Summary of Contents for Draytek Vigor 2910
- Page 1 Vigor 2910 Series Router Quick Start Guide Version: 1.0 Date: 2006/6/15...
- Page 2 Alternatively, fill in the registration card and mail it to the address found on the reverse side of the card. Firmware & Tools Due to the continuous evolution of DrayTek corporation, all routers will be Updates regularly upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.
-
Page 3: Regulatory Information
No. 26, Fu Shing Road, HuKou County, HsinChu Industrial Park, Hsin-Chu, Taiwan 303 Product: Vigor2910 Series Routers DrayTek Corp. declares that Vigor2910 series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 89/336/EEC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B. -
Page 4: Table Of Contents
1. Introduction... 1 1.1 LED Indicators and Connectors ... 2 1.1.1 For Vigor2910 ... 2 1.1.2 For Vigor2910G... 3 1.1.3 For Vigor2910i... 4 1.1.4 For Vigor2910V ... 5 1.1.5 For Vigor2910VG ... 6 1.1.6 For Vigor2910VGi ... 7 1.2 Package Content... 8 2. -
Page 5: Introduction
The Vigor2910 series router provides Dual-WAN interface (which is a confgiuration second Internet access to make the Internet connection more reliable. The wireless WAN) for LAN supports more secure features and the transmission speed is up to 108Mbps (SuperG ). Object-oriented firewall is flexible and allows your network be safe. In addition, throguh VoIP function, the communication fee for you and remote people can be reduced. -
Page 6: Led Indicators And Connectors
QoS Attack VPN Status ACT (Activity) Blinking Attack Blinking Printer WAN(W1-W2) Orange Green Blinking LAN (P1, P2, P3, Orange Green Blinking Printer Interface Description Printer Connecter for a USB printer. Connecter for a power adapter with 12-15VDC. ON/OFF Power Switch. LAN P4 –... -
Page 7: For Vigor2910G
QoS Attack WLAN Printer Status ACT (Activity) Blinking Attack Blinking WLAN Blinking Printer WAN(W1-W2) Orange Green Blinking Orange LAN (P1, P2, P3, Green Blinking Printer Interface Description Printer Connecter for a USB printer. Connecter for a power adapter with 12-15VDC. ON/OFF Power Switch. -
Page 8: For Vigor2910I
ISDN QoS Attack VPN Status ACT (Activity) Blinking ISDN Blinking Attack Blinking Printer WAN(W1-W2) Orange Green Blinking Orange LAN (P1, P2, P3, P4) Green Blinking Printer Interface Description Printer Connecter for a USB printer. Connecter for a power adapter with 12-15VDC. ON/OFF Power Switch. -
Page 9: For Vigor2910V
Phone FXS1 FXS2 VPN Printer Status ACT (Activity) Blinking FXS1/FXS2 Blinking Printer WAN(W1-W2) Orange Green Blinking Orange LAN (P1, P2, P3, P4) Green Blinking FXS2 Printer Interface Description Printer Connecter for a USB printer. Connecter for a power adapter with 12-15VDC. ON/OFF Power Switch. -
Page 10: For Vigor2910Vg
Phone FXS1 FXS2 Status ACT (Activity) Blinking FXS1/FXS2 Blinking WLAN Blinking Printer WAN(W1-W2) Orange Green Blinking Orange LAN (P1, P2, P3, P4) Green Blinking Printer Interface Description Printer Connecter for a USB printer. Connecter for a power adapter with 12-15VDC. ON/OFF Power Switch. -
Page 11: For Vigor2910Vgi
Phone ISDN FXS1 FXS2 WLAN Printer Status ACT (Activity) Blinking ISDN Blinking FXS1/FXS2 Blinking WLAN Blinking Printer WAN(W1-W2) Orange Green Blinking Orange LAN (P1, P2, P3, P4) Green Blinking Printer FXS2 Interface Description Connecter for a USB printer. Printer Connecter for a power adapter with 12-15VDC. Power Switch. -
Page 12: Package Content
Quick Start Guide Antenna for G models RJ-45 to RJ-45 Cable for i models The type of the power adapter depends on the country that the router will be installed: UK-type power adapte USA/Taiwan-type power adapter RJ-45 Cable (Ethernet) EU-type power adapt AU/NZ-type power adapter... -
Page 13: Installing Your Vigor Router
This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. Before starting to configure the router, you have to connect your devices correctly. Connect this device to a router/modem with an Ethernet cable. Connect one port of 4-port switch to your computer with a RJ-45 cable. - Page 14 This page is left blank.
-
Page 15: Configuring Web
The Quick Start Wizard is designed for you to easily set up your router for Internet access. You can directly access the Quick Start Wizard via Web Configurator. Make sure your PC connects to the router correctly. Notice: You may either simply set up your computer to get IP dynamically from the router or set up the IP address of the computer to be the same subnet as the default IP address of Vigor router 192.168.1.1. - Page 16 Enter the login password on the field of New Password and retype it on the field of Retype New Password. Then click Next to continue. On the next page as shown below, please select the WAN interface that you use. Choose Auto negotiation as the physical type for your router.
- Page 17 PPPoE: if you click PPPoE or PPPoA as the protocol, please manually enter the Username/Password provided by your ISP. Then click Next. PPTP: if you click PPTP, you will get the following page. Please type in all the information originally provided by your ISP. Then click Next for next step. Static IP: if you click Static IP, you will get the following page.
- Page 18 DHCP: if you click DHCP, you will get the following page. Simply click Next to continue. Now you can see the following screen. It indicates that the setup is complete. Different types of connection modes will have different summary. Click Finish and then restart the router.
-
Page 19: Wireless Lan Settings
(The default value of Frequency Domain was set by factory depends on the reselling region.) In an Infrastructure Mode of wireless network, Vigor wireless router plays a role as an Access Point (AP) connecting to lots of wireless clients or Stations (STA). All the STAs will share the same Internet connection with other wired hosts via Vigor wireless router. -
Page 20: General Settings
On the Wireless LAN group, select General Settings. The following page will be shown. Check the box Enable Wireless LAN to enable the wireless function. Select an appropriate wireless mode. The router can connect to IEEE802.11b, IEEE802.11g and Mixed SuperG stations simultaneously. Please choose this mode if (11b+11g+SuperG) your WAN clients have such features. -
Page 21: Security Settings
On the Wireless LAN group, select Security Settings. Select an appropriate encryption mode to improve the security and privacy of your wireless data packets. Disable WEP Only WEP/802.1x Only WEP or WPA/PSK Turn off the encryption mechanism. For the security of your router, please select any one of the encryption mode here. - Page 22 WEP/802.1x or WPA/802.1x WPA/PSK Only WPA/802.1x Only For WPA encryption, type in 8~63 ASCII characters or 64 Hexadecimal digits leading by 0x, for example "0123456789ABCD..." or "0x321253abcde..." on the field of Pre-Shared Key (PSK). WPA encrypts each frame transmitted from the radio using the Pre-Shared Key (PSK) which entered from this panel.
-
Page 23: Trouble Shooting
This section will guide you to solve abnormal situations if you cannot access into the Internet after installing the router and finishing the web configuration. Please follow sections below to check your basic installation status stage by stage. Checking if the hardware status is OK or not. Checking if the network connection settings on your computer are OK or not. - Page 24 The example is based on Windows XP. As to the examples for other operation systems, please refer to the similar steps or find support notes in www.draytek.com. Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties.
- Page 25 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used MacOs on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4.
-
Page 26: Pinging The Router From Your Computer
The default gateway IP address of the router is 192.168.1.1. For some reason, you might need to use “ping” command to check the link status of the router. The most important thing is that the computer will receive a reply from 192.168.1.1. If not, please check the IP address of your computer. -
Page 28: Checking If The Isp Settings Are Ok Or Not
Open WAN >> Internet Access page and then check whether the ISP settings are set correctly. Click Details Page to review the settings that you configured previously. Check if the Enable option is selected. Check if Username and Password are entered with correct values that you got from your ISP. - Page 29 Check if the Enable option for Broadband Access is selected. Check if WAN IP Network Settings is set appropriately. Check if IP Address, Subnet Mask and Gateway are set correctly (must identify with the values from your ISP) if you choose Specify an IP address. Check if the Enable option for PPTP Link is selected.
-
Page 30: Backing To Factory Default Setting If Necessary
Check if WAN IP Network Settings are set properly. If you select Specify an IP address, you have to type in the values of IP Address and Subnet Mask manually. Be sure the values that you type identify with the values from your ISP. Sometimes, a wrong connection can be improved by returning to the default settings. -
Page 31: Contacting Your Dealer
If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com.
