Si01-983
Step
3. Remove the fan motor.
1
Remove the nut of the
outdoor fan.
Remove the outdoor
2
fan.
3
Pull out the 2 terminals
(red, white) from the fan
capacitor (C2R).
Pull out the terminal
4
(black) from the
terminal board X1M (2).
5
Release the fan motor
lead wire from the hook.
Removal Procedure
Procedure
Outdoor fan
D-cut
Hook
Fan capacitor
Removal of Outer Panels / Fan Motor
Nut size: M6
(R15230)
Align the
outdoor fan with the D-cut
section of the motor shaft
when reassembling.
(R7197)
Fan capacitor (C2R)
to fan motor
(red)
Terminal
board
to terminal board
X1M(1): red
Terminal board (X1M)
(R16573)
X1M
(2)
Points
10 mm
(R12236)
mark of the
to fan motor
(white)
(R16409)
to fan motor
(upper: black)
(R15260)
5
