- Page 1 SRA60 COMPACTION RAMMER SRA 60 PARTS MANUAL © 2015 Stanley Black & Decker, Inc. New Britain, CT 06053 U.S.A. 76405 2/2016 Ver 4...
-
Page 2: Table Of Contents
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest authorized and certified dealer, call Stanley Hydraulic Tools at the number listed on the back of this manual and ask for a Customer Service Representative. -
Page 3: Machine Information
Because of the steady development of our products, the shown illustrations are non-committal. To order spare parts, please contact your local dealer or write to: Stanley Hydraulic Tools 3810 SE Naef Road Milwaukie, OR 97267... -
Page 4: Adhesives
ADHESIVES Sealing- and bonding adhesives as specified in the individual exploded views Convertion: Newtom-Meters to in. lb. and ft. lb. In. lb. Ft. lb. 44.2 88.5 11.0 14.7 221.2 18.4 265.5 22.1 309.7 25.8 29.5 398.2 33.1 36.8 486.7 40.5 44.2 4 ►... - Page 5 SRA 60 UPPER HANDLE PARTS Item No. Part No. Description 75471 Spring Element 75682 Socket Head Cap Screw 75531 Conical Spring Washer 75727 Hexagonal Head Cap Screw 75380 Holding Bow 75319 Retaining Pin 75371 Carrying Roller 75676 Socket Head Cap Screw 75752 Hexagon Nut SRA 60 Parts Manual ◄...
-
Page 6: Fuel Tank
SRA 60 FUEL TANK PARTS Item No. Part No. Description 75382 Fuel Tank Assy. 75568 Tank Cap 75564 Filter 75565 Fuel Tap 75759 Hexagon Nut 75545 Hose Clamp 75566 Hose 75554 Hose Clamp 75451 O-Ring 75567 Hose 75563 Fuel Filter 76498 Tube Clamp (For fuel line) 6 ►... - Page 7 SRA 60 ENGINE PARTS Item No. Part No. Description 75633 Petrol Engine 75866 Gasket 75873 Flange Nut 75870 Stud Bolt 75321 Suction Elbow Part 75455 Joint Washer 75559 Straight Coupling 75320 Hose 75335 Formed Hose 75548 Hose Clamp 75345 Cable 75087 Fan-Shaped Washer 75722...
- Page 8 SRA 60 ENGINE GUARDING PARTS Item No. Part No. Description 75330 Thermic Protection 75779 Button Socket Head Screw 75774 Thread Rolling Screw 75354 Engine Protection, Right 75355 Engine Protection, Left 75776 Button Socket Head Screw 75333 Console, Right 75334 Console, Left 75379 Engine Protection Panel, Top 75338...
- Page 9 SRA 60 THROTTLE PARTS Item No. Part No. Description 75644 Throttle Cable 75761 Countersunk Screw 75769 Cap Nut 75476 Rubber Buffer SRA 60 Parts Manual ◄ 9...
- Page 10 SRA 60 FILTER PARTS Item 18 (Foam Air Filter) Item No. Part No. Description 75571 Cyclone 75703 Threaded Pin 75572 Service Indicator 75356 Nipple 75326 Panel 75723 Hexagonal Head Cap Screw 75328 Cover 75542 Wing Screw 75511 Washer 75420 O-Ring 75516 Support Washer 75419...
-
Page 11: Gearbox
SRA 60 GEAR BOX PARTS Item No. Part No. Description 75377 Gearbox 75670 Screw Plug 75452 Joint Washer 75378 Cover 75426 O-Ring 75781 Button Socket Head Screw 75706 Stud Bolt 75539 Cylindrical Pin 75759 Hexagon Nut SRA 60 Parts Manual ◄ 11... -
Page 12: Clutch
SRA 60 CLUTCH PARTS Item No. Part No. Description 75318 Clutch Socket 75416 Shaft Sealing Ring 75399 Groove Ball Bearing 75317 Distance Ring 75489 Retaining Ring 75499 Retaining Ring 75579 Centrifugal Clutch 75729 Hexagonal Head Cap Screw 75531 Conical Spring Washer 75600 Set Of Lining Strap 12 ►... -
Page 13: Pinion
SRA 60 PINION PARTS Item No. Part No. Description 75325 Connecting Rod 75400 Groove Ball Bearing 75483 Retaining Ring 75315 Bush 75494 Retaining Ring 75360 Pinion 75400 Groove Ball Bearing 75401 Groove Ball Bearing 75485 Retaining Ring 75495 Retaining Ring SRA 60 Parts Manual ◄... -
Page 14: Guide Tube
SRA 60 GUIDE TUBE PARTS DANGER NOTE: Non serviceable item. Never attempt to remove item #4 Retaining Ring, com- ponents held by item 4 Retaining Ring are assembled under high spring com- pression. Removal of the Retainer ring may cause serious injury or death when energy is released. -
Page 15: Bellow
SRA 60 BELLOW PARTS Item No. Part No. Description 75362 Intermediate Piece 75694 Socket Head Cap Screw 75569 Oil Level Indicator 75381 Bellow 75551 Clamping Piece 75552 Clamping Piece 76404 Guide Tube, Assy. SRA 60 Parts Manual ◄ 15... -
Page 16: Base Plate
SRA 60 BASE PLATE PARTS Item No. Part No. Description 75323 Base Plate 75324 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75393 Grip 75366 Work Plate, Assy. 16 ►... -
Page 17: Decal Information
Part No. Description 75099 Decal Information 75103 Decal Information 75102 Decal Information 75101 Decal Information 75093 Decal Information 75097 Decal Information 75096 Sign, Operation 75777 Tapping Screw 74911 Stanley Logo 74900 Decal SRA 60 SRA 60 Parts Manual ◄ 17... - Page 18 SRA FOOT SIZE OPTIONS (WIDTH 165MM) 165 mm / 6-1/2 in. Work Plate Item No. Part No. Description 75336 Base Plate 75337 Floor Plate 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75348 Work Plate, Assy.
- Page 19 SRA FOOT SIZE OPTIONS (WIDTH 200MM) 200 mm / 7-7/8 in. Work Plate Item No. Part No. Description 75349 Base Plate 75350 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75347...
- Page 20 SRA FOOT SIZE OPTIONS (WIDTH 230MM) 230 mm / 9 in. Work Plate Item No. Part No. Description 75342 Base Plate 75343 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75346...
- Page 21 SRA FOOT SIZE OPTIONS (WIDTH 330MM) 330 mm / 13 in. Work Plate Item No. Part No. Description 75323 Base Plate 75363 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75358...
- Page 22 SRA FOOT SIZE OPTIONS (WIDTH 400MM) 400 mm / 15-3/4 in. Work Plate Item No. Part No. Description 75323 Base Plate 75364 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 75359...
- Page 23 SRA FOOT SIZE OPTIONS (WIDTH 340MM ASYMMETR) 340 mm / 13-3/8 in. Work Plate Asymmetr Item No. Part No. Description 75323 Base Plate 75368 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760...
-
Page 24: Intermediate Piece, Short
SRA PARTS INTERMEDIATE PIECE, SHORT (OPTION) Item No. Part No. Description 75322 Intermediate Piece, Short 24 ► SRA 60 Parts Manual... -
Page 25: Foot Extension
SRA FOOT EXTENSION PARTS Item No. Part No. Description 75369 Foot Extension 75694 Socket Head Cap Screw 75370 Foot Extension, Assy SRA 60 Parts Manual ◄ 25... -
Page 26: Trailer Assy
SRA TRAILER ASSY PARTS Item No. Part No. Description 75372 Axle 75637 Wheel 75517 75493 Retaining Ring 75331 Fastener 75332 Fastener 75085 Trailer, Assy. 26 ► SRA 60 Parts Manual... -
Page 27: Maintenance Kit
SRA (MAINTENANCE KIT) Item 9 (Foam Air Filter) Item No. Part No. Description 75088 Maintenance Kit 75871 Washer 75563 Fuel Filter 75570 Filter Element 75875 Spark Plug 75867 Starter Rope 75456 Joint Washer 75457 Joint Washer 76479 Foam Air Filter SRA 60 Parts Manual ◄... -
Page 28: Base Plate Kit
SRA BASE PLATE KIT Item No. Part No. Description 75836 Wear Parts Kit Base Plate 75366 Work Plate 75323 Base Plate 75324 Floor Plate 75789 Countersunk Screw 75787 Countersunk Screw 75316 Washer 75753 Hexagon Nut 75786 Countersunk Screw 75788 Countersunk Screw 75760 Hexagon Nut 28 ►... -
Page 29: Repair Kit (Coupling)
REPAIR KIT (COUPLING) Item No. Part No. Description 75790 Repair Kit Coupling 75318 Clutch Socket 75600 Repair Kit SRA 60 Parts Manual ◄ 29... -
Page 30: Repair Kit (Carry Roller)
REPAIR KIT (CARRYING ROLLER) Item No. Part No. Description 75794 Repair Kit Carrying Roller 75319 Retaining Pin 75371 Carrying Roller 75676 Socket Head Cap Screw 75752 Hexagon Nut 75793 Repair Kit Holding Bow 75471 Spring Element 75682 Socket Head Cap Screw 75539 Cylindrical Pin 30 ►... -
Page 31: Repair Kit (Carburator)
REPAIR KIT (CARBURATOR) Item No. Part No. Description 75791 Repair Kit Carburator 75863 Carburator 75864 Gasket 75865 Gasket SRA 60 Parts Manual ◄ 31... -
Page 32: Repair Kit (Bellow)
REPAIR KIT (BELLOW) Item No. Part No. Description 75795 Repair Kit Bellow 75381 Bellow 75551 Hose Clamp 75552 Hose Clamp 32 ► SRA 60 Parts Manual... -
Page 33: Repair Kit (Spring Leg)
REPAIR KIT (SPRING LEG) SPRING GUIDE ASSEMBLY DANGER NOTE: Non serviceable item. Never attempt to disassemble item #2 Spring Guide Assy, components held by item 11 Retaining Ring are assembled under high spring compression. Removal of the Retainer ring may cause serious injury or death when energy is released. - Page 34 Stanley Hydraulic Tools 3810 SE Naef Road Milwaukie, Oregon 97267-5698 USA (503) 659-5660 / Fax (503) 652-1780 www.stanleyhydraulics.com...
