ITC­100SL SLAVE Unit
INPUT
MIC / HEADSET SOCKET
TALLY OUT SOCKET
TALLY LED
POWER LED
OPERATING RANGE
OPERATING TEMP. RANGE
DIMENSION
WEIGHT
Specification
5 Pin XLR Connector
3.5mm Stereo Jack Socket for combination
Headphone / Microphone
Headset Impedance 8~600 ohms 100mW(min)
Microphone Level ­67dB
2.5mm Stereo Jack Socket, for Motorola Mobile
Phone type headset / microphone
3.5mm Jack Socket to connect to TD­1 Tally
Indicator
Bi­Color LED – RED indicates LIVE / AMBER
Indicates CUED
Illuminates to indicate that power is being
received
Up to 200m between Base Station and Slave
5 ~ 45°C
114mm x 97mm x 35mm
348g
