Clarion Ungo ProSecurity RS10 Owner's Manual

Remote engine start with keyless entry
Hide thumbs Also See for Ungo ProSecurity RS10:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
Model RS10
Owner's Guide

Advertisement

Table of Contents
loading

Related Manuals for Clarion Ungo ProSecurity RS10

Summary of Contents for Clarion Ungo ProSecurity RS10

  • Page 1 Model RS10 Owner's Guide...
  • Page 2 Warranty shall be limited to the repair or replacement of the product, at the sole discre- tion of Clarion. If it becomes necessary to send the product or any defective part to Clarion, the product must be shipped in its original carton or equivalent carton, fully insured, with shipping charges prepaid.
  • Page 3 ALSO HAVE THE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Should you have any difficulties with the performance of this product during warranty, please call: 1-800-GO-CLARION or visit your local Ungo Pro Security dealer. You may also contact the National Service Manager at the following address below for additional service help you may need.

  • Page 4: Table Of Contents

    Table of Contents limited lifetime consumer warranty ....... . i System Maintenance .

  • Page 5: System Maintenance

    By carefully reading this owner's guide prior to using your system, you will maximize the use of this sys- tem and its features. Additional or replacement copies of this guide can be printed by accessing the Clarion internet website at www.clarion.com. System Maintenance The system requires no specific maintenance.

  • Page 6: Fcc/Id Notice

    FCC/ID Notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interfer- ence received, including interference that may cause undesirable operation.

  • Page 7: Transmitter Functions

    Transmitter Functions The receiver uses a computer-based learn routine to learn the transmitter buttons. This makes it possible to assign any specific transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with the Standard Configuration, but may also be customized by an authorized dealer.

  • Page 8: Using Your System

    Buttons When simultaneously pressed these buttons control the timer mode. Buttons When simultaneously pressed these buttons control the turbo/short run mode. Buttons When simultaneously pressed these buttons control the rear win- dow defogger during remote engine starting. Using Your System Warning! Safety First The following safety warnings must be observed at all times: ■...
  • Page 9 start system must be disabled using the installed toggle switch. It is the user's sole responsibility to properly handle and keep out of reach from children all remote control trans- mitters to assure that the system does not unintentionally remote engine start the vehicle. THE USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.

  • Page 10: Locking

    performing the Neutral Safety Shutdown Circuit test, the remote engine start unit has not been properly installed. The remote engine start module must be removed or the installer must properly reinstall the remote engine start system so that the vehicle does not start in gear. All installations must be performed by an authorized Ungo dealer.

  • Page 11: Remote Engine Start

    Ignition Controlled Door Locks If power door locks have been connected to your system, the vehicle's door will lock three ignition has been turned on and unlock when the ignition is turned off. NOTE: If the ignition is turned on while the vehicle is remote engine started the doors will not lock until the remote engine start shuts off.
  • Page 12 operation. Once the vehicle has started, it will run for the pre-program- med period of time (12, 24, or 60 minutes) or until a shut- down input is triggered. This can be set to minute increments by your installer. When you are ready to drive the vehicle: Insert the ignition key and turn it to the ON (not the START) position.

  • Page 13: Timer Mode

    Short-Run/Turbo Short run turbo mode keeps the engine running after arriving at you destination for a programmable period of 1, 3, 5 or 10 min- utes. This allows the system’s timer to conveniently cool down the turbo after you have left the vehicle. To activate: Park the vehicle and set parking brake.

  • Page 14: Rear Defogger

    The vehicle will confirm with 4 parking light flashes. A 1-second delay will start. The system will start the car and will run for the specified duration, unless shut down by the remote engine start button . If shut down with the remote engine start button the system will remain in timer mode.

  • Page 15: Valet Take-Over

    To turn the rear defogger output ON: Simultaneously press & release the on the remote control. The lights will flash 3 times. The rear defogger output will once again activate when the vehicle is remote engine started. N N O O T T E E : : If the remote engine start is on the lights will turn off then flash 3-times before returning to their normal output and the defogger output will activate as programmed.

  • Page 16: Programming Options

    Programming Options Programming options control your system's normal, operational set-up. Most options do not require additional parts, but some may require installation labor. The following is a list of the programmable options, with the factory settings in Bold. ■ 12, 24, or 60 minute run time. your system can be pro- grammed to allow the vehicle to run for 12, 24, or 60 min- utes when remote engine started.

  • Page 17: Glossary Of Terms

    Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all the system functions. Transmitter: A hand-held, remote control which operates the var- ious functions of your system.

  • Page 18: Quick Reference Guide

    QUICK REFERENCE GUIDE To lock the doors using your remote ■ Pressing for one second will lock the doors. The parking lights will flash once to confirm the doors are locked. To unlock the doors using your remote ■ To unlock the doors, press will flash twice to confirm the doors are unlocked.

  • Page 19: Get Started

    Get Started Get Protected Ungo Pro Security 661 W. Redondo Beach Blvd. Gardena, Ca. 90247 800-GO-CLARION © 2006 Directed Electronics - All rights reserved GRS10 04-06...
