Model No. NTIVEL70417.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Keep this manual for future
reference.
USER'S MANUAL
www.iconeurope.com
Advertisement
Table of Contents
Related Manuals for NordicTrack E480
Summary of Contents for NordicTrack E480
- Page 1 Model No. NTIVEL70417.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 1D, The Gateway Fryers Way, Silkwood Park OSSETT...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT..............2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
Thank you for selecting the new NORDICTRACK E480 us assist you, note the product model number and serial elliptical. The E480 elliptical provides a selection of fea- number before contacting us. The model number and the tures designed to make your workouts at home more location of the serial number decal are shown on the front effective and enjoyable. -
Page 5: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in each drawing is the key num- ber of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 6: Assembly
ASSEMBLY • Assembly requires two persons. of the part, from the PART LIST near the end of this manual. The number following the parentheses is • Place all parts in a cleared area and remove the the quantity needed for assembly. packing materials. - Page 7 STEP 2 I. Sleeve the Mast cover (58) onto the Handlebar post (4); II. Connect the Extension wire (50) with Sensor wire (57) properly at first, and then lock the Handlebar post (4) onto the Main frame (1) with the Allen bolt (53), Spring washer (18) and Flat washer (12) as shown; III.
- Page 8 STEP 3 I. Insert the Long shaft (56) to the Handlebar post (4), attach the Swing tube (7L/R) on the Long shaft (56) with Allen bolt (26), Spring washer (25), Flat washer (59),D-shape washer (24) and Wave washer (21). Not to tighten till now.
- Page 9 STEP 4 Lock the Handlebar (6L/R) onto the Swing tube (7L/R) tightly with Carriage bolt (44), Arc washer (43) and Nylon nut (13). Thread the Hand Pulse wire (55) into the hole of Handlebar post (4) and then takes it out from the computer bracket on top as shown.
- Page 10 STEP 6 First, insert the Extension wire (50), Hand pulse wire (55) connect with the wire of Console (47) properly, then fix the Console (47) on the bracket of the Handlebar post (4) with Phillips Screw (52) and Flat washer (77); Fix the Tablet Holder support (15) on the console (47) with Phillips screw (61) Lock the Protective guard (51a/b) on the Handlebar post (4) with the Tapping Screw (35) as shown.
-
Page 11: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL WHEN YOU ARE FINISHED EXERCISING To mount the elliptical exerciser, hold the upper body arms If the pedals do not move for several minutes and the but- and step onto the pedal that is in the lowest position. Then, off and the tons are not pressed, the console will turn step onto the other pedal. -
Page 12: Console Features
CONSOLE FEATURES Contacts FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals with the touch of a button. - Page 13 HOW TO USE THE MANUAL MODE Resistance—This display will show the resistance level of the pedals for a few seconds each time the 1. Begin pedaling or press any button on the console resistance level changes. to turn on the console. RPM—This display will show your pedaling speed in When you turn on the console, the display will turn on.
- Page 14 If there are sheets of Contacts plastic on the metal At the end of each segment of the workout, a series of contacts on the hand- tones will sound. If a different resistance level and/or grip heart rate monitor, target speed is programmed for the next segment, the remove the plastic.
- Page 15 Make sure that the BLUETOOTH option is enabled on your smart device. Next, press the play button on your personal audio player. Adjust the volume level using the volume increase and Then, open the iFit app and follow the instructions to decrease buttons on the console or the volume control on set up an iFit account and customize settings.
-
Page 16: Maintenance And Troubleshooting
MAINTENENCE AND TROUBLESHOOTING MAINTENANCE CONSOLE TROUBLESHOOTING Regular maintenance is important for optimal performance If the console does not display your heart rate when you and to reduce wear. Inspect and properly tighten all parts hold the handgrip heart rate monitor, or if the displayed each time the elliptical is used. -
Page 17: Part List
PART LIST Model No. NTIVEL70417.0 Key No. Qty. Description Key No. Qty. Description Main frame Extension wire Front bottom tube 51a/b Protective guard Rear bottom tube Phillips Screw M4.2x12 Handlebar post Allen bolt M8x16 Fixed handlebar Adapter 6L/R Handlebar Hand pulse wire 7L/R Swing tube Long shaft... - Page 18 EXPLODED DRAWING...
-
Page 19: Exploded Drawing
EXPLODED DRAWING... -
Page 20: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
