PROGRAMMER'S REFERENCE MANUAL
Label layout definition commands
Defining a graphics field
A graphics field is linked to a graphics file. The graphics file may be downloaded after the
graphics field has been defined.
Syntax !F G <u> <b> <p> <a> <h> <w> <"name">
The parameters have the following meaning:
<u> Defines the direction of printing as the "up" direction of the printed character.
One upper-case character (N, E, S, or W).
<b>
The baseline of the field in
<p>
The position, in
<a> The alignment relative to the position. One upper-case character.
L = left end of the field aligned at p.
R = right end of the field aligned at p.
C = the field is centered around p.
<h> The height expansion of the original graphics file, 1 – 16.
<w> The width expansion of the original graphics file, 1 – 16.
<name> The name of the graphics file to be printed. The name must be enclosed in double
"
quotes (
For information on how to download graphics files, see section 'File System'.
Examples:
!F G N 300 500 C 1 1 "Printer"
This command creates a field linked to the graphics file named PRINTER.G
File name containing variable information.
!F G N 300 500 C 1 1 "FILE%1V"
If variable 1 is '10', then this command creates a field linked to the
graphics file named FILE10.G.
1
/ mm.
10
1
/ mm
10
) and can also contain variables. See examples below.
.
