Instruction Manual
Self-Contained Cuber
Model
IM-200BAB
hoshizakiamerica.com
Issued: 1-23-2017

Advertisement

loading

Related Manuals for Hoshizaki IM-200BAB

Summary of Contents for Hoshizaki IM-200BAB

  • Page 1 Instruction Manual Self-Contained Cuber Model IM-200BAB hoshizakiamerica.com Issued: 1-23-2017...
  • Page 2 WARNING...
  • Page 3 IMPORTANT CONTENTS PAGE...
  • Page 4 Important Safety Information WARNING Indicates a hazardous situation which could result in death or serious injury. NOTICE Indicates a situation which could result in damage to the appliance or property. IMPORTANT Indicates important information about the installation, use, and care of the appliance. WARNING precautions including the following: •...
  • Page 5 WARNING, continued NOTICE...
  • Page 6 A. Electrical and Refrigerant Data Model Number IM-200BAB...
  • Page 7 B. Dimensions/Connections...
  • Page 8 II. Installation and Operating Instructions WARNING • CHOKING HAZARD A. Location NOTICE Left Side and Top Right Side Rear...
  • Page 9 B. Checks Before Installation NOTICE C. How to Remove Panels See Fig. 1...
  • Page 10 Fig. 1...
  • Page 11 D. Setup NOTICE Fig. 2 Fig. 3...
  • Page 12 E. Electrical Connection WARNING • • THE APPLIANCE MUST BE GROUNDED:...
  • Page 13 F. Water Supply and Drain Connections - See Fig. 4 WARNING NOTICE...
  • Page 14 1. Icemaker Icemaker / Ice Icemaker Water Minimum Icemaker Minimum Icemaker Storage Bin Supply Inlet Water Supply Line Size Drain Line Size Drain Outlet 2-inch (5-cm) air gap Floor Drain Fig. 4...

  • Page 15: Choking Hazard

    G. Final Checklist WARNING CHOKING HAZARD Left Side and Top Right Side Rear...
  • Page 16 H. Startup WARNING NOTICE WARNING! To reduce the risk of electric shock, do not touch the control switch or plug with damp hands.
  • Page 17 I. Display 1. Normal Operation 2. Error Code...
  • Page 18 III. Maintenance WARNING • CHOKING HAZARD: A. Maintenance Schedule Maintenance Schedule Frequency Area Task...
  • Page 19 B. Cleaning and Sanitizing Instructions WARNING NOTICE 1. Cleaning Procedure Fig. 5...
  • Page 21 2. Sanitizing Procedure - Following Cleaning Procedure...
  • Page 22 IV. Preparing the Appliance for Periods of Non-Use NOTICE 1. Remove the water from the icemaker water supply line:...
  • Page 23 2. Drain the water tank: Fig. 6 V. Disposal IMPORTANT...
  • Page 24 618 Hwy. 74 South, Peachtree City, GA 30269 USA (P) 770.487.2331 (F) 770.487.3360 hoshizakiamerica.com L1M076101...
