- Page 1 200L BELT DRIVEN AIR COMPRESSOR MODEL NO: AIRMASTER 14/200 PART NO: 2245309 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0721...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this 200L Belt Driven Air Compressor. Read this manual fully before use and follow the instructions carefully. In doing so you will ensure the safety of yourself and those around you, and you can look forward to your purchase giving you long and satisfactory service. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Before using your compressor it is in your own interest to read and pay attention to the following safety precautions. 1. Compressed air is dangerous. DO NOT point a jet of air at persons or animals and do not discharge compressed air against the skin. -
Page 4: Safety Symbols
SAFETY SYMBOLS Read this instruction booklet carefully before positioning, operating or adjusting the compressor. Risk of electric shock. The compressor must be disconnected from the mains supply before removing any covers. Do not use in a damp environment. Risk of accidental start-up. The compressor could start automatically in the event of a power cut and subsequent reset. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket, or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below. -
Page 6: Before Use
BEFORE USE CAUTION: TO PREVENT INJURY, GET ASSISTANCE WHEN LIFTING OR MOVING THIS COMPRESSOR. Before connecting your compressor to the power supply, check the following:- • Set the ON/OFF switch to the OFF position (pushed down). • Make sure that the compressor is on level ground. -
Page 7: Operation
OPERATION If the compressor has not been used for more then 24 hours, open the drain valve (on the bottom of the reservoir) and drain any condensate which has collected. See page 10. MOVING THE AIR COMPRESSOR • Stop the compressor and disconnect it from the power supply before you move it. -
Page 8: Turning The Compressor On
TURNING THE COMPRESSOR ON 1. Plug the compressor into the power supply. 2. Lift the On/Off button. • The compressor will operate until the reservoir is fully pressurised. It will then shut down. • The compressor will start up again when the pressure in the reservoir decreases. -
Page 9: Removing Tools From The Air Hose
REMOVING TOOLS FROM THE AIR HOSE 1. Push down on the On/Off button to stop the compressor. 2. Turn the outlet valve handle to the off position. 3. Operate the tool to depressurise the air hose. 4. Disconnect the tool from the hose. TURNING THE COMPRESSOR OFF 1. -
Page 10: Draining The Reservoir
DRAINING THE RESERVOIR CAUTION: YOU MUST DRAIN THE RESERVOIR AFTER EACH DAYS USE AND BEFORE YOU PUT YOUR COMPRESSOR INTO STORAGE. 1. Turn the compressor off and disconnect from the power supply. 2. Put a container below the drain valve to collect the condensate. 3. -
Page 11: Maintenance
MAINTENANCE WARNING: MAKE SURE THAT THE COMPRESSOR IS DISCONNECTED FROM THE ELECTRICAL SUPPLY BEFORE CARRYING OUT ANY MAINTENANCE DRAIN THE RESERVOIR After use, always open the drain valve to make sure that any condensate is drained off. CHECK THE OIL Ensure the oil level is between the min and max marks on the dipstick. - Page 12 REPLACING THE OIL After the first 100 hours use, replace the oil using SAE30 compressor oil. Then replace the oil after every 500 hours of operation or every 6 months. To empty the oil from the machine, remove the oil drain plug from the crankcase.
-
Page 13: Replacing The Drive Belt
REPLACING THE DRIVE BELT WARNING: MAKE SURE THAT THE COMPRESSOR IS DISCONNECTED FROM THE ELECTRICAL SUPPLY BEFORE REPLACING THE DRIVE BELT. 1. Rotate the clips on the front of the safety cage. 2. Remove the front of the cage and take out the worn or broken drive belt. -
Page 14: Specifications
SPECIFICATIONS MODEL AIRMASTER 14/200 Part Number 2245309 Motor Power 3 hp Voltage 230 VAC (50Hz) Air Displacement 394 L/min (14 cfm) Max Pressure 10 Bar (145 psi) Receiver Capacity 200 L Ingress Protection IP20 Fuse Rating 13 A Duty cycle... -
Page 15: Troubleshooting
TROUBLESHOOTING CAUTION: DO NOT TRY TO REPAIR OR ADJUSTMENT IF YOU ARE UNCERTAIN. IF YOU HAVE ANY QUERIES, CONTACT YOUR MACHINE MART DEALER. PROBLEM PROBABLE CAUSE REMEDY The compressor Bad electrical 1. Check electrical has stopped connections. connections. and does not 2. -
Page 16: Component Parts
COMPONENT PARTS Parts & Service: 0871 410 1270 / e-mail: parts@machinemart.co.uk or customerservice@machinemart.co.uk... -
Page 17: Component Parts List
COMPONENT PARTS LIST NO DESCRIPTION NO DESCRIPTION POWER CABLE CRANKCASE MOTOR CYLINDER BODY BELT GUARD CYLINDER HEAD DELIVERY PIPE CRANKSHAFT PUMP ASSEMBLY COMPLETE LOWER COVER RUBBER FEET (X4) VALVE HOLDER ASSEMBLY RILSAN TUBE CONROD DRIVE PULLEY INTAKE FILTER ASSEMBLY DRIVE BELT AIR COOLER END COVER BEARING HOUSING... -
Page 18: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 0871 410 1270 / e-mail: parts@machinemart.co.uk or customerservice@machinemart.co.uk... - Page 19 DECLARATION OF CONFORMITY Parts & Service: 0871 410 1270 / e-mail: parts@machinemart.co.uk or customerservice@machinemart.co.uk...
