Ford 2000 F250 Owner's Manual

Table of Contents

Quick Links

Before driving

Introduction

Instrumentation

Controls And Features

Seating And Safety Restraints

Starting and driving

Starting

Driving

Roadside Emergencies

Servicing

Maintenance And Care

Capacities And Specifications

Customer Assistance

Reporting Safety Defects

Index

photocopying, recording or by any information storage and retrieval system or translation

in whole or part is not permitted without written authorization from Ford Motor Company.

Ford may change the contents without notice and without incurring obligation.

Contents

104

109

145

172

222

234

246

247

Table of Contents

Summary of Contents for Ford 2000 F250

Page 1 All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning Engine exhaust, some if its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm. ICONS Indicates a safety alert.
Page 3 INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. SPECIAL NOTICES Notice to owners of diesel-powered vehicles Read the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s...
Page 4 Truck Body Builders Advisory Service 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance...
Page 5 You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer. Ford Ambulance Preparation Package is only available on certain 7.3L Diesel engine equipped vehicles. Notice to owners with vehicles equipped with Power Take Off...
Page 6 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows...
Page 7 Vehicle Symbol Glossary Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Introduction Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature Battery...
Page 8: Instrumentation
Instrumentation Turn signal and wiper/washer control (pg. 61) Headlamp control (pg. 25) Instrument panel dimmer switch (pg. 26) * if equipped Instrument cluster (pg. 10) Speed control* (pg. 56) FUEL FILL FUEL 0 0 0 0 0 0 0 0 0 km/h RPM 1000 SERVICE...
Page 9 Instrumentation Electronic sound system (pg. 32) Gearshift lever* (pg. 114) Auxiliary Passenger air bag power point deactivate switch (pg. 27) (pg. 92) Climate control system (pg. 27) 4WD selector* (pg. 123)
Page 10 Instrumentation WARNING LIGHTS AND CHIMES FUEL FILL FUEL Low fuel Illuminates as an early reminder of a low fuel condition indicated on the fuel gauge (refer to Fuel Gauge in this chapter for more information). When refueling, after the light comes on, the amount of fuel that is added will be less than the advertised capacity since there is fuel still in the tank.
Page 11 What you should do if the Service Engine Soon light illuminates Light turns on solid: This means that the OBD II system has detected a malfunction. Temporary malfunctions may cause your Service Engine Soon light to illuminate. Examples are: 1. The vehicle has run out of fuel. (The engine may misfire or run poorly.) 2.
Page 12 Instrumentation government emission standards. The OBD II system also assists the service technician in properly servicing your vehicle. The Service Engine Soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. If it comes on after the engine is started, one of the engine’s emission control systems may be malfunctioning.
Page 13 Instrumentation Air bag readiness Momentarily illuminates when the ignition is turned ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Transmission control indicator light (TCIL) Illuminates when the Transmission Control Switch (TCS), refer to OVERDRIVE Overdrive control in the Controls and Features chapter, has been...
Page 14 Instrumentation Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position. If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.
Page 15 Four wheel drive indicator (if equipped) Momentarily illuminates when the ignition is turned to the START position. Illuminates when 4x4 range is engaged. If the light continues to flash have the system serviced. Door ajar Illuminates when the ignition is in the ON or START position and any door is open.
Page 16 Instrumentation The “SET” light comes on when either the COAST/SET or RES/ACCEL controls are pressed. The “SET” light turns off when the cruise cancel control is pressed or the brake is applied. Both the “CRUISE” and “SET” lights turn off when the OFF control is pressed or the ignition is turned to the OFF position.
Page 17 Instrumentation Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion. The ignition should be in the OFF position while the vehicle is being refueled.
Page 18 Instrumentation Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. Odometer Registers the total kilometers (miles) of the vehicle.
Page 19 Instrumentation Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer at the top of the scale or in the red zone may damage the engine. Battery voltage gauge This shows the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated), have the vehicle’s...
Page 20 Instrumentation TRIP COMPUTER (IF EQUIPPED) The trip computer tells you about the condition of your vehicle through a constant monitor of vehicle systems. You may select display features on the trip computer for a display of status. The appearance of your vehicle’s trip computer may differ depending on your vehicle’s option package, but the functions are the same.
Page 21 Instrumentation • variations in top-off procedure from one fill-up to another • rounding of the displayed values to the nearest liter (gallon) To reset the average fuel economy: 1. Press the MODE control repeatedly until average fuel economy is displayed (this is the only resettable display). 2.
Page 22 Instrumentation Outside air temperature The temperature can be displayed in Centigrade or Fahrenheit by pressing the E/M control. MODE If the outside temperature falls below 3°C (38°F), the display will alternate from “ICE” to the outside temperature at a two second rate for one minute.
Page 23 Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Locate the trip computer on the overhead console. 3. Turn ignition to the ON position. 4. Press and hold both trip computer controls.
Page 24 Instrumentation Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines. For optimum calibration, turn off all electrical accessories (heater/air conditioning, wipers, etc.) and make sure all vehicle doors are shut. 1. Locate the trip computer located in the overhead console. 2.
Page 25: Controls And Features
HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: •...
Page 26 Controls and features Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. • Rotate up to brighten. • Rotate down to dim. •...
Page 27 Controls and features AUXILIARY POWER POINT The auxiliary power point is located on the instrument panel. POWER POINT Do not plug optional electrical accessories into the cigarette lighter. Use the power point. CLIMATE CONTROL SYSTEM Heater only system (if equipped) Fan speed control Controls the volume of air circulated in the vehicle.
Page 28 Controls and features • OFF-Outside air is shut out and the fan will not operate. • (Panel and floor) -Distributes outside air through the instrument panel registers and the floor ducts. • (Floor) -Allows for maximum heating. Distributes outside air through the floor ducts.
Page 29 Manual heating and air conditioning system Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle. The air conditioning compressor will operate in all modes except (Panel) and (Floor).
Page 30 Controls and features • (Panel) -Distributes outside air through the instrument panel registers. However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode. • OFF-Outside air is shut out and the fan will not operate. For short periods of time only, use this mode to prevent undesirable odors from entering the vehicle.
Page 31 • Remove any snow, ice or leaves from the air intake area (at the bottom of the windshield under the hood). • If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 32 Controls and features USING YOUR AUDIO SYSTEM AM/FM Stereo (with 2 speakers) PUSH TONE AM/FM Stereo (with 4 speakers and fade capability) PUSH TONE AM / FM STEREO SEEK TONE VOL TUNE AM/FM SEEK TONE VOL TUNE AM/FM...
Page 33 Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 34 Controls and features Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly. • Press to move to the next frequency up the band (whether or not a listenable station is located there).
Page 35 Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the TONE control once, then use the volume knob to adjust the desired level. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output.
Page 36 Controls and features Setting the clock Press CLK to toggle between listening frequencies and clock mode. To set the hour, press and hold the CLK control until CLOCK SET appears in the display and press the SEEK control: • to decrease hours and •...
Page 37 reverting back to the clock. In media mode, the media information will always be displayed. AM/FM stereo cassette VOL - PUSH ON BASS TREB SEEK SCAN TUNE Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume.
Page 38 Controls and features If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FM select The AM/FM select control works in radio and tape modes.
Page 39 Seek function in radio mode • Press to find the next listenable station down the frequency band. • Press to find the next listenable station up the frequency band. Scan function The scan function works in radio mode. Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band.
Page 40 Controls and features Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. BASS Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers.
Page 41 Tape select • To enter tape mode while in radio mode, press the TAPE AMS control. Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection.
Page 42 Controls and features Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 43 • to decrease minutes and • to increase minutes. The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 44 Controls and features Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Audio power can also be turned on by pressing the AM/FM select control or the tape/CD select control. Audio power is turned off by using the volume/power control.
Page 45 Tune adjust The tune control works in radio or CD changer mode. Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.
Page 46 Controls and features Seek function in radio mode • Press to find the next listenable station down the frequency band. • Press to find the next listenable station up the frequency band. Seek function in tape mode • Press to listen to the previous selection on the tape. •...
Page 47 Controls and features Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape. (The tape scans in a forward direction. At the end of the tape’s first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again.
Page 48 Controls and features Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing.
Page 49 Press the TREB control then press: • to decrease the treble output • to increase the treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control then press: • to shift sound to the left and •...
Page 50 Controls and features Tape/CD select • To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
Page 51 Controls and features Eject function Press the EJ control to stop and eject a tape. Press the EJ control to stop and eject a CD. Dolby noise reduction Dolby noise reduction operates in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback.
Page 52 Controls and features Setting the clock To set the hour, press and hold the CLK control and press SEEK: • to decrease hours and • to increase hours. To set the minute, press and hold the CLK control and press TUNE: •...
Page 53 The CLK button will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 54 Controls and features Cleaning compact discs Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion. CD and CD changer care •...
Page 55 Radio reception factors Three factors can affect radio reception: • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/ volume relative to other stations.
Page 56 Controls and features TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. SPEED CONTROL (IF EQUIPPED) To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph).
Page 57 To turn speed control off • Press OFF or • Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To set a speed • Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph).
Page 58 Controls and features To set a higher set speed • Press and hold SET/SET ACC/ SET ACCEL. Release the control when the desired vehicle speed is reached or • Press and release SET/SET ACC/ SET ACCEL. Each press will increase the set speed by 1.6 km/h (1 mph) or •...
Page 59 Controls and features To disengage speed control • Depress the brake pedal or • Depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.
Page 60 Controls and features To return to a previously set speed • Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). TILT STEERING WHEEL (IF EQUIPPED) Pull the tilt steering control toward you to move the steering wheel up or down.
Page 61 Controls and features HAZARD FLASHER For information on the hazard flasher control, refer to Hazard flasher in the Roadside emergencies chapter. WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers.
Page 62 Controls and features The TCIL (the word OFF) will no longer be illuminated. When you shut off and re-start your vehicle, the transmission will automatically return to normal For additional information about the gearshift lever and the transmission control switch operation refer to the Automatic Transmission Operation section of the Driving chapter.
Page 63 One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the left side of the control.
Page 64 Controls and features CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 65 Controls and features 3. Return to the center position to lock mirrors in place. Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 66 Controls and features ILLUMINATED VISOR MIRROR (IF EQUIPPED) To turn on the visor mirror lamps, slide the mirror cover open. To turn off the visor mirror lamps, slide the mirror cover closed. CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: •...
Page 67 Controls and features REMOTE ENTRY SYSTEM (IF EQUIPPED) The remote entry system allows you to lock or unlock all vehicle doors without a key. The remote entry features only operate with the ignition in the OFF position. If there is any potential remote keyless entry problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to the dealership, to aid in troubleshooting.
Page 68 Controls and features Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada.
Page 69 Controls and features To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation.
Page 70 Controls and features Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: •...
Page 71 Reprogramming transmitters To reprogram all transmitters, place the key in the ignition and turn from OFF to ON eight times in a row (within 10 seconds). After doors lock/unlock, press any control on all transmitters (up to four). When completed, turn the ignition to OFF. All transmitters must be reprogrammed at the same time.
Page 72: Seating And Safety Restraints
Seating and safety restraints SEATING Full bench seat (if equipped) • Lift the track release bar to move the seat forward or backward. Ensure that the seat is relatched into place. • Pull up on the release lever located at the bottom of the seatback to quickly fold the seatback forward.
Page 73 Seating and safety restraints Captain’s chair (if equipped) • Lift the track release bar to move the seat forward or rearward. Make sure that the seat is relatched into place. • Pull the seatback handle up to recline the seat. •...
Page 74 Seating and safety restraints Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Turn the lumbar support control toward the front of vehicle to move the lumbar support forward for...
Page 75 Seating and safety restraints Folding up the rear seats (if equipped — SuperCab only) The rear seatback has a split 60/40 seat. Each seat cushion can be flipped up into the seatback position. 1. Pull control to release seat cushion. 2.
Page 76 Seating and safety restraints Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag SRS is provided.
Page 77 Seating and safety restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 78 Seating and safety restraints Automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
Page 79 Seating and safety restraints • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode.
Page 80 Seating and safety restraints Safety belt replacement label (Crew Cab Only) The short plastic boot on the front safety belt at the passenger outboard anchor location covers a “Replace Belt” label on the safety belt. In the event of a collision, the colored label (REPLACE BELT) may become visible.
Page 81 Seating and safety restraints Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury. Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger.
Page 82 Seating and safety restraints • 4–door Super Cab To lower the shoulder belt height, push the button and slide the height adjuster down. To raise the height of the shoulder belt, slide the height adjuster up. Pull down on the height adjuster to make sure it is locked in place.
Page 83 Seating and safety restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 84 Seating and safety restraints Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding...
Page 85 I’m not going far 3 of 4 fatal crashes occur within 25 miles of home. Belts are Ford designs its safety belts to enhance comfort. If uncomfortable you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 86 Seating and safety restraints One time disable Anytime the safety belt is buckled and then unbuckled during an ignition ON cycle, Belt Minder will be disabled for that ignition cycle only. Deactivating/activating the belt minder feature Read steps 1 - 9 thoroughly before proceeding with the deactivation/activation programming procedure.
Page 87 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 88 This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
Page 89 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 90 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains sufficient longitudinal deceleration. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
Page 91 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag is deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 92 If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. PASSENGER AIR BAG...
Page 93 If the light is illuminated when the passenger air bag switch is in the ON position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. The passenger side air bag should always be ON (the air bag OFF light...
Page 94 Seating and safety restraints Always transport children who are 12 and younger in the rear seat. Always use safety belts and child restraints properly. If a child in a rear facing infant seat must be transported in front, the passenger air bag must be turned OFF. This is because the back of the infant seat is too close to the inflating air bag and the risk of a fatal injury to the infant when the air bag inflates is substantial.
Page 95 Seating and safety restraints • although children ages 1 to 12 ride in the rear seat(s) whenever possible, children ages 1 to 12 sometimes must ride in the front because no space is available in the rear seat(s) of the vehicle; or •...
Page 96 Seating and safety restraints 2. Child age 12 or under: A child age 12 or under must ride in the front seat because: • my vehicle has no rear seat; • although children age 12 and under ride in the rear seat whenever possible, children age 12 and under have no option but to sometimes ride in the front seat because rear seat space is insufficient;...
Page 97 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 98 Seating and safety restraints A belt-positioning booster should be used if the shoulder belt rests in front of the child’s face or neck, or if the lap belt does not fit snugly on both thighs, or if the thighs are too short to let the child sit all the way back on the seat cushion when the lower legs hang over the edge of the seat cushion.
Page 99 (passenger side front and outboard rear seating positions) (if equipped). Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 100 Seating and safety restraints An air bag can kill or injure a child in a child seat. Child seats should never be placed in the front seats, unless passenger air bag switch is turned off, See Passenger air bag deactivation switch. Rear facing child seats should NEVER be placed in the front seats unless the passenger airbag switch is turned off.
Page 101 Seating and safety restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 102 Ford or Lincoln/Mercury dealer. If you have a Super Cab or Crew Cab, Ford recommends you attach tether safety seats in the rear seating position (if possible) with the tether strap attached to the tether anchorage bracket as shown in the...
Page 103 Seating and safety restraints Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision.
Page 104 Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 105 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: •...
Page 106 Starting FUEL FILL FUEL Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the STARTING THE ENGINE 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 107 Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 108 Starting Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch).
Page 109: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 110 Driving released. (If your brake warning lamp illuminates, have your vehicle serviced immediately.) Using RABS • In an emergency, applying full pressure may cause the front wheels to lock. If the front brakes lock, the vehicle cannot be steered. You should apply the brakes with steadily increasing force, as if “squeezing”...
Page 111 With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with parking brake released. (If your brake warning lamp illuminates, have your vehicle serviced immediately.) Using ABS •...
Page 112 Driving Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission). The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency.
Page 113 Extended use of other than the manufacturer’s specified size tires on a Traction-Lok rear axle could result in a permanent reduction in effectiveness. This loss of effectiveness does not affect normal driving and should not be noticeable to the driver. To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire.
Page 114 Driving AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1.
Page 115 Driving with a 4–speed automatic transmission Understanding gearshift positions To put your vehicle in gear, start the engine, depress the brake pedal, then move gearshift lever out of P (Park). Hold the brake pedal down while you move the gearshift lever from P (Park) to another position.
Page 116 Driving (Overdrive) can be deactivated by pressing the transmission control OVERDRIVE switch (TCS) on the end of the gearshift lever. The transmission control indicator light (TCIL) (the word OFF) on the OVERDRIVE end of the gearshift lever will illuminate. Drive – Not shown on the display. Activate by pressing the transmission control switch (TCS) on the end of the gearshift lever with the gearshift in the position.
Page 117 Driving higher speeds causes the transmission to shift to a lower gear, and will shift to 1 (Low) after vehicle decelerates to the proper speed. Forced Downshifts To gain acceleration in (Overdrive) or Drive (O/D OFF) when passing another vehicle, push the accelerator to the floor. The transmission will downshift to the appropriate gear: third, second or first gear.
Page 118 Driving When starting a vehicle with a manual transmission, you must: 1. Make sure the parking brake is fully set. 2. Depress the clutch pedal fully. 3. Put the gearshift lever in N (Neutral). 4. Turn the ignition to position 5 (START) to start the engine, let the engine idle for a few seconds.
Page 119 Recommended shift speeds Downshift according to the following charts for your specific engine/drivetrain combination: Maximum downshift speeds 5-speed transmission Shift from: (Overdrive) - 4 72 km/h (45 mph) 4 - 3 56 km/h (35 mph) 3 - 2 32 km/h (20 mph) 2 - 1 8 km/h (5 mph) Use 2H or 4H for 4WD equipped vehicles.
Page 120 Driving Parking your vehicle 1. Disengage the clutch, apply brake and shift into N (Neutral). 2. Set parking brake. 3. Shift into 1 (First). 4. Turn the ignition key to position 3 (OFF).
Page 121 Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
Page 122 Driving Removing key from ignition • Turn the ignition key to position • Push the release lever forward and rotate the key towards you and remove. POWER TAKE OFF (PTO) CAPABILITY (IF EQUIPPED) Some vehicles equipped with an automatic transmission and the 6.8L or 7.3L engine are also equipped with Power Take Off (PTO) capability.
Page 123 FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. When Four–wheel drive (4WD) is engaged, power is supplied to all four wheels through a transfer case. 4WD power can be selected when additional driving power is desired.
Page 124 4WD system indicator lights The 4WD system indicator lights illuminate only under the following conditions. If these lights illuminate when driving in 2WD, contact your Ford dealer as soon as possible. • 4x4 -momentarily illuminates when the ignition is turned to the ON position.
Page 125 • LOW RANGE –momentarily illuminates when the ignition is turned to the ON position. Illuminates when 4L (4x4 Low) is engaged. Using a manual 4WD system (if equipped) 2H (2WD High) – Power to rear axle only. 4H (4WD High) – Power to front and rear axles. N (Neutral) –...
Page 126 Driving Shifting from 4H (4WD high) to 2H (2WD high) Move the transfer case lever to 2H (2WD High) at a stop or any forward speed up to 88 km/h (55 mph). With the vehicle at complete stop, disengage the locking hubs (optional) by rotating the hub lock control from LOCK to FREE.
Page 127 4. Move the transfer case shift lever through N (Neutral) directly to 4H (4WD High) or 2H (2WD high) and hold the shift lever in position until the transfer case has fully engaged (up to 15 seconds). 5. If the transfer case does not engage, repeat steps 1 through 4.
Page 128 Driving Shifting from 2WD (2WD high) to 4x4 HIGH (4WD high) Rotate the 4WD control to the 4x4 HIGH position at speeds up to 88 km/h (55 mph). • To prevent damage, the electronic shift 4WD system is designed to engage 4x4 HIGH (4WD high) when the vehicle is moving.
Page 129 4. Move the 4WD control to the 4x4 LOW position. 5. Hold the shift command until the LOW RANGE indicator light illuminates. 6. If the LOW RANGE indicator light does not illuminate after 15 seconds, start the vehicle moving, then repeat steps 1 through 5 before reporting any shift concerns to your dealer.
Page 130 Driving Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps. You should either know the terrain or examine maps of the area before driving. Map out your route before driving in the area. For more information on driving off-road, read the “Four Wheeling”...
Page 131 Driving If the transmission, transfer case or front axle are submerged in water, their fluids should be checked and changed, if necessary. Water intrusion into the transmission may damage the transmission. If the front or rear axle is submerged in water, the axle lubricant should be replaced.
Page 132 Driving If your vehicle is equipped with a Four Wheel Anti-lock Brake System (ABS), apply the brakes as you normally would. In order to allow the ABS to operate properly, keep steady pressure on the brake pedal. When driving on snow or ice with either braking system, allow more stopping distance and drive slower than usual.
Page 133 • Maximum Trailer Weight: Maximum weight of a trailer the loaded vehicle (including passengers and cargo) is permitted to tow. It is determined by subtracting the weight of the loaded trailer towing vehicle from the GCWR for the towing vehicle. •...
Page 134 Driving Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in the Driving chapter of this owner guide. Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles.
Page 135 Driving through deep water where the transmission vent tube is submerged may allow water into the transmission and cause internal transmission damage. TOWING A TRAILER Your vehicle may tow a Conventional/Class IV trailer or fifth wheel trailer provided the maximum trailer weight is less than or equal to the maximum trailer weight listed for your engine and rear axle ratio...
Page 136 Driving Trailer towing tables F-250 with manual transmission Engine Rear axle ratio 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 Conventional/Class IV trailer hitch only. Fifth wheel trailer maximum weights can be calculated by subtracting GVW from GCWR. F-250 with automatic transmission Engine Rear axle ratio...
Page 137 F-350 with automatic transmission Engine Rear axle ratio 5.4L 3.73 5.4L 4.10 6.8L 3.73 6.8L 4.30 Conventional/Class IV trailer hitch only. Fifth wheel trailer maximum weights can be calculated by subtracting GVW from GCWR. F-450 with manual transmission Engine Rear axle ratio 6.8L 4.88...
Page 138 Driving Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle. See your dealer or a reliable trailer dealer if you require assistance. Hitches Do not use hitches that clamp onto the vehicle’s bumper or attach to the axle.
Page 139 Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.
Page 140 Driving Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your Scheduled Maintenance guide for more information. Trailer towing tips • Practice turning, stopping and backing up in an area before starting on a trip to get the feel of the vehicle trailer combination.
Page 141 SNOWPLOWING For low speed snow removal, Ford offers a Snowplow Package as an option. If you do not have this equipment, do not use your vehicle as a snowplow or powertrain and suspension system damage may occur.
Page 142 Driving • The Front Axle Accessory Reserve Capacity and the Total Accessory Reserve Capacity listed on the bottom right of the Safety Compliance Certification Label will determine whether or not the addition of a snowplow will overload your vehicle. • The weight of the snowplow and supporting components distributed to the front axle must not exceed the front accessory reserve capacity.
Page 143 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Engine temperature while plowing...
Page 144 Driving If you are driving more than 24 km (15 miles) at temperatures above freezing, angle the plow blade either full left or full right to provide maximum airflow to the radiator. If you are driving less than 24 km (15 miles) at speeds up to 64 km/h (40 mph) in cold weather, you will not need to worry about blade position to provide maximum airflow.
Page 145: Roadside Emergencies
GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 146 Roadside coverage beyond basic warranty In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, you may purchase additional coverage beyond the basic coverage period by consulting the Ford Roadside Assistance Club brochure or by calling 1–877–294–CLUB (1–877–894–2582).
Page 147 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 148 Roadside emergencies Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse Mini Standard Rating Fuses...
Page 149 Roadside emergencies To remove the fuse panel cover, turn the panel fasteners counterclockwise. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 150 Roadside emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating Turn/Hazard Lamps Airbag Module Cigar Lighter, Data Link Connector Glove Box Lamp, Map Lamps, Power Mirrors, Underhood Lamp — Not Used — Not Used Power Window/Lock Switch Illumination Radio, Headlamp Switch Illumination —...
Page 151 Fuse/Relay Fuse Amp Location Rating Auxiliary Powertrain Control Module (APCM) (Diesel only), Instrument Cluster, GEM Module, Overdrive Cancel Switch, Idle Validation Switch (Diesel only), Overhead Console, Diesel PCM via Clutch Starter Motor Relay Coil, Clutch Switch — Not Used Air Bag Module, Passenger Air Bag Activation/Deactivation Switch, Blower Motor Relay Coil —...
Page 152 Roadside emergencies Power distribution box The power distribution box, trailer tow and electronic shift on the fly relay blocks are located in the engine compartment near the brake master cylinder. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
Page 153 The high-current fuses and relays are coded as follows. Fuse/Relay Fuse Amp Location Rating 7.5A * 10A* 7.5A* 20A* 20A* (Gasoline only) 5A* (Diesel only) 10A* 20A* (Gasoline only) 5A* (Diesel only) 15A* 10A* 20A* 10A* 15A* 30A** 60A** — 30A** 30A** 30A**...
Page 154 Roadside emergencies Fuse/Relay Fuse Amp Location Rating 50A** 50A** 40A** 30A** (Gasoline only) 20A** (Diesel only) 30A*** 20A** - (Gasoline only) 30A** (Diesel only) 30A** 20A** — * Mini Fuses ** Maxi Fuses ***Circuit Breaker Power Distribution Box Description Ignition Switch (B1 & B3) Junction Box Battery Feed Blower Motor PCM Power...
Page 155 CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Spare tire information Your vehicle may be equipped with a spare tire that can be used as either a spare or a regular tire.
Page 156 Roadside emergencies • one wheel nut wrench. Slide over square end of jack handle. 2. The following steps are required to move the support bracket (if equipped) away from the spare tire: • With tapered end of lug wrench, loosen the eyebolt on the support bracket.
Page 157 4. Insert the hooked end of the jack handle into the rear bumper drive tube. The handle will stop moving and you will feel forward resistance to turning when properly engaged. 5. Turn the handle counterclockwise and lower the spare until you can slide the tire rearward and the cable is slack.
Page 158 Roadside emergencies Tire change procedure 1. Park on a level surface, activate hazard flashers and set the parking brake. • Automatic transmission: Place gearshift lever in P (Park). • Manual transmission: Place gearshift lever in R (Reverse). • Electronic Shift On the Fly four wheel drive: Place transfer case in 2WD, 4x4 HIGH or 4x4 LOW.
Page 159 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park) (automatic transmission) or R...
Page 160 Roadside emergencies • Front (4x2) • Front passenger side (4x4)
Page 161 Roadside emergencies • Front driver side (4x4) Make sure the jack fits into the notched area on the differential housing. • Rear...
Page 162 Roadside emergencies 8. Turn the jack handle clockwise until the wheel is completely off the ground and high enough to install the spare tire. 9. Remove the lug nuts with the lug wrench. 10. On single rear wheel vehicles, replace the flat tire with the spare tire, making sure the valve stem is facing outward for all front tires and vehicles equipped with single rear...
Page 163 Roadside emergencies • Front (4x2) • Front driver side (4x4) • Front passenger side (4x4) 2000 F250/350/450/550 (f23) Owners Guide (owners) USA English (fus)
Page 164 18. Lower the wheel by slowly turning the release valve counterclockwise. Opening the release valve slowly will provide a more controlled rate of descent. 2000 F250/350/450/550 (f23) Owners Guide (owners) USA English (fus)
Page 165 M14 x 1.5 200-225 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On all two-piece flat wheel nuts, apply one drop of motor oil between the flat washer and the nut. Do not apply motor oil to the wheel nut threads or the wheel stud threads.
Page 166 Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. 2000 F250/350/450/550 (f23) Owners Guide (owners) USA English (fus)
Page 167 Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 2000 F250/350/450/550 (f23) Owners Guide (owners) USA English (fus)
Page 168 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 169 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 170 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 171 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company provides a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 172: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
Page 173 3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on • Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 174 Maintenance and care OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch located under the right center of the hood. Slide the handle to release the auxiliary latch.
Page 175 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 5.4L V8/6.8L V10 gasoline engines Refer to the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for diesel engine component locations. 1. Engine oil dipstick 2. Clutch fluid reservoir (manual transmission) 3.
Page 176 Maintenance and care ENGINE OIL Checking the engine oil Refer to the Scheduled Maintenance Guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 177 • If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range. • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7.
Page 178 Change your engine oil and filter according to the appropriate schedule listed in the Scheduled Maintenance Guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 179 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 180 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 181 Check the clutch fluid level. Refer to the Scheduled Maintenance Guide for the service interval schedules. Use only a DOT 3 brake fluid designed to meet Ford specifications. Refer to Capacities and specifications. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 182 In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 183 • protection against rust and other forms of corrosion. • an accurate temperature readout from the engine coolant gauge. The engine coolant must be maintained at the correct fluid level and concentration to work properly. If the engine coolant fluid level and concentration is not maintained correctly, damage to the engine and cooling system may result.
Page 184 Use only Ford Premium Engine Coolant E2FZ-19549-AA (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A. • DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA (orange in color). • DO NOT USE a DEX-COOL engine coolant or an equivalent engine coolant that meets Ford specification WSS-M97B44-D.
Page 185 4. When you are sure that all the pressure has been released, use the cloth to turn it counterclockwise and remove the cap. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44-A.
Page 186 Maintenance and care Severe climates If you drive in extremely cold climates (less than –36° C [–34° F]): • it may be necessary to increase the coolant concentration above 50%. • NEVER increase the coolant concentration above 60%. • increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage.
Page 187 How fail-safe cooling works If the engine begins to overheat: • the engine coolant temperature gauge will move to the red (hot) area. • the symbol will illuminate. • the Service Engine Soon indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 188 Maintenance and care 5. Re-start the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid.
Page 189 Maintenance and care 5. Recheck the fluid level on the dipstick. Do not add fluid if the level is between the arrows in the FULL COLD range. 6. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the FULL COLD range.
Page 190 Maintenance and care Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 10°C (50°F). Correct fluid level The transmission fluid should be checked at normal operating temperature 66°C-77°C (150°F-170°F) on a level surface.
Page 191 Maintenance and care Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Lubricant specifications section in the Capacities and specifications chapter.
Page 192 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. Checking and adding transfer case fluid (if equipped) 1. Clean the filler plug.
Page 193 Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. AIR FILTER MAINTENANCE Refer to the Scheduled Maintenance Guide for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed.
Page 194 Maintenance and care 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the open end of the air filter housing. 4. Install a new air filter element, ensuring the arrow on the top half of the air filter housing lines up with the notch on the bottom half of air filter housing.
Page 195 However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules. Keep the electrolyte level in each cell up to the “level indicator”. Do not overfill the battery cells. If the electrolyte level in the battery is low, you can add plain tap water to the battery, as long as you do not use hard water (water with a high mineral or alkali content).
Page 196 Maintenance and care Because your vehicle’s engine is also electronically controlled by a computer, some control conditions are maintained by power from the battery. When the battery is disconnected or a new battery is installed, the engine must relearn its idle and fuel trim strategy for optimum driveability and performance.
Page 197 Maintenance and care Checking the wiper blades If the wiper blades do not wipe properly, clean both the windshield and wiper blades using undiluted windshield wiper solution or a mild detergent. Rinse thoroughly with clean water. To avoid damaging the blades, do not use fuel, kerosene, paint thinner or other solvents.
Page 198 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 199 The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. SERVICING YOUR TIRES Checking the tire pressure •...
Page 200 Maintenance and care • Four tire rotation • Five tire rotation...
Page 201 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires.
Page 202 Maintenance and care The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains. If you need to use chains, it is recommended that steel wheels (of the same size and specifications) be used as chains may chip aluminum wheels.
Page 203 Automotive fuels can cause serious injury or death if misused or mishandled. Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. •...
Page 204 Maintenance and care When refueling always shut the engine off and never allow sparks or open flames near the filler neck. Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container.
Page 205 World-wide Fuel Charter. Cleaner air Ford approves the use of reformulated “cleaner-burning” gasolines to improve air quality. These gasolines may contain oxygenates up to 10% ethanol or 15% MTBE. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 206 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 207 ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fillups or fuel gauge readings are NOT accurate as a measure of fuel economy.
Page 208 Maintenance and care Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in kilometers or miles). 2. Each time you fill the tank, record the amount of fuel added (in liters or gallons). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
Page 209 • Using the air conditioner or defroster may reduce fuel economy. • You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs. Unnecessary shifting of this type could result in reduced fuel economy.
Page 210 Guide are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 211 Illumination of the “Service Engine Soon” light, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly. Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment.
Page 212 Maintenance and care BULBS Replacing exterior bulbs Check the operation of the following lamps frequently: • Headlamps • High-mount brakelamp • Brakelamps • Turn signals • License plate lamp • Tail lamps • Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones.
Page 213 Maintenance and care 6. Insert the glass end of the new bulb into the headlamp assembly. When the grooves in the plastic base are aligned, push the bulb into the lamp assembly until the plastic base contacts the rear of the lamp assembly.
Page 214 Maintenance and care 6. Remove the four screws and the headlamp retaining ring from headlamp. 7. Disconnect the electrical connector and remove headlamp. To install the new headlamp, reverse the removal procedure. Replacing tail lamp/turn/backup lamp bulbs — F250/F350 only The tail lamp/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below...
Page 215 Maintenance and care Replacing brake/tail/backup lamp bulbs — F450/F550 only The brake/tail/backup lamp bulbs are located in the same portion of the tail lamp assembly. Follow the same steps to replace either bulb: 1. Remove the four screws and the lamp lens from lamp assembly.
Page 216 Maintenance and care Replacing roof marker bulbs To change the cab marker bulbs: 1. Remove the screw and lens from the lamp assembly. 2. Carefully pull the bulb straight out of the socket and push in the new bulb. 3. Install lens on lamp assembly with screw.
Page 217 If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes. Maintenance and care...
Page 218 Maintenance and care Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap. If your vehicle is particularly dirty, use a quality car wash detergent. Always use a clean sponge, washing glove or similar device and plenty of water for best results.
Page 219 Ultra Touch Prep and Finishing Kit (#F7AZ-19K507–BA), Lacquer Touch-up Paint (#ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (#ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line. Please note that the part numbers (shown as XXXX above) will vary with your vehicle’s specific coloring. Observe the application instructions on the products.
Page 220 Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
Page 221 For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.
Page 222: Capacities And Specifications
*Refer to the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for Motorcraft diesel engine service part numbers. **Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Ford Part Fluid Name Front axle Motorcraft SAE 75W-90...
Page 223 Capacities and specifications Ford Part Fluid Name Engine coolant Premium Engine Coolant Engine oil Motorcraft SAE (includes filter 5W-30 Super change)-Gas Premium Motor engines Engine oil Refer to your 7.3L Diesel Supplement (includes filter change)-Diesel engine Fuel tank Power steering...
Page 224 Ford Specification EST-M2C118-A for complete refill of Traction-Lok axles. Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter.
Page 225 80W-90 Premium Rear Axle Lubricant (Dana 135 axles) Brake fluid High Performance and clutch DOT 3 Motor fluid (if Vehicle Brake equipped) Fluid Engine coolant Ford Premium Engine Coolant Ford part Ford number specification XY-75W90-TQL WSP-M2C201-A F1TZ-19580-B WSL-M2C192-A XY-80W90-QL WSP-M2C197-A...
Page 226 Add 236 ml (8 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of Traction-Lok axles. Ford design rear axles contain a synthetic lubricant that does not require changing unless the axle has been...
Page 227 Capacities and specifications submerged in water. Dana rear axles also contain a synthetic lubricant but do require a change. Refer to your “Service Guide” for change intervals on Dana rear axles. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 228 Capacities and specifications VEHICLE DIMENSIONS F250–except Crew Cab Dimension Regular Cab 4x2 (1) Overall 1 864 mm 1 958 mm height (74 in) (77.1 in) (2) Track 1 736.3 mm 1 736.3 mm (Front / (68.3 in) / (68.3 in) / Rear) 1 729.3 mm 1 729.3 mm...
Page 229 Capacities and specifications F350–except Crew Cab Dimension Chassis Regular (1) Overall 1 972 mm 1 860 mm height (77.6 in) (73.2 in) (2) Track 1 736.3 mm 1 736.3 mm (Front / (68.3 in) / (68.3 in) / Rear) 1 879.6 mm 1 729.3 mm (74.0 in) (68.0 in)
Page 230 Capacities and specifications F350-Crew Cab Dimension Crew Cab 4x2 (1) Overall height 1 929 mm (75.9 in) (2) Track (Front / 1 745 mm (68.7 in)/ Rear) 1 729 mm (68.1 in) (3) Overall width 1 988 mm (78.3 in) (4) Wheelbase 3 967 mm (156.2 in ) 4 379 mm (172.4 in)
Page 231 Capacities and specifications F550 Dimension Chassis Chassis Cab 4x2 Cab 4x4 (1) Overall 2 076 mm 2 075 mm height (81.7 in) (81.6 in) (2) Track 1 736 mm 1 736 mm (Front / (68.3 in) / (68.3 in) / Rear) 1 879 mm 1 879 mm...
Page 232: Certification Label
Certification Label may be located. The Certification Label is located on the front door latch pillar on the driver’s side. MFD. BY FORD MOTOR CO. IN U.S.A. DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX...
Page 233 Capacities and specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and...
Page 234: Customer Assistance
5,000 participating Ford or Lincoln/Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options.
Page 235 Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Assistance Center to find an authorized dealership to help you.
Page 236 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Assistance Center: • Your telephone number (home and business) •...
Page 237 THE DISPUTE SETTLEMENT BOARD (U.S. only) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes • available free to owners and lessees of qualifying Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford...
Page 238 • the file number assigned to your application • the toll-free phone number of the DSB’s independent administrator Your dealership and a Ford Motor Company representative will then be asked to submit statements. To properly review your case, the Board needs the following information: •...
Page 239 • a brief summary of the action taken by the dealer(s) and Ford Motor Company • the names (if known) of all the people you contacted at the dealership(s) • a description of the action you expect to resolve your concern You will receive a letter of explanation if your application does not qualify for Board review.
Page 240 UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 241 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 242 Customer assistance Ford Deluxe Leather and Vinyl Cleaner (not available in Canada) Motorcraft Vinyl Cleaner (Canada only) Ford Extra Strength Tar and Road Oil Remover* (not available in Canada) Ford Extra Strength Upholstery Cleaner (Canada only) Ford Extra Strength Upholstery Cleaner (not available in Canada)
Page 243 Customer assistance Comfort and convenience Air conditioner Bed web net Cargo nets Cargo organizers Cargo storage bin Cargo trays Engine block heaters Power sliding rear window Tire step Travel equipment Auto headlamp system with Daytime Running Lights (DRL) Bumper mounted bike courier Daytime running lights (DRL) Electrochromic inside mirror with compass Electrochromic inside mirror with compass and temperature display...
Page 244 Customer assistance Protection and appearance equipment Air bag anti-theft locks Bed mat/bedliner tailgate covers Bed mats Bedliners Carpet floor mats Cleaners, waxes and polishes Diamond plate bed rail caps Diamond plate front box protection Diamond plate splash guards Diamond plate tool box Flat splash guards Front end covers (full) Hood deflectors...
Page 245 • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. ORDERING ADDITIONAL OWNER’S LITERATURE...
Page 246: Reporting Safety Defects
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 247: Index
Accessory delay ...63 Air bag supplemental restraint system ...88 and child safety seats ...89 description ...88 disposal ...92 driver air bag ...90 indicator light ...13,91 operation ...90 passenger air bag ...90 passenger deactivation switch ...92 Air cleaner filter ...193,222 Air conditioning ...27 Ambulance packages ...4 Antifreeze (see Engine coolant) ...182...
Page 248 ...182 refill capacities ...185,222 specifications ...225,227 Cruise control (see Speed control) ...56 Customer Assistance ...145 Ford accessories for your vehicle ...241 Ford Extended Service Plan ...234 Getting assistance outside the U.S. and Canada ...240 Getting roadside assistance ...145 Getting the service you need ...234...
Page 249 capacity ...222 choosing the right fuel ...204 comparisons with EPA fuel economy estimates ...210 detergent in fuel ...205 filling your vehicle with fuel ...202,206,207 filter, specifications ...206,222 fuel pump shut-off switch ...146 gauge ...17 improving fuel economy ...207 low fuel warning light ...10 octane rating ...204,227,228 quality ...205 running out of fuel ...205...
Page 250 Index replacing bulbs ...212,213,214,215,216 Lane change indicator (see Turn signal) ...56 Lights, warning and indicator ...10 air bag ...13 anti-lock brakes (ABS) ...14,110 brake ...13 charging system ...14 check coolant ...15 cruise indicator ...15 door ajar ...15 engine oil pressure ...15 high beam ...14 low fuel ...10 safety belt ...13...
Page 251 Snowplowing ...4,141,142,143 Spark plugs, specifications ...222,227,228 Special notice ...3,5 ambulance conversions ...4 diesel-powered vehicles ...3 four-wheel drive vehicles ...143,144 utility-type vehicles ...3 Specification chart, lubricants ...225,227 Speed control ...56 Speedometer ...17 Starting your vehicle ...104,106 jump starting ...166 Steering wheel tilting ...60 Tachometer ...19 Tailgate ...71...
Page 255: Filling Station Information
Refer to Refill capacities in the Capacities and specifications chapter. Engine oil (includes 5.7L (6.0 quarts). Use Motorcraft SAE 5W-30 filter change) Super Premium Motor Oil, Ford specification WSS-M2C153-G. Tire size and pressure Refer to the Certification Label inside of driver’s door Hood release Pull handle under the left side of the instrument panel.
Page 256 Filling station information fluid. However, these dual usage fluids may be used in transmissions that require the MERCON V type fluid. MERCON and MERCON V type fluids are not interchangeable. DO NOT mix MERCON and MERCON V. Use of a transmission fluid that indicates dual usage (MERCON and MERCON V) in an automatic transmission application requiring MERCON may cause transmission damage.

This manual is also suitable for:

2000 f 350

Ford 2000 F250 Owner's Manual

Quick Links

Related Manuals for Ford 2000 F250

Summary of Contents for Ford 2000 F250

This manual is also suitable for:

Table of Contents
