargo cover Diamond plate, bed rail caps Diamond plate, front box protector Diamond plate, tool box Door edge guards...
Page 270 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. ORDERING ADDITIONAL OWNER’S LITERATURE...
Page 271 Customer assistance Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3.
Page 272: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 273: Index
Accessory delay ...79 Air bag supplemental restraint system ...113 and child safety seats ...114 description ...113 disposal ...117 driver air bag ...115 indicator light ...12, 116 operation ...115 passenger air bag ...115 passenger deactivation switch ...65, 117 Air cleaner filter ...220–221, 247 Air conditioning ...60 Ambulance packages ...3 Antifreeze...
Page 274 ...206 refill capacities ...210, 248 specifications ...251, 253 Cruise control (see Speed control) ...67 Customer Assistance ...175 Ford accessories for your vehicle ...266 Ford Extended Service Plan ...259 Getting assistance outside the U.S. and Canada ...265 Getting roadside assistance ...175 Getting the service you need ...259...
Page 275 check engine/ service engine soon light ...11 cleaning ...243 coolant ...206 fail-safe coolant ...211 idle speed control ...218 lubrication specifications ...251, 253 refill capacities ...248 service points ...199–200 starting after a collision ...176 Engine block heater ...136 Engine oil ...200 checking and adding ...200 dipstick ...200 filter, specifications ...203, 247...
Page 276 Index driving with a heavy load ...160 location ...160 GVWR (Gross Vehicle Weight Rating) ...160 calculating ...160, 162 definition ...160 driving with a heavy load ...160 location ...160 Hazard flashers ...176 Headlamps ...20 aiming ...242 autolamp system ...22 bulb specifications ...241 daytime running lights ...20 flash to pass ...20 high beam ...13, 20...
Page 277 anti-lock brakes (ABS) ...13, 140 anti-theft ...13 brake ...12 charging system ...13 check coolant ...14 cruise indicator ...15 door ajar ...15 engine oil pressure ...14 high beam ...13 low fuel ...10 safety belt ...12 service engine soon ...11 speed control ...71 turn signal indicator ...13 Load limits ...160 GAWR ...160...
Page 278 Index Safety belts (see Safety restraints) ...15, 102–106 Safety defects, reporting ...272 Safety restraints ...102–106 belt minder ...108 cleaning the safety belts ...112, 245 extension assembly ...107 for adults ...103–105 for children ...122 lap belt ...107 warning light and chime ...12, 15, 108 Safety seats for children ...123 Seat belts (see Safety restraints) ...102...
Page 279 Vehicle dimensions ...253 Vehicle Identification Number (VIN) ...258 Vehicle loading ...160 Ventilating your vehicle ...137 Warning chimes ...15 Warning lights (see Lights) ...10 Washer fluid ...206 Water, Driving through ...162 Windows power ...78 Windshield washer fluid and wipers checking and adding fluid ...206 checking and cleaning ...221 operation ...72 replacing wiper blades ...222...
Page 280: Filling Station Information
Coolant capacity Power steering fluid capacity Transmission fluid capacity Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.

Ford F-150 2000 Introduction Manual

Quick Links

Related Manuals for Ford F-150 2000

Summary of Contents for Ford F-150 2000

Table of Contents
