Crown CTs 1200 Specifications

CTs Series
2-channel
B uilding on the foundation of the Crown
Com-Tech ® Series, the CTs Series offers new
fl exibility and value for installed sound appli-
cations. The Com-Tech Series was the fi rst to offer
independent selection of high- and low-impedance
operation for a specifi c channel, and CTs Series
amplifi ers continue that tradition, with power
levels and features carefully chosen to perfectly
integrate into fi xed install design requirements.
For added fl exibility, the CTs Series includes both
dual-channel and multi-channel models.
All models in the CTs Series feature Crown's new
Switching Power Supply for lighter weight, and
all models are also compatible with Harman Pro
System Architect as well as the IQ System
Two-channel models accept PIP2™ modules, and
also feature selectable high-pass fi lters and input
sensitivity for each channel.
In a profession where unplanned service calls
quickly wipe out profi ts, the CTs Series amplifi ers
are designed to be the most reliable amplifi ers you
can install.
For more details about the Crown CTs Series,
contact Crown Customer Service at 800-342-6939
or 574-294-8200. Also, visit the Crown Audio
website at www.crownaudio.com.
C T s S E R I E S
®
Features
• Switching Power Supply for reduced weight
• High power-density, with all two-channel models in
a 2U chassis
• Direct constant-voltage (70V/100V/140V/200V) or
low-impedance (2/4/8 ohm) operation
• Input sensitivity independently selectable for each
channel
• TLC protection circuitry protects the amplifi er from
long-term excessive heat by subtly and dynamically
reducing the gain only when necessary
®
.
• PIP2 (Programmable Input Processor) connector
accepts accessory modules that tailor the amplifi er
to suit specifi c applications
• Removable terminal block input connectors, with "Y"
Input Switch in the standard PIP2-BBY module
• Switchable high-pass fi lter for each channel provides
low-frequency roll off to eliminate step down trans-
former saturation when used in distributed systems
CTs 2000
2-ohm Dual (per ch.)
4-ohm Dual (per ch.)
8-ohm Dual (per ch.)
16-ohm Dual (per ch.)
70V Dual (per ch.)
100V Dual (per ch.)
4-ohm Bridge
8-ohm Bridge
16-ohm Bridge
140V Bridge
200V Bridge
20 Hz–20 kHz Power refers to maximum average
power in watts from 20 Hz to 20 kHz with 0.35% THD.
CTs 3000
2-ohm Dual (per ch.)
4-ohm Dual (per ch.)
8-ohm Dual (per ch.)
16-ohm Dual (per ch.)
70V Dual (per ch.)
100V Dual (per ch.)
4-ohm Bridge
8-ohm Bridge
16-ohm Bridge
140V Bridge
200V Bridge
20 Hz–20 kHz Power refers to maximum average
power in watts from 20 Hz to 20 kHz with 0.35% THD.
• Comprehensive array of indicators including Power,
Data and Bridge, along with Ready, Signal, Clip,
Thermal and Fault for each channel, provide accurate
diagnostics
• Blue Power Indicator fl ashes if the AC mains is
under/over voltage
• Advanced protection circuitry guards against: shorted
outputs, DC, mismatched loads, general overheating,
under/over voltage, high-frequency overloads and
internal faults
• JTs circuitry (CTs 600/1200) quickly protects output
transistors from unsafe operating conditions without
shutting the channel down
• Legendary Crown AB+B (Multi-Mode
topology in the CTs 600/1200 and Class I (BCA
output topology in the CTs 2000/3000 offer the best
in amplifi er reliability
• Continuously variable fans optimize cooling effi ciency
• Three Year, No-Fault, Fully Transferable
Warranty completely protects your investment and
guarantees its specifi cations
20 Hz–20 kHz Specifi cations
Power
Minimum Guaranteed Power: See power charts
1000W
at left.
1000W
Frequency Response (at 1 watt, 20 Hz - 20 kHz):
1000W
±0.25 dB.
625W
1000W
Signal to Noise Ratio below rated power (20 Hz
1000W
to 20 kHz): 105 dB A-weighted.
2000W
Total Harmonic Distortion (THD) at full rated
2000W
power, from 20 Hz to 20 kHz: CTs 600/1200:
2000W
< 0.1%. CTs 2000/3000 < 0.35%.
2000W
Damping Factor: 10 Hz to 100 Hz: > 3000.
2000W
Crosstalk (below rated power, 20 Hz to 1 kHz):
> 80 dB.
Common Mode Rejection (CMR) (20 Hz to 1
kHz): 50 dB.
DC Output Offset: < ±2 mV.
20 Hz–20 kHz
Power
Input Impedance (nominal): 10 kilohms balanced,
1500W
5 kilohms unbalanced.
1500W
Maximum Input Level: +20 dBu before input com-
1250W
pression, +32 dBu absolute maximum.
625W
Load Impedance: (Note: Safe with all types of
1500W
loads)
1500W
3000W
CTs 600/1200
3000W
Stereo: 2/4/8/16 ohms, 70V, 100V
2500W
Bridge Mono: 4/8/16 ohms, 140V.
3000W
CTs 2000/3000
3000W
Stereo: 2/4/8/16 ohms, 70V, 100V
Bridge Mono: 4/8/16 ohms, 140V, 200V.
®
) output
®
)
