Devolo dsl+ 1100 duo Specifications

+
dsl 1100 duo
ADSL2+ Modem & Router

Technical details

LAN standards
DSL standards
Data transfer rate
Firewall
Ports
WAN connection
LAN connection
LEDs
Power supply
Weight
Dimensions
Environment
devolo AG
Sonnenweg 11 • 52070 Aachen • Tel: +49 (0)241-182 79 0 • Fax: +49 (0)241-182 79 99 • www.devolo.de • info@devolo.de
Stand: 20.05.08
Ethernet specification IEEE 802.3
Fast-Ethernet specification IEE 802.3u
Full-duplex specification IEEE 802.3x
USB 1.1 (CDC / RNDIS)
ADSL over ISDN (Annex B)
T-Com Spezifikation 1TR112 (U-R2)
ITU G.992.1 (G.dmt)
ITU G.992.3 (ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
or: ADSL over POTS (Annex A)
ANSI T1.413 Issue2
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.992.3 (ADSL2)
ITU G.992.3 Annex L (RE-ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
ITU G.997.1 (G.ploam)
Download: up to 25 Mbps, Upload: up to 1 Mbps
Stateful Packet Inspection
Stealth Mode
Dos-Blocking
NAT
IP-Masquerading
1 Ethernet-LAN with Auto MDI/MDI-X
1 USB-LAN
1 ADSL-WAN
1 Connector type: RJ11
1 Connector type: RJ45 (Ethernet)
1 Connector type: USB-B (USB 1.1, connection with USB 2.0 possible)
Simultaneous usable
Connect status
Power
LEDs: DSL status
Status LED for Ethernet connection
Status LED for USB connection
AC adapter 9 V AC / 500 mA, EU
360 g
202 x 152 x 38 mm (width x depth x height)
0–40° C, 10-90% humidity (non-condensing)
