Sony RDR-VX511 Quick Start Manual

RDR-VX511
Follow the three steps below to connect, setup and make
recordings on your VCR-DVD recorder.
©2005 Sony Corporation
Printed in China
Before hookup
Disconnect your VCR
1
If you have been using a VCR, you do not need to disconnect all of your
equipment. Just disconnect your VCR from the other equipment and
connect this VCR-DVD recorder in its place.
Television
Cable Box /
Satellite Receiver
VCR
VCR-DVD Recorder
Select a connection
2
Select one of the following two types of basic connections according to the
type of equipment you have.
Cable Box With Video/Audio Output
– or –
Satellite Receiver
Cable Box Without Video/Audio Output
(or cable with no cable box)
– or –
Antenna (no cable TV)
Proceed to Step 1 and begin!
You have a:
Cable Box With Video / Audio Output
–or–
Satellite Receiver
Cable Box /
Satellite Receiver
to CABLE IN
OUT TO
TV
CA
ANT IN
PTICA L
to your antenna
wall jack
to OUT TO
TV
VCR-DVD Recorder
2- 650-210-11(1)
AK68-00834A
You have a:
Cable Box Without Video / Audio Output
(or cable with no cable box)
–or–
Antenna (no cable TV)
Cable Box
to RF IN
to RF OUT
to your antenna
wall jack
VCR-DVD Recorder
You will need:
(one audio/video cord is supplied)
to an
AC outlet
to VIDEO OUT/
AUDIO OUT
VID VIDEO OUT
4
S VIDEO
2 to VHF/UHF IN
IN
VHF /UHF
to LINE OUT
IN
to LINE 1 IN
DIGITA T T L AUDIO
AU
OPTIC A
3
1
You will need:
(one audio/video cord is supplied)
If you don't have a cable box, connect
this antenna cable directly to VHF/UHF
to an
IN on the VCR-DVD recorder.
AC outlet
RF
4
1
to VHF/UHF
IN
to LINE OUT
L
U
3
X2 X2
antenna
(one cable is supplied)
Optional
Television
Connecting an S video cord or a
component video cord
to LINE IN
LINE IN
to an
AC outlet
Connect all power
4
cords last!
a
b
Connecting an AV amplifi er (receiver)
X1 X3
(one antenna cable is supplied)
to DIGITAL IN
Television
to LINE IN
to VHF/UHF IN
LINE IN
IN
VHF /UHF
Connecting to an AV amplifi er (receiver) with digital cords will enable you to listen
to Dolby Digital or DTS surround effects. For further explanations, see "Connecting
2
to an
to Your AV Amplifi er (Receiver)" in the Operating Instructions.
AC outlet
to VHF/UHF
OUT
Connect all power
4
cords last!
Television
to COMPONENT
to S VIDEO IN
VIDEO IN
to COMPONENT
a
VIDEO OUT
VHF/UHF
NE OUT
UT
DEO b
B
DIGITA T T L AUD R
OPTIC
to S VIDEO
VCR-DVD Recorder
OUT
Connect an S video cord (not supplied). You will enjoy high quality images.
-or-
Connect the COMPONENT VIDEO OUT jacks using a component video cord
(not supplied) or three video cords (not supplied) of the same kind and length.
You will enjoy accurate color reproduction and high quality images.
If your TV accepts progressive 480p format signals, you must use this
connection and then set "Progressive" of "Video" to "On" in the Setup menu. For
further explanations, see "Video Settings (Video)" in the Operating instructions.
AUDIO OUT
L/R
to DIGITAL AUDIO OUT
VCR-DVD Recorder
(COAXIAL or OPTICAL)
NE 1 IN
ONEN
DIG DIG
AV Amplifi er
c
(OPTICAL)
b
a
L
to LINE IN
to DIGITAL IN
(AUDIO)
(COAXIAL)
Connect one of the following
cords (not supplied)
audio cords a
-or-
coaxial digital cord b
-or-
optical digital cord c
