- Page 1 OPERATING INSTRUCTIONS CDMP364 120/45 SECONDS ANTI-SHOCK PORTABLE MP3/CD PLAYER WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- Page 2 OPERATING INSTRUCTIONS CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This compact disc player is classified as a CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT CLASS 1 LASER product.
-
Page 3: Using On Dry Cell Batteries
USING ON DRY CELL BATTERIES Open the battery compartment and insert two LR6 (size AA) alkaline batteries with the + and - marks correctly aligned. (Batteries not included.) Battery replacement The battery indicator in the display ^^^^ according to the remaining power of the batteries. -
Page 4: Using On Rechargeable Batteries
USING ON RECHARGEABLE BATTERIES Be sure to use size AA Ni-Cd 1.2v rechargeable batteries. (Not included.) which are commercially available Be sure to read the instructions of the purchased rechargeable batteries before use. Before charging the batteries, close the disc compartment, you cannot charge the batteries while it is opened Ni-Cd 1. -
Page 5: Before Playback
BEFORE PLAYBACK HOLD switch Release the HOLD switch to OFF position before playback.When not using the unit, set the HOLD switch to the ON position, Accidentally pressed button will not function, If buttons are pressed when the HOLD switch is set to the ON position. "HOLD" light on the display. - Page 6 Inserting a disc 1. Push the OPEN switch to open the disc compartment 2. Place a disc in the center with the label side facing up. 3.Close the disc compartment. To remove the disc Pick up the disc, holding its edge, while pressing the pivot gently.
-
Page 7: Repeat All
PLAYBACK Connect the supplied headphone to the PHONE jack. 1.Release HOLD to OFF position. 2.Place a disc with label side facing up. 3.Press PLAY/PAUSE Playback starts from the first track. BASIC OPERATION To stop: press STOP To pause: press PLAY/PAUSE To resume, press it again. - Page 8 6.Press play key, start playing. 7.To clear programing. press the "STOP" key, then press "PROG" key to program state, then press "STOP" key ,or open the door or power off. Support Disc & File: CD-RW, CD-R, CD Disc playback Multi-session Disc playback MPEG 1(ISO/IEC 11172-3) Layer 1/2/3 All MPEG Bit Rates except 8kpbs and free format...
-
Page 9: Connection To An External Unit
CONNECTION TO AN EXTERNAL UNIT Use a commercially available connection cord which has a 3.5mm stereo plug at one and two phono plugs at the other end. connect the stereo plug to the LINE OUT jack of the unit and connect the phono plugs to the analog input (AUX) terminals of the external unit. -
Page 10: Specifications
SPECIFICATIONS Tracking system 1-beam laser Laser pickup Semiconductor laser D/A conversion 8-times over sampling digital filter +1- bit DAC Frequency response 20-20,000Hz Outputs PHONES: stereo jack (3.5mm) [20mW+20mW,32 ohms at 1 KHz] Input DC 4.5V for external power from AC adaptor: Not included. - Page 11 SUBJECT TO MODIFICATION WITHOUT NOTICE!
