2001 OWNER'S MANUAL
SUPPLEMENT FOR THE
CARRYALL 2 XRT VEHICLE
SUPPLEMENT TO THE 2001 CARRYALL
GASOLINE VEHICLE OWNER'S MANUAL
The following pages are supplemental to the 2001 Carryall Utility Gasoline Vehicle Owner's Manual. This
supplement documents only those sections of the manual requiring changes or additions describing features
and procedures specific to the 2001 Carryall 2 XRT model vehicle. All other information in the Owner's
Manual pertaining to the Carryall 2 vehicle applies to the Carryall 2 XRT model as well. The placement of
sections in this supplement corresponds to the placement of sections in the manual. If you do not have a
2001 Carryall Utility Gasoline Vehicle Owner's Manual, you may obtain one from your Club Car dealer or
distributor.
This supplement includes installation instructions for the following:
• Rear fenders
• Wheel and tire assemblies
Supplement Part No. 102189813
Print Code 0800B00000

Advertisement

Table of Contents
loading

Related Manuals for Club Car CARRYALL 2 XRT

Summary of Contents for Club Car CARRYALL 2 XRT

  • Page 1 2001 Carryall 2 XRT model vehicle. All other information in the Owner’s Manual pertaining to the Carryall 2 vehicle applies to the Carryall 2 XRT model as well. The placement of sections in this supplement corresponds to the placement of sections in the manual. If you do not have a 2001 Carryall Utility Gasoline Vehicle Owner’s Manual, you may obtain one from your Club Car dealer or...

  • Page 2: Table Of Contents

    Club Car, Inc. Club Car is not liable for errors in this supplement or for incidental or consequential damages that result from the use of the material in this supplement.

  • Page 3: Safety Details

    VEHICLE. FAILURE TO HEED THE WARNINGS OR FOLLOW THE INSTRUCTIONS IN THIS SUPPLEMENT AND IN THE MANUAL COULD RESULT IN PROPERTY DAMAGE, SEVERE PERSONAL INJURY, OR DEATH. See the 2001 Carryall Utility Gasoline Vehicle Owner’s Manual for complete safety details. 2001 Carryall 2 XRT Owner’s Manual Supplement...

  • Page 4: Vehicle Feature Identification

    When driving on uneven terrain or down steep hills, • and warnings on dash. Maximum trailer hitch tongue weight - 150 lbs. reduce speed and load. • CCI 102006701 2001 Carryall 2 XRT Owner’s Manual Supplement...
  • Page 5 Excessive speed. Do not contact positive (+) battery post or cable to frame. Can cause severe injury or death. Disconnect negative battery lead first. Do not tamper with engine governor adjustment. CCI 101915201 2001 Carryall 2 XRT Owner’s Manual Supplement...

  • Page 6: Pre-Operation Checklist

    Center and secure cargo as far forward as possible in the cargo bed. Do not overload the vehicle. The total capacity of the vehicle is 900 lb. (409 kg) for the Carryall 2 XRT. This includes all passengers, the load in the cargo bed, and the sum of the gross weight and tongue weight of a trailer.

  • Page 7: Electric Winch Accessory

    Make sure a winch warning decal is affixed to the vehicle on the seat support panel next to the receptacle for the remote operation switch. See Vehicle Feature Identification on pages 4 and 5. The winch kit available from Club Car includes a remote operation switch which enables the operator to move away from the vehicle and cable.
  • Page 8 Seat Height: At seat bottom. 28.0 in. (71 cm) NOTE: CLUB CAR, INC. RESERVES THE RIGHT TO CHANGE SPECIFICATIONS AND DESIGN OF EITHER GASOLINE OR ELECTRIC VEHICLES AT ANY TIME WITHOUT NOTICE AND WITHOUT OBLIGATION TO MAKE THESE CHANGES ON UNITS PREVIOUSLY SOLD.

  • Page 9: Rear Fender Installation

    2. Open the cargo bed and engage the prop rod. WARNING • USE CAUTION WHEN WORKING UNDER BED. BE SURE PROP ROD IS SECURE. OTHERWISE THE BED COULD FALL, RESULTING IN SEVERE PERSONAL INJURY OR DEATH. 2001 Carryall 2 XRT Owner’s Manual Supplement...
  • Page 10 9. Lower cargo bed. UPPER SIDE PANEL FENDER RIB Before drilling holes, move fender as far forward as possible. Do not allow any gap between fender and side panel. Figure 2 Drill Additional Mounting Holes 2001 Carryall 2 XRT Owner’s Manual Supplement...

  • Page 11: Wheel And Tire Installation

    AND TIRE ASSEMBLIES. Unlike other Club Car Carryall vehicles, the Carryall 2 XRT’s front and rear wheels are NOT interchangeable. The rear wheels have a different offset than do the front wheels; The rear wheels must be installed with the deeper offset facing out.
