Page 1
Setting Up Your MX452 In Default Mode (Tel Priority Mode) Without An Answering Machine DSL/Cable Modem Connection Next...
Page 2
Fax Easy Setup Click Next to step through this image-friendly version of Fax Easy Setup. If you started Fax Easy Setup, on the fax machine’s operation panel, and prefer to go through this image-friendly version… Step 1 Step 2 Press the FAX button at any screen Click Next to proceed...
Page 4
Fax to Phone Line Connection Before Hand Set (Existing Phone Cord) (Existing Phone Cord) (Phone) DSL/Cable Modem Wall jack After Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 5
Fax to Phone Line Connection • Plug the provided phone cord into the DSL/Cable Modem. Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 6
Fax to Phone Line Connection • Plug the provided phone cord into the “LINE” jack on the rear of the multifunction. Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 7
Fax to Phone Line Connection • Remove the white plug from the upper jack labeled “EXT.” Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 8
Fax to Phone Line Connection • Plug the second phone cord into the “EXT.” jack located on the rear of the multifunction. Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 9
Fax to Phone Line Connection • Plug the existing phone cord into the phone Hand Set (Phone) (Phone Cord included with Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
Page 11
Step 1 Step 2 Turn on the MX452 by pressing the Press the FAX button. ON button, if it is not powered on already. Previous Next...
Page 12
Step 3 Step 4 The fax standby screen will appear. Press the Menu button. Previous Next...
Page 13
Step 5 Step 6 The FAX menu screen will appear. Use the LEFT or RIGHT button to select “Receive mode set”. Previous Next...
Page 14
Step 7 Step 8 Press the OK button. Use the LEFT or RIGHT button to select “TEL priority mode”. Previous Next...
Page 15
Step 9 Step 10 Press the OK button. Use the LEFT or RIGHT button to select “Yes” at Make adv. settings screen. Previous Next...
Page 16
Step 11 Step 12 Press the OK button. Use the LEFT or RIGHT button to select “User-friendly RX”. Previous Next...
Page 17
Step 13 Step 14 Press the OK button. Use the LEFT or RIGHT button to select “ON”. Previous Next...
Page 18
Step 15 Step 16 Press the OK button. You will return to the “Fax standby screen” and the receive mode will appear on the screen. Previous Next...
Page 19
Receiving A Fax To receive a fax: • Pick up the handset on the phone connected to the MX452. • Listen for fax tones. • When the tones stop hang up the handset. • The MX452 will receive the fax document.
