- Page 1 Technical Manual Condensing unit Condensing unit for medium temperature application for low temperature application DRM Codes DMSS Codes DRM Codes DMSS Codes JEHBSCU0200M1 LRMSS0200AXV1 JEHBSCU0200L3 LRLSS0200AXY1 JEHBSCU0200M3 LRMSS0200AXY1 JEHBSCU0300L3 LRLSS0300AXY1 JEHBSCU0250M1 LRMSS0250AXV1 JEHBSCU0400L3 LRLSS0400AXY1 JEHBSCU0250M3 LRMSS0250AXY1 JEHBSCU0500L3 LRLSS0500AXY1 JEHBSCU0300M1 LRMSS0300AXV1...
-
Page 2: Table Of Contents
Nomenclature Standard Product Configuration Specifications Product System Cycle Outline Drawings Performance Data Wiring Diagram Safety and Health Installation & commissioning Checklist Service and Maintenance Trouble Shooting Exploded View T-CU01-MAR21-3... -
Page 3: Nomenclature
1. Nomenclature Digit Description L – Daikin low temperature air conditioner R – Outdoor Unit LS – Low Temp. Scroll 3 & 4 MS – Medium Temp. Scroll (propose) LSF – Low Temp. Scroll with Fan Speed Controller LVF – Low Temp. Scroll Vapor Injection with Fan Speed Controller Refrigerant, S –... -
Page 4: Specifications
3. Specifications Model Elec tric al Data Compressor Fan Motors Swept Operating Current DRM c odes DMSS c odes Power Input Type Volume Oil type LRC (A) FLC (A) Oil Charge (c m (A)* (A)** (m3/h) JEHBSCU- 0200- M1 LRMSS0200AXV1 230V/1~ /50Hz ZB15KQE- PFJ 1240... -
Page 5: Product System Cycle
4. Product System Cycle Series 2 MT : JEHBSCU0200M~JEHBSCU0300M LRMSS0200~ LRMSS0300 Series 2 LT : JEHBSCU0200L3 & JEHBSCU0300L3 LRLSS0200 & LRLSS0300 T-CU01-MAR21-3... - Page 6 Series 3 MT : JEHBSCU0350M~JEHBSCU0680M LRMSS0350~ LRMSS0680 Series 3 LT : JEHBSCU0400L3~JEHBSCU0600L3 LRLSS0400~ LRLSS0600 T-CU01-MAR21-3...
- Page 7 Series 4 MT : JEHBSCU0800M3~JEHBSCU1000M3 LRMSS0800~ LRMSS1000 Series 4 LT : JEHSCU0750CL3 LRLSFS0750 T-CU01-MAR21-3...
- Page 8 Series 4 LT EVI : JEHSCU0951CL3 EVI LRLVFS0951 T-CU01-MAR21-3...
-
Page 9: Outline Drawings
5. Outline Drawings Series 2: JEHBSCU0200~JEHBSCU0300; LRMSS0200~ LRMSS0300; LRLSS0200 & LRLSS0300 Series 3: JEHBSCU0350~JEHBSCU0680 LRMSS0350~ LRMSS0680; LRLSS0400~ LRLSS0600 T-CU01-MAR21-3... - Page 10 Series 4 MT: JEHBSCU0800~JEHBSCU1000 LRMSS0800~ LRMSS1000 Series 4 LT: JEHSCU0750~JEHSCU0951 LRLSFS0750~ LRLVFS0951 T-CU01-MAR21-3...
-
Page 11: Performance Data
6. Performance Data R404A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL DRM Codes DMSS Codes JEHBSCU0200M1 LRMSS0200AXV1 CC (W) 2688 3279 3924 4676 5536 6470 JEHBSCU0200M3 LRMSS0200AXY1 PC (W) 1460 1510 1560 1600 1630 1655 CC (W) - Page 12 R404A Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL DRM Codes DMSS Codes JEHBSCU0600M3 LRMSS0600AXY1 CC (W) 7149 8708 10535 12578 14835 17340 PC (W) 4560 4660 4770 4890 5030 5177 CC (W) 6611 8116 9836 11718 13921 16286 PC (W) 4940...
- Page 13 R404A Low Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL DRM Codes DMSS Codes JEHBSCU0200L3 LRLSS0200AXY1 CC (W) 1156 1451 1790 2182 2634 PC (W) 1390 1480 1580 1690 1800 CC (W) 1075 1355 1677 2053 2483 PC (W) 1480 1570 1670...
- Page 14 R134a Medium Temperature (Rating Condition: Superheat 10K, Sub cooling 0K) MODEL DRM Codes DMSS Codes JEHBSCU0200M1 LRMSS0200AXV1 CC (W) 1840 2305 2830 3450 4150 4950 5850 JEHBSCU0200M3 LRMSS0200AXY1 PC (W) 1027 1066 1109 1150 CC (W) 1735 2175 2680 3250...
-
Page 15: Wiring Diagram
7. Wiring Diagram Important Note: All wiring and connections to the condensing unit must be made in accordance to the local codes. SINGLE PHASE Series 2 MT: JEHBSCU0200M1, JEHBSCU0250M1, JEHBSCU0300M1 LRMSS0200AXV1, LRMSS0250AXV1, LRMSS0300AXV1 Series 3 MT: JEHBSCU0350M1, JEHBSCU0400M1 LRMSS0350AXV1, LRMSS0400AXV1... - Page 16 THREE PHASE Verification of proper rotation direction is made by observing that suction pressure drops and discharge pressure rises when the compressor is energized. Reverse rotation of a scroll compressor could results in substantially reduced current draw, suction temperature will be high, discharge temperature will be low and the abnormal sound is heard from the compressor.
- Page 17 Series 3 MT: JEHBSCU0350M3, JEHBSCU0400M3, JEHBSCU0500M3, JEHBSCU0600M3, JEHBSCU0680M3, LRMSS0350AXY1, LRMSS0400AXY1, LRMSS0500AXY1, LRMSS0600AXY1, LRMSS0680AXY1 Series 3 LT: JEHBSCU0400L3, JEHBSCU0500L3, JEHBSCU0600L3 LRLSS0400AXY1, LRLSS0500AXY1, LRLSS0600AXY1 T-CU01-MAR21-3...
- Page 18 Series 4 MT: JEHBSCU0800M3, JEHBSCU1000M3 LRMSS0800AXY1, LRMSS1000AXY1 Series 4 LT: JEHSCU0750CL3 LRLSFS0750BXY1 T-CU01-MAR21-3...
- Page 19 JEHSCU0951CL3 LRLVFS0951BXY1 T-CU01-MAR21-3...
-
Page 20: Safety And Health
8. Safety and Health Important Note Only qualified specialists could carry out the installation, maintenance and commissioning of the system. To avoid potential injury, use care when working around coil surfaces or sharp edges of metal cabinets. All piping and electrical wiring should be installed in accordance with all applicable codes, ordinances and local by-laws. -
Page 21: Installation & Commissioning
9. Installation & Commissioning Unit site location • In order to achieve maximum cooling capacity, the installation location for the condensing unit should be carefully selected. • Install the condensing unit in such a way so that hot air ejected by the condensing unit cannot be drawn in again (short circuit of hot discharge air). - Page 22 Installation clearances • The installation location should allow sufficient space for air flow and maintenance around the unit. • Space not less than1.5m is necessary for installation or maintenance. Compressor handling To ensure compressor reliability, the condensing unit together with the compressor must not tilt greater than an angle of 45°.
- Page 23 Field piping Important Note: Pipe sizing should only be determined by qualified personnel. All local codes of practice must be observed in the installation of refrigerant piping. To ensure satisfactory operation and performance, the following points should be noted for field piping arrangements: •...
- Page 24 Pipe Size Selection (For EVI unit Only) Sizing of liquid and suction lines for EVI model will be different from standard scroll models. Piping sizes of this model need to follow the recommended correction coefficient of cooling capacity. This is vital as if the pipework selected is oversized, especially for the suction pipe, the gas velocity will be decreased at low mass flow rate / low evaporating temperature, causing oil return problems.
- Page 25 Pressure testing • It is recommended to use inert gas such as nitrogen for pressure testing. • The pressure differential between the high and low side of the compressor should not exceed 30 bar (435 psig). • Test pressures are : 19 bar (275 psig) on the Low Side 28 bar (405 psig) on the High Side Leak detection •...
- Page 26 9.11 Electrical Important Note: The mains electrical supply to the condensing unit must be via a suitable motor rated circuit breaker or fuse. J&E Hall Basic Scroll condensing units require either a 230 volt / 1 phase / 50Hz supply or a 400 volt / 3 phase / 50Hz supply, both of which must include a Neutral and an Earth.
- Page 27 9.13 Running the unit • Run the unit and check compressor and condenser fan operation. • Check system pressures and temperatures, gas charge and running currents of motors to ensure correct operation. • Check compressor superheat. • Final adjustment of safety switches setting and fan speed controller. •...
- Page 28 9.14 Safety pressure switch settings The pressure switch fitted to JEH model condensing units with auto reset for Low Pressure and manual reset for High Pressure is NOT factory preset. BOTH THE LP AND HP SWITCH SETTINGS MUST BE ADJUSTED TO SUIT THE APPLICATION BEFORE STARTING THE UNIT.
- Page 29 9.14.3 Low pressure safety (Auto reset) The low pressure safety switch protects the compressor against deep vacuum operation, a potential cause of failure due to internal arcing and also operation outside the compressor limits. The low pressure safety cut out should never be set below the settings as shown in the following table. For systems without pump-down the LP switch signal contact shall be used to energize a low pressure safety alarm.
- Page 30 Safety Instructions: 1. Read installation instruction carefully. Failure to comply can result in device failure, system damage or personal injury. 2. Only person having knowledge and skill are allowed to manipulate the controller. appropriate 3. Disconnect all voltages from system before installation. Electrical Installation •...
- Page 31 Digital input Di1/Di2 • The digital input Di1 is the interface between controller EXD-HP1 and system controller if Modbus communication has not been used. • The digital status is dependent to operation of system’s compressor or demand. Operating Condition Digital input status Compressor starts Closed (Start) Compressor stops...
- Page 32 9.15 Wiring The unit must be isolated from power supply prior to installation. In order to ensure the safety of the installation and its smooth operation, it is necessary to: • Verify the installation is compatible with the wiring diagram. •...
-
Page 33: Checklist
10. Checklist • Check all electrical termination and circuits. • Check the service valves are fully open. • Check compressor oil level. • Check the pressure switch for right settings. • Ensure fan motor and fan blades are installed properly. •... -
Page 34: Trouble Shooting
4. Controls • Check settings and operation of pressure switches. • Check overload setting. 5. Power Supply – Inspect at regular intervals. • Check the running current and voltage for the condensing unit. • Check the electrical wiring and tighten the wires onto the terminal blocks if necessary 6. -
Page 35: Exploded View
13. Exploded View Series 2: T-CU01-MAR21-3... - Page 36 Series 3: T-CU01-MAR21-3...
- Page 37 Series 4 MT: T-CU01-MAR21-3...
- Page 38 Series 4 LT: T-CU01-MAR21-3...
- Page 39 Series 4 LT EVI: T-CU01-MAR21-3...
