Lorex LEV1522 SERIES Quick Start Manuals

Contents
• Weatherproof HD dome camera*
• Mounting kit*
• Allen key (x1)*
• 60ft BNC / power extension cable*
• Power adapter**
*Model LEV1522PK4 is a 4-pack that includes four of the listed items.
** A multi-camera power adapter that provides power to multiple cameras or individual power
adapters may be provided, depending on product configuration.
WARNING - A REGULATED APPROVED 12V DC power supply is REQUIRED
for use with this camera. Use of a non-regulated, non-conforming power
supply can damage this product and voids the warranty.
Warning/Caution
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle with care.
• Do not disassemble the camera.
• Do not point the camera directly towards the sun or a source of intense
light.
• Use only the supplied regulated power supply. Use of a non-regulated, non-
conforming power supply can damage this product and voids the warranty.
• Periodic cleaning may be required. Use a damp cloth only. Do not use
harsh cleaners or aerosol cleaners.
• The supplied extension cable is rated for surface mounting only.
• Cables for in-wall / floor-to-floor installations are sold separately.
Installation Tips
• Point the camera where there is the least amount of obstructions
(i.e. tree branches).
• Install the camera in a location that is difficult for vandals to reach.
• Secure cabling so that it is not exposed or easily cut.
• Camera rated for outdoor use. Installation in a sheltered location
recommended.
Dimensions
98mm / 3.9"
Resources
Visit us online for up-to-date software and complete
1
2
Search the model number of your product
3
Click on your product in the search results
4
THE FOLLOWING RESOURCES ARE ALWAYS AT
Product Information
User Manuals
94mm / 3.7"
Quick Start Guides
Copyright © 2015 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OE
Need Help?
instruction manuals
Go to www.lorextechnology.com
Click on the Downloads tab
YOUR FINGERTIPS
Specification Sheets
Software Upgrades
Firmware Upgrades
HD WEATHERPROOF
IR DOME CAMERA
Quick Start Guide
English Version 2.0
LEV1522 SERIES
LEV1522_SERIES_TRIFOLDQSG_EN_R2
