Cisco SFE2000 Datasheet page 3

© 2008-2009 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information.
Performance
Switching capacity
Forwarding rate
(based on 64-byte packets)
Stacking
Stack operation
Layer 2
MAC table size
Number of VLANs
VLAN
Head-of-line (HOL) blocking
Layer 3
Layer 3 options
Management
Web user interface
SNMP
SNMP MIBs
RMON
Firmware upgrade
Port mirroring
Other Management
Security
Up to 12.8 Gbps, nonblocking
Up to 9.5 mpps
● Up to 8 units in a stack (192 ports)
● Hot insertion and removal
● Ring and chain stacking options
● Master and backup master for resilient stack control
● Auto-numbering or manual configuration of units in stack
8000
256 active VLANs (4096 range)
● Port-based and 802.1Q tag-based VLANs
● Protocol-based VLAN
● Management VLAN
● Private VLAN Edge (PVE)
● GVRP
HOL blocking prevention
● Static routing
● Classless interdomain routing (CIDR)
● 128 static routes
● IPv4
● Forwarding in silicon-wire-speed forwarding of Layer 3 traffic
Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)
SNMP version 1, 2c, 3 with support for traps
● RFC1213 MIB-2, RFC2863 interface MIB, RFC2665 Ether-like MIB
● RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge)
● RFC2819 RMON MIB (groups 1, 2, 3, 9 only), RFC2737 entity MIB
● RFC3621 Power Ethernet MIB, RFC 2618 RADIUS client MIB, RFC 1215 traps
Embedded RMON software agent supports four RMON groups (history, statistics, alarms,
and events) for enhanced traffic management, monitoring, and analysis
● Web browser upgrade (HTTP) and Trivial File Transfer Protocol (TFTP)
● Dual images for resilient firmware upgrades
Traffic on a port can be mirrored to another port for analysis with a network analyzer or
RMON probe
● Traceroute
● Single IP management
● SSL security for web user interface
● SSH
● RADIUS
● Port mirroring
● TFTP upgrade
● Dynamic Host Configuration Protocol (DHCP) client
● BOOTP
● Simple Network Time Protocol (SNTP)
● Xmodem upgrade
● Cable diagnostics
● Ping
● Syslog
● Telnet client (SSH secure support)
Data Sheet
Page 3 of 5
